MegaLite Baby Color Q70 User manual

USER MANUAL
Table of Contents
Safety Information…………………………………………………..…3
Specifications…………………………………………………………..4
Main Power Connection…………………………………………….. 5
DMX-512 Connection……………………………………………...... 5
Main Control Menu.........................................................................6
DMX Profile.................................................................................... 9
Rigging the Fixture……………………………...…………………….10
Cleaning & Maintenance................................................................10
Parts List........................................................................................10

Check that the unit has not been damaged during transport
Protection Against Fire
1. Maintain a minimum of 1 foot distance from any type of flame.
3. Replace fuse only with the specified type and rating.
4. Do Not install the unit to close to a heat source.
5. Make sure cable are properly secured
6. Maximum surface operating temperature 80º.
Protection Against Fire
1. Disconnect power before servicing.
2. For connection to main power supply proceed to page 5.
3. This unit must be earthed. (electronically grounded)
4. Do not expose unit to rain or moisture.
Protection Against Mechanical Hazards
1. Use safety chain when hanging unit.
2. Use quality clamps or bolts when positioning unit
3. Do not open unit while it is on, risk of electrical shock.
3

Technical Information
4
4035– Baby Color Q70
Mechanical Specifications
Fixture In ATA Road Case
Size: 8.25” x 4” x 7.25
Weight: 5lb
Size: 10.25” x 9.5” x 6.25”
Weight: 6lb
Electrical Specifications
DMX 512 Protocol
DMX Modes: Mode 1 3 Channels R,G,B,
Mode 2 4 Channels R,G,B,W
Mode 3 7 Channels R,G,B,W, Strobe, Macro, Dimmer
Control Options: Audio Trigger, Master Slave
Control & Programming
DMX Connectors: 3 pin XLR connectors in and out
Thermal: Maximum ambient temperature 104°
Maximum surface temperature 140°
Fastening System: Double Mounting Yoke
Display: Digital
Power connection: Power Con in & out
LED Quantity: 7LED Angle: 20°
Diffusion Beam Angel: 25°
Red: 7Power Input Voltage: 110V-240 50/60 Hz
Green: 7
Blue:7Ballast: Electronic auto switching
White: 7
Power Consumption Watts: 48
Amps: .74
LED Watts: 10
LED Lifetime: 60 to 100 thousand hours
Part Numbers
4.25”
7.25”
8.25”
4.8”

5
Main Power Connec-
Caution!
1. Do not connect fixture to a dimmer system.
2. This unit has Auto switching power supply. It will respond to 110V or 220V automatically
3. This unit must be earthed. (electronically grounded)
4. Replace fuse only with the specified type and rating.
The occupation of the connection-cable is as follows:
DMX-512 Connec-
This fixture is equipped with an electronic power supply that will let the unit operate from 90V to 240V from 50Hz to
The fixture is equipped with 3 pin XLR Sockets for DMX input and output. The sockets are wired in parallel. Only use a
shielded twisted pair cable designed for RS-485 and 3 pin XLR plugs and connectors in order to connect the controller
with the fixture or the fixture with another.
Caution!
At the last fixture the DMX signal needs to be terminated with a terminator. Solder a
120 Ohm resistor between the (-) and the (+) signal into a 3 pin XLR plug and plug it
in to the last fixture on the signal run. Pre-manufactured terminator plugs are availa-
Cable (USA) Cable (EU) Pin 110V
Black Brown
White
Green
Light Blue
Yellow/Green
Live
Neutral
Ground
L
N
L
L
220V
L
L
110V
Connec-
220V
Connec-
N
L
1
2
3
2
3
1
DMX—input DMX—output
1. Shield
2. Signal (-)
3. Signal (+)

DMX Ad-
Press Enter to select the DMX start channel use the up/down keys, display will be flashing once you have selected
the desired start channel Press Enter to confirm display will stop flashing.
DMX Ad- Red Dim- Green Dim- Blue Dimmer
Fade
DMX Mode
1-512 0-255 0-255 0-255
0-15
Strobe
0-15
DMX Mode
This function allows you to select the mode in witch
you want to control the fixture. Press Enter use the
up/down keys to select desired DMX mode set-
tings. Press Enter to confirm the settings.
4 CH
7 CH
Red, Green, Blue, White
Red, Green, Blue, White, Strobe, Macro, Dimmer
White Dimmer
0-255
Display Menu
3 CH Red, Green, Blue
3-Ch
4-Ch
7-Ch
Color Chase
0-15
6
The control board on the fixture base is your interface to access and
control all the functions on the unit. Its digital display gives you a code
view of the options and functions. The following will explain each func-
tion and its options.
Slave Speed Pro-
0-15
Pre Pro-
0-30
Sound Display
On
Off
Fade Time
Mode 0
Mode 1
Mode 2
Mode 3
Software Ver-
VE 2.0
Speed Program
This function allows you to select the speed of the pre programs. Press Enter use the up/down keys to select desired
speed settings from 0 to 15. Press Enter to confirm the settings.
Slave
This function allows the fixture to copy all the pre programs the master fixture is doing. Please make sure the fixtures
are connected via 3 pin XLR DMX connection. Press Enter to confirm the settings.
Pre Program
This function allows you to access the LED’s Pre Programs. Press Enter use the up/down keys to select desired Pre
Programs settings from 0 to 30. Press Enter to confirm the settings.
Menu Up Down Enter
CONTROL BOARD

Red Dimmer
This function allows you to dim up or down the red LED’s . Press Enter use the up/down keys to select desired dimmer
settings. Press Enter to confirm the settings.
Green Dim-
This function allows you to dim up or down the green LED’s . Press Enter use the up/down keys to select desired dim-
mer settings. Press Enter to confirm the settings.
Blue Dimmer
This function allows you to dim up or down the blue LED’s . Press Enter use the up/down keys to select desired dimmer
settings. Press Enter to confirm the settings.
Fade Scroll
This function allows you to fade the LED’s from one color to another. Press Enter use the up/down keys to select desired
fade speed settings from 0 to 15. Press Enter to confirm the settings.
Flash
This function allows you to strobe all the LED’s. Press Enter use the up/down keys to select desired strobe speed set-
tings from 0 to 15. Press Enter to confirm the settings.
White Dim-
This function allows you to dim up or down the white LED’s . Press Enter use the up/down keys to select desired dimmer
settings. Press Enter to confirm the settings.
Color Chase
This function allows you to chase the colors from one to another with out fading. Press Enter use the up/down keys to
select desired fade speed settings from 0 to 15. Press Enter to confirm the settings.
7
Sound Mode
This function allows the fixture to snap from color to color via it’s internal microphone. Press Enter to confirm the set-

LED Display
This function allows you to set the display to automatically turn off after it has not been used for 1 minute. Press Enter
use the up/down keys to select desired setting ON for the display to stay on at all time or OFF for the display to automati-
cally turn off. Press Enter to confirm the settings.
Fade Time
This function allows you to set the fade time. Press Enter use the up/down keys to select desired fade time 0 will be the
fastest fade time and 4 will be the slowest fade time . Press Enter to confirm the settings.
Software Ver-
This function allows you to confirm the software version you are using.
Menu Up Down Enter
CONTROL BOARD
DMX Indicator
When DMX Signal is being received the last point on the control board display will turn on. If
there is no DMX signal present is will be off.
8

9
DMX Profile
Baby Color Q70 3 Channel Mode
DMX Chanel Function Description Value
1LED Color Red LED intensity 0-255
2LED Color Green LED Intensity 0-255
3LED Color Blue LED Intensity 0-255
Baby Color Q70 4 Channel Mode
DMX Chanel Function Description Value
1LED Color Red LED intensity 0-255
2LED Color Green LED Intensity 0-255
3LED Color Blue LED Intensity 0-255
4LED Color White LED Intensity 0-255
Baby Color Q70 7 Channel Mode
DMX Chanel Function Description Value
1LED Color Red LED intensity 0-255
2LED Color Green LED Intensity 0-255
3LED Color Blue LED Intensity 0-255
4LED Color White LED Intensity 0-255
5Strobe Strobe (slow to fast) 0-196
Random Strobe (slow to fast) 197-255
No Function 0-1
Color fade (slow to fast) 2-19
Color Snap (slow to fast) 20-39
Random (slow to fast) 40-59
Yellow 60-79
Purple 80-99
6Macro Aqua 100-119
Orange 120-139
Red Pulse 140-159
green Pulse 160-179
Blue Pulse 180-199
Yellow Pulse 200-219
Aqua Pulse 220-229
White Pulse 230-249
White LED Full 250-255
7Dimmer Dimmer Off to Full 0-255

10
Cleaning and maintenance
Installation Maintenance: The operator has to make sure that the unit is operating safely and has the installa-
tions and electronics checked by an expert every 2 years.
The following points have to be considered during the inspection:
1) All screws used for installing the device or part of the device have to be tightly connected and must not be corroded.
2) There must not be any deformations on the housing, fixation and installation spots (ceiling, suspension, trussing).
3) The electronic power supply cables must not show any damages, material fatigue (e.g. porous cables) or sediments.
Further instructions depending on the installation spot and usage have to be adhered by a skilled installer and any
safety problems have to be removed.
Note: There is no serviceable parts inside the device except for the LED’s. Maintenance and service operations are
to be carried out by authorized dealers.
Replacing the fuse: Only replace the fuse with the same type and rating.
Replacing the power cable: If the power cable of this device becomes damaged, it has to be replaced by author-
ized dealers or trained professional only.
Should you have further questions , please contact your dealer.
Parts List
4035-MPCB Main PCB card
4035-PS Power Supply
4035-DIS Display
4035-DF Removable Diffusion Filter
4035-FAN Replacement fan
Rigging the fix-
Caution!
1. The installations must be carried out by an authorized dealer or trained profes-
sional.
2. Unit may cause severe injures if you have doubts concerning the safety do not
install.
When rigging a unit it is very important that you follow common safety procedures. Rigging requires extensive experi-
ence including but not limited to calculating working loads, material being used and periodic safety inspections. If you
lack these qualifications, do not attempt the installation yourself, instead use a professional structural rigger.
When rigging the unit always be secured with a secondary safety attachment. The installation location of the fixture has
got to be built in the way that it can hold 10 times the weight for 1 hour with out any harming. Installation should be
checked at least one time a year by a skilled person.
4035-LED LED Replacement
4035-KNOB Knob Set

Mega-Lite
5718 Kenwick St
San Antonio, TX 78238
Ph 210-684-2600 Fax [phone]
www.mega-lite.com / [e-mail]
Warranty Information
Warranty Conditions
-Unless otherwise stated in writing, your product is covered by a one year parts and labor limited warranty.
-LEDs are not guaranteed to match in color temperature or output.
-It is the owner’s responsibility to furnish receipts or invoices for verification of purchase, date, and reseller or distributor.
If purchase date cannot be provided, date of manufacture will be used to determine warranty period.
-Goods returned under warranty must follow the proper authorization procedure and must be accompanied by a copy of
the original invoice.
-Goods repaired under warranty will be returned to the owner with the freight prepaid by MSI via the most economical
means of shipment.
-Repair or replacement as provided for under this warranty is the exclusive remedy of the consumer. MEGA SYSTEMS
INC. makes no warranties, express or implied, with respect to any product, and Mega Systems specifically disclaims any
warranty of merchantability or fitness for a particular purpose. Mega Systems shall not be liable for any indirect, inci-
dental or consequential damage, including lost profit, sustained or incurred in connection with any product or caused by
product defect or the partial or total failure of any product regardless of the form of action, weather in contract, tort
(including negligence), strict liability or otherwise, and weather or not such damage was foreseen or unforeseen.
- Warranty is void if the product is misused, damaged, modified in any way, or for unauthorized repairs or parts. This
warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
