MELINERA Z30094A-D Technical specifications

Z30094A-D
Indoor FountaIn
Assembly, operating and safety instructions
ZImmerbrunnen
Montage-, Bedienungs- und Sicherheitshinweise
SobnI Zdenac
Upute za montažu, uporabu i sigurnost
Διακοσμητικο σιντριβανι
Δωματιου
Οδηγίες συναρμολόγησης, χειρισμού και ασφάλειας
Fântână de InterIor
Indicaţii de montaj-, utilizare- şi siguranţă
Стаен фонтан
Инструкции за монтаж, обслужване и безопасност
7

GB/CY Assembly, operating and safety instructions Page 3
HR Upute za montažu, uporabu i sigurnost Stranica 14
RO Indicaţii de montaj-, utilizare- şi siguranţă Pagina 25
BG Инструкции за монтаж, обслужване и безопасност Страница 37
GR/CY Οδηγίες συναρμολόγησης, χειρισμού και ασφάλειας Σελίδα 49
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 62

3GB/CY
Table of Contents
Introduction
Normal use.............................................................................Page 4
Description of parts................................................................Page 4
Technical data........................................................................Page 5
Included in delivery................................................................Page 6
Safety notes.....................................................................Page 6
Before first use...............................................................Page 9
Preparing for use/Use
Assembly.................................................................................Page 10
Switching the tabletop fountain on and off..........................Page 10
Changing the distilled water .................................................Page 11
Replacing the bulb.................................................................Page 12
Maintenance/Cleaning/Care..........................Page 12
Disposal...............................................................................Page 13

4 GB/CY
IntroductionIntroduction
Indoor Fountain
QIntroduction
Familiarise yourself with the product before using it for the
first time. In addition please refer carefully to the operating
and assembly instructions and to the safety advice set out
below. Use the product only as described and for the indicated pur-
pose. Keep these instructions in a safe place. If you pass the product
on to anyone else, please ensure that you also pass on all the docu-
mentation.
QNormal use
The tabletop fountain is intended for use in a domestic indoor environ-
ment only. Any use other than that previously described or any
change to the product is not permitted and may lead to injuries and/
or damage to the product. The manufacturer does not assume any
liability for damage arising from improper use. The product is solely
intended for private and not for commercial use.
QDescription of parts
1Lamp attachment assembly
2Ornamental stone (made of sythetic resin)
3Holes for lamp attachment
4Lamp attachment
5Screws (for lamp attachment)
6Base
7Connection hose

5GB/CY
Introduction
8Pump
9Pump plug
10 Connection plug
11 Adapter
12 Water container
13 Pebbles
14 +/- switch (“Water flow control”)
15 Connection piece
16 Recess
17 Screws
18 Halogen bulb
QTechnical data
Tabletop fountain:
Dimensions: model A, B: approx. 19 x44x9.5cm
(WxHxD)
model C, D: approx. 19 x41x9.5cm
(WxHxD)
Max. capacity: Approx. 800 ml
Max. temperature of the
pumped liquid: 35°C
Weight (empty): 1.7kg
Halogen bulb: MR11
Pump:
Model: AP-300L
Rated voltage: 12V~
Energy consumption: 2W
Protection class:
Protection type: IPX8
Max. flow: 250ml/min.

6 GB/CY
Safety notesIntroduction/Safety notes
Adapter:
Model: JBA41V-12-600
Input voltage: 230-240V~, 50Hz
Output voltage: 12V~, 600mA, 7.2VA
Protection class:
The mains adapter (Model No. JBA41V-12-600) is TÜV/GS tested.
QIncluded in delivery
Note: When opening the packaging, please make sure not to acci-
dentally throw away assembly materials. Please check immediately
on unpacking that the delivery is complete and that the product and
all parts are in perfect condition. Do not under any circumstances
assemble the product if the delivery is incomplete.
1 Lamp attachment assembly with halogen bulb
1 Ornamental stone (made of sythetic resin) with base
2 Screws
1 Pump
1 Adapter
1 Water container
1 Bag of pebbles
1 Operating instructions
Safety notes
WARNING!
Please read all safety information and instructions.
Failure to comply with the safety information and instructions may result
in, fire and/or severe injuries.

7GB/CY
Safety notes
Keep all the safety advice and instructions in a safe
place for future reference!
J
WARNING!
DANGER TO LIFE AND ACCI-
DENT HAZARD FOR TODDLERS AND SMALL
CHILDREN! Never allow children
to play unsuper-
vised with the packaging material. There is a danger of suffoca-
tion from the packaging material. Children frequently underesti-
mate the dangers. Children should be kept away from the prod-
uct at all times. This is not a toy.
J Children or persons who lack the knowledge or experience to
use the device or whose physical, sensory or intellectual capaci-
ties are limited must never be allowed to use the device without
supervision or instruction by a person responsible for their safety.
Children must never be allowed to play with the device.
JThis device is not a toy and should not be played by children. Chil-
dren are not able to understand the dangers that can occur when
handling this device.
CAUTION! RISK OF INJURY! Ensure that all parts are un-
damaged and have been assembled appropriately. Risk of injury
exists if assembled incorrectly. Damaged parts can effect safety
and function.
JMake sure that the product is only assembled by competent
persons.
JDo not use the device/product if it is damaged.
J Check all accessories and materials regularly for rust, wear
and/or other damage. Do not use the product if it is rusty, worn
or otherwise damaged.
J Place the product onto a flat and level surface. Otherwise the
product may topple over. This could result in injuries and/or dam-
age to the product.
JUse the tabletop fountain only in conjunction with the supplied
accessories.

8 GB/CY
Safety notes/Before first useSafety notes
JThe tabletop fountain is suitable for use indoors only.
JUse the pump 8(Model: AP-300L) only in conjunction with the
supplied adapter 11 (Model: JBA41V-12-600), otherwise dam-
age to the product may occur.
JUse the pump 8only if it is fully covered with water. Failure to
observe this advice may result the pump 8overheating and
damage to the product.
JEnsure that the water is free of foreign objects that could be
sucked into the pump 8otherwise damage to the product may
occur.
JOperate the tabletop fountain with distilled water only. Do not
add any additives such as aromatic oils or similar substances, as
they could ignite and result in injury and / or damage.
Avoid putting your life at
risk from electric shock!
J Before using the device, make sure that power supply available
corresponds to the required operating voltage of the adapter 11
supplied.
J Before connecting the product to the mains, always check the de-
vice, the pump 8and the adapter 11 for any possible damage.
J A damaged device represents the danger of death from electric
shock.
J Please consult a specialist electrician if you discover any damage
or problems with the device, or for the performance of repairs to
the device.
J Never open any of the electrical equipment or insert any objects
into it. Such interventions represent the danger of death from elec-
tric shock.
J Never touch the mains plug with damp or wet hands.

9GB/CY
Safety notes/Before first use
JEnsure that the connection plug 10 and adapter 11 never come
into contact with water or other liquids.
J Do not misuse the power cable by using it to carry or hang up
the pump 8or to pull the adapter 11
out of the socket. Keep
the power cable away from heat, oil, sharp edges or moving
parts. Damaged or tangled power cables increase the risk of
electric shock.
J Dispose of the pump 8when the power cables of the pump 8
are damaged! The power cables of the pump 8cannot be
replaced.
J Position the device and all electrical installations and connections in
such a way that the location cannot be flooded. All electrical con-
nections and installations must be located in the area that is safe
from flooding.
J Make sure that the adapter 11 is protected from water splashes.
J Only carry out work on the device when the adapter 11 has
been disconnected from the mains current.
JEnsure that the pump plug 9is fitted and seated properly on the
connection plug 10 before you fill the water container 12 with water.
J Never run the pump 8without water.
QBefore first use
j Select a suitable location for the tabletop fountain.
j Ensure that the supporting surface is solid, flat and even.
CAUTION! If the supporting surface is uneven, the assembled
and water-filled tabletop fountain could overturn, resulting in inju-
ry and/or damage to the product.
CAUTION! Risk of fire if the halogen bulb 18 falls over.
CAUTION! RISK OF INJURY! Never try to move the tabletop
fountain if it is filled with distilled water. This could result in injury
or damage to property.

10 GB/CY
Preparing for use/UsePreparing for use/ Use
QPreparing for use/Use
QAssembly
Note: Have a vessel filled with approx. 800 ml water ready before
you start assembly.
j Unpack the product and the accessories carefully.
Note: When you are unpacking the components make sure that
you do not unintentionally throw away any of the assembly materials.
j Place the water container 12 on a flat and even supporting sur-
face near a mains socket (230-240V ~, 50 Hz).
j Mount the lamp attachment assembly 1on to the ornamental
stone 2. To do this, position the lamp attachment 4exactly
over the holes for the lamp attachment 3and fix it firmly in
place by screwing in the screws 5(see Figure A and “Replacing
the bulb”). Use a PH1 screwdriver to tighten the screws.
j Fill the water container 12 with water up to the MAX marking (in-
side wall) of the water container 12 .
j Connect the pump 8to the connection hose 7with the con-
nection piece 15 .
j Increase (MAX) or reduce (MIN) the flow of water issuing from
the ornamental stone 2by means the +/- slider 14 (Fig. C).
j Place the base 6with the attached pump 8on the water container
12 and guide the lead from the pump 8through the recess 16 .
j Decorate the base 6with the pebbles 13 .
j Push the pump plug 9on to the connection plug 10 .
j Your tabletop fountain is now ready for use.
QSwitching the tabletop fountain on and off
j Push the seal 9on to the connection plug 10 .
j Insert the adapter 11 into a properly installed mains socket to

11GB/CY
Preparing for use/Use
switch the tabletop fountain on. The lamp halogen bulb 18 illumi-
nates and water flows out of the ornamental stone 2.
Note: Brush your hand across the water ouwtlet in the ornamen-
tal stone 2to ensure that the water flows evenly out of the orna-
mental stone 2.
j Pull the adapter 11 out of the socket to switch off the tabletop
fountain.
QChanging the distilled water
WARNING!
RISK OF LOSS OF LIFE BY ELECTRIC
SHOCK! Ensure that the pump plug 9does not fall into the water
or come into contact with water.
Note: To prevent algae from forming, change the water at regular
intervals – at least 1 x per week - and clean the water container 12 .
WARNING!
RISK OF LOSS OF LIFE BY ELECTRIC
SHOCK! Pull the adapter 11 out of the socket.
jSeparate the pump plug 9from the connection plug 10 .
jRemove the base 6together with ornamental stone 2from the
water container 12 .
jPull the connection hose 7from the connection piece 15 .
jPlace the base 6together with the ornamental stone 2, lamp
attachment assembly 1and pump 8carefully to one side.
jPour out the water carefully. Clean the water container 12 with a
soft cloth (or similar) and a little cleaning agent, if necessary.
Remove limescale deposits from the water container 12 when
required using an ordinary limescale remover.
jFill the water container 12 with fresh water up to the MAX mark-
ing (inside wall) of the water container 12 .
jReassemble the tabletop fountain (see “Assembly”).

12 GB/CY
Disposal.../Use/Maintenance/ Cleaning/Care
QReplacing the bulb
WARNING!
RISK TO LIFE FROM ELECTRIC SHOCK!
Pull the adapter 11 out of the mains socket before performing
any tasks on the product.
jRelease the screws 17 on the lamp attachment assembly 1
using a screwdriver (see Figure B).
jTake off the halogen bulb 18 . Insert a new halogen bulb 18 (see
Figure B).
jRetighten the screws 17 using a screwdriver.
Q Maintenance/Cleaning/Care
J
WARNING!
DANGER TO LIFE FROM ELEC-
TRIC SHOCK! Before doing any work on the prod-
uct, pull the adapter 11 out of the socket.
jEnsure that the water level never drops below the MIN marking
(inside) wall of water container 12 .
jFill up or change the “distilled” water when the water level is be-
low the MIN mark (see “Changing the water”). Check the water
level by slightly raising the base 6. If no water flows from the or-
namental stone 2, and the mains adapter 11 is connected to a
mains socket, then the water level is probably too low.
jChange the “distilled” water at least once a week (see “Chang-
ing the water”). This will prevent algae from forming.
jCheck and clean the tabletop fountain, pebbles 13 , water con-
tainer 12 and pump 8at regular intervals. Never use aggres-
sive or corrosive cleaning agents to do this. Ensure that no foreign
bodies can enter the pump 8or the connection hose 7.
jPour out the water and allow the tabletop fountain to dry com-
pletely if you are going to leave it unused for an extended period
(see “Changing distilled the water”).

13GB/CY
Disposal
QDisposal
The packaging is made entirely of recyclable materials,
which you may dispose of at local recycling facilities.
Contact your local refuse disposal authority for more details of how to
dispose of your worn-out product.
To help protect the environment, please dispose of the
product properly when it has reached the end of its useful
life and not in the household waste. Information on collec-
tion points and their opening hours can be obtained from
your local authority.
Faulty or used batteries must be recycled in accordance with Directive
2006/66/EC. Please return the batteries and/or the device to the
available collection points.
EMC
Product description:
Indoor Fountain
Model No.: Z30094A-D
Version: 08/2010

14 HR
UvodPopis sadržaja
Uvod
Namjenska uporaba........................................................ Stranica 15
Opis dijelova.................................................................... Stranica 15
Tehnički podatci ............................................................... Stranica 16
Opseg pošiljke ................................................................. Stranica 17
Sigurnosne upute.................................................. Stranica 17
Prije puštanja u rad............................................. Stranica 20
Puštanje u rad/Uporaba
Montaža........................................................................... Stranica 21
Uključivanje/isključivanje sobnog zdenca..................... Stranica 21
Mijenjanje vode ............................................................... Stranica 22
Mijenjanje rasvjetnog sredstva ....................................... Stranica 23
Opsluga/Čišćenje/Održavanje............... Stranica 23
Zbrinjavanje otpada.......................................... Stranica 24

15HR
Uvod
Sobni zdenac
Q
Uvod
Upoznajte se prije prve uporabe s uređajem. Pročitajte za
to pažljivo slijedeća uputstva za uporabu i montažu, te
upute za sigurnost. Upotrebljavajte uređaj samo kako je
opisano i za navedena područja uporabe. Sačuvajte ovo uputstvo
dobro. Izručite također sve dokumente kada uređaj dajete drugima.
Q
Namjenska uporaba
Sobni zdenac je predviđen isključivo za uporabu u privatnom nutar-
njem prostoru. Druga uporaba ili promjene na uređaju smatrat će se
nenamijenskim i mogu prouzročiti opasnost od ozljeda i/ili oštećenje
uređaja. Proizvođač ne preuzima nikakvu odgovornost za štete nastale
od nenamjenske uporabe. Uređaj nije namijenjen za komercijalne svrhe.
Q
Opis dijelova
1nastavak svijetiljke
2ukrasni kamen (od umjetne smole)
3rupe za učvršćivanje svijetiljke
4učvršćenje svijetiljke
5vijci (za učvršćivanje svijetiljke)
6donja ploča
7priključno crijevo
8pumpa
9utikač pumpe
10 priključni utikač

16 HR
Uvod/Sigurnosne uputeUvod
11 mrežni adapter
12 spremnik za vodu
13 oblutci
14 +/- klizač („reguliranje količine vode“)
15 priključni dio
16 otvor
17 vijak
18 halogenska svijetiljka
Q
Tehnički podatci
Sobni zdenac:
mjere: model A, B: oko 19 x 44 x 9,5 cm
(širina x visina x dubina)
model C, D: oko 19 x 41 x 9,5 cm
(širina x visina x dubina)
maksimalan volumen punjenja: oko 800 ml
maksimalna temperatura
tekućine koja se pumpa: 35°C
težina (prazno stanje): 1,7 kg
halogenska žarulja: MR11
Pumpa:
model: AP-300L
nazivni napon: 12 V~
potrošak energije: 2 W
zaštitna klasa:
vrsta zaštite: IPX8
maksimalan protok: 250ml / min.
Mrežni adapter:
model: JBA41V-12-600

17HR
Uvod/Sigurnosne upute
ulazni napon: 230-240 V~, 50 Hz
izlazni napon: 12 V~, 600mA, 7,2 VA
zaštitna klasa:
Mrežni adapter (model broj JBA41V-12-600) je TÜV/GS provjeren.
Q
Opseg pošiljke
Uputstvo: Pazite kod raspakiranja na to da zabunom ne bacite
montažni materijal. Provjerite neposredno nakon raspakiranja opseg
isporuke na potpunost kao i na besprijekorno stanje proizvoda i svih
dijelova. Ne montirajte proizvod ni u kom slučaju, ako opseg isporuke
nije potpun.
1 nastavak svijetiljke sa halogenskom svijetiljkom
1 ukrasni kamen sa donjom pločom
2 vijka
1 pumpa
1 mrežni adapter
1 spremnik za vodu
1 vreća oblutaka
1 uputstvo za montažu, uporabu i sigurnost
Sigurnosne upute
UPOZORENJE! Pročitajte sve sigurnosne upute i ostale upute.
Propusti u pridržavanju sigurnosnih uputa i ostalih uputa mogu prou-
zrokovati strujni udar, požar i/ili teške ozljede.
saČuvaJte sve siGurnosne upute i ine upute Za
uBuduĆe!

18 HR
Sigurnosne uputeSigurnosne upute
J UPOZORENJE! OPASNOST PO ŽIVOT I
OD NEZGODE ZA DJECU! Ne ostavljajte djecu
nikad bez nadzora zajedno sa omotnim materijalom.
Prijeti opasnost od zagušenja kroz omotni materijal. Djeca često
podcjenjuju opasnost. Držite djecu uvijek podalje od proizvoda.
Ovaj proizvod nije igračka.
J Ovaj uređaj nije namjenjen za korištenje osobama (uključujući dje-
cu) s ograničenim fizičkim, senzoričkim i umnim sposobnostima ili
kojima nedostaje iskustva i/ili kojima nedostaje znanja, jedino
ako će biti nadgledani od za sigurnost zadužene osobe ili ako su
od nje dobili naputak kako koristiti uređaj. Djecu je potrebno nad-
gledati kako bi se osiguralo da se neće igrati s uređajem.
J Ovaj uređaj nije igračka i ne pripada u dječje ruke. Djeca ne
mogu prepoznati opasnosti koje nastaju u ophođenju s uređajem.
OPREZ! OPASNOST OD OZLJEĐIVANJA! Uvjerite se da
su svi dijelovi neoštećeni i stručno montirani. Kod nestručne mon-
taže postoji opasnost od ozljeđivanja. Oštećeni dijelovi mogu
utjecati na sigurnost i funkciju.
J Pazite na to da proizvod montira samo stručna osoba.
J Ne upotrebljavajte uređaj / proizvod ni u kom slučaju, ako je
oštećen.
J Provjerite sav pribor i sve materijale redovito na hrđu, amortizaci-
ju i / ili druga oštećenja, jer se u tom slučaju proizvod više ne smi-
je upotrebljavati.
J Stavite proizvod na ravnu i glatku površinu. U suprotnom se proi-
zvod može prekrenuti. Ozljeđivanje i / ili oštećenje proizvoda
mogu biti posljedica.
J Upotrebljavajte sobni zdenaca samo zajedno s isporučenim dije-
lovima pribora.
J Upotrebljavajte sobni zdenac samo u nutranjem prostoru.
J Upotrebljavajte pumpu 8(model: AP-300L) samo zajedno s
isporučenim mrežnim adapterom 11 (model: JBA41V-12-600).
U suprotnome može doći do oštećenja uređaja.

19HR
Sigurnosne upute
J Upotrebljavajte pumpu 8samo kada je potpuno prekrivena
vodom. U suprotnome može doći do pregrijavanja pumpe 8.
Oštećenja uređaja mogu biti posljedica.
J Pazite na to da se nikakvi predmeti, koje bi pumpa 8mogla
usisati, ne nalaze u vodi. U suprotnome može doći do oštećenja
proizvoda.
J Upotrebljavajte sobni zdenac samo sa vodom iz vodovoda bez
ikakvih dodataka kao npr. arome i sl. Primješani dodaci mogu biti
zapaljivi. Ozljeđivanje i / ili oštećenja mogu biti posljedica.
Izbjegavajte životnu opasnost
od strujnog udara!
J Uvjerite se prije uporabe da se postojeći mrežni napon podudara
s potrebnim pogonskim naponom isporučenog mrežnog adapte-
ra 11 .
J Provjerite prije svakog priključenja na mrežu uređaj, pumpu 8i
mrežni adapter 11 na eventualna oštećenja.
J Oštećeni uređaj predstavalja životnu opasnost od strujnog udara.
J Obratite se kod oštećenja, popravak ili drugih problema na ure-
đaju elektrotehničkom stručnjaku.
J Nikada ne otvarajte električnu pogonsku opremu i ne stavljajte
nikakve predmete u iste. Takvi zahvati predstavljaju životnu opa-
snost od strujnog udara.
J Ne hvatajte mrežni adapter 11 nikada sa vlažnim ili mokrim
rukama.
J Pazite na to da priključni utikač 10 i mrežni adapter 11 nikada
ne dođu u dodir sa vodom ili drugim tekućinama.
J Ne otuđujte priključne vodove svrsi, kako bi nosili ili objesili pum-
pu 8, ili kako bi mrežni adapter 11 izvukli iz utičnice. Držite pri-
ključne vodove dalje od vrućine, ulja, oštrih rubova ili pokretnih
dijelova uređaja. Oštećeni ili zavrzlani priključni vodovi povisuju

20 HR
Puštanje u rad/UporabaSigurnosne upute/ Prije puštanja u rad
rizik od strujnog udara.
J Uklonite pumpu 8u otpad kada su priključni vodovi pumpe 8
oštećeni! Priključni vodovi pumpe 8se ne mogu izmijeniti.
J Postavite uređaj i sve elektroinstalacije i spojeve tako, da mjesto
stajanja ne može poplaviti. Svi električni spojevi i instalacije se
moraju nalaziti u nepoplavnom području.
J Pazite na to da je mrežni adapter 11 zaštićen od prskajuće vode.
J Provodite radove na uređaju samo onda kada je mrežni adapter
11 odvojen od strujne mreže.
J Pazite na ispravno i čvrsto sjedište utikača pumpe 9na priključ-
nom utikaču 10 prije nego spremnik za vodu 12 punite vodom.
J Ne puštajte pumpu 8nikada da radi bez vode.
QPrije puštanja u rad
j Tražite prikladno mjesto stajanja za vaš sobni zdenac.
j Pazite na to da je podloga čvrsta, ravna i glatka.
OPREZ! Neravna podloga može dovesti do toga da se montira-
ni i sa vodom napunjeni sobni zdenac prevrne. Ozljeđivanje i / ili
oštećenja proizvoda mogu biti posljedica.
OPREZ! Opasnost od požara zbog prevrtanja halogenske svije-
tiljke 18 .
OPREZ! OPASNOST OD OZLJEĐIVANJA! Ne pokušavajte
nikada promijeniti mjesto stajanja sobnog zdenca kada je isti
napunjen vodom. U suprotnome može doći do ozljeđivanja i
materijalne štete.
