Memmert SV1524 User manual

www.memmert.com
Operating manual
SV
CPM
CDP
Shaking device SV1524 | SV3550
Pumping device CPM650
Cooling unit CDP115
Translation of the original operating manual

2 06/2021
About this manual
Purpose and target audience
This manual describes the design, function, transport, operation and maintenance of
accessories for WTB water baths. It is intended for use by trained personnel of the
owner, who have the task of operating and/or maintaining the respective accessories.
If you are asked to work on the accessories, read this manual carefully before starting.
Familiarise yourself with the safety regulations. Only carry out work described in this
manual for the respective accessories. If there is something you do not understand, or
certain information is missing, ask your manager or contact the manufacturer. Do not
do anything without authorisation.
Versions
Several accessories of different sizes and functions are available. The functions de-
scribed in this manual refer to the latest rmware version. Due to individual sizes, illus-
trations in this manual may be slightly different to the actual appearance.
Other documents that you must observe:
■the general operating manual for all water baths WTB
■for service and repair work, observe the separate service manual
Storage and resale
This operating manual is part of the accessories and must always be stored so
that persons to work with the respective accessories have access to them.
The owner's responsibility is to ensure that persons who work or are to work
with the respective accessories are informed of where these operating manu-
al are located. We recommend that you always keep them in a protected place
near the accessories. Make sure that the operating manual is not damaged by
heat or humidity. If an accessory is resold or transported and then set up again at
a different location, the operating manual must remain with it. The current ver-
sion of this operating manual in PDF format is also available for download from
http://www.memmert.com/
Manufacturer address and customer service
MEMMERT GmbH + Co. KG
Willi-Memmert-Str. 90-96
D-91186 Büchenbach
Germany
Phone: [phone]
Fax: [phone]
E-mail: [e-mail]
Internet: www.memmert.com
Customer service:
Hotline: [phone]
Service fax: +49(0)91719792979
Email: [e-mail]
For service enquiries, please always specify the appliance number
given on the name plate.

306/2021
Content
1. Safety 4
1.1 Terms and signs used ............................................................................................................................................................................ 4
1.2 Product safety and dangers ................................................................................................................................................................... 5
1.3 Requirements of the operating personnel.............................................................................................................................................. 5
1.4 Responsibility of the owner .................................................................................................................................................................... 6
1.1 Applied directives and standards ........................................................................................................................................................... 6
1.5 Changes and alterations......................................................................................................................................................................... 6
1.6 Behaviour in case of malfunctions and irregularities............................................................................................................................. 6
1.7 Switch off in an emergency.................................................................................................................................................................... 7
2. Slopingandatlids 8
2.1 Sloping lid ............................................................................................................................................................................................... 8
2.2 Flat lid ................................................................................................................................................................................................... 10
3. Test tube racks 11
4. Shelf reversible 13
5. Shaking Device 15
5.1 Assembly and description .................................................................................................................................................................... 15
5.2 Delivery, Transport and Setting Up ....................................................................................................................................................... 19
5.3 Putting into operation........................................................................................................................................................................... 23
5.4 Operation and control........................................................................................................................................................................... 25
5.5 Faults, Warning & Error Messages ....................................................................................................................................................... 28
5.6 Cleaning and decontamination............................................................................................................................................................. 29
5.7 Repairs and service .............................................................................................................................................................................. 30
5.8 Storageanddisposal............................................................................................................................................................................ 31
6. Pumping device CPM 32
6.1 Assembly and description .................................................................................................................................................................... 32
6.2 Delivery, Transport and Setting Up ....................................................................................................................................................... 36
6.3 Putting into operation........................................................................................................................................................................... 40
6.4 Operation and control........................................................................................................................................................................... 41
6.5 Dismantling the hoses.......................................................................................................................................................................... 41
6.6 Faults, Warning & Error Messages ....................................................................................................................................................... 42
6.7 Cleaning and decontamination............................................................................................................................................................. 43
6.8 Repairsandservice .............................................................................................................................................................................. 44
6.9 Storage and disposal............................................................................................................................................................................ 44
7. Cooling unit CDP 45
7.1 Assembly and description .................................................................................................................................................................... 45
7.2 Delivery, Transport and Setting Up ....................................................................................................................................................... 49
7.3 Putting into operation........................................................................................................................................................................... 53
7.4 Operation and control........................................................................................................................................................................... 54
7.5 Dismantling the hoses.......................................................................................................................................................................... 54
7.6 Faults, Warning & Error Messages ....................................................................................................................................................... 55
7.7 Cleaning and decontamination............................................................................................................................................................. 56
7.8 Repairsandservice .............................................................................................................................................................................. 57
7.9 Storage and disposal............................................................................................................................................................................ 57
8. Attachment 58

4 06/2021
Safety
1. Safety
1.1 Terms and signs used
In this manual and on the appliance itself, certain common terms and signs are used to
warn you of possible dangers or to give you hints that are important in avoiding injury
or damage. Observe and follow these notes and regulations to avoid accidents and
damage. These terms and signs are explained below.
1.1.1 Terms used
DANGER
warns of a dangerous situation that leads directly to death or serious (irreversible)
injuries.
WARNING
warns of a dangerous situation that might le
ad to death or serious injuries.
CAUTION
warns of a dangerous situation that might lead to mo
derate or minor injuries.
NOTICE
warns of material damage
1.1.2 Signs used
Symbol Meaning Symbol Meaning
General warning sign - Observe
operating manual Gases/vapours
Danger of electric shock Danger of explosion
Flammable substance warning Caution: hot steam
Caution: hot Disconnect the mains plug
Observe information in separate
manual Use gloves

506/2021
Safety
1.2 Product safety and dangers
The accessories are technically sophisticated, manufactured using high-quality
materials and tested for many hours in the factory. They reect the state of the
art and comply with recognised technical safety regulations. However, there are
still risks involved, even when the appliances are used as intended. These are
described below.
DANGER
Danger due to electric shock.
Penetration of liquid into the appliance can cause electric shocks and short circuits.
–Protect the appliance from splashing water.
–Switch off the appliance and disconnect the mains plug before cleaning and
maintenance work.
–The appliance must not be cleaned and disinfected wet. Allow the appliance to
dry completely before putting it back into operation.
WARNING
When loading the appliance with an unsuitable chamber load, poisonous or explosive
vapours or gases may be produced. This could cause the appliance to explode, and
persons could be severely injured or poisoned. The appliance may only be loaded with
materials / test objects that do not emit any poisonous or explosive vapours when
heated up.
WARNING
Depending on operation, the surfaces of the appliance and the chamber load
may still be very hot after the appliance is switched off. Touching these sur-
faces can cause burns. Wear heat-resistant protective gloves or wait until the
appliance cools down before touching.
1.3 Requirements of the operating personnel
The accessories may only be operated and maintained by persons who are of legal age
and have been instructed accordingly. Personnel who are to be trained, instructed or
who are undergoing general training may only work with the appliance under the contin-
uous supervision of an experienced person. Repairs may only be performed by qualied
electricians. The regulations in the separate service manual must be observed.

6 06/2021
Safety
1.4 Responsibility of the owner
The owner of the appliance
■is responsible for the awless condition of the appliance and for it being operated in
accordance with its intended use;
■is responsible for ensuring that persons who are to operate or service the appliance
are qualied to do this, have been instructed accordingly and are familiar with the
operating manual at hand;
■must know about the applicable guidelines, requirements and operational safety regu-
lations, and train staff accordingly;
■is responsible for ensuring that unauthorised persons have no access to the appliance;
■isresponsible forensuring that themaintenance planis adheredtoand thatmaintenance
work is properly carried out;
■has to ensure that the appliance and its surroundings are kept clean and tidy, for exam-
ple through corresponding instructions and inspections;
■is responsible for ensuring that personal protective clothing is worn by operating per-
sonnel, e.g., work clothes, safety shoes and protective gloves.
1.1 Applied directives and standards
EU Declaration of Conformity for the appliance can be found at the end of the document
and online at:
www.memmert.com/de/downloads/downloads/eu-konformitaetserklaerung
Under the REACH regulation, Memmert provides the information on chemical sub-
stances in Memmert appliances online at
https://www.memmert.com/de/reach-rohs/
1.5 Changes and alterations
The accessories may be used only in connection with a Memmert water bath WTB.
The accessories must not be converted or modied without authorisation. No parts
may be added or inserted which have not been approved by the manufacturer.
Unauthorised modications or changes to the appliance will void any manufacturer's
responsibility regarding the CE conformity of the product.
The manufacturer is not liable for any damage, danger or injuries that result from un-
authorised changes or alterations, or from non-compliance with the provisions in this
manual.
1.6 Behaviour in case of malfunctions and irregularities
The accessories may only be used in a awless condition. If you, as the operator, notice
irregularities, malfunctions or damage, immediately turn off the accessories and inform
your superior.

706/2021
Safety
1.7 Switch off in an emergency
Press the main switch on the respective accessories. This disconnects the appliance
from the power supply at all poles.
Illustration Accessories
Shaking device - SV
Cooling unit - CDP115
Pumping device - CPM650

8 06/2021
Sloping and at lids
2. Sloping and at lids
You may suffer bruising injuries to your hands. Always wear protective gloves. Do not
let the mounted slanted or at lid of the water bath fall shut.
Note that the slanted or at lid heats up to the temperature control liquid temperature
during operation.
2.1 Sloping lid
To avoid unwanted evaporation of the temperature control liquid and to achieve the
most even temperature distribution possible, the appliance should always be operated
with the slanted lid closed. The shape of the lid ensures that condensate does not drip
into the chamber load.
Water bath size Stainless steel sloping lid
WTB6
WTB11
B39844
WTB15
WTB24
B39845
WTB35
WTB50
B39846
CAUTION
CAUTION

906/2021
Sloping and at lids
2.1.1 Assembly
1. Loosen the blind plugs at the fastening points (left + right)
for the lid on the water bath.
2. Remove the dummy plug and store it.
3. Putonthefasteningbracketofthecoverandxitwithscrews.
4. Tightenscrewsandcheckthatthelidtstightly.

10 06/2021
Sloping and at lids
2.2 Flat lid
The at lid, available as an accessory, can be used to place test asks on the surface of
the temperature control liquid. By removing or inserting rings, the recesses are adapted
to the piston size. The rings may only be inserted or removed when they have cooled
down.
Water bath size Stainless steel at lid Stainless steel special at lid
WTB6
WTB11
B48804 B48807
WTB15
WTB24
B48805 B48808
WTB35
WTB50
B48806 B48809

1106/2021
Test tube racks
3. Test tube racks
The test tube racks differ in the number and diameter of the individual bores. They are
hooked into the water bath from above. The test tube racks may only be inserted or
removed when they have cooled down.
Ø Bores WTB6 / WTB11 WTB15 / WTB24 WTB35 / WTB50
Ø10mm
34 bores
B48822
58 bores
B48823
74 Bores
B50656
Ø12mm
30 bores
B48824
58 bores
B48825
66 Bores
B50657
Ø14.5mm
26 Bores
B48826
45 Bores
B48827
58 bores
B50658
Ø18mm
22 bores
B48828
38 Bores
B48829
50 Bores
B50659
33 Bores
B48834
57 Bores
B48835
75 Bores
B50662

12 06/2021
Test tube racks
Ø Bores WTB6 / WTB11 WTB15 / WTB24 WTB35 / WTB50
Ø18mm
44 bores
B48836
76 Bores
B48837
100 Bores
B50663
Ø21mm
18 Bores
B48830
34 bores
B48831
44 bores
B50660
Ø32mm
14 Bores
B48832
22 bores
B48833
30 bores
B50661

1306/2021
Shelf reversible
4. Shelf reversible
Maximum loading of the waterbaths with reversible shelf
Size WTB Maximum Loading
WTB 6/11 25 kg
WTB 15/24 50 kg
WTB 35/50 100 kg
Conversion of reversible shelf
60 mm
1. Reversible shelves can be set to two heights: 60mm and 30 mm
2. Unscrew screws to remove feet
3. Remove feet and rotate depending on desired height (in this case 30mm)

14 06/2021
Shelf reversible
4. Position rotated feet on holders of oor grate and x with screws
30 mm
5. Reversible shelf now has a height of 30 mm

1506/2021
Shaking Device
5. Shaking Device
5.1 Assembly and description
5.1.1 Design
Description Overview
1. Water bath
1
2
3
4
2. Recording frame
3. Shaking Device
4. Display shaker
5.1.2 Description
Brief technical description
The shaking device enables controlled shaking of test asks or test tubes in a water
bath. The shaking device performs a back and forth movement with a frequency of ap-
prox. 30 to 150 strokes per minute. The shaking frequency is electronically controlled
and adjustable via touch screen. The same ambient conditions apply for use as for the
basic units.
NOTICE
If the shaking device remains in a switched-on water bath, the shaking device must always be switched on, as in the switched-off
state, the overpressure steam barrier is inoperative, and condensate can enter the shaking device housing.
5.1.3 Intended use
The Memmert shaking device is intended exclusively for a Memmert water bath WTB15,
WTB24, WTB35 or WTB50. It is used for the controlled back and forth movement of
samples at 30 to 150 rpm (strokes per minute), with one of approx. 15mm. The sample
holder is in direct contact with the temperature control medium.
5.1.4 Use not in accordance with the intended purpose
Depending on the loading of the shaking device and the selected shaking frequency,
the temperature control medium and/or the shaking material could spill over. The user's
responsibility is to adjust the shaking frequency or the ll level but without going below
the minimum ll level.

16 06/2021
Shaking Device
5.1.5 Material
The shaker complies with the current requirements of the RoHS Directive.
You can nd more information on this and material compliance on our homepage:
https://www.memmert.com/de/downloads/
Components Material
Shaking Device Stainless steel 1.4301 - ASTM 304
Support basket Stainless steel 1.4301 - ASTM 304
Screws and hinges Stainless steel 1.4301 - ASTM 304
iThe chamber load for the appliance must be carefully checked for chemical compati-
bility with the materials mentioned.
5.1.6 Electrical equipment
■Operating voltage and current consumption: See name plate or technical data
■Protection class I, i.e. operating insulation with PE conductor in accordance with
EN 60664-1
■Protection type IP 20 acc. to EN 60 529
■Interference suppression acc. to EN 55011 class B
■Appliance fuse: Fuse F15H250V
5.1.7 Electrical connection
The appliance is intended for operation on a power supply network with a system im-
pedance Zmax at the transfer point (house connection) of a maximum of 0.292 Ohm.
The operator must ensure that the appliance is only operated on power supply network
that meets these requirements. If necessary, you can ask your local energy supply com-
pany what the system impedance is. When connecting, observe the country-specic
regulations (e.g. in Germany DIN VDE 0100 withFI protective circuit).

1706/2021
Shaking Device
5.1.8 Designation (nameplate)
Description Overview
1. Type designation
GmbH+Co.KG D-91126 Schwabach FRG
Äußere Rittersbacher Str. 38 Made in Germany
memmert
Schutzart DIN EN 60529 - IP 20
1
2
3
4
5
6
8
7
Typ: SV1524
~ 230 V 50/60 Hz
F-Nr.: P321.0001
0,1 A 8 W
2. Operating voltage
3. Protection type
4. CE conformity
5. Address of manufacturer
6. Disposal note
7. Connection / power ratings
8. Appliance number
5.1.9 Technical data – Shaking device
Gerätegröße 15/24 35/50
Dimensions Length mm 706 826
Width mm 297 500
Height mm 190 190
electrical data
Shaking frequence
Number of
strokes per
minute
35 bis 150
Operating voltage V 115/ 230
Frequency Hz 50/ 60
Power W 8 12
Current
consumption
50/60 Hz
115V
A
0,1 0,1
230V 0,1 0,1
Packaging material Net weight kg 6,1 8,7
Gross weight (in cardboard
box) kg 8,1 11,7
Width cm 84 98
Height cm 47 70
Depth cm 33 33

18 06/2021
Shaking Device
5.1.10 Ambient conditions
Ambient temperature +5 °C to 40 °C
Air humidity max. 80 % rh (non-condensing)
Overvoltage category II
Pollution degree 2
Altitude of installation max. 2,000 m above sea level
Maximum mains voltage uctuations AC 115 (+/– 10 %)
AC 230 (+/– 10 %)
■The appliance may only be used in enclosed areas and under the ambient conditions
listed below
■The appliance may not be used in areas where there is a risk of explosion. The sur-
rounding air must not contain any explosive dusts, gases, vapours or gas-air mixtures.
The appliance is not explosion-proof.
■Heavy dust production or aggressive vapours in the vicinity of the appliance could lead
to sedimentation in the interior and, as a consequence, could result in short circuits or
damage to electrical parts. For this reason, sufcient measures to prevent large clouds
of dust or aggressive vapours from developing should be taken.
5.1.11 Scope of delivery
Standard
■Shaking Device
■Recording frame
Optional
■Support basket
■Sloping lid

1906/2021
Shaking Device
5.2 Delivery, Transport and Setting Up
5.2.1 Safety
WARNING
Condensation in the electrical components may cause short circuits. After
transporting or storing the appliance under humid conditions, remove it from its pack-
aging and let it ventilate for at least 24 hours in normal ambient conditions. Do not
connect the appliance to the mains power during this time.
CAUTION
You may suffer crush injuries to your hands when transporting and setting up the
accessories. Always wear protective gloves. Grip the appliance downwards only at the
sides
CAUTION
Danger of cuts due to sharp edges.
Always wear gloves when working on the appliance.
5.2.2 Delivery/unpacking
■The accessories are packed in a cardboard box
■Do not unpack the accessories until they are in their installation location to avoid dam-
age
■Carefully cut open the cardboard packaging along one edge.
5.2.3 Product control
■Check the delivery note to ensure that the scope of delivery is complete
■Check the accessories for damage
If you notice deviations from the scope of delivery, damage or irregularities, do not put
the accessories into operation, but inform the carrier and the manufacturer's factory.
5.2.4 Disposing of packaging material
■Dispose of the packaging material (cardboard, wood, foil) in accordance with the appli-
cable disposal regulations for the respective material in your country

20 06/2021
Shaking Device
5.2.5 Setting up
CAUTION
Theappliancemayfall fromtheinstallationlocationdue tounevennessandinjureyou or
someone else. Always place the appliance on an even, load-bearing and non-slip sur-
face.
CAUTION
The surfaces of the appliance can overheat during operation and overheat heat-sen-
sitive surfaces in close proximity to the appliance. Always place the appliance on a
heat-resistant surface and maintain the specied clearance around the appliance.
The distance between the wall and the rear of the appliance must be at least 15 cm. The
clearance from the ceiling must not be less than 75 cm and the side clearance from
walls or nearby appliances must not be less than 10 cm. Sufcient air circulation in the
vicinity of the appliance must be guaranteed at all times.
10 cm 10 cm
75 cm
10 cm
15 cm
