Memmert UN plus Series User manual

www.memmert.com
MADE IN GERMANY.
OPERATING
INSTRUCTIONS
UNIVERSAL OVEN U
INCUBATOR I
UNxxplus | UFxxplus
INxxplus | IFxxplus
UNxxmplus | UFxxmplus
INxxmplus | IFxxmplus

Manufacturer and customer service
Memmert GmbH + Co. KG
Willi Memmert Straße 90-96
D-91186 Büchenbach
Deutschland
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
Internet: www.memmert.com
Customer service:
Service hotline: [phone]
Service fax: [phone]
E-mail: [email protected]
When contacting customer service, always quote the product serial number on the nameplate
(see page 13).
Shipping address for repairs:
Memmert GmbH + Co. KG
Kundenservice
Willi-Memmert-Str. 90-96
DE-91186 Büchenbach
Germany
Please contact our customer service before sending appliances for repair or before returning
equipment, otherwise, we have to refuse acceptance of the shipment.
© 2020 MEMMERT GmbH + Co. KG
D33355 | Date 01/2020
We reserve the right to make changes

D33355 | Date 01/2020 3
About this manual
About this manual
Purpose and target group
This manual describes the assembly, function, transport and operation of the universal ovens
UNxxplus/UFxxplus/UNxxmplus/UFxxmplus and the incubators INxxplus/IFxxplus/INxxmplus/IFxxmplus.
It is intended for use by trained personnel of the owner, who have the task of operating and/
or maintaining the respective appliance.
If you are asked to work on the appliance, read this manual carefully before starting. Familiar-
ise yourself with the safety regulations. Only perform work that is described in this manual. If
there is something you do not understand, or certain information is missing, ask your superior
or contact the manufacturer. Do not do anything without authorisation.
Versions
The appliances are available in different configurations and sizes. If specific equipment fea-
tures or functions are available only for certain configurations, this is indicated at the relevant
points in this manual.
The functions described in this manual refer to the latest firmware version.
Due to individual configurations and sizes, illustrations in this manual may be slightly different
from the actual appearance. Function and operation are identical.
Other documents that have to be observed:
►For operation of the appliance with MEMMERT AtmoCONTROL, observe the respective
software manual. To open the AtmoCONTROL software manual, click on “Help” in the
AtmoCONTROL menu bar.
►For service and repair (see page 56), please refer to the separate service manual
Storage and forwarding
This instruction manual belongs with the appliance and should always be stored where
persons working on the appliance have access to it. It is the responsibility of the owner to
ensure that persons who are working or will work on the appliance are informed as to the
whereabouts of this instruction manual. We recommend that it is always stored in a protected
location close to the appliance. Make sure that the instruction manual is not damaged by heat
or humidity. If the appliance is sold on or transported and then set up again at a different
location, the operating instructions must go with it.
You will find the current version of our operating manual as pdf file if you go to
www.memmert.com/de/service/downloads/bedienungsanleitung/.

4 D33355 | Date 01/2020
Contents
1. For your Safety 6
1.1 Terms and signs used........................................................................................................... 6
1.2 Product safety and dangers ................................................................................................ 7
1.3 Requirements of the operating personnel.......................................................................... 7
1.4 Responsibility of the owner................................................................................................. 8
1.5 Changes and alterations...................................................................................................... 8
1.6 Behaviour in case of malfunctions and irregularities.......................................................... 8
1.7 Switching off the appliance in an emergency .................................................................... 8
2. Construction and description 9
2.1 Construction ........................................................................................................................ 9
2.2 Function............................................................................................................................. 11
2.3 Material.............................................................................................................................. 11
2.4 Electrical equipment.......................................................................................................... 11
2.5 Connections and interfaces............................................................................................... 12
2.6 Designation (nameplate)................................................................................................... 12
2.7 Technical data .................................................................................................................... 13
2.8 Declaration of conformity ................................................................................................. 15
2.9 Ambient conditions........................................................................................................... 15
2.10 Scope of delivery ............................................................................................................... 16
2.11 Optional accessories.......................................................................................................... 16
3. Delivery, transport and setting up 17
3.1 For your Safety................................................................................................................... 17
3.2 Delivery .............................................................................................................................. 18
3.3 Transport............................................................................................................................ 18
3.4 Unpacking ......................................................................................................................... 18
3.5 Storage after delivery ........................................................................................................ 18
3.6 Setting up .......................................................................................................................... 19
4. Putting into operation 23
4.1 Connecting the appliance .................................................................................................23
4.2 Switching on...................................................................................................................... 24
5. Operation and control 25
5.1 Operating personnel.......................................................................................................... 25
5.2 Opening the door.............................................................................................................. 25
5.3 Loading the appliance....................................................................................................... 26
5.4 Operating the appliance.................................................................................................... 26
5.5 Temperature monitoring .................................................................................................. 33
5.6 Graph................................................................................................................................. 37
5.7 Ending operation............................................................................................................... 37
Contents

D33355 | Date 01/2020 5
Contents
6. Malfunctions, warning and error messages 38
6.1 Warning messages of the monitoring function................................................................ 38
6.2 Malfunctions, operating problems and appliance errors ................................................ 39
6.3 Power failure...................................................................................................................... 41
7. Menu mode 42
7.1 Overview............................................................................................................................ 42
7.2 Basic operation in menu mode using the example of language selection....................... 43
7.3 Setup.................................................................................................................................. 44
7.4 Date and Time ................................................................................................................... 48
7.5 Calibration ......................................................................................................................... 50
7.6 Programme........................................................................................................................ 52
7.7 Sound ................................................................................................................................ 53
7.8 Protocol ............................................................................................................................. 54
7.9 User ID ............................................................................................................................... 55
8. Maintenance and service 56
8.1 Cleaning............................................................................................................................. 56
8.2 Regular maintenance.........................................................................................................56
8.3 Repairs and service ............................................................................................................ 56
9. Storage and disposal 57
9.1 Storage .............................................................................................................................. 57
9.2 Disposal ............................................................................................................................. 57

6 D33355 | Date 01/2020
For your Safety
1. For your Safety
1.1 Terms and signs used
In this manual and on the appliance itself, certain common terms and signs are used to warn
you of possible dangers or to give you hints that are important in avoiding injury or damage.
Observe and follow these hints and regulations to avoid accidents and damage. These terms
and signs are explained below.
1.1.1 Terms used
"Warning" is used whenever you or somebody else could be injured if you do not
observe the accompanying safety regulation.
"Caution" is used for information that is important for avoiding damage.
1.1.2 Signs used
Warning signs (warning of a danger)
Danger of
electrocution
Danger of
explosion
Dangerous
gases / va-
pours
Danger of
burns
Danger of
toppling
over
Hazard area!
Observe the op-
erating instruc-
tions
Prohibition signs (forbidding an action)
Do not lift Do not tilt Do not enter
Regulation signs (stipulating an action)
Disconnect
the mains
plug
Wear
gloves
Wear safety
boots
Observe
information
in separate
manual
Other icons
Important or useful additional information

D33355 | Date 01/2020 7
For your Safety
1.2 Product safety and dangers
The appliances described in this manual are technically sophisticated, manufactured using
high-quality materials and subject to many hours of testing in the factory. They contain the
latest technology and comply with recognised technical safety regulations. However, there are
still risks involved, even when the appliances are used as intended. These are described below.
Warning!
After removing covers, live parts may be exposed. You may receive
an electric shock if you touch these parts. Disconnect the mains plug
before removing any covers. Only electrical technicians may work on
the electrical equipment of the appliances.
Warning!
When loading the appliance with an unsuitable load, poisonous or
explosive vapours or gases may be produced. This could cause the
appliance to explode, and people could be severely injured or poi-
soned. The appliance may only be loaded with materials/test objects
which do not form any toxic or explosive vapours when heated up
(see also page 10).
Warning!
If the door is open while the appliance is in operation, the appliance
may overheat and pose a fire hazard. Do not leave the door open
during operation.
Warning!
Depending on operation, the surfaces in the working chamber
and the chamber load may still be very hot after the appliance is
switched off. Touching these surfaces can cause burns. Wear heat-
resistant protective gloves or wait until the appliance cools down.
Warning!
In case of appliances of a certain size, you can get accidentally
locked in, which is life-threatening. Do not climb into the appliance!
1.3 Requirements of the operating personnel
The appliance may only be operated and maintained by persons who are of legal age and
have been instructed accordingly. Personnel who are to be trained, instructed or who are un-
dergoing general training may only work with the appliance under the continuous supervision
of an experienced person.
Repairs may only be performed by qualified electricians. The regulations in the separate service
manual must be observed.

8 D33355 | Date 01/2020
For your Safety
1.4 Responsibility of the owner
The owner of the appliance
►is responsible for the flawless condition of the appliance and for its proper operation in
accordance with its intended use (see page 10);
►is responsible for ensuring that persons who are to operate or service the appliance are
qualified to do this, have been instructed accordingly and are familiar with the operating
instructions at hand;
►must know about the applicable guidelines, requirements and operational safety regula-
tions, and train staff accordingly;
►is responsible for ensuring that unauthorised persons have no access to the appliance;
►is responsible for ensuring that the maintenance plan is adhered to and that maintenance
work is carried out properly (see page 56);
►has to ensure that the appliance and its surroundings are kept clean and tidy, for example
through corresponding instructions and inspections;
►is responsible for ensuring that personal protective clothing is worn by operating person-
nel, e.g. work clothes, safety shoes and protective gloves.
1.5 Changes and alterations
No unauthorised changes or alterations may be made to the appliance. No parts may be
added or inserted which have not been approved by the manufacturer.
Unauthorised modifications or changes result in the CE declaration of conformity losing its
validity and the appliance must no longer be operated.
The manufacturer is not liable for any damage, danger or injuries that result from unauthor-
ised changes or alterations, or from non-observance of the regulations in this manual.
1.6 Behaviour in case of malfunctions and irregularities
The appliance may only be used in a flawless condition. If you as the operator notice irregu-
larities, malfunctions or damage, immediately take the appliance out of service and inform
your superior.
You can find information on correcting malfunctions from page 38.
1.7 Switching off the appliance in an emergency
Push the On/Off switch on the control panel
(Fig. 1) and disconnect power plug. This
disconnects the appliance from the power
supply at all poles.
Warning!
Depending on operation,
the surfaces in the working
chamber and the chamber
load may still be very hot af-
ter the appliance is switched
off. Touching these surfaces
can cause burns. Wear heat-
resistant protective gloves or wait until the appliance cools down.
ON
O
O
ON
N
N
N
O
O
N
O
Fig. 1
Switch off the appliance by pressing the On/
Off switch

D33355 | Date 01/2020 9
Construction and description
2. Construction and description
2.1 Construction
1
2
3
4 5 6
7
8
9
Fig. 2 Construction
1 ControlCOCKPIT with capacitive function
keys (see page 27)
2 On/Off switch (see page 24)
3 Working chamber fan (for
UF.../IF... appliances only)
4 Steel grid
5 Working chamber
6 Nameplate (covered, see page 13)
7 Door handle (see page 25)
8 Turn control with confirmation key
9 USB interface (see page 12)

10 D33355 | Date 01/2020
Construction and description
2.2 Intended use
Based on the standards and guidelines listed in the following, the products described
in this manual have received a CE label from the company Memmert:
Product Intended use Directives
UNxxplus
UFxxplus
INxxplus
IFxxplus
This appliance is exclusively intended
for heating up non-explosive sub-
stances and objects. Any other use is
improper and may result in hazards
and damage.
The appliance is not explosion-proof
(does not comply with the German oc-
cupational health and safety regulation
VBG 24). The appliance may only be
loaded with materials and substances
which cannot form any toxic or explo-
sive vapours at the set temperature
and which cannot explode, burst or
ignite.
The appliance may not be used for the
drying, evaporation and burning-in of
paints or similar materials, the solvents
of which could form an explosive mix-
ture when combined with air. If there
is any doubt as to the composition of
materials, they must not be loaded
into the appliance. Potentially explosive
gas-air mixtures must not form, neither
in the working chamber nor in the
direct vicinity of the appliance.
►Directive 2004/108/EC amended
(Directive of the European Parlia-
ment and of the Council on the
approximation of the laws of
the Member States relating to
electromagnetic compatibility).
Standards complied with:
DIN EN 61326:2004-05, EN
61326:1997, EN 61326/A1:1998,
EN 61326/A2:2001
EN 61326/A2:2003
►Directive 2006/95/EC amended
(Directive of the European Parlia-
ment and of the Council on the
harmonisation of the laws of
Member States relating to electri-
cal equipment designed for use
within certain voltage limits).
Standards complied with:
DIN EN 61 010-1
(VDE 0411 part 1)
DIN EN 61 010-2-010
(VDE 0411 part 2-010)
EN 61 010-1:2001,
EN 61 010-2-010
Product Intended use as a medical device Directive
UNxxmplus
UFxxmplus
The appliance may be used for heating
fango, silicate and APS packs for physi-
cal therapy and keeping them warm. Directive 93/42/EEC (Council Directive
concerning medical devices)
INxxmplus
IFxxmplus
The appliance may be used for tem-
perature control of rinsing and infusion
solutions and contrast agents.

D33355 | Date 01/2020 11
Construction and description
2.3 Function
Appliances of the UN...
and IN... type series feature
natural circulation (convec-
tion). For the UF... and IF...
type series, air is circulated
with a fan at the working
chamber rear panel (Fig. 3,
No. 1). It increases the air
flow and provides stronger
horizontal forced air
circulation than natural
convection.
In both the convection and
fan ventilated appliances,
supply air (2) is preheated
in a pre-heating chamber
(3). Through the ventilation
slits in the side panel of the
working chamber, the pre-
heated air is introduced into
the interior of the chamber.
The supply and exhaust air
(5) volume (air change) is
controlled by the air flap
(4) on the rear panel of the
appliance.
2.4 Material
For the outer housing, MEMMERT deploys stainless steel (Mat.No. 1.4016 – ASTM 430)
and for the interior, stainless steel (Mat.No. 1.4301 – ASTM 304) is used, which stands out
through its high stability, optimal hygienic properties and corrosion-resistance towards many
(but not all!) chemical compounds (caution for example with chlorine compounds).
The chamber load for the appliance must be carefully checked for chemical compatibility with
the materials mentioned. A material resistance table can be requested from the manufacturer.
2.5 Electrical equipment
►Operating voltage and current consumption: See nameplate
►Protection class I, i.e. operating insulation with PE conductor in accordance with EN 61010
►Protection type IP 20 acc. to EN 60 529
►Interference suppression acc. to EN 55011 class B
►Appliance fuse: Fusible link 250 V/15 A quick-blow
►The temperature controller is protected with a miniature fuse 100 mA (160 mA at 115 V)
4
1
2
5
3
Fig. 3 Function
1 Fan
2 Fresh air
3 Pre-heating chamber
4 Air flap
5 Exhaust air

12 D33355 | Date 01/2020
Construction and description
2.6 Connections and interfaces
2.6.1 Electrical connection
This appliance is intended for operation on an electrical power system with a system imped-
ance Zmax of a maximum of 0.292 ohm at the point of transfer (service line). The operator
must ensure that the appliance is operated only on an electrical power system that meets
these requirements. If necessary, you can ask your local energy supply company what the
system impedance is.
Observe the country-specific regulations when connecting (e.g. in Germany
DIN VDE 0100 with residual current circuit breaker).
2.6.2 Communication interfaces
The interfaces are intended for appliances which meet the requirements of IEC 60950-1.
USB interface
The appliance is fitted by default with a USB
interface in accordance with the USB specifi-
cation. This way, you can
►transfer software stored on a USB stor-
age medium to the appliance (see page
52).
►export protocol logs from the appliance
to a USB storage medium (see page
54).
►transfer user ID data stored on a USB storage medium to the appliance (see page 55).
The USB interface is located on the lower right of the ControlCOCKPIT (Fig. 4).
Ethernet interface
Via Ethernet interface, the appliance can be
connected to a network, so that you can
transfer programmes created with Atmo-
CONTROL software to the appliance and read
out protocol logs. The Ethernet interface is
located on the rear of the appliance (Fig. 5).
For identification purposes, each appliance
connected must have its own unique IP ad-
dress. Setting the IP address is described on
page 44.
You will find a description of how to transfer programmes via Ethernet in the en-
closed AtmoCONTROL manual.
With an optional USB to Ethernet converter, the appliance can be directly connected to a com-
puter / laptop (see Scope of delivery on page 16).
Fig. 4 USB interface
Fig. 5 Ethernet interface

D33355 | Date 01/2020 13
Construction and description
2.7 Designation (nameplate)
The nameplate (Fig. 6) provides information about the appliance model, manufacturer and
technical data. It is attached to the front of the appliance, on the right side behind the door
(see page 9).
GmbH+Co.KG D-91126 Schwabach FRG
Äußere Rittersbacher Str. 38 Made in Germany

Schutzart DIN EN 60529 - IP 20
1
2
3
4
5
6
10
9
8
7
Typ: UN260plus
230 V~ 50/60 Hz
DIN12880-2007-Kl.:3.1
F-Nr.: B618.3008
14,8 A 3400 W
Nenntemp.: 300 °C
Fig. 6 Nameplate (example)
1 Type designation
2 Operating voltage
3 Applied standard
4 Protection type
5 CE conformity
6 Address of manufacturer
7 Disposal note
8 Temperature range
9 Connection / power ratings
10 Appliance number

14 D33355 | Date 01/2020
Construction and description
2.8 Technical data
Appliance size 30 55 75 110 160 260
Appliance width D1[mm] 585 585 585 745 745 824
Appliance height E1[mm] 707 787 947 867 1107 1186
Appliance depth F1(footprint) [mm] 434 514 514 584 584 684
Depth of door lock [mm] 56
Working chamber width A1[mm] 400 400 400 560 560 640
Working chamber height B1[mm] 320 400 560 480 720 800
Working chamber depth C1[mm] 250 330 330 400 400 500
Chamber volume [litres] 32 53 74 108 161 256
Weight [kg] 48 57 66 78 96 110
Power [W]
I... 115 V, 50/60 Hz 800 900 900 900 900 900
230 V, 50/60 Hz 1600 1000 1250 1400 1600 1700
U... 230 V, 50/60 Hz 1600 2000 2500 2800 3200 3400
115 V, 50/60 Hz 1600 1700 1800 1800 1800 1800
Current
consumption [A]
I... 230 V, 50/60 Hz 7,0 4,3 5,4 6,1 7,0 7,4
115 V, 50/60 Hz 7,0 7,8 7,8 7,8 7,8 7,8
U... 230 V, 50/60 Hz 7,0 8,7 10,9 12,2 13,9 14,8
115 V, 50/60 Hz 13,9 14,8 15,6 15,6 15,6 15,6
max. number of sliding shelves 3 4 6 5 8 9
max. load per sliding shelve [kg] 20
max. load per appliance [kg] 60 80 120 175 210 300
Setting temperature range IN/IF +20 bis +80 °C2
UN/UF +20 bis +300 °C2 3
Adjustment precision IN/IF 0,1 K
UN/UF bis 99,9 °C: 0,1 K, ab 100 °C: 0,5 K
1See Fig. 7 on page 15
2 With the interior lighting on, the minimum temperature might not be reached.
3to +250 °C if your device is equipped with a glass door.
Appliance size 450 750 1060
Appliance width D1[mm] 1224 1224 1224
Appliance height E1[mm] 1247 1720 1720
Appliance depth F1(footprint) [mm] 784 784 1035
Depth of door lock [mm] 56
Working chamber width A1[mm] 1040 1040 1040
Working chamber height B1[mm] 720 1200 1200
Working chamber depth C1[mm] 600 600 850
Chamber volume [litres] 449 749 1060
Weight [kg] 170 217 252

D33355 | Date 01/2020 15
Construction and description
Appliance size 450 750 1060
Power [W]
I... 115 V, 50/60 Hz 1500 1800 –
230 V, 50/60 Hz 1800 2000 –
U...
400 V, 50/60 Hz 5800 7000 7000
3 x 230 V o. N., 50/60 Hz 5800 7000 7000
3 x 208 V, 50/60 Hz 4800 5700 5700
Current consumption
[A]
I... 230 V, 50/60 Hz 7,8 8,7 –
115 V, 50/60 Hz 13,0 15,6 –
U...
400 V, 50/60 Hz 3 x 8,4 3 x 10,1 3 x 10,1
3 x 230 V o. N., 50/60 Hz 3 x 14,6 3 x 17,6 3 x 17,6
3 x 208 V, 50/60 Hz 3 x 13,3 3 x 15,1 3 x 15,1
max. number of sliding shelves 8 14 14
max. load per sliding shelve [kg] 30 60
max. load per appliance [kg] 300
Setting temperature range IN/IF +20 bis +80 °C2–
UN/UF +20 bis +300 °C2 3
Adjustment precision IN/IF 0,1 K –
UN/UF bis 99,9 °C: 0,1 K, ab 100 °C: 0,5 K
1See Fig. 7 on page 15
2 With the interior lighting on, the minimum temperature might not be reached.
3to +250 °C if your device is equipped with a glass door.
D
A
F
C
56
E
B
Fig. 7 Dimensions (see table on page 14)

16 D33355 | Date 01/2020
Construction and description
2.9 Declaration of conformity
You can download the EC declaration of conformity of the appliance online:
English: http://www.memmert.com/en/service/downloads/ce-statement/
German: http://www.memmert.com/de/service/downloads/eg-konformitaetserklaerung/
2.10 Ambient conditions
►The appliance may only be used in enclosed rooms and under the following ambient
conditions:
Ambient temperature +5 ºC to +40 ºC
Humidity rh max. 80 %, non-condensing
Overvoltage category II
Pollution degree 2
Altitude of installation max. 2,000 m above sea level
►The appliance may not be used in areas where there is a risk of explosion. The ambient air
must not contain any explosive dusts, gases, vapours or gas-air mixtures. The appliance is
not explosion-proof.
►Heavy dust production or aggressive vapours in the vicinity of the appliance could lead to
sedimentation in the interior and, as a consequence, could result in short circuits or dam-
age to electrical parts. For this reason, sufficient measures to prevent large clouds of dust
or aggressive vapours from developing should be taken.
2.11 Scope of delivery
►Power cable
►Tilt protection
►One or two sliding steel grids (load capacity 30 kg each)
►USB storage medium with software and AtmoCONTROL manual
►The operating instructions at hand
►Calibration certificate
2.12 Optional accessories
►USB to Ethernet converter (Fig. 8). Makes it
possible to connect the appliance's
network interface (see page 12) to the
USB port of a computer / laptop.
►Reinforced, sliding steel grids with a load
capacity of 60 kg each (for appliance size
110 and larger)
Fig. 8 Converter USB to Ethernet

D33355 | Date 01/2020 17
Delivery, transport and setting up
3. Delivery, transport and setting up
3.1 For your Safety
Warning!
Because of the heavy weight of the appliance, you could injure
yourself if you try to lift it. To carry appliances of the sizes 30 and
55, at least two persons, for appliances of the sizes 75, 110, 160 and
260, four people are needed. Appliances larger than that may not be
carried but must be transported with a manual pallet jack or forklift
truck.
30 55 75 110 160 260 450 750
Warning!
You may get your hands or feet squashed when transport-
ing and installing the appliance. Wear protective gloves and
safety boots. When grasping the bottom of the appliance,
grasp it only on the sides:
9
Warning!
The appliance could fall over and seriously injure you. Never
tilt the appliance and transport it in upright position and
without load only (except for standard accessories such as
steel grids or shelves). Appliances with castors always have to
be moved by two people.

18 D33355 | Date 01/2020
Delivery, transport and setting up
3.2 Delivery
The appliance is packed in cardboard and is delivered on a wooden palette.
3.3 Transport
The appliance can be transported in three ways:
►With a forklift truck; move the forks of the truck entirely under the pallet
►On a manual pallet jack
►On its own castors, in case of the corresponding configuration, for which the catch on the
(front) castors must be released
3.4 Unpacking
To avoid damage, do not unpack the appliance until you reach the installation site.
Remove the cardboard packaging by pulling it upwards or carefully cutting along an edge.
3.4.1 Checking for completeness and transport damage
►Check the delivery note to ensure that the delivery is complete.
►Check the appliance for damage.
If you notice deviations from the delivery note, damage or irregularities, do not put the appli-
ance into operation but inform the haulage company and the manufacturer.
3.4.2 Removing the transport protection
Remove the transport protection. It is located between the door hinge, door and frame and
has to be removed after opening the door.
3.4.3 Disposing of packaging material
Dispose of the packaging material (cardboard, wood, foil) in accordance with the applicable
disposal regulations for the respective material in your country.
3.5 Storage after delivery
If the appliance is first to be stored after delivery: Read the storage conditions from page
57.

D33355 | Date 01/2020 19
Delivery, transport and setting up
3.6 Setting up
Warning!
Due to its centre of gravity, the appliance can fall over to the front
and injure you or other people. Always attach the appliance to a wall
with the tilt protection (see page 21). If this cannot be done due
to space problems, do not operate the appliance and do not open
the door. Contact the Memmert service team (see page 2).
3.6.1 Prerequisites
The installation site must be flat and horizontal and must be able to reliably bear the weight
of the appliance (see "Technical data" on page 14). Do not place the appliance on a flam-
mable surface.
Depending on the model (see nameplate), a 230 V, 115 V or 400 V power connection must be
available at the installation site.
The distance between the wall and the rear of the appliance must be at least 15 cm. The clear-
ance from the ceiling must not be less than 20 cm and the side clearance from walls or nearby
appliances must not be less than 5 cm (Fig. 9). Sufficient air circulation in the vicinity of the
appliance must be guaranteed at all times.
For appliances with castors, these need to be positioned in forward direction at all times.
FP FP FP
FP
Fig. 9 Minimum clearance from walls and ceiling

20 D33355 | Date 01/2020
Delivery, transport and setting up
3.6.2 Installation options
Setting up Comments Suitable for appliance size ...
30 55 75 110 160 260 450 750
Floor

Table
Check the load
capacity first 
Stacked
two appliances
maximum; mount-
ing material (feet)
provided

Wall
mounting Separately packaged
fastening material is
included in the scope
of delivery. Observe
the assembly instruc-
tions provided.

Base
with/without cas-
tors 
Castor
frame

Height ad-
justable feet

