Mercedes-Benz Actros MP4
Driver familiarisation
1 September 2020
1800 851 281

Introduction
2
The following instructions and video links aim to familiarize drivers with the key features and
functions of Mercedes-Benz Actros trucks.
Please note this document is not a substitute for a full operating instructions and is designed to
familiarise experienced heavy vehicle operators holding the correct drivers licence with the vehicle
and its features.
This document is designed to be read online, so users can click on the video links to view the
content. A full set of online instructions can be accessed via the internet.
Please note some functionality and variations may exist across different models and country’s.
If you have any questions please call us on 1800 851 281 or ask your local Daimler dealer.
To access the Daimler Roadside Assistance help line call 1800 033 557

Contents
3
1.
Cabin entry
13.
Refrigerator
2.
Seat and steering wheel adjustment
14.
Fuel and Adblue
3.
Mirror controls and adjustment
15.
Truck level control
4.
Bluetooth pairing smartphone
16.
Climbing behind cab
5.
Maintenance flap
17.
Trailer connection
6.
Starting the vehicle
7.
Dash and steering wheel controls
8.
Lights, indicators and windscreen wipers
9.
Park brake and trailer brake
10.
Powershift Transmission
11.
Auxiliary braking (engine brake)
12.
Vehicle safety features incl proximity control
Introduction

1. Cabin entry and exit
4
Steps and grab handles on either side of the door allows for three points of contact when
entering and exiting the cabin.
To watch the video click here: cabin entry and exit (0.35)
Contents Page

2. Seat and steering wheel adjustment
5
The Actros offers a wide range of seat adjustments including options to slide the seat forwards and
back, raise and lower seat height, adjust the seat incline angle and shoulder area, as well as adjust
the lumber support and seatbelt.
At 0.50 the video covers the adjustment of the multi-function steering wheel to move the steering
wheel into the ideal driving position. This adjustment is made by pressing the foot operated switch
with your left leg allowing the steering wheel to move towards or away from the driver as well as the
telescopic extension of the steering wheel by pulling or pushing the wheel up or down as required.
To watch the video click here: seat and steering wheel adjustment (1.39)
Contents Page

3. Mirror controls and adjustment
6
Mirror adjustment controls are located on the right hand door.
1. Press the top rocker button to select the required mirror and adjust using the multi-directional button to
suit.
2. A maneuvering mirror on the near (passenger) side offers functionality to move the mirror out
approximately 10 degrees for a wider view. This can be useful when reversing to the near side and can
be activated by pressing the lower rocker switch to initiate the adjustment. The function self-ends after 2
minutes or the vehicle moving forward at a speed exceeding 10km/h. It can also be cancelled by pressing
the button again.
To watch the video click here: mirror controls and adjustment (1.39)
Contents Page

4. Bluetooth pairing
7
To pair your smartphone to the multi-media centre:
1. Set your phone to pairing mode and ensure it’s showing as discoverable.
2. Then on the truck multi-media centre press the green phone button on the bottom right hand side of the
unit.
3. Press the connection button on the touch screen followed by the pairing button.
4. Enter the pin code displayed into your phone to complete the pairing process. The systems will then
acknowledge the success pairing of the devices.
To watch the video click here: bluetooth pairing (1.00)
Contents Page

5. Maintenance flap (fluid top up and filters)
8
To open the exterior maintenance flap go to the front of the vehicle and release the locking levers
located behind the outer edge of the grill about half way half way up by moving in an inwards
direction. The flap will then swing upwards. Located behind the grill is access to the following items
for top up and cleaning as required.
•Coolant expansion tank
•Engine Oil
•Windscreen washer fluid
•Pollen filter, and
•Bug screen
NB: a dash display will notify the driver if engine oil needs toping up
To watch the video click here: maintenance flap (2.21)
Contents Page

6. Starting the vehicle
9
Remote control key can be used to:
lock and unlock the vehicle
activate the lights to enable the driver to do a pre-start inspection
manually open the doors if the battery fails
To start the vehicle:
Insert the key in the slot located to the left of the dash next to the start/stop button
Pressing the start/stop button once will activate the electronics, Pressing a second time will activate the
ignition, and Pressing a third time will start the truck.
Alternatively pressing the button as far as it will go will start the truck.
To turn off the engine, press the button as far as it will go.
To watch the video click here: starting the vehicle (2.48)
Contents Page

7. Dash and steering wheel controls
10
A range of dash controls can be operated from the control buttons on either side of the
steering wheel
Left hand side Instrument control buttons
•Instrument scroll buttons
- Left and Right to go through the menus
- Up and Down to go through each page
- OK button to select
•Stereo volume control button up/down (+/-)
•Memory button the can be used to select a
preferred screen by holding the button down.
To watch the video click here: dash controls part 1 (8.49)
Right hand side Instrument control buttons
•Phone button - Answer and hang-up phone
•Cruise Control, Speed limiter and proximity control
(adaptive cruise control)
•Menu button
To watch the video click here: dash controls part 2 (9.01)
