Mercia Garden Products 03LBRO1208-V7 Instruction manual

P 1
03LBRO1208-V7
12x8 Combi Summerhouse
2mm Drill bit
Winter = High Moisture = Expansion
Summer = Low Moisture = Contraction
All building’s should be
erected by two adults
For ease of assembly, you
MUSTpilot drill all screw
holes and ensure all screw
heads are countersunk.
CAUTION
Every eort has been made during the
manufacturing process to eliminate the
prospect of splinters on rough surfaces of the
timber. You are strongly advised to wear gloves
when working with or handling rough sawn
timber.
Please retain product label and instructions for future reference
General Instructions
BEFORE YOU START PLEASE READ INSTRUCTIONS CAREFULLY
- Check the pack and make sure you have all the parts listed.
- When you are ready to start, make sure you have the right tools at hand (not supplied) including a Phillips
screwdriver, Stanley knife, Wood saw, Step ladder, Hammer and a Drill with 2mm bit.
- Ensure there is plenty of space and a clean dry area for assembly.
LOCATION FOR YOUR GARDEN BUILDING
A minimum of 60cm should be left around the perimeter of your garden building to allow access for
maintenance, annual treatment and to allow air ow around the building.
Where possible you should avoid placing your garden building underneath large trees to prevent the tree
causing damage to the building.
TIMBER
As with all natural materials, timber can be aected during various weather conditions. For the duration of heavy
or extended periods of rain, swelling of the wood panels may occur. Warping of the wood may also occur during
excessive dry spells due to an interior moisture loss. Unfortunately, these processes cannot be avoided but can
be helped. It is suggested that the outdoor building is sprayed with water during extended periods of warm
sunshine and sheltered as much as possible during rain or snow.
Once your garden building has been installed it will need to be treated as soon as possible and annually to
prevent the timber from deteriorating and to waterproof it. This is required to maintain the anti-rot guarantee.
Dip Treated buildings - Require a preservative treatment to protect against rot and decay and a waterproof
treatment to prevent water ingress
Pressure Treated buildings - Require a waterproof treatment to prevent water ingress
Log Cabins - Are supplied untreated and require a preservative and waterproong treatment.
BUILDING A BASE
When thinking about where the building and base is going to be constructed:
Ensure that there will be access to all sides for maintenance work and annual
treatment.
Ensure the base is level and is built on rm ground, to prevent distortion. Refer to diagrams for the base
dimensions, The base should be slightly smaller than the external measurement of the building, i.e. The cladding
should overlap the base, creating a run o for water. It is also recommended that the oor be at least 25mm
above the surrounding ground level to avoid ooding.
TYPES OF BASE
- Concrete 75mm laid on top of 75mm hard-core.
- Slabs laid on 50mm of sharp sand.
Whilst all products manufactured are made to the highest standards of Safety and in the case of childrens
products independently tested to EN71 level, we cannot accept responsibility for your safety whilst erecting or
using this product.
For assistance please contact customer care on: 01636 821215
Mercia Garden Products Limited,
Sutton On Trent,
Newark,
Nottinghamshire,
NG23 6QN
www.merciagardenproducts.co.uk
**Protim Aquatan T5 (621)**
Your building has been dip treated with Aquatan.
Aquatan is a water-based concentrate which is diluted with water, the building as been treated by the correct
application of Aquatan solution and then allowed to dry.
Aquatan is a decorative nish to colour the wood, which is applied industrially to timber fence panels and
garden buildings.
Aquatan undiluted contains: boric acid, sodium hydroxide 32% solution, aqueos mixture of sodium dioctyl
sulphosuccinat and alcohols: 2, 4, 6-trichlorophenol.
REGISTER FOR YOUR
ANTI-ROT
GUARANTEE TODAY
PLEASE SCAN HERE:

P 2
2345
1
6 7 8910
11 12 13 14 15
16 17 18
20
19
21
Door Panel Back Panel
Short Panel
Short Window
Panel
AI-03LBRO1208DP-V7
Internal Panel
AI-03LBRO1208BP-V7
AI-03LBRO1208SPP-V7
AI-03LBRO1208SWP-V7
AI-03LBRO1208INPP-V7
Floor
Roof
Front Window
Panel
Storage Door
Panel
Side Panel
AI-03LBRO1208F-V7
AI-03LBRO1208R-V7
AI-03LBRO1208FWP-V7
AI-03LBRO1208SDP-V7
AI-03LBRO1208PP-V7
QTY x2
QTY x2
Double Boarded Gable Top
Gable Top Right
Gable Top Left
AI-03LBRO1208GTDB-V7
AI-03LBRO1208GTR-V7
AI-03LBRO1208GTL-V7
Storage Gable
Left
Storage Gable
Right
AI-03LBRO1208SGPL-V7 AI-03LBRO1208SGPR-V7
Under Roof Veranda
Small Floor
AI-03LBRO1208UR-V7 AI-03LBRO1208V-V8
AI-03LBRO1208SF-V7
QTY x2
Storage Door
Slave Door
Master Door
AI-03LBRO1208MD-V7 AI-03LBRO1208SD-V7 AI-03LBRO1208SHD-V7
QTY x2
22 30
29
28
27
26
25
24
23
5x Floor Blocks - 28x28x400mm
Cover Trim A - 12x56x1980mm
2x Cover Trim B - 12x56x2000mm
Cover Trim C - 12x56x2011mm
Cover Trim D - 12x56x2040mm
Cover Trim E - 12x56x2070mm
2x Cover Trim F - 12x56x2080mm
2x Front Fascia - 12x134x1903mm
4x Side Fascia - 12x134x1250mm
F2828-400mm
S12134-1250mm
Fixing Kit
Door Stop
32
34
Felt
35
2x Press Lock Base-
28x28x95mm
36
37 38
Press Lock
Handle
4x Barrel Bolt
Fixing Kit continues on P3
S12134-1903mm
S1256-1980mm
S1256-2000mm
S1256-2011mm
S1256-2040mm
S1256-2070mm
S1256-2080mm
PLY TRIANGLE
F2828-95mm
PI-07-0162
PI-07-0114
PI-07-0159
31
2x Door Trim - 16x60x1698mm
F1660-1698mm (rounded edge)
Panel Framing- 44x44x1910mm
33
F4444-1910mm
17b
Plain Door
AI-03LBRO1208PD-V7
03LBRO1208-V7
Overall Dimensions:
Width =3796mm
Depth = 2514 mm
Height = 2146mm
Base Dimensions:
Width = 3688mm
Depth = 2439mm
Please retain product label and instructions for future reference
Before assembly
please make sure you have a
suitable base ready to erect your
building
MADE IN GREAT BRITAIN

P 3
39
2x Door Handles
PI-07-0001
Step 1
Secure the oor (No. 13) to the
Floor Blocks (No.22) and 10x30mm
screws per oor.
20x30mm Screws
Pre drill
hole
30mm
screw
13
22
Step 2
Place the 2 oor panels (No. 13) onto a rm
and level base, ensuring the
base has suitable drainage and is free from
areas where standing water can collect.
Secure the oors together using 10x30mm
screws per oor.
10x30mm Screws
13
13
14
Step 3
Flip over the two oor boards (No. 13)
Place the small oor (No. 14) ush against
the assembled oor and x to (No.13)
Using 4x50mm screws x the small oor in
place as shown in the diagram.
4x50mm Screws
Pre drill
hole
50mm
screw
13
Please retain product label and instructions for future reference
41
42
43
12x Butt Hinge
Key Plate
4x Turn Button
Fixing kit cont..
PI-07-0066
PI-07-0017
PI-07-0034
40
Mortice Lock
PI-07-0017
PI-02-1028
PI-02-1008
50mm Screw x 97
40mm Screw x 4
Felt Tacks x 199
30mm Screw x 168
10mm Screw x 16
30mm Black Screw x 4
Felt Tacks x 199
30mm Screw x 168
30mm Black Screw x 4
70mm Screw x 13
Nail Bag
Pre Assembly
Before assembling remove the transportation
blocks from the bottom of each panel.
*This building can be built with the shed on the LEFT hand side. Follow the
same steps but be aware to position panels to the opposite side.*

5
4
Step 4
Fix the side of the short panel (No. 4)
against the framing of the back panel (No. 5)
with 3x50mm screws as shown in diagram.
Do not secure the building to the Floor
until the roof is tted.
3x50mm Screws
Pre drill
hole
50mm
screw
3
4
Step 5
Fix the side of the short panel (No. 4)
against the side of the short window panel
(No. 3) with 3x50mm screws as shown in
diagram.
Do not secure the building to the Floor
until the roof is tted.
3x50mm Screws
Pre drill
hole
50mm
screw
Please retain product label and instructions for future reference
Step 6
Fix the side of one Back Panel (No. 5)
against the side of the other Back Panel
(No. 5) with 3x50mm screws as shown in
diagram.
Do not secure the building to the Floor
until the roof is tted.
3x50mm Screws
Pre drill
hole
50mm
screw
5
5
Pre drill
hole
50mm
screw
Step 7
Before xing the internal panel in position,
x the Right Gable Top (No. 20) in place
slotting the groove of the boarding on the
gable into the tongue of the internal panel
(No. 8) as shown with 4x50mm screws.
Once the Gable top is positioned and xed,
x the Panel Framing (No. 32) to the side of
the Internal Panel (No. 8) as shown making
sure it is ush to the panel and framing as
shown with 3x50mm screws.
Do not secure the building to the Floor
until the roof is tted.
7x50mm Screws
32
20
8
P 4

P 5
Step 8
Fix the side of the Internal panel/Panel
Framing (No. 8/No. 32) against the frame of
the Back Panel (No. 5). Align the panel with
Storage Floor as shown and x internally
with 3x50mm screws.
Do not secure the building to the Floor
until the roof is tted.
3x50mm Screws
Pre drill
hole
50mm
screw
8
20
32
5
Step 9
Fix the Left Gable Top (No. 21) in place
slotting the groove of the boarding on the
gable into the tongue of the side panels
(No. 3,No. 4) as shown with 4x50mm
screws.
4x50mm Screws
21
3
4
Pre drill
hole
50mm
screw
Step 10
Place the Door Panel (No. 1) onto a at
surface and x the Front Window
Panel (No. 2) in place as shown.
Make sure the panels are ush to
each other.
3x50mm Screws
Pre drill
hole
50mm
screw
12
Pre drill
hole
70mm
screw
Step 11
Place the Door Panel/ Front Window
Panel (No. 1/No. 2) onto the
assembly between the Short Window Panel
(No. 3) and Internal Panel (No. 8). Fix internally with
3x70mm screws into the Internal panel and
3 x50mm screws into the Short Window Panel
as shown in diagram.
Do not secure the building to the Floor
until the roof is tted.
3x70mm Screws
3x50mm Screws
50mm
screw
Please retain product label and instructions for future reference

P 6
Please retain product label and instructions for future reference
Step 12c
Fit the mortice lock (No. 40) into
the recess and x in place with the screws
provided. Fit the key plate(No. 42) to the
opposite door using the 4X30mm screws
provided.
Fix door handles (No. 39) using 8x30mm
screws.
Fix the Door Cover Strips (No. 31) to the
plain (No. 17b) and slave door (No. 17),
positioning the strip with a small overhang
to the right hand door. Fit the barrel bolts
(No. 38) to top and bottom of the door
strips as shown in diagram. Use 4x10mm
screws per barrel bolt.
Ensure doors open and close freely.
10x30mm Screws
8x10mm Screws 40
42 The Mortice Lock is Reversible
39
38
Pre drill
hole
31
31
41
Step 12a
Attach the Plain Door (No.17b) to the door panel
using 3x butt hinges (No.41) per door.
18x30mm Screws
Pre drill
hole
30mm
screw
17b
41
16
Pre drill
hole
30mm
screw
Step 12b
Fix the master door (No.16) to the outside of the door framing
and slave door (No.17) to the attached plain doors with
3x butt hinges per door, using 6x25mm screws
per hinge.
*Ensure the doors open freely,
folding back into the building
unrestricted.
48x25mm Screws
17

Please retain product label and instructions for future reference
P 7
Step 16
Place the Storage Door panel
(No. 6) against the end of the Storage
Gable Sides (No. 9/10) and x into position
internally.
Fix with 3x50mm screws per side internally as
shown in diagram.
Do not secure the building to the Floor
until the roof is tted.
6x50mm Screws
Pre drill
hole
50mm
screw
6
10
9
910
Step 15
Place the Storage Gable Sides Left/Right
(No. 9/10) against the sides of the Internal
(No. 8) and Side Panel (No. 7) with the
boarding facing outwards as shown.
Fix with 3x50mm screws per
gable side as shown in diagram.
Do not secure the building to
the Floor until the roof is tted.
6x50mm Screws
Pre drill
hole
50mm
screw
5
7
Step 13
Fix the side of the Side Panel (No. 7)
against the framing of the back panel (No. 5)
screwing internally with 3x50mm screws
as shown in diagram.
Do not secure the building to the Floor
until the roof is tted.
3x50mm Screws
Pre drill
hole
50mm
screw
Step 14
Fix the Double Boarded Gable Top (No. 19)
in place slotting the groove of the boarding
on the gable into the tongue of the Side
Panels (No. 7) as shown with 4x50mm
screws.
4x50mm Screws
719
Pre drill
hole
50mm
screw

P 8
Please retain product label and instructions for future reference
Storage Door hinges tted on the right
hand side of the door which means that
your door will open on the left side.
Step 16b - Fitting Door
Secure the hinge (No. 41) to the
storage door (No. 18) and the
storage door panel (No. 6).
18x30mm Screws
Pre drill
hole
50mm
screw
6
18 41
Pre drill
hole
70mm
screw
Step 17
Lay the 2x Veranda (No. 15) face down, side by side
and x together with 3x70mm screws through the bearers
as shown in the diagram, to secure the
two Verandas together.
3x70mm Screws
15
15
Step 18
Place the assembled Verandas (No. 15) ush to the
building as shown to make sure the building
is square.
Step 19a
Place the Roof Panels (No. 11) onto the top
of the building. Align the 2 Roof Panels
so they sit square before xing into postion.
Do not secure the building to the Floor
until the roof is tted.
11
11

P 9
Please retain product label and instructions for future reference
Step 20a
Once the Roof is aligned and secure the
oor can be xed into postion.
Fix the building into place by screwing
through the panel framing, securing all of the panels
to the oor.
*External panels not shown
18x50mm Screws
Pre drill
hole
50mm
screw
Step 19b
Fix the two Roof panels together using
50mm screws oset from each other as shown
in the diagram.
Do not secure the building to the Floor
until the roof is tted.
8x50mm Screws
Pre drill
hole
50mm
screw
11
11
Step 19c
Screw in 8x50mm screws securing the roof
panels (No. 11) x 2 to all of the panels on
the front of the building
Do not secure the building to the
Floor until the roof is tted.
*External panels not shown
8x50mm Screws
Pre drill
hole
50mm
screw

Please retain product label and instructions for future reference
Step 20b
Continue to x the building into place by
screwing through the panel into the oor.
*External panels not shown
Pre drill
hole
50mm
screw
12
Pre drill
hole
30mm
screw
Step 21
Place the Under Roof (No. 12) into position,
making sure it is ush to the Door panel
and Storage section.
Fix in place making sure to screw through
the Roof framing. Pre-drill holes rst.
15x30mm Screws
P 10
