mercor mcr RPO-1 User manual

Gdańsk, ver. 1.8 - 2022.01.25
Manual Emergency Pushbutton
mcr RPO-1
OPERATION AND MAINTENANCE MANUAL
User Instruction Manual
Spis treści:
USER INFORMATION.............................................................................................................................................1
DESCRIPTION OF THE DEVICE ...........................................................................................................................2
TECHNICAL SPECIFICATION................................................................................................................................3
WARRANTY TERMS AND CONDITIONS..............................................................................................................4
User information
Thank you for selecting the mcr RPO-1 manual emergency
pushbutton. Please, read this document carefully and follow the
instructions. This will ensure smooth and reliable operation of smoke
exhaust systems and safety for the users and easy assembly of the
device.
„MERCOR” S.A. reserves the right to modify the product or the
documentation without notice.
We wish to ensure your full satisfaction with our products and will
be glad to provide professional service and assistance to you, if
necessary. „MERCOR” S.A.
ul. Grzegorza z Sanoka 2
80-408 Gdańsk
tel. [phone]
fax [phone]
Waste electrical and electronic equipment should be collected selectively and then subjected to recovery
and recycling processes!
SMOKE EXHAUST

Page 2 of 4
Description of the device
The mcr RPO-1 manual emergency pushbutton is used to
manually release an alarm in smoke exhaust systems and to provide
information on the status of mcr 9705 or mcr 0204 smoke exhaust
control units.
Related documents:
technical approval CNBOP-PIB-KOT-2021/0274-1009 issue 1,
certificate of conformity CNBOP-PIB no. 4529/2022,
declaration of conformity no. 097/HO/2022 dated 25.01.2022.
The electrical diagram pushbutton is shown in Fig. 2.
The view of the interior of the pushbutton housing is shown in Fig. 1.
The pushbutton has three LED indicators:
red –ALARM,
amber –FAULT,
green –OK,
LED terminals are directly and independently connected to a terminal
strip which ensures the universal character of the mcr RPO-1
manual emergency pushbutton.
Assembly
The emergency pushbutton should be placed in a location which
allows easy access for users and maintenance staff (if possible along
evacuation routes).
Install the device on a level surface, using appropriate metal
connectors selected in accordance with the substrate material.
Alarm release
After breaking the glass panel in the device door (CAUTION!
GLASS), push the alarm button (1). The SW1 contact switch will close
the alarm line. A mechanical block will keep the line closed until the
block is released.
Alarm reset
Open the device housing by a special key and release the
mechanical block
of the button, using the lever. Replace the glass panel.
The ALARM RESET (2) button is used to cancel the alarm status
of the control unit and to automatically close the vents after the alarm.
The R1 resistor (10kΩ) connected in series with the SW2 contact
switch ensures appropriate current supply, which is interpreted by the
control unit as the alarm reset signal. Hold down the button for at
least 1 second!

Page 3 of 4
Fig. 1 View of the interior of the housing of the RPO-1 pushbutton.
Along the top edge of the board, there are terminal strips used to
connect leads. Connection diagram is shown in Fig. 3.
1, 2 - LINE RESET 1
3, 4 - LINE RESET 2
5 - LED ALARM cathode
6 - LED ALARM anode
7, 8 - LINE RPO 1
9, 10 - LINE RPO 2
11 - LED DEFECT cathode
12 - LED DEFECT anode
13 - LED OK cathode
14 - LED OK anode
Fig. 2 Electric diagram of the RPO-1 pushbutton.
Technical specification
Item
Value
Compatible control units
mcr 9705; mcr 0204
Alarm pushbutton parameters
24V=, max. 100 mA
Working temperature range
-10°C + 55°C
Protection level for housing
IP 3X
Dimensions (H x W x D)
135 x 135 x 33 mm
Range of diameters leads to be connected
0.5 ÷ 0.75 mm²
Required number of wires in the connected lead
7
Release mode
Indirect
Type
I (operation and signalisation)
Climate class
I
1
2

Page 4 of 4
Fig. 3 Connection diagram of the mcr RPO-1 pushbutton with mcr 0204 control unit
(on the left) and mcr 9705 control unit (on the right).
