Metal Defender HZ-600 User manual

HZ-600 METAL DEFENDER MANUAL, TECHNICAL SPECIFICATIONS

Parts on the detector:
Main Board (1) , Left Probe (1), Right Probe (1), Bolts and Nuts (8), AC Power
Cord (1), Serial Port Plug (2) , Allyn Wrench (1), Instruction Manual (1), Keys (2)

1. Type: 6 Zone Stand up metal detector
2. Application: For use in commercial or industrial use. It detects both
ferromagnetic and non-ferromagnetic items. Detection in size as small as
paperclip.
Due to the devices smaller and lighter size as well as roller wheel
attachments (sold separately) the unit can be mobile.
3. WARNING: ATTENTION!! can cause interference with the operation of
A pacemaker. It should NOT BE OPERATED in the
vicinity of a person equipped with a pacemaker.
4. Components: items comes with 2 side panels/probes, 1 main monitor
panel/board.
Technical specifications
Power Supply: AC90V-250V 50HZ-60HZ
Power: <35 W
Dimensions: 86.6 inches (H)
31.5 inches (W)
19.7 inches (Depth)
Channel dimensions: 79.2 inches (H)
27.5 inches (W)
19.7 inches (D)
Color: Black, charcoal gray
Weight: approximately 155 lbs
Operating environment: -5 –115 degrees F
Metal detector has met all national standards through 2003

Product details
Alarm Display, LED lights determine metal objects on both sides
Computer networking and ability to adjust security settings
General information
Regional Sensitivity:
The maximum sensitivity can detect the metal content as small as a paper clip,
in self-regulation between 0-255 sensitivity detection requirements may need
to be adjusted. Be sure to determine items looking for beforehand and remove
keys, jewelry, belt buckles, and steel toe boots to prevent false alarms. Also
make sure that the unit is at least 4 feet from any metal frame door or revolving
door
Product Process:
Made of PVC synthetic materials, the unit is waterproof for mild outdoor usage.
Its appearance is very aesthetic is suitable for many different types of users.
Smart Statistics:
Intelligent traffic and alarm counting function; can automatically detect the
number of passing individuals and the number of detections that have gone off.
Anti-interference ability:
Digital, analog, and left and right balanced technology, help in preventing false
alarms and false negatives, and greatly improve the anti-jamming capability.
Safety protection:
Double password protected, allowing only authorized personnel operation and

access. Multiple passwords allow for better security parameters. Parameter
settings are automatically stored without interrupting power supply protection,
both safe and convenient.
Electromagnetic radiation:
EMC electromagnetic radiation standards; use of weak magnetic field
technology, safe for pregnant women, cell phones, film, video tapes and other
sound equipment.
Installation:
This series metal detector has an integrated design, which allows for easy
installation or removal within 20 minutes.
Field of use:
Airport, schools, concert venues, events, railway stations, docks, entertainment
facilities, prisons, courts, government departments, factories, examination
room, shopping malls, community channels, security check and prohibited items
inspection areas.
