METREL AlphaPAT User manual

AlphaPAT
MI 2142
Instruction manual
Ver. 1.2. Code no. 20 750 748

2
Distributor:
Producer:
Metrel d.d.
Ljubljanska cesta 77
SI-1354 Horjul
E-mail: [email protected]
http://www.metrel.si
Mark on your equipment certifies that this equipment meets the requirements of the EU
(European Union) concerning safety and interference causing equipment regulations
© 2003…2008 Metrel
No part of this publication may be reproduced or utilized in any form or by any means
without permission in writing from METREL.

MI 2142 AlphaPAT Table of contents
3
1General description............................................................................................................................5
1.1 Warnings...................................................................................................................................... 6
1.2 Warning markings on connector panel ........................................................................................ 6
1.3 Standards applied........................................................................................................................ 6
2Instrument description ......................................................................................................................7
2.1 Front panel................................................................................................................................... 7
2.2 Connector panels......................................................................................................................... 8
2.3 Bottom side.................................................................................................................................. 9
2.4 Safety pre-tests.......................................................................................................................... 10
2.5 Meaning of symbols and messages on the instrument display ................................................. 10
3Technical specifications..................................................................................................................13
3.1 Earth bond resistance................................................................................................................ 13
3.2 Insulation resistance .................................................................................................................. 13
3.3 Substitute leakage current ......................................................................................................... 13
3.4 Leakage current and apparent power........................................................................................ 14
3.5 Touch leakage current ............................................................................................................... 14
3.6 Polarity test ................................................................................................................................ 14
3.7 TRMS current ............................................................................................................................ 15
3.8 General data .............................................................................................................................. 15
4Main menu and test modes.............................................................................................................17
4.1 Help menus................................................................................................................................ 17
4.1.1 How to enter help menu.................................................................................................... 17
4.2 Main menu ................................................................................................................................. 17
4.2.1 Autotest shortcut menu ..................................................................................................... 18
4.2.2 Autotest custom menu ...................................................................................................... 18
4.2.3 Single test menu ............................................................................................................... 18
4.2.4 Recall results menu........................................................................................................... 18
4.2.5 Autotest TAG menu........................................................................................................... 19
4.2.6 Setup menu....................................................................................................................... 19
5Single test mode...............................................................................................................................20
5.1 How to perform measurements in single test mode .................................................................. 20
6Measurements ..................................................................................................................................21
6.1 Earth bond resistance................................................................................................................ 21
6.1.1 How to perform single earth bond resistance measurement ............................................ 21
6.2 Insulation resistance .................................................................................................................. 22
6.2.1 Insulation resistance on class I appliances....................................................................... 22
6.2.2 Insulation resistance on class II appliances...................................................................... 23
6.2.3 How to perform single insulation resistance measurement .............................................. 23
6.3 Substitute leakage current ......................................................................................................... 24
6.3.1 Substitute leakage current on class I appliances.............................................................. 24
6.3.2 Substitute leakage current on class II appliances............................................................. 24
6.3.3 How to perform single substitute leakage current measurement ..................................... 25
6.4 Leakage current and power.......................................................................................................26
6.4.1 How to perform single leakage current measurement...................................................... 26
6.5 Touch leakage current ............................................................................................................... 27
6.5.1 How to perform single touch leakage current measurement ............................................ 27
6.6 Polarity test ................................................................................................................................ 28
6.6.1 How to perform the measurement .................................................................................... 29
6.7 True RMS current measurement ............................................................................................... 29
6.7.1 How to perform TRMS clamp current measurement ........................................................ 29
7Autotest modes ................................................................................................................................31
7.1 Autotest shortcut menu.............................................................................................................. 31
7.1.1 How to set the autotest shortcut sequence....................................................................... 31
7.1.2 How to set autotest parameters ........................................................................................ 31
7.1.3 How to set or enter autotest shortcut code ....................................................................... 32
7.1.4 How to set autotest sequence by using barcode reader................................................... 32
7.1.5 How to view autotest shortcut sequence measurement parameters................................ 33

MI 2142 AlphaPAT Table of contents
4
7.1.6 How to start autotest shortcut sequence .......................................................................... 33
7.2 Autotest custom menu ............................................................................................................... 33
7.2.1 How to view and/or change an existing autotest custom sequence ................................. 34
7.2.2 How to save the autotest custom sequence ..................................................................... 34
7.2.3 How to delete an existing custom test sequence from the list.......................................... 35
7.2.4 How to start custom autotest sequence............................................................................ 35
7.3 Autotest TAG menu ................................................................................................................... 35
7.3.1 How to view autotest sequence from RFID TAG .............................................................. 36
7.3.2 How to view and/or save autotest results from TAG......................................................... 36
7.3.3 How to send an autotest sequence/results to TAG .......................................................... 36
7.4 Performing autotest sequences................................................................................................. 37
7.4.1 Visual inspection ...............................................................................................................37
7.4.2 Earth bond resistance measurement................................................................................ 37
7.4.3 Insulation resistance measurement .................................................................................. 37
7.4.4 Substitute leakage current measurement ......................................................................... 38
7.4.5 Leakage current and apparent power measurement........................................................ 38
7.4.6 Touch leakage current measurement ............................................................................... 38
7.4.7 Polarity test ....................................................................................................................... 39
7.4.8 TRMS clamp current measurement.................................................................................. 39
8Saving and recalling autotest results ............................................................................................40
8.1 Autotest save results menu ....................................................................................................... 40
8.1.1 How to view autotest sequence results ............................................................................ 40
8.1.2 How to save autotest sequence results ............................................................................ 40
8.1.3 How to download or send autotest sequence results ....................................................... 41
8.2 Recall results menu ................................................................................................................... 41
8.2.1 How to search for and recall saved autotest results ......................................................... 41
8.2.2 How to delete saved autotest results................................................................................ 42
8.2.3 How to download or send stored autotest results............................................................. 43
9Measuring 110 V appliances ...........................................................................................................44
9.1 110 V adapter ............................................................................................................................ 44
9.1.1 How to perform measurements by using 110 V adapter .................................................. 44
10 Other instrument operations...........................................................................................................45
10.1 Setup menu ............................................................................................................................... 45
10.1.1 Setting date and time ........................................................................................................ 45
10.1.2 Display contrast adjustment.............................................................................................. 45
10.1.3 Language selection........................................................................................................... 46
10.1.4 Viewing of instrument data................................................................................................ 46
10.1.5 Serial communication port settings ................................................................................... 46
10.1.6 Reset instrument settings ................................................................................................. 47
11 Maintenance......................................................................................................................................48
11.1 Periodic calibration .................................................................................................................... 48
11.2 Fuses ......................................................................................................................................... 48
11.3 Service....................................................................................................................................... 49
11.4 Cleaning..................................................................................................................................... 49
12 Instrument set and accessories......................................................................................................50
Appendix A ................................................................................................................................................51
Appendix B ................................................................................................................................................54

MI 2142 AlphaPAT General description
5
1 General description
AlphaPAT MI 2142 is a portable test instrument intended for all measurements
performed when testing the electrical safety of portable electrical equipment. The
following tests can be performed/done:
 earth bond resistance,
 insulation resistance,
 substitute leakage current,
 leakage current,
 touch leakage current,
 functional test,
 IEC cord polarity test, and
 TRMS current measurement.
Wide graphic matrix display with backlight offers easy to read results, indications,
measurement parameters, and messages. Operation is simple and clear – operator
does not need any special training (except reading this user manual) to operate the
instrument.
Built-in flash memory for storing test results is an important feature of the AlphaPAT MI
2142 instrument. Professional PC software enables simple transfer of test results and
other measurement parameters in both directions between the test instrument and PC.
Two RS232C communication ports also allow communication with barcode reader,
printer, and RFID reader/writer.
The instrument is equipped with all accessories necessary for comfortable performance
of tests. It is kept in a soft carrying bag together with all accessories.

MI 2142 AlphaPAT General description
6
1.1 Warnings
In order to reach high level of operator safety while carrying out various measurements
using AlphaPAT, as well as to keep the test equipment undamaged, it is necessary to
consider the following general warnings:
 If the test equipment is used in manner not specified in this user manual the
protection provided by the equipment may be impaired!
 Read this user manual carefully, otherwise use of the instrument may be
dangerous for the operator, for the instrument or for the equipment under test!
 Use only earthed mains outlets to supply the instrument!
 Do not use the instrument and accessories if any damage is noticed!
 In case a fuse has blown follow the instructions in this user manual to replace it!
 Service intervention or calibration procedure is allowed to be carried out only by
a competent authorized person!
 Use only standard or optional test cables supplied by your distributor!
 In some countries the leakage and touch leakage current measurements shall be
executed for normal connection of tested equipment and also for the connection
with changed L and N. It is advised to prepare appropriate test set-up for the test
with the changed lines. Consider local regulations.
 High voltages and currents are generated during some tests or
measurements. Never touch the appliance being tested or the test
terminals, whilst a test or measurement is in progress!
1.2 Warning markings on connector panel
Refer to chapter 2.2 Connector panels!
1.3 Standards applied
The AlphaPAT MI 2142 instrument has been manufactured and tested in accordance
with the following standards:
Safety:
 EN61010-1
Electromagnetic compatibility (emission and immunity):
 IEC 61326
Measurements in accordance with:
 British standard BS89
 German standards VDE 0701 and VDE 0702

MI 2142 AlphaPAT Instrument description
7
2 Instrument description
2.1 Front panel
2
abc
1
*
3
def
6
m
no
5
j
kl
4
ghi
7
pqrs
8
tuv
9
wxyz
CLR
0
F1
Send
F2
ESC
Help
START
ENTER
123456
8
9
10 7
Front panel
Legend:
1.............. START/STOP key
2.............. HELP key
3.............. SEND key
4.............. Function keys F1 and F2
5.............. Alpha-numeric selector key
Press the key to select the type of entry (large/small letters, numbers) via
keypad.
6.............. CLEAR key
7.............. Alpha-numeric keypad
8.............. 128 x 64 dots graphic matrix display with backlight
9.............. ESCAPE key
10............ Cursor keys and ENTER key

MI 2142 AlphaPAT Instrument description
8
2.2 Connector panels
12
3
WARNING!
Earth wander
lead
45
6
7
Connector panels
Legend:
1................ Test socket
Warning! Maximum output current is 16 A, test only appliances with
maximum rated supply current not higher than 16 A!
2................ IEC lead connector
Warning! The connector input is only for test purposes; do not
connect it to mains supply!
3................ Earth bond connector, also used as an input in some class II
measurements:
subleakage current, touch leakage current, and insulation resistance
Warning! When cord test being carried out the wander earth lead must
not be connected to the instrument!
4................ PC connector
5................ Barcode reader/printer/RFID TAG connector
6................ Clamp current input
Warning! Do not connect any voltage source on this input. It is
intended only for connection of current clamp with current output.
Maximum input current is 30 mA!
7................ Mains supply cord

MI 2142 AlphaPAT Instrument description
9
2.3 Bottom side
7
6
5
4
3
2
1
Bottom side
Legend:
1................ Plastic cover
A screw under the cover needs to be unscrewed when opening the
instrument for service or calibration purposes.
2................ Screw
3................ Label with measurement data
4................ Fuse compartment cover
5................ Information label
6................ Fixing screw for fuse compartment cover
(see chapter 11.2 Fuses for instructions on fuse replacement).
7................ Rubber foot

MI 2142 AlphaPAT Instrument description
10
2.4 Safety pre-tests
The instrument makes pre-tests before a regular test of connected appliance to ensure
safety and to prevent any damage. These safety pre-tests check for:
 any external voltage against earth on test socket and test probe,
 too high leakage current,
 too high touch leakage current,
 short circuit or too low resistance between L and N on appliance,
 correctly applied mains voltage to the test socket and
 if the 110V adapter is used.
If pre-test fails, an appropriate warning message will be displayed.
The warnings and measures that have to be taken are described in chapter 2.5
Meaning of symbols and messages on the instrument display.
2.5 Meaning of symbols and messages on the instrument
display
MAINS VOLTAGE IS
NOT CORRECT OR
PE NOT CONNECTED!
Check mains voltage
and PE connection!
Improper supply voltage warning. Determine and
eliminate the problem before proceeding! Check for
incorrect wiring on wall socket. Possible causes:
 no earth connection,
 incorrect mains voltage.
L and N are crossed.
Press Start key to
continue.
The instrument works normally also in the case when L
and N are interchanged. Pay attention to wrong polarity of
line and neutral wires on test socket.
L-N RESISTANCE TOO
HIGH (>30kΩ)!
Are you sure to
proceed?
YES NO
Too high resistance was measured in the fuse pre-test.
Indication means that appliance has too low consumption
or is:
 not connected,
 switched off.
Select YES or NO with or key and press Enter key to
confirm.
L-N RESISTANCE TOO
LOW (<20.0Ω)!
Are you sure to
proceed?
YES NO
It is very likely that too high current will flow after applying
power to the tested appliance. If the too high current is
only of short duration (caused by the short inrush current)
the test can be performed, otherwise not.
Select YES or NO with or key and press Enter key to
confirm.

MI 2142 AlphaPAT Instrument description
11
L-N SHORTED (<3.0Ω)!
Are you sure to
proceed?
YES NO
It is very likely that fuses will blow after applying power to
the tested appliance. If the too high current is only of short
duration (caused by the short inrush current) the test can
be performed otherwise it must be stopped.
Check the appliance!
Select YES or NO with or key and press Enter key to
confirm.
LEAKAGE TOO HIGH
(>20.0mA)!
Are you sure to
proceed?
YES NO
Dangerous leakage current (higher than 3.5mA) will flow if
the power is connected to the tested appliance. Proceed
with testing only if all safety measures are taken.
Check regularity of cord connections of tested
appliance before continuing test.
Select YES or NO with or key and press Enter key to
confirm.
110V ADAPTER
CONNECTED!
No fuse test!
Indication that adapter for 110V appliance is connected
into test socket.
110V ADAPTER
CONNECTED!
Measurement is
prohibited!
110V appliance can not be tested with mains supply
voltage of 230V.
TEST WAS SKIPPED
FOR SAFETY!
Instrument detected unsafe condition and skipped the
required test.
INSTRUMENT
OVERHEATED!
Measurement is
aborted!
Temperature of internal components in the instrument
reached top limit. Measurement is prohibited until
temperature is lower than that limit.

MI 2142 AlphaPAT Instrument description
12
VOLTAGE ON TEST
SOCKET TOO HIGH!
DANGER!
Voltage on test socket is higher than 20V (AC or DC)
approximately!
Disconnect the connections to the instrument immediately
and determine the external voltage source!
VOLTAGE ON TEST
PROBE TOO HIGH!
POSSIBLE DANGER!
Voltage on test probe is higher than 15V (AC or DC)
approximately!
Disconnect the test probe from the appliance and
determine the cause of error!
HARDWARE ERROR
In self-test and before test where mains voltage is applied
the functionality of the instrument output relays is checked.
In case of error the mains voltage is not applied to the test
socket. In case of this warning return the instrument to the
repair centre.
The earth bond test probe must be used in this test.
Remove the EB clip, especially if it is connected to any
part that will begin to rotate or move when power is
applied.
Warning!
High voltage is (will be) applied on the instrument output!
(Insulation test voltage or mains voltage).
The tested appliance should be switched on (to ensure
that the complete circuit will be tested).
Connect the lead to be tested to the IEC plug!
Test passed.
Test failed.
Numeric entry
Small character entry
Caps entry

MI 2142 AlphaPAT Technical specifications
13
3 Technical specifications
3.1 Earth bond resistance
Earth bond resistance readout
Range Resolution Accuracy
0.00 Ω÷19.99 Ω0.01 Ω±(5 % of reading + 3 digits)
Test currents............. 25 A, 10 A, 100 mA into 100 mΩat mains voltage of 230 V AC
Open circuit voltage .. <6 V AC at mains voltage of 230 V AC
Pass levels ............... 0.01 Ω÷0.09 Ω, 0.10 Ω÷0.90 Ω, 1.00 Ω÷9.00 Ω
Test duration............. 2 s, 3 s, 5 s, 10 s, 30 s
Output....................... test probe connector, test socket (PE)
Test method.............. 4-wire measurement, floating to earth
3.2 Insulation resistance
Insulation resistance readout
Range Resolution Accuracy
0.000 MΩ÷0.500 MΩ0.001 MΩ±(10 % of reading + 5 digits)
0.501 MΩ÷1.999 MΩ0.001 MΩ±(5 % of reading + 3 digits)
2.00 MΩ÷19.99 MΩ0.01 MΩ±(5 % of reading + 3 digits)
Nominal voltages ...... 250 V DC, 500 V DC (-0%, +10 %)
Measuring current..... min. 1 mA at 250 kΩ(250 V), 500 kΩ(500 V)
Short circuit current... <0.5 mA
Pass levels ............... 0.50 MΩ, 1.00 MΩ, 2.00 MΩ, 4.00 MΩ, 7.00 MΩ, 10.00 MΩ
Test duration............. 2 s, 3 s, 5 s, 10 s, 30 s
Output....................... test socket (Class I) / test socket, test probe connector (Class II)
Auto discharge after test.
3.3 Substitute leakage current
Substitute leakage current readout
Range Resolution Accuracy
0.00 mA ÷19.99 mA 0.01 mA ±(5 % of reading + 5 digits)
Open circuit voltage .. <50 V AC at mains voltage of 230 V AC
Short circuit current... <40 mA
Pass levels ............... 0.25 mA, 0.50 mA, 0.75 mA, 1.00 mA, 1.50 mA, 2.50 mA,
3.50 mA, 7.00 mA, 9.90 mA
Test duration............. 2 s, 3 s, 5 s, 10 s, 30 s
Output....................... test socket (Class I) / test socket, test probe connector (Class II)
Displayed current is calculated to appliance mains supply voltage (230 V / 115 V).

MI 2142 AlphaPAT Technical specifications
14
3.4 Leakage current and apparent power
Differential leakage current readout
Range Resolution Accuracy
0.00 mA ÷19.99 mA 0.01 mA ±(5 % of reading + 5 digits)
Pass levels ............... 0.25 mA, 0.50 mA, 0.75 mA, 1.00 mA, 1.50 mA, 2.25 mA,
2.50 mA, 3.00 mA, 3.50 mA, 9.90 mA
Test duration............. 2 s, 3 s, 5 s, 10 s, 30 s, 60 s, 120 s, 180 s
Output....................... test socket
Apparent power readout
Range Resolution Accuracy
0.00 kVA ÷3.7 kVA 0.01 kVA ±(10 % of reading + 3 digits)
Test duration............. 2 s, 3 s, 5 s, 10 s, 30 s, 60 s, 120 s, 180 s
Output....................... test socket
3.5 Touch leakage current
Touch leakage current readout
Range Resolution Accuracy
0.00 mA ÷1.99 mA 0.01 mA ±(5 % of reading + 5 digits)
Pass levels ............... 0.25 mA, 0.50 mA, 1.00 mA
Test duration............. 2 s, 3 s, 5 s, 10 s, 30 s, 60 s, 120 s, 180 s
Output....................... test socket, test probe connector
Probe ........................ human body model with resistance of 2 kΩ
3.6 Polarity test
Test voltage .............. <50 V AC
Detects ..................... Pass, L-open, N-open, PE-open, L-N crossed, L-PE crossed, N-
PE crossed, L-N shorted, L-PE shorted, N-PE shorted, multiple
faults
Output....................... test socket, IEC cord

MI 2142 AlphaPAT Technical specifications
15
3.7 TRMS current
True RMS current readout using 1000:1 current clamp
Range Resolution Accuracy*)
0.00 mA ÷9.99 mA 0.01 mA ±(5 % of reading + 5 digits)
10.0 mA ÷99.9 mA 0.1 mA ±(5 % of reading + 5 digits)
100 mA ÷999 mA 1 mA ±(5 % of reading + 5 digits)
1.00 A ÷9.99 A 0.01 A ±(5 % of reading + 5 digits)
10.0 A ÷24.9 A 0.1 A ±(5 % of reading + 5 digits)
*)Consider accuracy of current transformer.
Pass levels ............... 0.25 mA, 0.50 mA, 0.75mA, 1.00 mA, 1.50 mA, 2.25 mA,
2.50 mA, 3.00mA, 3.50 mA, 9.90 mA, none
Test duration............. 2 s, 3 s, 5 s, 10 s, 30 s, 60 s, 120 s, 180 s
Input.......................... current clamp terminals
3.8 General data
Rated supply voltage .........................230 V AC (±10 %, 50 or 60 Hz)
Max. power consumption...................140 VA (without tested appliance)
Maximum appliance current...............16 A
Overvoltage category.........................Cat II / 300 V
Protection classification .....................I
Pollution degree.................................2
Display...............................................64*128 dots graphic matrix display with backlight
Dimensions (w*h*d) ...........................26.5 cm × 11 cm × 18.5 cm
Weight (without accessories).............3.5 kg
Memory..............................................1100 memory locations
RS232 interfaces .............................. 1200 bps ÷115200 bps, 1 start bit, 8 data bits,
1 stop bit
RS232 connectors .............................9-pin subminiature type D, female
Reference conditions
Reference temperature range............10 °C ÷30 °C
Reference humidity range..................40 % ÷70 % RH
Operation conditions
Working temperature range ...............0 °C ÷40 °C
Maximum relative humidity ................95 % RH (0 °C ÷40 °C), non-condensing

MI 2142 AlphaPAT Technical specifications
16
Storage conditions
Temperature range ............................-10 °C ÷+70 °C
Maximum relative humidity ................90 % RH (-10 °C ÷+40 °C)
80 % RH (40 °C ÷60 °C)
Accuracies apply for 1 year in reference conditions. Temperature coefficient outside
these limits is 0,2 % of measured value per °C, and 1 digit.
Fuses
Instrument protection .........................T1.25 A / 250 V, 5 ×22 mm
Test socket protection........................2 x T16 A / 250 V, 6.3 ×32 mm
Protection pre-tests
 External voltage between L and PE or N and PE (DC and AC)
 External voltage on test clip (DC and AC)
 Excessive leakage between L and PE
 Short circuit or too low resistance between L and N
Connectivity (fuse) pre-test
 Appliance not switched on or too high resistance between L and N
Maximum resistance for connectivity pre-test.................................. 30 kΩ

MI 2142 AlphaPAT Main menu and test modes
17
4 Main menu and test modes
The AlphaPAT instrument uses user-friendly manipulation. By using only a few keys
most of the actions can be done. Menu tree of the instrument is simple to understand
and easy to operate.
Instrument enables testing of appliances in:
 single test mode, and
 autotest modes.
After the instrument is switched on, the last used menu will be displayed.
4.1 Help menus
The measurement help menus are available in single and autotest modes. Help menu
contains schematic diagrams for illustration of proper connection of appliance under test
to the AlphaPAT instrument.
4.1.1 How to enter help menu
After entering the selected measurement and before pressing START, press HELP key
in order to view help menu.
Examples of help menu
Press HELP key again to see the next page if available. Press HELP or ESC key to
return to the last test/measurement menu.
4.2 Main menu
From the Main menu all instrument functions can be selected.
Main menu
Select the function you want to perform by using and cursor keys and press
ENTER key to confirm. To return to the Main menu press ESC key.

MI 2142 AlphaPAT Main menu and test modes
18
Note:
 Press ESC key one or more times to return to Main menu from any submenu or
selected function.
4.2.1 Autotest shortcut menu
In this menu one of 120 pre-defined autotest sequences can be selected and
performed. When the autotest sequence is completed measurement results can be
stored into instrument flash memory or sent to the printer or PC for further processing.
4.2.2 Autotest custom menu
It might happen that none of the offered autotest shortcut sequences corresponds with
test requirements. For this reason any autotest procedure can be set in the autotest
custom menu. In this menu the autotest results can be stored into instrument flash
memory or sent to the PC for further purposes (as well test reports can be printed out,
etc.).
Autotest custom menu
See chapter 7 Autotest modes for detailed description about these modes.
4.2.3 Single test menu
In single test menu individual tests can be performed. Note that measurement results
performed in this mode cannot be stored.
Single test menu
See chapter 5 Single test mode for detailed description about the single test mode.
4.2.4 Recall results menu
Manipulation with stored results is allowed in this menu. Stored results can be recalled
according to appliance name and date.
Recall results menu

MI 2142 AlphaPAT Main menu and test modes
19
See chapter 8 Saving and recalling autotest results for detailed description about
recalling results.
4.2.5 Autotest TAG menu
Autotest sequence and measurement results for tested appliance can be downloaded
(uploaded) from (to) the RFID TAG.
Autotest RFID TAG menu
See chapter 7.3 Autotest TAG menu for detailed description about Autotest.
4.2.6 Setup menu
In this menu general instrument parameters can be set.
Setup menu
See chapter 10.1 Setup menu for detailed description.

MI 2142 AlphaPAT Single test mode
20
5 Single test mode
In single test mode individual tests can be performed. This is especially helpful when
you suspect one or more faults in the tested appliance.
Note:
 The measurement results cannot be saved in this mode!
5.1 How to perform measurements in single test mode
Select Single test in Main menu by using and cursor keys and press ENTER key
to confirm. The Single test menu is displayed.
Single test menu
By using and cursor keys select the measurement you want to perform and press
ENTER key to confirm. To return to the Single test menu press ESC key.
Selected test measurement parameters are detailed in the lower left corner of the
display. In general the following parameters can be set:
 output test voltage/current,
 pass level, and
 measurement duration.
Once the measurement parameters are set, the settings are kept until new changes are
made or the instrument is reset to the default configuration.
Note:
 To keep new settings in case of power fail return to main menu before turning the
power off.
