Dilog PU690 User manual

PU690 - Proving Unit
690V AC Proving for Voltage
Indicators
Instruction Manual

PU690 Operating Manual
Di-LOG
...measurably better
Contents
I. Overview 3
II. Safety Notice 3
III. Instrument Symbols 4/5
IV. Technical Specication 6
V. Display and Controls 7
1. Operating Instructions 7/8
2. Battery Replacement 8
3. Accessories 9
4. Warranty Information 10
1

PU690 Operating Manual PU690 Operating Manual
Di-LOG
...measurably better
Certicate of conformity
As the manufacturer of the instrument
listed below, we declare under our sole
responsibility that the product:
Di-LOG PU690 - Proving Unit
to which this declaration relates is in
conformity with the relevant clauses of
the following standards:
EN 61010-1
EN 61010-2-030
EN 61326-1
EN 61326-2-2
LVD, EMC & RoHS
The safety and performance of this
instrument is assured when operated
within the specications in this instruction
manual.
The product identied above conforms
to the requirements of council directive
2014/30/EU and 2014/35/EU.
2

PU690 Operating Manual
Di-LOG
...measurably better
I. Overview
The PU690 proving unit is a compact and
lightweight voltage proving unit designed
for the compliance safety checking of 2
pole voltage testers prior to testing on a live
circuit.
It is a requirement of the Electrical Safety
Council and the HSE that every Electrician
proves their voltage testers before and after
conrming safe isolation. The PU690 is
also high and low Z impedance compatible
for proving voltage on mulimeters.
3
II. Safety Notices
1. Please carefully read and fully understand
the warnings and operating instructions
before use. If the instrument is used in a
manner not specied by the manufacturer,
the protection provided by the instrument
may be impaired.
2. If the proving unit appears damaged or is
not working properly, stop using it
immediately.
The operator’s safety is no longer ensured,
the instrument is to be put out of service
and protected against use. Safety may
be compromised if the instrument:
● Shows obvious damage.
● Does not carry out the desired measurements.
● Has been stored for too long under
unfavourable conditions.
● Has been subjected to mechanical stress
during transport.
3. Once the indicators on the voltage tester
have been visualised, please remove the
test probe from the right input rst, and then
from the left.

PU690 Operating Manual PU690 Operating Manual
Di-LOG
...measurably better
4
Warning! Warns of potential danger,
and to comply with the instruction
manual.
Caution! Dangerous voltage,
potential risk of electrical shock.
Equipment protected throughout by
double or reinforced insulation.
Conformity symbol, the instrument
complies with the relevant
directives. It complies with EMC
Directive (2014/30/EU),
Standards EN 61326-2-2. It also
complies with the Low Voltage
Directive (2014/35/EU), Standards
EN 61010-1, EN 61010-2-030 and
EN61326-1 are fullled.
III. Instrument & Manual Symbols
Symbols displayed on the instrument and
in the instruction manual:
II. Safety Notices (continued)
4. Do not operate the proving unit for periods
longer than 10 seconds.
3. Clean the tester casing with a damp cloth
and mild detergent. Do not use abrasives or
solvents!
4. When low battery indication appears,
please replace the batteries.
5. Comply with local and national safety
6. The proving unit may not output voltage
if the unit is used outside of the operating
specications (see technical specication
for details).

PU690 Operating Manual
Di-LOG
...measurably better
The PU690 meets the standard
(2012/19/EU) WEEE. This marking
indicates that this product should
not be disposed with other house-
hold wastes throughout the EC. To
prevent possible harm to the envi-
ronment or human health from
uncontrolled waste disposal, recycle
it responsibly to promote the
sustainable reuse of material
resources. To return your used
device, please use the return and
collection systems or contact the
retailer where the product was
purchased. They can take this product
for environmental safe recycling.
The instruction manual contains
information and references, necessary
for safe operation and maintenance
of the instrument. Prior to using
the instrument the user is kindly
requested to thoroughly read the
instruction manual and comply with
it in all sections.
Failure to read the instruction manual
or to follow the warnings and
references contained herein can
result in serious bodily injury or
instrument damage. The respective
accident prevention regulations
established by the professional
associations are to be strictly
enforced at all times.
III. Instrument Symbols (continued)
5

PU690 Operating Manual PU690 Operating Manual
Di-LOG
...measurably better
IV. PU690 Series Specication
6
PU690 Proving Unit Specification
PU690
Voltage Output 690V AC
Output current <3.5mA
Frequency 50 Hz
Load ≥200 KΩ
High Voltage LED p
Low Voltage LED p
Low battery indication ≤7.6V
Safety rating CAT II 750V
Operating temperature -10°C to 40°C at max
Storage temperature -10°C - 50°C
Relative humidity ≤70% non-condensing
Altitude Up to 2000m
Pollution Degree 2
Dimensions (H/W/D) 140mm x 80mm x 50mm
Weight (net) 400g
Power supply 6 x 1.5V (LR6) AA (supplied)
EAN 5060082543562
Measurement category II is for
measurements performed on
circuits directly connected to the
low-voltage installation. Examples
of this would be; measurements
on household appliances, portable
tools and similar equipment.

PU690 Operating Manual
Di-LOG
...measurably better
1. Operating Instructions
Proof Testing
Insert the voltage tester probes into the
output sockets (690V AC). Apply su󰀩cient
pressure to ensure a good connection.
Check the voltage indication on the voltage
tester under test. Ensure the output voltage
LED is on during the test. Once visual
indication has been conrmed and
veried, remove the right test probe rst
before removing the left test probe.
7
Please note the output voltage
may not be 690V and will depend
upon the load applied by the voltage
indicator.
V. Display and Controls
unit
Proving
PU690
690V AC
Output Voltage On LED
Voltage Output
Points
Low Battery
Indicator

PU690 Operating Manual PU690 Operating Manual
Di-LOG
...measurably better
Voltage output against load resistance chart
2. Battery Replacement
Position the PU690 face down and
release the single captive screw in the
battery compartment cover.
Remove the battery compartment cover.
Remove the discharged batteries from
the compartment.
Fit a new set of LR6 (AA) 1.5v batteries.
Relocate the battery cover over the
battery compartment and fasten in
position with the battery cover captive
screw.
8
All Di-LOG voltage indicators draw
<3.5mA and will indicate up to 690V
but other manufacturers’ instruments
may vary.

PU690 Operating Manual
Di-LOG
...measurably better
9
3. Accessories
Optional Accessories for PU690
CCDLPK Combined carry pouch for PU690
Proving Unit and CombiVolt
Voltage Tester.
User Notes

PU690 Operating Manual PU690 Operating Manual
Di-LOG
...measurably better
4. 24 Month Warranty
Di-LOG instruments are subject to stringent
quality controls. If in the course of normal
daily use a fault occurs we provide a 24
month warranty (only valid with proof of
purchase). Faults in manufacture and
material defects will be rectied by us free
of charge, provided the instrument has not
been tampered with and returned to us
unopened. Damage due to dropping, abuse
or misuse are not covered by the warranty.
Product Support
[email protected]
Di-LOG Ltd
Unit 28 Wheel Forge Way
Tra󰀨ord Park
Manchester M17 1EH
UK
Tel:[phone]
Email: [email protected]
Website: www.dilog.co.uk
