Meyer PV Series User manual

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
MODELS LISTED IN THIS BOOKLET
GAS-DRIVEN (HONDA AND BRIGGS & STRATTON)
HYDRAULIC
BASE LINE
00108-760-01-REV-B
Page 1
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
THE BEST SAFETY
DEVICE IS A
CAREFUL OPERATOR
SAFETY ALERT SYMBOL
THIS SYMBOL MEANS ATTENTION!
BECOME ALERT!
YOUR SAFETY IS INVOLVED!
PLEASE READ AND UNDERSTAND COMPLETELY BEFORE DO-
ING!
SAFE EQUIPMENT INSTALLERS and OPERATORS:
NOTICE: INSTRUCTIONAL MATERIAL AND PARTS LISTS INCLUDED IN THIS MANUAL ARE
SUBJECT TO CHANGE WITHOUT NOTICE.
turn off all power before performing any service operations
• follow recommenDeD operating proceDures.
• Keep eQuipment in safe operating conDition at all times.
• recogniZe anD avoiD HaZarDs wHile operating, servicing anD
maintaining eQuipment.
00108-760-01-REV-B
Page 3
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
9
WARNING
USE SAFETY GLASSES OR OTHER FACE PROTECTION AGAINST POSSIBLE BATTERY
EXPLOSION. DO NOT SMOKE AND AVOID OTHER SOURCES OF IGNITION.
10. Attach the positive battery cable (each end should have a rubber boot) to the positive terminal of the
solenoid and to the positive terminal of the battery. Make sure these protective boots are covering the
positive terminal post on the battery and on the solenoid. Attach one end of the remaining battery cable
to the negative terminal of the battery.
11. Connect the negative battery terminal to the battery hold down post. When finished, make sure all
wires are away from moving parts and lower engine shroud.
12. Plug cable from spreader into socket mounted on truck.
Never operate machine with engine shroud in the upright position. Never climb into hopper
while the engine is operating or capable of being operated.
SERIOUS INJURY or DEATH MIGHT OCCUR.
NOTE: Read and fully understand the owners manual supplied by the engine manufacturer
before operating this equipment. Not doing so, endangers your safety and the warranty
of the engine.
WARNING
9
WARNING
USE SAFETY GLASSES OR OTHER FACE PROTECTION AGAINST POSSIBLE BATTERY
EXPLOSION. DO NOT SMOKE AND AVOID OTHER SOURCES OF IGNITION.
10. Attach the positive battery cable (each end should have a rubber boot) to the positive terminal of the
solenoid and to the positive terminal of the battery. Make sure these protective boots are covering the
positive terminal post on the battery and on the solenoid. Attach one end of the remaining battery cable
to the negative terminal of the battery.
11. Connect the negative battery terminal to the battery hold down post. When finished, make sure all
wires are away from moving parts and lower engine shroud.
12. Plug cable from spreader into socket mounted on truck.
Never operate machine with engine shroud in the upright position. Never climb into hopper
while the engine is operating or capable of being operated.
SERIOUS INJURY or DEATH MIGHT OCCUR.
NOTE: Read and fully understand the owners manual supplied by the engine manufacturer
before operating this equipment. Not doing so, endangers your safety and the warranty
of the engine.
WARNING
00108-760-01-REV-B
Page 4
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
ENGINE COVER PROP ROD INSTRUCTIONS
9
WARNING
USE SAFETY GLASSES OR OTHER FACE PROTECTION AGAINST POSSIBLE BATTERY
EXPLOSION. DO NOT SMOKE AND AVOID OTHER SOURCES OF IGNITION.
10. Attach the positive battery cable (each end should have a rubber boot) to the positive terminal of the
solenoid and to the positive terminal of the battery. Make sure these protective boots are covering the
positive terminal post on the battery and on the solenoid. Attach one end of the remaining battery cable
to the negative terminal of the battery.
11. Connect the negative battery terminal to the battery hold down post. When finished, make sure all
wires are away from moving parts and lower engine shroud.
12. Plug cable from spreader into socket mounted on truck.
Never operate machine with engine shroud in the upright position. Never climb into hopper
while the engine is operating or capable of being operated.
SERIOUS INJURY or DEATH MIGHT OCCUR.
NOTE: Read and fully understand the owners manual supplied by the engine manufacturer
before operating this equipment. Not doing so, endangers your safety and the warranty
of the engine.
WARNING
1. Raise engine cover.
2. Locate the prop rod and remove it
from the plastic retainer allowing the
prop rod to swing down.
3. Locate the hole on the spreader
marked “insert prop rod here” and
slowly lower the engine cover until the
prop rod fully engages in to this hole.
4. Carefully release the engine cover
while ensuring it is being solidy sup-
ported by the prop rod.
2.500
Hole
Prop Rod
(Top View of Spreader with engine cover removed)
Engine
Cover
To prevent injury extreme caution must be used when opening, closing, or working under or near the engine
cover. To prevent the engine cover from falling the prop rod must be fully engaged into the proper hole.
Never operate or transport the spreader with the engine cover open.
Some maintenance proceedures may require the engine cover to be completley removed from the spreader to
allow full access to the gasoline engine or other components. The engine cover must be reinstalled and in the
closed position before starting engine or operating spreader.
00108-760-01-REV-B
Page 5
OCTOBER, 2013

INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
8
CENTER HIGH MOUNTING STOP LIGHT
ITEM PART NO. QTY. DESCRIPTION
62097 1 Kit, Center High Mount Stop Light
1 62714 1 • Lamp, Stop
2 62715 1 • Grommet
3 62364 1 • Cable, Light Power
4 62738 1 • Cable, Stop Lamp
5 62283 1 • Weld, Stop Lamp Bracket - Hydraulic Units ONLY
6 62739 1 • Hardware Bag - Not Shown
(GAS ENGINE)
(HYDRAULIC)
3
4
2
1
2
1
5


Item Part Number Qty. Description
1 62714 04605-153-00 1 Lamp, Stop
2 62715 04605-154-00 1 Grommet, Mounting
3 62364 04605-155-00 1 Cable, Light Power (Hopper)
4 62738 04616-075-00 1 Cable, Stop Lamp Power (Truck)
5 63155 00119-878-00 1 Forming, Rear Stop Light Bracket
CS (Hydraulic units only)
64076 00119-878-01 Stainless steel bracket.

  
   
  
  

1. Use high quality butt connectors and shrink wrap on
all electrical splice connections. Wire should be routed
and secured to protect against abrasion, sharp edges,
and excessive movement. It is highly recommended that
wiring be placed in convoluted tubing and secured with
tie wraps
2. When drilling holes, any bare metal should be coated with
a rust preventative; use appropriate size grommets and seal
hole with appropriate sealant.
3. Allow for normal movement/twisting between
cab and chassis/pickup box when routing wires.
4. When spreader is removed from the truck, the
 must be reconnected.













     
     


     


00108-760-01-REV-B
Page 6
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
INSTALLATION INSTRUCTIONS:
The PV Series Spreader can be mounted and stored
as a single unit. The PV Series Spreader will mount
on most medium or heavy-duty pickup trucks as well
as 1 ton trucks (with optional extended spinner).
DO NOT OVERLOAD THE VEHICLE
It is quite possible to overload the vehicle by im-
properly mounting or overloading the spreader. This
could result in dangerous stability and braking prob-
lems. Always consult and follow the vehicle manu-
facturer’s recommendations before attempting these
instructions.
1. Place the spreader in the rear of the truck with
the engine/motor to the rear of the truck. Center the
spreader(side to side) in the truck.
2. Attach or lower spinner assembly.
3. Position the spreader in the truck bed, just short of making
contact with the rear most part of the truck bed, bum-
per, pintle hook etc. Bolt the unit to the truck using a
minimum of four (4) 1/2” Grade 5 bolts and correspond-
ing washers and locknuts. The spreader is designed to
sit at on the bed of the truck, supported by the longitu-
dinal sides.
DO NOT SUPPORT THE SPREADER BY THE BODY
JACKS ALONE! UNIT IS NOT DESIGNED FOR CHASSIS
MOUNT APPLICATIONS!
5. Attach the hold down at each corner of the hopper
as shown. Locate and drill four .531(17/32”) diameter
holes for eyebolts in the truck bed. Straps must be po-
sitioned at opposing angles so that the spreader cannot
slide forward or rearward. Assemble ratchet/strap to
eye bolts. Tighten hold downs evenly. Do not overtight-
en, damage will result to the spreader or the truck.
Note: If vehicle is equipped with sufcient
tie downs, they may be used in place of
eyebolts.
INSTALLATION AND ASSEMBLY INSTRUCTIONS
BEFORE STARTING, VERIFY THAT THIS
MOUNTINGMETHODISACCEPTABLE TOTHE
VEHICLE MANUFACTURER.
CAUTION!
CAUTION!
ENSURETHESPREADERCANNOT TIPWHENTHE SPIN-
NER ASSEMBLY IS ATTACHED.
CAUTION!
READ ALL OF THE INSTALLATION
INSTRUCTIONS BEFORE STARTING.
WARNING!
BEFORE BEGINNING ANY INSTALLATION ON
THIS UNIT, DISCONNECT THE SPREADER AND
VEHICLE NEGATIVE BATTERY CABLES.
THE SPREADER UNIT MUST BE SECURELY
FASTENED TO THE VEHICLE. FAILURE TO
PROPERLY RESTRAIN THE UNIT COULD
PERMIT THE UNIT TO BREAK FREE FROM THE
TRUCK AND CREATE THE POTENTIAL FOR A
LIFE THREATING ACCIDENT.
WARNING!
DO NOT SUPPORT THE SPREADER BY
THE BODY JACKS ALONE! UNIT IS NOT
DESIGNED FOR CHASSIS MOUNT APPLI-
CATIONS.!
CAUTION!
00108-760-01-REV-B
Page 7
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
4
OPTIONAL HOLD-DOWN KIT
Part No. 62562 (00002-306-00)
INSTALLATION INSTRUCTIONS
READ ALL THE INST
ALLA
TION INSTRUCTIONS BEFORE ST
ARTING
Before starting, verify that this mounting is acceptable to the vehicle manufacturer.
Attach the hold down at each corner of hopper as shown. Locate and drill four .531
(17/32”) diameter holes for eye-bolts in the truck bed (position may vary from that shown). Straps must be
positioned at opposing angles so that spreader cannot slide forward or rearward. Mount eye-bolts as
shown, with locknuts and flatwashers on the bottom side. Assemble ratchet/strap to eye-bolts. Tighten
hold downs evenly. Do not over tighten damage will result to the spreader or the truck.
ITEM PART NUMBER QTY. DESCRIPTION
1 62602 04068-038-00 4 Ratchet/Strap
2 62807 04048-504-02 4 Bolt, 1/2” Eye
3 20307 04003-804-06 4 Locknut, 1/2-13 Esna ZP
4 62604 04003-801-11 4 Nut, 1/2-13 Hex ZP
5 62605 04004-002-16 8 Flatwasher, 3/4"
CAUTION
1
2
4
5
00108-760-01-REV-B
Page 8
OCTOBER, 2013

INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
4
OPTIONAL HOLD-DOWN KIT
Part No. 62562 (00002-306-00)
INSTALLATION INSTRUCTIONS
READ ALL THE INST
ALLA
TION INSTRUCTIONS BEFORE ST
ARTING
Before starting, verify that this mounting is acceptable to the vehicle manufacturer.
Attach the hold down at each corner of hopper as shown. Locate and drill four .531
(17/32”) diameter holes for eye-bolts in the truck bed (position may vary from that shown). Straps must be
positioned at opposing angles so that spreader cannot slide forward or rearward. Mount eye-bolts as
shown, with locknuts and flatwashers on the bottom side. Assemble ratchet/strap to eye-bolts. Tighten
hold downs evenly. Do not over tighten damage will result to the spreader or the truck.
ITEM PART NUMBER QTY. DESCRIPTION
1 62602 04068-038-00 4 Ratchet/Strap
2 62807 04048-504-02 4 Bolt, 1/2” Eye
3 20307 04003-804-06 4 Locknut, 1/2-13 Esna ZP
4 62604 04003-801-11 4 Nut, 1/2-13 Hex ZP
5 62605 04004-002-16 8 Flatwasher, 3/4"
CAUTION
1
24
5
00108-760-01-REV-B
Page 9
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES

(Sequence of Operations)

F. TO TURN ENGINE OFF (With or without conveyor
running).
1. TURTLE Push throttle slow button to
reduce setting to idle (this prevents
engine flooding and hard starting).
2. STOP Push STOP button and hold
5 seconds.




G. Do not attempt to start the engine
with the conveyor engaged.
H. Close fuel shut off valve on engine if
unit is to be transported while not
running.

1. As with all power equipment, safety is the number
one concern.
2. Do not operate this equipment until you fully
understand how it functions.
3. Before starting engine, be sure that no one is near
the rear of the unit and that no one is inside the
unit!
4. Do not start the engine or engage the conveyor
(which is interconnected to the spinner) until
everyone is clear from moving parts and flying
material from the spinner.
A. ON/Off System power activated (ready to
start). Spreader engine not running.
Spreader conveyor is not engaged.
B. START (Engine Only)
1. Open fuel shut off valve on engine.
CHOKE (Cold engine.) Hold down for
5 seconds to move the throttle
actuator to the choke position.


TART Hold down button until engine
starts.
URTLE Decreases throttle speed - adjust
asengine warms up. Will stop the
choke function.
RABBIT Increases throttle speed.
C. TO ENGAGE SPREADER CONVEYOR
1. CONVEYOR Push CONVEYOR switch only after
you are sure no one is in the hopper
or near the spinner!
D. TO CONTROL CONVEYOR SPEED
1. RABBIT Hold RABBIT to increase speed.
Note DO NOT hold switch in HI position
after the desired RPM is achieved
or you will choke and/or stall the
engine.
2. TURTLE Hold TURTLE to decrease speed.
E. TO DISENGAGE SPREADER CONVEYOR
1. CONVEYOR Push conveyor button.





2. S
3. T
Standard 
00108-760-01-REV-B
Page 10
OCTOBER, 2013

INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
The wireless controller is a compact unit with two parts. One part is the Base Unit (Receiver) and the
other part is the Transmitter (Hand Held Controller). The Transmitter is used to send a corresponding
signal to the Base Unit to act as a remote switching device.

@ 418MHz) interface between the Transmitter and Base Unit. See Figures 1 & 2 for Transmitter button
When programming is completed, only (5) buttons are functional (Buttons #1, #3, #4, #5, & #6) (see Fig.
1).
Fig. 1: Transmitter Front Button Assignments
Fig. 2: Transmitter Back Button Assignments
B
utton #1 (clutch on/off)
Button #3 (Throttle decrease) Button #4 (Throttle increase)
& “Hold to Choke
”
Button #6 (engine off)
Button
#
5 (engine start)
“
ADD” Button
depress with paperclip
“blue” LED
Button #7 (open button) Button #8 (open button)
Button #2 (open button)
For use with Gas Engine packages
Meyer Products Standard
The Meyer Wireless Controller comes factory programmed. That means matching the Base Unit to
the Transmitter has been done by Meyer Products. This gives a matched (1 of 16 million combinations
assignments. On the 8 button Meyer Products Transmitter, all (8) buttons are used when programming.
00108-760-01-REV-B
Page 11
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
Fig. 3: Base Unit layout (Figure shown without Base Unit Cover)
Programming/Reprogramming the Transmitter and the Base Unit:
Tools needed: A small “phillips” screwdriver and a small diameter pin (paper clip).
Instructions to program Transmitter and Base Unit:
1. Remove (4) screws and cover on Base Unit.
2. Power-up the Base Unit. Connect a 12V power source to the spreader 12V battery terminals and
plug the engine wire harness to the Base Unit wire harness (see Male Connector in Fig. 3). DO
NOT DISCONNECT THE BATTERY TERMINALS from the 12V source when engine is running.
3. On the backside of the Transmitter depress the “ADD” button (see Fig. 2) using a small pin or
paper clip – You will see a “blue” LED start to blink (for approximately 15-17 seconds).
4. On the front side of the Transmitter press all (8) buttons (see Fig. 1). There is no certain order to
press the buttons. Firmly press each button, separately. Perform this step before the 15-17 seconds
are up (before “blue” LED stops blinking). The Transmitter is now programmed and has created its
own 1 in 16 million address. Once the “blue” LED stops blinking, this step is completed.
5. On the Base Unit (see Fig. 3) press the black “LEARN” button. The “red” LED will start to blink
(for approximately 15-17 seconds).
6. On the front side of the Transmitter you only need to press Button #1 (clutch on/off), once.
Perform this step before the 15-17 seconds are up (before “red” LED stops blinking). The base unit
has now recognized the Transmitters unique 1 in 16 million address. Once the “red” LED stops
blinking, this step is completed.
7. Verify the (5) functional buttons (Buttons #1, #3, #4, #5, & #6) on the Transmitter are working with
the Spreader Unit by pressing each button, individually (the Base Unit “red” LED will flash when a
Transmitter button is pressed). If Transmitter buttons are not working, repeat steps 3 – 8 or see the
Trouble shooting directions.
8. When Transmitter buttons are functioning properly, re-assemble the Cover on the Base Unit with
“LEARN” Button
(
“
b
lack”
p
ress button
)
Programming “red” LED
Antenna (coiled) Male Connector
STANDARD RECEIVER
the (4) screws. Your Meyer Products Wireless Controller is now ready to use!
00108-760-01-REV-B
Page 12
OCTOBER, 2013

INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES

pole DC motor that can output 180 amps for up to 5 seconds and a continuous amperage
of up to 80 amps. The speed or RPM control is done by providing the user 5 outputs,
RPM feature the runs the motor full speed for 6 seconds and then automatically shuts off
and an E-Stop.
include:
•Automatic shut down if motor is locked up. How this is done is if the receiver
senses a current draw of more than 180 amps for more than 10mS the unit will
shut down from 1 to 30 seconds.
•Automatic shut off if the current draw does not drop below 80 amps after 5
seconds. Once again, the receiver will shut down for 1 to 30 seconds.
Typical Wiring Connection Diagram
12VDC
MOTOR
RECEIVER
PWM OUT
(GREEN
WIRE)
GROUND DIRECT
FROM POWER
SOURCE (BLACK
WIRE
)
12VDC IN
(RED
WIRE
)
DC POWER
SUPPLY
FROM
REGULATED
12VDC
SOURCE
For use with Electric Packages
The Variable speed Wireless DC Motor Controller provides RPM control for a single, 2
approximately 1/5 of the maximum motor RPM. The also incorporates a full
To protect the motor and electronics, the variable speed has built-in safety circuits. These
Variable speed
Meyer Products Variable Speed
00108-760-01-REV-B
Page 13
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
OPERATION:
Shown above is a typical transmitter for wireless operation of a 12VDC motor. The
button functions are as follows:
1. ON/ This button turns on the receiver unit and will allow the receiver to function.
It also will stop the unit, but does not shut down the receiver.
2. #1/ Slow speed setting of approximately 1/5th of full motor speed.
3. #2/ Speed setting or approximately 2/5th of full motor speed.
4. #3/ Speed setting or approximately 3/5th of full motor speed.
5. #4/ Speed setting or approximately 4/5th of full motor speed.
6. #5/ Full Speed.
7. Blast/ A timed 6 to 8 second full speed with auto shut down.
8. OFF/ Shuts down the receiver unit. Must be turned on using Button #1
Programming Transmitter to Receiver:
The following are the step by step procedures for setting the unique address between the
transmitter and receiver or adding extra transmitters to the receiver (up to 40
transmitters).
1. Disconnect green PWM wire from motor.
2. On the backside of the Transmitter, use a paperclip and insert it in the hole next to
the clear blue window. Once the programming button is depressed, a blue LED
will begin to blink for 15 seconds. Flip the Transmitter over and firmly depress all
8 buttons starting with the ON button within 15 seconds. Now the Transmitter has
acquired a 1 in 16 million address.
3. Next step is to remove the receiver box cover noting the drain hole positions in
the cover. Hook up the Power (red wire) and Ground (black wire) to a 12VDC
power source. Inside the box next to the red LED depress the black programming
VARIABLE SPEED TRANSMITTER
Button #8 (open button)
Button #7 (open button)
control speed
Numbered buttons
Button #1 ( on)
00108-760-01-REV-B
Page 14
OCTOBER, 2013

INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
button. The red LED will begin to flash for 15 seconds. Take the Transmitter
while the red LED is flashing and firmly depress the ON button within the 15
seconds. Now the unique address of the Transmitter will only be recognized by
that matched receiver. The red LED will automatically shut off after 15 seconds.
To make sure the programming procedure was successful, depress any of the
Transmitter buttons and the red LED in the receiver should light. Re-install the
cover noting drain hole position and re-connect the PWM (green wire) to the
Specifications:
•Up to180 amp output for up to 5 seconds.
•Continuous output of up to 80 amps.
•5 motor speed outputs of approximately 1/5,2/5,3/5,4/5 and 5/5ths of
motor current draw.
•Built in E-Stop using OFF button.
•Built-in over current safety protection. If a lock-up condition occurs at the
motor causing the motor to draw more than 200 amps the unit will
automatically shut down and must be turned back on using the ON button
after the circuit temperature drops to an acceptable range taking 1 to 30
seconds. Warning: If this situation continues to re-occur the operator
needs to check for reasons why the motors will not turn.
motor. TheVariable speed controller is now ready to operate the DC motor.
00108-760-01-REV-B
Page 15
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
Fig. 3: Base Unit layout (Figure shown without Base Unit Cover)
Programming/Reprogramming the Transmitter and the Base Unit:
Tools needed: A small “phillips” screwdriver and a small diameter pin (paper clip).
Instructions to program Transmitter and Base Unit:
1. Remove (4) screws and cover on Base Unit.
2. Power-up the Base Unit. Connect a 12V power source to the spreader 12V battery terminals and
plug the engine wire harness to the Base Unit wire harness (see Male Connector in Fig. 3). DO
NOT DISCONNECT THE BATTERY TERMINALS from the 12V source when engine is running.
3. On the backside of the Transmitter depress the “ADD” button (see Fig. 2) using a small pin or
paper clip – You will see a “blue” LED start to blink (for approximately 15-17 seconds).
4. On the front side of the Transmitter press all (8) buttons (see Fig. 1). There is no certain order to
press the buttons. Firmly press each button, separately. Perform this step before the 15-17 seconds
are up (before “blue” LED stops blinking). The Transmitter is now programmed and has created its
own 1 in 16 million address. Once the “blue” LED stops blinking, this step is completed.
5. On the Base Unit (see Fig. 3) press the black “LEARN” button. The “red” LED will start to blink
(for approximately 15-17 seconds).
6. On the front side of the Transmitter you only need to press Button #1 (clutch on/off), once.
Perform this step before the 15-17 seconds are up (before “red” LED stops blinking). The base unit
has now recognized the Transmitters unique 1 in 16 million address. Once the “red” LED stops
blinking, this step is completed.
7. Verify the (5) functional buttons (Buttons #1, #3, #4, #5, & #6) on the Transmitter are working with
the Spreader Unit by pressing each button, individually (the Base Unit “red” LED will flash when a
Transmitter button is pressed). If Transmitter buttons are not working, repeat steps 3 – 8 or see the
Trouble shooting directions.
8. When Transmitter buttons are functioning properly, re-assemble the Cover on the Base Unit with
“LEARN” Button
Programming “red” LED
(“black” press button)
VARIABLE SPEED RECEIVER
Antenna (coile d)
the (4) screws. Your Meyer Wireless Controller is now ready to use!
00108-760-01-REV-B
Page 16
OCTOBER, 2013

INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
Transmitter Battery Replacement
The Transmitter uses a standard CR2032 lithium button cell battery. In normal use it will provide 1 to 2
years of operation. To replace the Transmitter battery, gently press and slide the battery cover off.
Remove the battery by sliding (NOT lifting) it out from underneath the retainer (see Fig. 4). Observe the
battery polarity when replacing (“+” showing face up).
N
otes:
1. If the battery looses power or is removed the Transmitter and Base Unit may need to be reprogrammed
(see reprogramming Transmitter and Base Unit instructions). Check Transmitter functional buttons to
verify if reprogramming is necessary.
2. When removing lithium battery, please use caution to slide not lift the battery from the controller! If
excess force is used to remove the battery (example: lifting the battery with a small screw driver) – the
solder connections from the battery clip to the circuit board could be pried loose. This action is not
covered under warranty.
Fig. 4: Back of Transmitter with back cover and battery removed
Other Considerations
1. Powering off the engine will not automatically power off the Clutch (engagement of
conveyor/spinner). If clutch remains engaged, after engine is turned off, it could lead to a slow
2. If an unregulated voltage (example: sparking the battery cable terminal to the 12V battery post.) is
sent to the Base Unit it could erase the Base Unit programming. The remote may show signs of
no longer working with the Base Unit. Reprogramming will be required. When 14Amps are
supplied the Base Unit circuit board is designed to shut off. See additional trouble shooting
comments.
3. Only one transmitter at a time can be activated within a reception area. Only one carrier of a
particular frequency may occupy the same airspace at a given time. This means that if two
transmitters are activated in the same area at the same time the signals will interfere and the decode
r
on the receiver will not see a valid transmission and the wireless controller will not function.
4. Multiple Transmitters can be programmed to (1) Base Unit.
5. To verify the Base Unit is receiving a signal from the Transmitter. Press a button on the Transmitter -
“red” LED on the Base Unit will light-up.
Transmit
Lithium batter
y
Battery Cove
r
electrical drain on the 12V battery. (Gas engine models only)
6. Meyer Products has no control over the intended usage of this product. Because of that ,
Meyer Produtcs offers no written or expressed liability as to how this product is used.
Meyer Products recommends that these units are intended for OFF ROAD USE ONLY!
00108-760-01-REV-B
Page 17
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
TROUBLE SHOOTING
1. To verify the Transmitter and Base Unit are working together: Once the base unit has power the
“red” LED will come on when the Transmitter buttons are depressed (Cover of Base Unit will need
to be removed to see “red” LED). If the “red” LED does not come on, the Base Unit is NOT
getting a signal from the Transmitter.
Possible Solutions:
A. Reprogramming the Transmitter and Base Unit might be required.
B. Base Unit might not be functioning properly (see Base Unit trouble shooting below).
C. Transmitter might not be functioning properly. (see Transmitter trouble shooting below).
2. Base Unit Programming Lose: If an unregulated voltage (spark) is sent to the Base Unit from a
power source the Base Unit could lose its programming. The voltage spike will not damage the
Base Unit or Transmitter. Unregulated voltage could generate from the following:
- Connecting battery cables to a 12V battery source.
- Charging the 12V battery.
Possible Solutions:
A. Reprogramming the Transmitter and Base Unit may be required.
B. Base Unit might be damaged, a new Base Unit & Transmitter will need to be ordered.
3. Base Unit does not function properly: (example: “red” LED will not light up when “LEARN”
button is depressed on Base Unit).
Possible Solutions:
A. Check/verify voltage of 12V is being supplied by the 12V battery. Lower voltages than 12V
will not allow the Base Unit to function properly.
B. Confirm all wires on engine wire harness are secure and properly connected.
C. Base Unit could be damaged, a new Base Unit & Transmitter will need to be ordered.
4. Transmitter does not have power: (example: “blue” LED will not light up when “ADD” button is
depressed on Transmitter).
Possible Solutions:
A. Verify tool diameter (example: paperclip) to depress Transmitter “ADD” button is small
enough to enter the “ADD” button hole.
B. Verify the lithium button cell battery polarity is correct (“+” will be facing up).
C. If the Transmitter is 1-2 years old, check the lithium battery voltage with a meter or replace the
battery as needed (CR2032 lithium button cell battery).
D. Transmitter could be damaged, a new Transmitter will need to be ordered.
5. General troubleshooting:
A. Try to Program/reprogram the Transmitter and Base Unit.
B. Verify the Ground wires (all wires) are secure.
C. Check connections to the components that the unit is trying to operate using a voltmeter.
WARNING
IS RUNNING. This could disable or permanently damage the Base Unit.
1. Disconnecting 12V Battery Cables/Terminals:
A. DO NOT DISCONNECT THE BATTERY (CABLES/TERMINALS) WHEN THE ENGINE/MOTOR
- Pull-starting the engine.(Gas engine models only)
- Jump starting the 12V battery.(Gas engine models only)
www.meyerproducts.com
to download updated Wireless Controller Instructions.
For further technical assistance please contact Meyer Products at 216-533-6512 or visit us at
00108-760-01-REV-B
Page 18
OCTOBER, 2013

INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
13
BOTTOM VIEW
A - A
(SHOWN W / O FITTINGS)
61190










FLANGE PLATE
00105-873-00
8.0"
HOSE SLACK
AFTER PLUMMING
A
A
VALVE STAND
(2) HALVES
00105-874-00
TRUCK CAB
FLOOR BOARD
*
DUAL FLOW VALVE/STAND
INSTALLATION INSTRUCTIONS
1. IMPORTANT: A pipe joint sealant compatible with
hydraulic oil must be applied to all screw fittings.
(Teflon Tape Sealant Is Not Recommended)
2. Hose ends connected to flow valve must be of the
"swivel" type.
3. CAUTION: Over tightening of the fittings in flow valve
may cause damage to valve body.
4. Approximately 8" of hose slack must be realized
between the flow valve and valve stand after the
flow valve has been completely plumbed. If this
condition does not exist after the plumbing has
been completed, removal of valve will require hoses
to be removed at opposite end of valve.
5. Assembly of valve on stand:
a. Cut a 5" x 5" square opening in floor board of
truck where the valve stand is to be located.
b. Bolt valve stand halves together forming a
"box" over the 5" x 5" square opening. NOTE:
When bolting valve stand halves in place,
make sure holes in flanges align with holes in
flange plate.”*”
c. Bolt flange plate to VALVE (Use (2) 1/4" x 3"
bolts, lockwashers, etc.)
d. Insert hoses through floor opening and valve
stand and connect appropriate hoses (see
instructions #1 thru #4) to flow valve.
e. Bolt flange plate to valve stand flanges.
00108-760-01-REV-B
Page 19
OCTOBER, 2013

PV SERIES
INSTALLATION AND INSTRUCTIONAL MANUAL
xxxxx-xxx-xx month/day/year
PV SERIES
12
HYDRAULICS
LEAKING HIGH PRESSURE FLUIDS CAN INJECT THEMSELVES UNDER THE SKIN OF PERSONS
NEAR A LEAK, CREATING GRAVE MEDICAL RISKS. TAKE CARE TO AVOID EXPOSURE TO
HIGH PRESSURE FLUIDS.
1 . Hydraulic components should be kept as clean as possible during assembly operations.
2. Galvanized pipe and pipe fittings must not be used because flaking or galvanizing material can cause
damage to major hydraulic components.
3. A pipe joint sealant, compatible with hydraulic oil, must be applied to all screwed fittings. (Teflon tape is not
recommended.)
4. Hose should be protected where severe wear may be caused by vibration or sliding movement.
5. Long runs of hose should be supported by tie wiring or clamping.
6. Pressure and return hoses, connected to hydraulic motors, may be reversed for proper motor rotation.
Spinner rotates in a clockwise direction when looking down from top.
7. Use hose manufacturer’s recommendations for fitting re-useable hose ends.
8. Hydraulic pumps must be mounted so shaft rotates in direction of arrow.
9. Locate reservoir as close to pump as possible. It may be installed on truck frame or truck box.
10. Hydraulic return line filter is screwed directly onto reservoir with cartridge down. Oil must flow through filter
in direction of arrow on filter.
11. Install the quick connect couplings so that when disconnected, there is a male and female on the truck as
well as on the spreader. This way, hoses will always be hooked up properly. and hose ends can be coupled
together when spreader is in storage to prevent system contamination.
12. See page 13 for valve assembly
13. Operate hydraulic system for several minutes to warm up. Check all connections for leaks.
14. After running, refill reservoir to three fourths full.
CONTROL AND HYDRAULIC SYSTEM SPECIFICATIONS
* Hydraulic Oil ................................. Good Grade of MS10W Hydraulic Oil Which has
wear, oxidation and foam inhibitors.
* Oil Filter ........................................ 10 Micron Element Return Line Filter.
* Relief Valve Setting ...................... 1500 PSI
* Oil Flow ......................................... 0 - 10 GPM
WARNING
00108-760-01-REV-B
Page 20
OCTOBER, 2013
