Meyer HotShot 38185 User manual

HOTSHOT
HOTSHOT HOTSHOT
HOTSHOT
DROP SPREADER
OWNER’S MANUAL
MODEL #38185
3818538185
38185

ASSEMBLY INSTRUCTIONS
2. Slide wheels onto the axle with the hub
cap side of the hup away from the hopper.
Note: the drive wheel has a rectangular
opening matching one end of the axle. Insert
cotter pins in the holes on each end of the
axle and bend to secure. Align the hub caps
and snap them into place.
1. Remove the spreader and
components from carton and place
hopper facing on a padded surface as
shown. Insert lower ends of the handle
brace inside the hopper, align the holes
and attach the leg bracket using (2) 1/4-
20 x 1 1/2” Hex bolts and Wing Nuts.
Secure Leg to Bracket (Leg can be
located in 2 positions to best fit operator)
using (2) 1/4-20 X 1/2” Hex Head Bolts,
and Wing Nuts. Repeat on opposite side.
3. Turn spreader upright and insert the
T-handle/tube assembly into the handle
with the ON/OFF on the T-handle facing
up. Align hole and insert the Carriage
Bolt as shown and secure with a Wing
Nut. Slide control wire through handle
brace removing the safety tag. Push the
thumb release toward the center and
push down on the control knob until it
latches. (See Fig.1) Caution: do not
move thumb release until bottom of
wire is attached.
3. Slide the wire retaining clip onto the
bottom end of the control wire. Insert the “L”
end of wire through the hole in the shutoff
link. Slide wire retaining clip over the shutoff
link and protruding wire until the hole in the
clip seats over the wire as shown.

OPERATION
1. Before filling hopper, make sure spreader is in the
“OFF” position. Always fill spreader on walk or drive,
not on the lawn.
2. Turn the rate control dial to the desired setting. If
setting is not known, try different settings until desired
results are achieved.
3. Always push spreader, do not pull. Start spreader
in motion and as it passes over the area to be treated,
move the thumb release to the “ON” position. Close
spreader at the end of each pass.
4. Operate spreader at 2 1/2 MPH pace (18 feet in 5
seconds).
MAINTENANCE
1. Never store unused material in spreader. Return unused product to its original container.
2. Set rate dial on the highest number, open spreader and spin wheels to remove excess
material.
3. Wash out hopper thoroughly after each use to remove material clinging to surfaces. Pay
close attention to area between the shutoff bar and hopper. Allow spreader to completely dry.
4. Oil the axle bearings and the control knob wire. Store spreader in open position.
5. Apply two header strips at each endof area to be treated
and then proceed lengthwise between the header strips. Be
sure to overlap the wheel tracks slightly to prevent missed
strips.
6. Apply ice melt prior to the storm to reduce unmanageable
levels of ice and snow.
WARRANTY
Meyer Products warrants to Purchaser the following:
Meyer Products, Inc., warrants to the original purchaser for a period of one year from the date of purchase of Meyer® brand spreader products that they will be free from
defects in materials or workmanship, with the excepons stated below. No person is authori ed to change this warranty or to create any addional warranty on Meyer®/
products.
Meyer Products will repair any product that proves to be defecve in materials or workmanship. In the event repair is not possible or praccal (as determined by Meyer
Products in its sole discreon), Meyer Products will either replace the product with a new product of similar model and price, or refund the full purchase price, as deter-
mined by Meyer Products. Customer must keep the complete spreader system serviced/maintained as recommended by Meyer Products.
This warranty does not cover:
• Problems caused by failure to follow the product instrucons, or failure to maintain the product as described in the Operator’s Manual;
• Damage resulng from rust, corrosion
• Damage caused by usage that is not in accordance with product instrucons (use of the spreader for any purpose other than spreading approved material is considered
misuse and abuse);
• Any spreader, or any part, component, or assembly thereof, which has been modified or altered;
• Problems caused by using accessories, parts, or components not supplied by Meyer Products;
• Cost of tax, freight, transportaon or storage charges, environmental charges, solvents, sealants, lubricants or any other normal shop supplies.
• Problems caused by collision, fire, the0, vandalism, riot, explosion, lightning, earthquake, windstorm, hail, water, flood, or any other Acts of God;
• Liability for damage to property, or injury to, or death of any person arising out of the operaon, maintenance or use of the covered product;
• Products with missing or altered serial numbers;
How To Get Service:
• It is the responsibility of the original purchaser to establish the warranty period by verifying the original delivery date. A bill of sale, cancelled check or some other
appropriate payment record may be kept for that purpose. It is recommended, but not required, that the consumer verify the original
delivery date by immediately returning the a8ached Warranty Registraon Card.
How State Law Applies:
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.

Key Description Part No. Key Description Part No.
1
Hopper Assembly PSB16441
11
Control Knob/Wire Ass’y. PSB13640-1
2
*Hopper PSB16442
12
Spring-Control Wire PSB14462
3
Shut Off Bar PSB14703
13
T-Handle Assembly PSB13634-3
4
*Shutoff Link PSB14704
14
Handle Tube PSB16416
5
*Agitator (Inside Hopper) PSB14702
15
Lower Handle PSB14613
6
*Axle PSB14706
16
Hopper Cover PSB16443
7
Drive Wheel PSB16080
17
Free Wheel PSB16081
8
Hub Cap (2) PSB16082
18
*Axle Bushings (2) PSB12696
9
Leg Extension Bracket (2) PSB16383
19
Fastener Package PSB16444
10
Legs (2) PSB12714
1
3
2
4
5
6
7
8
9
10
11
12
13
14
15
16
PARTS
PARTSPARTS
PARTS L
LL
LIST
ISTIST
IST FOR
FORFOR
FOR MODEL #38185
MODEL #38185MODEL #38185
MODEL #38185
PART OF OUR SERVICE IS
PROVIDING REPLACEMENT
PARTS. Parts may be obtained
through your local distributor
Be sure to give:
1. SPREADER MODEL NUMBER
2. SPREADER NAME
3. PART NUMBER
4. NAME OF PART AS SHOWN
IF YOUR LOCAL
DISTRIBUTOR CANNOT
SUPPLY PARTS, CONTACT:
Meyer Products, Inc.
18513 Euclid Ave
Cleveland, Ohio 44112
216-486-1313
www.meyerproducts.com
10
17
18
19
*Parts Included in Hopper Assembly
**Parts Included in Handle Assembly
