Mi-Light FUT069 Installation instructions

User Instruction
Model No.: FUT069
RGB+CCT Smart LED Downlight
IP Rate: IP54

RGB+CCT
16 Millions of colors to choose
Color temperature
2700-6500K
Dimmable
Saturation control
2.4G RF wireless transmission
technology
Remote control
Control distance 30m
Smart phone App control
Mi-Light WiFi ibox is needed
Waterproof and dustproof
grade IP54
Made in China
IP54

Model No.: FUT069
Power: 15W
Input Voltage: AC86~265V / 50~60Hz
Color temperature: 2700K-6500K
Luminous Flux: 1200LM
Light Efficiency: 80LM/W
CRI:>80
PF: >0.5
Lifespan: 50000 hours
Beam Angle: 120°
IP Rate: IP54
HoIe Size: ø175~180mm
MateriaI: AIuminum
190mm
50mm

ø175~180mm
Driver(Contrller inside)
Ceiling
AC86-265V
1. Please open the hole on the ceiling according to
the correct size of Diagram 1.
2. Connect the driver properly according to the wire
connection Diagram 2. And then put the driver and
wire into the ceiling from the hole.
3. Push in the two spring elements, make sure that
they are deployed and anchored on the back of
the ceiling Diagram 3 and 4.
1 2
3 4

Link: Switch off the power, then switch on again
after 5 seconds, press " " 3 times within 3 seconds;
the light will blink 3 times slowly when it is done.
Unlink: Switch off the power, then switch on again
after 5 seconds, press corresonding " " or master
ON button 5 times within 3 seconds;the light will
blink 10 times quickly when it is done.
Master ON
Color Ring
Speed+
Speed-
Saturation
Control
Master OFF
Indicator
Color
temperatureLine
Brightness
Dimming
Mode
Zone ON
(Link/Unlink)
Zone OFF
FUT092
Compatible with FUT089 / FUT092 remote controls
(Purchased separately)

Color Ring
Speed+
Mode
Speed-
White light
Saturation
Indicator light
Master OFF
Master ON
/ CCT Control
Brightness
Dimming
“ ” Zone ON
(Link/Unlink) “ ” Zone OFF
FUT089
Amateur do not dismantle and install the light
Users must be correct, strict and solid to install the
light; do not use the light on strenuous vibration area.
The lighting will be heating on working, pls do not
cover the lighting housing.
The waterproof and dustproof rate is IP54,just
working on water drop and spray protection, pls do
not put the light into water long time.
Power supply is not waterproof, pls put it at dry area.
