Finelite E3 LED Engine Guide

• All power connections should be installed according to
local/national codes by a Certified Electrician.
• Turn off power to luminaire while switching out LED engine.
NOTES
Overview
Step 1
Opening Luminaire
Page 2
Step 2
Replacing LED Engine
Page 3
1of 3
E3 LED Engine Replacement Instructions
Patent Pending
Finelite, Inc. • 30500 Whipple Road • Union City, CA 94587-1530 • [phone] • Fax: [phone] • www.finelite.com
This is a hypothetical build to show the capabilities of this luminaire family and mount type. Your build may vary.
© 2022 FINELITE, INC. ALL RIGHTS RESERVED. Form 98604. V1 EFFECTIVE DATE: 04/22

Step 1 - Opening Luminaire
• Use a putty knife to lift open the lower edge of the diffusers. Slowly work down the length of the
diffuser until it is fully removed.
• Set diffuser aside in a safe place to avoid damage.
• Unplug feed wire connectors, jumper wires, and shunt wire. Set aside in a safe place.
• Remove all #6-23 x 3/16" screws holding the LED engine in place with a #2 Philips screwdriver
A. Remove Diuser B. Disconnect LED Engine
Remove Shunt
Remove Screws
Shunt Wire
(provided)
Diuser
(provided)
2of 3
© 2022 FINELITE, INC. ALL RIGHTS RESERVED. Form 98604. V1 EFFECTIVE DATE: 04/22
E3 LED Engine Replacement Instructions

Step 2 - Replacing LED Engine
• Remove LED engine and replace with new engine.
• Reinstall all #6-23 x 3/16" screws to secure the LED engine in place.
• Re-connect feed wire connectors, jumper wires, and shunt wire.
• Re-install diffuser by slipping the upper portion of the diffuser into the pocket above the LED engine.
• Start at one end and press the snap edge into place until it snaps over the edge of the housing, continue
snapping down the length until fully installed.
A. Replace LED Engine B. Re-Connect Engine C. Replace Diuser
Shunt Wire
(provided)
Diuser
(provided)
6-32 screw
(provided)
3of 3
© 2022 FINELITE, INC. ALL RIGHTS RESERVED. Form 98604. V1 EFFECTIVE DATE: 04/22
E3 LED Engine Replacement Instructions
