LDR Arpa F150 W User manual

01151000
01151100
01152000
01152100
ArpaF150WRDM,LED
ArpaF150CRDM,LED
ArpaPC150WRDM,LED
ArpaPC150CRDM,LED
DMX512+RDM
istruzioniperl'uso
operatinginstructions
Bedienungsanleitung
instruccionesdemanejo
moded'emploi
gebruiksaanwijzing
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredomnItaly.tel+390376771777‐fax+390376772140‐email[email protected]

ArpaF&PC150,3200Kand5600K,DMX512+RDMLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
1
ENGLISH–TABLEOFCONTENTS
INTRODUCTION
1.Importantsafetyinformation…………………………………………………………………………..2
2.Boxcontents……………………………………………………………………………………………………4
3.Weightanddimensions…………………………………………………………………………………..4
4.Importantnoticebeforetheinstallation/installation………………………………………4
5.Mechanicaloperation……………………………………………………………………………………..5
6.Wiring……………………..……………………………………………………………………………………..5
7.Voltage…………………………………………………………………………………………………………..6
8.Frequency……………………………………………………………………………………………………..6
9.Localcontrolpanelandoperation…………………………………………………………………..6
10.Connecttothepowersupply………………………………………………………………………..6
11.Menu………………………………………….………………………………………………………………….6
11.1DMXormanual……………………………………………………………………………………………6
11.2DMXaddress……………………………………………………………………………………………….7
11.3Dimmerresolution………………………………………………………………………………………7
11.4LostDMXsignal………………………………………………………………………………………….7
11.5Strobe…………………………………………………………………………………………………………7
11.6Strobespeed………………………………………………………………………………………………8
11.7Dimmingcurve…………………………………………………………………………………………….8
11.8Cutoffdimmingresponse……………………………………………………………………………8
11.9Dimmingbehaviour…………………………………………………………………………………….8
11.10LEDfrequencyadjustment…………………………………………………………………………9
11.11LCDretroillumination……………………………………………………………………………….9
11.12TemperatureControl…………………………………………………………………………………9
11.13Softwareversion……..…………………………………………………………………………………9
11.14ProordBasiccontrol………………………………………………………………………………….9
11.15Factorysetting……………………………………………………………………………………………10
11.16IDforRemoto….............................................................................................10
11.17Calibration….…..............................................................................................10
11.18Exithiddenmenu…........................................................................................10
MAINTENANCE
10.Cleaningandmaintenance…………………………………………………………………………….10
11.Spareparts……………………………………………………………………………………………………10
12.Warranty……………………………………………………………………………………………………....11
SUMMARYOFCONTROLANDOPERATION
13.SummaryoftheARPAfunction……………………………………………………………………..12
14.DMXCharts…………………………………………………………………………………………………..13
14.1DMXChart1……………………….……………………………………………………………………..13
14.2DMXChart2……………………………………………………………………………………………….13
14.3DMXChart3……………………………………………………………………………………………….14
14.4DMXChart4………………………………………………………………………………………………15

LDRConformityCertificate–CertificatodiConformità–Konformitätserklärungpage16
Complaintform–Modulodireclamo–Reklamationsformular………………………….Page17
WEEEDirective–DirettivaRAEE–WEEERichtlinie……………………………………………Page18



ArpaF&PC150,3200Kand5600K,DMX512+RDMLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
2

ENGLISH
ThankyouforchoosingaqualityproductfromLucidellaRibaltasrl.Wetrustourproductsand
servicesmeetyourrequirements,butshouldthisnotbethecasepleasecontactusdirectlyusing
theattachedfeedbackformtohelpusimprovethequalityofourservice.
Thisspotlighthasbeenmanufacturedwithgreatcareandleftourfactoryinperfectconditions,
butifithasbeendamagedintransportpleasecontactyourdealerinthefirstinstance.Afeedback
formisappended.Ourwarrantycoversallmanufacturingandcomponentdefectsfor2yearsfrom
thedateyoureceivedtheproduct.
Ourproductsaredesignedfortheuseofprofessionaltechnicians,andtheinstructionsprovided
hereensureasafeandcorrectoperationofthisproduct.LucidellaRibaltasrlwillnotacceptany
responsibilitywheredamagehasbeencausedtotheproductorpersonsthroughimproperuseof
theproductand/ornon‐compliancewiththeregulationsdescribedherein.

IMPORTANT:Readtheseuserinstructionsbeforeusingthislightingunit

Theinstructionsgivenhereensureasafeandcorrectusageofthisproduct.Auser’sfailureto
complywiththeinstallation,operating,maintenanceandsafetyproceduresmentionedinthis
manual,aswellasthosegenerallyapplicabletothislightingequipment,maycausetheluminaire
nottoperformasexpected.
LucidellaRibaltaacceptsnoliabilityfordirect,indirect,incidental,specialorconsequential
damagesresultingfromthecustomer’sfailuretofollowtheinstallation,operating,maintenance
andsafetyproceduresinthismanualorthosegenerallyapplicabletolightingequipments.
Thelimitationextendstodamagesforpersonalinjury,propertydamage,lossofoperations,lossof
profits,lossofproductorlossoftime,whetherincurredinbythecustomer,thecustomer’s
employeesorathirdparty.
Apartfromtheinstructionsgivenonthismanual,allrelevantsafetyandhealthstandardsofthe
appropriateEUDirectivesorthelocalsafetyandhealthstandardsofthecountrywheretheunitis
installed,mustbecompliedwith.

1. IMPORTANTSAFETYNORMS

ThisproductisratedIP20andisthereforedesignedforinterioruseonly.Fordetailson
maximumambienttemperatureandtiltanglepleaserefertowhatindicatedonthe
productlabelorscreen‐printingonthesideofthelens‐tubeortherearoftheLED‐house
Warning,highvoltageignition.Disconnecttheunitfrompowerbeforeservicing
Continuousmainspowerisrequiredforthisspotlightasaninternaldimmercontrolsthe
intensityviaDMXorlocalrotaryknob.Useofaphasecontroldimmedmainssupplymay
damagetheinternalelectronics.
Useofaphasecontroldimmedmainssupplymaydamagetheinternalelectronics
Thisproductfeaturesfan‐assistedventilation.Makesureyoudonotcoverthefansor
obstructtheairflowatanyonetime.
Makesurethefansareworkingcorrectly.Shouldyoudetecteventheslightest
malfunction,switchtheluminaireoffandcarryoutthenecessaryservicing.Replacethefan
ifnecessary.
Repairingandreplacementofanycomponentofthisproductmustbecarriedout
exclusivelybyprofessionalpersonnelinconformitywiththerelevantsafetyandhealth
standardsandonlywithoriginalLucidellaRibaltasrlcomponents.

ArpaF&PC150,3200Kand5600K,DMX512+RDMLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
3
Replacementofanypartofthewiringsystemmustbecarriedoutexclusivelyby
professionalpersonnelincompliancewiththeoriginalwiringdiagramandwith
componentsidenticaltoorcompatiblewiththoseoriginallyfitted.
Installationofthisproductmustbeexclusivelycarriedoutbyprofessionalpersonnelin
compliancewiththesafetynormsinforceinthecountrywheretheproductisused.

Thisproductmustbefittedwithasecondaryfixingsystemsuchasasafetychainorbond.
Shouldthisnotbesuppliedasastandardaccessory,pleasemakesureyoubuyitseparately
andinstallitbeforeusingtheproduct.



WARNING:DANGEROFELECTRICALSHOCK
DONOTOPERATEONLIVEEQUIPMENT
Disconnectpowerbeforeopeningthisfixturetoaccessitslightsourceorelectronics.
ThereplacementoftheLEDsourceoranyofitselectroniccomponentscanbecarriedout
exclusivelybyprofessionalpersonneluponLDR’swrittenauthorizationandonlywith
originalLucidellaRibaltasrlcomponents.Failuretoobtainthemanufacturer’s
authorizationtocarryoutthereplacement/repair,willimmediatelyinvalidatethe
product’swarranty




WARNING:EYEDAMAGEHAZARD
Makesurethisfixtureisinstalledsoastoavoidprolongeddirectstaringatitsoperatinglight
source(LED)fromadistanceoflessthan7m/23ft.




WARNING:FIREHAZARD
Neverlocatethisfixtureonanyflammablesurface.
Minimumdistanceofanypartofthebodyoftheluminairefromanyflammablesurfaceor
object:0,5m
Minimumdistancefromlitsurface,pleaserefertoproductlabel
Makesurethemainspowersupplythefixturewillbeconnectedtoisprotectedbya
suitablethermalmagneticcircuitbreaker

ArpaF&PC150,3200Kand5600K,DMX512+RDMLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
4
2.BOXCONTENTS
Uponopeningthepackaging,pleasemakesureitcontainsthefollowing:
lightingunitinthechosenmodel
metalcolourframe185x185mm,fitted
160cmmainspowercablewithfittedNeutrikPower‐Conblueconnector

Shouldoneormoreitemsmiss,wekindlyaskyoutocontactyourdealerimmediately.


3.WEIGHTANDDIMENSIONS


 

ArpaF150LEDArpapc250LED
netweight:9,7kgnetweight:10,1kg
grossweight:11,9kggrossweight:12,3kg
packingdimensions:60x40x45hcm  packingdimensions:60x40x45hcm



4. IMPORTANTNOTICEBEFORETHEINSTALLATION/INSTALLATION
Beforeinstallingthisfixturecheckitsweightontheproductlabelandtheweightofeachaccessory
youareaddingandmakesurethestructureyouareinstallingittowithstandsthetotalweight.
Themountingstirruprotatesaroundthebodyoftheluminaireandisdesignedtoallowthe
spotlighttobesuspendedfromaboveusingaC‐clamporsimilar,orsupportedonastandor
bracketfrombelow.

CAUTION
DONOTTURNTHELUMINAIREUPSIDE‐DOWNBUTALWAYSTURNTHESTIRRUP
IFYOUNEEDTOMOUNTITONASTANDORBRACKET

Note:thespotlight’slocationmustprovidesuitableventilationfortheLEDmodule.

Ifnotsuppliedchooseasuitableclampandmakesureitiscorrectlyfixedandstrongly
tightenedtothestirrupaccordingtotheclamp’smanufacturer’sinstructions
Ifnotsuppliedchooseasuitablesafetycableorbond.Clampittotheeyeletprovidedon
theupperrearpartoftheluminaire(seepictureherebelow),runittwicearoundthe
stirrupandthestructuretheluminaireishungtosoastobondthemtogetherandclose
theloop.



ArpaF&PC150,3200Kand5600K,DMX512+RDMLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
5



Whentiltingtheunitmakesuretheknobblockingthestirrupisstronglytightenedandthat
theluminairecanholdthedesiredtiltangle


5.MECHANICALOPERATION
Focuscontrol:islocatedontherearendoftheproduct.Turntheknobclockwisetonarrowthe
beam(SPOT).Turntheknobanticlockwisetowidenthebeam(FLOOD).
Thebeamdistribution(peak/flat)isfixed.
Beam‐shaping:a4leafbarndoor(A20100306)canbefittedonthefrontoftheAlbatocontrol
andshapethebeam
Tilt:thestirrupisfittedwithapositivefrictionclampcontrolledbyalargeknob.Turntheknob
anticlockwisetoreleaseit,positiontheluminaireatthedesiredtiltangleandturntheknob
clockwisetoholdthedesiredposition.Makesuretheknobisstronglytightenedatanytimeduring
operation


6.WIRING

Beforebeingconnectedtothemainpower,thisunitmayneedtobewiredwithasuitableplugif
notalreadyinstalled.Makesuretheplugyouareusingisratedfortheproperpowerloadandit
conformstotherelevantEU/ULelectricalstandards.

Makesuretheplugyouarefittingwithstandsthelamppowerload.
Thisfixturemustbegrounded
Toperformacorrectwiring,pleasenotethatthecoresinthismainsleadarecolour‐codedas
follows:
Ground:green+yellow–Neutral:blue‐Hot:brown

Incasethecoloursofthewiresdonotcorrespondtothecolouroftheconnectionpointson
yourplug,pleaseproceedasfollows:
Thegreenorgreenandyellowwiremustbeconnectedtotheconnectionpointmarked
withtheletterEorwiththesymbolorcolouredingreenoringreen‐yellow
ThebluewiremustbeconnectedtotheconnectionpointmarkedwiththeletterNorwith
thesymbolorcolouredinblack
ThebrownwiremustbeconnectedtotheconnectionpointmarkedwiththeletterLor
withthesymbol orcolouredinred


ArpaF&PC150,3200Kand5600K,DMX512+RDMLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
6
Beforeyoufinallypositionthisproductforuse,temporarilyconnectittoaproperlyfused
powersupplytocheckthelampworkscorrectly.


7.VOLTAGE

Beforeoperatingthisunitpleaserefertotheproductlabelmountedatthebackoftheluminaire
tocheckyouareoperatingwiththecorrectvoltage.
Thisunitcanbeoperatedbetween90Vand260VandtheelectronicPSUinsidethefixturewill
automaticallyswitchtotheavailablevoltage

8. FREQUENCY

FrequencyonthisproductisautomaticallyselectedbytheelectronicPSU(50/60Hz)

9. CONNECTTOTHEPOWERSUPPLY
Connecttheunittoacontinuousmainspowersource
Makesurethepowersupplyisprotectedbyasuitablethermalmagneticcircuitbreaker
Thisfixturemustbegrounded

10. LOCALCONTROLPANELANDOPERATION

OPERATION:LCDdisplayforDMXaddress,systemsetupandstatusdetails.
POWER:powerLEDstatusindicator,redcolor.ON=power
DMX:DMXLEDstatusindicator,greencolor.LEDOFF=DMXOFFandmanualcontrolactivated,
LEDON=DMXMODEactivatedwithnoDMXsignal,FLASHINGLED=receivingDMX
MENU:rotaryswitchselectortoselectandmodifytheoperationalmodes.Turnleftorrightto
navigatethroughthemenuandpresstoselectortoconfirm
DMXIN:inputDMXsignal(pin1=0,pin2=DATA‐,pin3=DATA+).
DMXOUT:LoopthroughDMXsignaloutput
POWERIN:Mainspowerinput
POWEROUT:Mainspoweroutput

11. MENU

TherearefourteendifferentmenustocontrolthesettingsoftheARPALED.Therotaryselectoris
usedtoadjustthesettingsandtonavigatethroughthemenu.Turnleftorrighttoselectthe
menuandpushtoaccessortoconfirmtheselecteddataorfunctions.Toexittheselectedmenus
withoutsavingthedata,presstherotaryselectorforatleast1second.


11.1DMXORMANUAL(Mode)
SelecttheLEDcontrolmodebetweenDMX(factorysetting)andmanual.Tochangethecontrol
modepressoncetherotaryselectoruntilanarrow()appearsonthemenu.Turntheselectorto
therightorthelefttoselectthedesiredmodeofoperationandpresstoconfirmyourselection.




ArpaF&PC150,3200Kand5600K,DMX512+RDMLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
7




TaptherotaryselectorandtheLCDscreenwilldisplaythemodestatusandthecurrentvalue:








11.2 DMXADDRESS(Addr)
ItallowstoselecttheinitialDMXstartingaddresstoremotelycontroltheLEDfunctions.To
changetheinitialDMXaddresspresstherotaryswitchuntilanarrowappears,thenturntochange
tothedesiredDMXstartingaddress.Presstoconfirmyourselection.Factorysettingis001.





11.3 DIMMERRESOLUTION(8/16b)
Thedimmingresolutioncanbecontrolledat8bitsfromoneDMXchannelor16bitswith2DMX
channels.Factorysettingis8Bit.





11.4 LOSTDMXSIGNAL(DMXMem)
IncaseofsignalfailurethisfunctionallowstostoreinmemorythelastDMXvalue.Factorysetting
isON.Threeoptionsareavailable:










11.5STROBE(Strobe)
Thisfunctionenablestoactivatethestrobefunction.FactorysettingisDISABLE.




M: Manual
XX % XXX
M: DMX
XX %
1 Mode
DMX
1 Mode
MANUAL
TAPTHEROTARY
SELECTORTODISPLAY
THEVALUE
TAPTHEROTARY
SELECTORTODISPLAY
THEVALUE
00%=LEDOFF
100%=LEDFULL
00%(000)=LEDOFF
100%(FFF)=LEDFULL
2 Addr
001
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
1 Mode
DMX
1 Mode
DMX 
1 Mode
MANUAL 
TURNTOSELECT
MANUALORDMX
ANDPRESSTO
CONFIRM
2 Addr
001 
2 Addr
### 
TURNTOASSIGNTHE
DMXADDRESSAND
PRESSTOCONFIRM
3 8/16b
8 BITS
PRESSTHEROTARY
SELECTORTO
ACTIVATE
3 8/16b
8 BITS 
3 8/16b
16 BITS 
TURNTOSELECT8OR
16BITSANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
4 DMXMem
ON
5Strobe
DISABLE
5Strobe
DISABLE 
5Strobe
ENABLE 
TURNTOENABLEOR
DISABLESTROBEAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
LASTSCENEHOLD
4 DMXMem
ON 
4 DMXMem
OFF=80% 
DIMTHELEDTO80%OF
ITSMAXIMUMPOWER
4 DMXMem
OFF=00% 
DIMTHELEDTO0%

ArpaF&PC150,3200Kand5600K,DMX512+RDMLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
8

11.6 STROBESPEED(SetStr)
Itallowstosetthestrobespeed.Thismenuisnotactivewhenthestrobefunctionisdisabledor
whenitisremotelycontrolledthroughDMX.FactorysettingisOPEN.










11.7 DIMMINGCURVE(Curves)
ThisfunctionallowstoselectaresponsecurvefortheARPALED.Achoiceoftwocurvesis
available:SquareandLinear.FactoringsettingisSQUARE.







11.8 CUTOFFDIMMINGRESPONSE(CutOff)
ThisfunctionallowstoselecttheLEDbehavioursimulatingatungstenorhalogenlampduringthe
dimmingcutoff.
FactorysettingisSLOW.








11.9DIMMINGBEHAVIOUR(Smooth)
ThisfunctionallowstosettheLEDdimmingresponse.FactorysettingisNORMAL.











PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
6 SetStr
OPEN
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
7 Curves
SQUARE
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
8 CutOff
SLOW
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
9 Smooth
NORMAL
9 Smooth
FAST 
IMMEDIATEDIMMING
RESPONSE
WITHSTROBEENABLE
THELIGHTISSETTOON
6 SetStr
OPEN 
6 SetStr
SPEED # 
CHOOSETHESTROBE
SPEEDVALUEFROM
1(SLOW)TO10(FAST)
6 SetStr
CLOSED 
WITHSTROBEENABLE
THELIGHTISSETTO
OFF
SQUARETOINCREASE
VOLTAGERESPONSEAT
LOWERVALUE
7 Curves
SQUARE 
7 Curves
LINEAR 
LINEARDIMMING
CONTROL
SOFTLEDDIMMINGAT
SHUTDOWN
8 CutOff
SLOW 
8 CutOff
FAST 
DIRECTDIMMING
RESPONSEATSHUT
DOWN
FASTDIMMING
RESPONSE=150ms
9 Smooth
NORMAL 
9 Smooth
SLOW 
SLOWDIMMING
RESPONSE=300ms

ArpaF&PC150,3200Kand5600K,DMX512+RDMLEDUser’sManual–2.0
LucidellaRibaltasrl,ViaBerna14,46042CastelGoffredo(MN)Italy
Tel.+390376771777–fax+390376772140–email[email protected]–webwww.ldr.it
9
11.10FANSETTING(Fan)
Thisfunctionallowstosetthefanresponse.Achoiceofthreemodesisavailable:Automatic,Silent
orSteady.WhenfanisinAutomode,thespeedisregulatedbyLEDtemperature.InSilentthefan
runslowlytoreducethenoise.InSteadythefanrunwithconstantspeed,halfwaybetweenthe
minimumandmaximumspeed.Inallcases,ifLEDtemperatureexceedsthemaximumadmitted
value,theLEDisprotectedbyade‐ratingsecuritysystem.FactorysettingisAUTO.












11.11LCDSCREENILLUMINATION(BackL)
ThisfunctionallowstoturnofftheLCDbacklight,theLEDPOWERandLEDDMXafter1’30”from
lastsetting.FactorysettingisAutoOFF.







11.12TEMPERATURECONTROL(Tled)
ThisfunctionallowstovisualizetheLEDtemperature.Factorysettingis°C.




11.13SOFTWAREVERSION(SwVer)
Thisfunctionallowstovisualizethesoftwareversion.

11.14PROorBASICCONTROL(ProBasic)
ThePRO‐BASICcontrolisaspecialfunctionwhichallowstolimittheaccesstothecontrolmenu.
SelectProBasicwiththerotaryswitchandpresstoaccessthemenu.Select:
PRO,toenableaccesstoallthefunctions
BASIC,tolimitaccesstofunctions11.1DMXorMANUALMODE,11.2DMXADDRESS,11.12
TemperatureControland11.13Softwareversion.
FactorysettingisPRO.





11 BackL
AutoOFF
11 BackL
AutoOFF 
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
LCDBACKLIGHTOFF
AFTER1MINUTEAND
30SECONDS
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
10 Fan
AUTO
10 Fan
STEADY 
CONSTANTFANSPEED
FANSPEEDIS
REGULATEDBYLED
TEMPERATURE
10 Fan
AUTO 
10 Fan
SILENT 
SLOWFANSPEEDTO
REDUCETHENOISE
11 BackL
ON 
LCDBACKLIGHT
ALWAYSON
12 Tled
##°C
12 Tled
##°C 
12 Tled
###°F 
TURNTOSELECT°C
OR°FANDPRESSTO
CONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
Choose
ProBasic
MenuType
PRO 
MenuType
BASIC 
TURNTOSELECTPRO
ORBASICMENUAND
PRESSTOCONFIRM
PRESSTOACTIVATE
THEMENU,AN
ARROWSHOULD
APPEAR
