Mi MJSXJ09CM User manual
Product Overview
Package Contents: Mi 360° Home Security Camera 2K, charging cable,
wall mounting kit, user manual
Front ViewRearView
Loudspeaker
Reset
Micro-USB
Power Port
Read this manual carefully before use, and retain it for future
reference.
MicroSD Card
Slot (Visible
when lens is
facing upward)
Indicator
Lens
Microphone
RESET
You can place the Mi 360° Home Security Camera 2K on horizontal surfaces,
such as desks, dining tables, and coffee tables. You can also mount it on a wall.
2. Insert a plastic wall plug into each drilled hole.
Installation
1. First use a pencil to mark the positions for the base mounting holes on the
wall, then drill two holes at the marked positions. The diameter of each hole is
approximately 6 mm, and the depth is approximately 30 mm.
Mounting the camera on a wall:
4. Align the grooves on the bottom of the camera
with the raised part on the base, and then turn it
clockwise until it locks into place.
3. Place the side of the base with arrows facing
forward, and then align the holes. Insert the
screws and then tighten them into the wall plugs
with a Phillips head screwdriver.
Notes:
The wall must be able to support at least three times the total weight of
the camera.
Warning
To prevent possible injury, the camera must be securely fixed to the ceiling
or wall according to the installation instructions.
How to Use
Make sure the camera is turned off. Push the lens upward to reveal the
MicroSD card slot. Insert the microSD card into the card slot with its
contact points facing downward.
Note: Disconnect the camera from the power before installing or removing
a MicroSD card. Please use a genuine MicroSD card (up to 32 GB)
manufactured by a qualified supplier. It is recommended to use a card with
a reading/writing speed of no less than U1/Class 10.
Installing a MicroSD card
MicroSD
Plug the charging cable into Micro-USB port on the back, the camera
automatically turns on, and the indicator quickly blinks orange.
Note: When the camera is working, do not turn the lens of the camera nor
force it to rotate. If the positioning of the lens is inaccurate, please calibrate
it in the Mi Home/Xiaomi Home app.
Turning on the camera
RESET
Indicator
Blue: Connected successfully/Working properly
Blinking blue: Network error
Quickly blinking orange: To be connected
Slowly blinking orange: Updating
If the network connection or the Mi account that the camera is paired with
has been changed, you need to restore the factory settings. Press and hold
the reset button for about three seconds. Once the indicator starts quickly
blinking orange, the factory settings have been restored successfully. Then
you can reconnect the camera with the app.
Note: Restoring factory settings will not delete the content on the MicroSD
card.
Restoring factory settings
Connectwith Mi Home/Xiaomi Home App
This product works with Mi Home/Xiaomi Home app*. Control your device with
Mi Home/Xiaomi Home app.
Scan the QR code to download and install the app.
You will be directed to the connection setup page if the
app is installed already. Or search "Mi Home/Xiaomi
Home" in the app store to download and install it.
Open Mi Home/Xiaomi Home app, tap "+" on the
upper right, and then follow prompts to add your device.
* The app is referred to as Xiaomi Home app in Europe
(except for Russia). The name of the app displayed on
your device should be taken as the default.
Note: The version of the app might have been updated, please follow the
instructions based on the current app version.
Make sure the camera turns on and the network connection is stable during
connecting. The indicator is quickly blinking orange when waiting for a
connection, and turns into blue once the camera is successfully connected.
In the app, you can view the real-time surveillance, adjust the sharpness of the
image, adjust the horizontal and vertical angles, capture and record, and make
calls.
Real-time Surveillance
Playback
As the ambient light dims, the camera can automatically switch to night vision
mode. With the built-in infrared lights, it can clearly capture video in the dark.
Infrared Night Vision
The playback feature of the camera is only available when a compatible
MicroSD card is installed.
Once a MicroSD card is installed and the camera is plugged in, it will
automatically start recording video. Tap the playback button in the
app, then drag the timeline to select the time period you want to
playback. The maximum supported playback speed is 16x.
Home Surveillance Assistant
When the home surveillance assistant is enabled, the camera will record
videos if it detects human movement and changes in real-time within its
surveilled area. Then you will get the app push notification.
You can enable or disable the home surveillance assistant in the
Mi Home/Xiaomi Home app.
You can set 24-hour, daytime, nighttime, custom period surveillance, alert
sensitivity and alert time intervals, etc.
In the app, you can select the device sharing option in the settings
menu to share the camera with others. Users you share the camera
with need to download the app and sign in with their Mi account.
Video Sharing
Note: Illustrations of product, accessories, and user interface in the user
manual are for reference purposes only. Actual product and functions may
vary due to product enhancements.
Precautions
The operating temperature range for this camera is between -10°C and 40°C.
Do not use the camera in environments with temperatures above or below
the specified range.
The camera is a precision electronic product. In order to ensure its normal
operation, do not install the camera in environments with high humidity
levels nor allow water to get into it.
To improve the camera's performance, do not place its lens facing or next to
a reflective surface, such as glass windows or white walls, as this will cause
the image to appear overly bright in areas close to the camera and darker in
areas further away, or cause the camera to produce white images.
Make sure the camera is installed in an area with a strong Wi-Fi signal. Do
not place the camera near the objects that may affect its Wi-Fi signal, such
as metal objects, microwave ovens.
Under normal use of condition, this equipment should be kept a separation
distance of at least 20 cm between the antenna and the body of the user.
WEEE Information
EU Declaration ofConformity
All products bearing this symbol are waste electrical and electronic
equipment (WEEE as in directive 2012/19/EU) which should not be
mixed with unsorted household waste. Instead, you should protect
human health and the environment by handing over your waste
equipment to a designated collection point for the recycling of waste
electrical and electronic equipment, appointed by the government or local
authorities. Correct disposal and recycling will help prevent potential negative
consequences to the environment and human health. Please contact the
installer or local authorities for more information about the location as well as
terms and conditions of such collection points.
Hereby, Shanghai Imilab Technology Co., Ltd. declares that the radio
equipment type Mi 360° Home Security Camera 2K is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is
available at the following internet address:
http://www.mi.com/global/service/support/declaration.html
Specifications
Name: Mi 360° Home Security Camera 2K
Model: MJSXJ09CM
Item Dimensions: 115 × 78 × 78 mm
Viewing Angle: 110°
Aperture: F1.4
Operating Temperature: -10°C to 40°C
Compatible with: Android 4.4 & iOS 9.0 or above
Storage: MicroSD card (up to 32 GB)
Wireless Connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4 GHz
Wi-Fi Operation Frequency: 2412–2472 MHz
Wi-Fi Maximum Output Power: <20 dBm
For further information, please go to www.mi.com
Manufactured by: Shanghai Imilab Technology Co., Ltd.
(a Mi Ecosystem company)
Address: Room 001A, Floor 11, Block 1, No. 588 Zixing Road, Minhang District,
Importer:
Beryko s.r.o.
Na Roudné 1162/76, 301 00 Plzeň
www.beryko.cz
Shanghai, China
Net Weight: 269 g
Input: 5 V 2 A
Resolution: 2304 × 1296
Video Codec: H.265
