TV-IP522P ProView Megapixel Internet Camera

AboutThis User’s Guide
This user’s guide provides instructions on how to install the TV-IP522P ProView Megapixel
Internet Camera and
use it for camera monitoring applications. Camera monitor applications
are accessible through an Ethernet local area network.
BeforeYou Start
Please read and make sure you understand all the prerequisites for proper installation of your
new PoE Network Camera. Have all the necessary information and equipment on hand before
beginning the installation.
PackingList
Open the shipping carton and carefully remove all items. In addition to this Manual, ascertain
that you have:
• One TV-IP522P
• One Camera Stand
• One Power Adapter
• One Ethernet Cable
• One Installation CD-ROM (Utilities and User’s Guide)
• One Quick Installation Guide
If any of the above items are missing, please contact your reseller.
CAUTION: If powering up the camera with DC power, the
Camera must be used with the power adapter included with
the device.

v
TV-IP522P ProView Megapixel Internet Camera
SystemRequirements
Computer
• CPU:
o For Intel x86 compatible CPUs: Intel Pentium IV 2.0Ghz or above
o For IA64 compatible CPUs: AMD Athlon 64 3000+ and above
• Memory: 1GB or above
• VGA Resolution: 1024 x 768 or above (Independent Display Card recommended)
• 10BASE-T Ethernet or 100BASE-TX Fast Ethernet Network Interface Card
• CD-ROM Drive for SetupWizard on Installation CD-ROM
• IPView Pro 2.0 Application Users must use Microsoft® Windows® 7, Vista, XP or 2000
OperatingSystem with Internet Explorer 6.0 or above with
DirectX 9.0.
Note: When you connect multiple cameras and monitor their images
synchronously, it is recommendedto use a high performance system,
such as a Pentium 4 2.4GHz PC.
Network
• Local Area Network: 100Base-TX Fast Ethernet or Gigabit

vi
T
V
-IP522P ProView Megapixel Internet Camera
DefaultSettings
Use the default settings to access the web-based managementsoftware and live video display.
Default configuration settings
Username This is the Username you will be prompted to enter when you access the TV-IP522P
configuration screens using a Web browser. The default Username is admin.
Password This is the Password you will be prompted to enter when you access the
configuration windows using a Web browser. The default Password is admin.
IP address This is the IP address you will enter into the Address field of your Web browser to
access the camera monitor screen and configuration menus using a Web Browser.
The camera uses DHCP for IP settings by default. If a DHCP server is not detected,
the default IP address is 192.168.10.30. (Make sure your computer is
configured to belong to the 192.168.10.X subnet if using the default IP
address of the camera.)
Subnet
Mask
The default subnet mask is 255.255.255.0.

T
V
-IP522P ProView Megapixel Internet Camera
7
1
Introduction
The TV-IP522P ProView Megapixel Internet Camera transmits live real-time high-quality M-JPEG/
MPEG-4/H.264 video through an Ethernet network useful for remote monitoring applications. The
live video can be viewed remotely and managed through the network from any computer
connected to the network.
Featuresand Benefits
Easy to use - The Camera is a standalone system with built-in CPU, no special hardware or
software is required. The camera supports DirectX 9.0; therefore, the only requirement you need
is the web browser software such as Internet Explorer 6.0 or above. Once you have a valid IP
Address, just connect it and you can view the picture and receive sound from your camera. In
addition, the camera’s stand allows you to adjust the camera for optimal viewing angle.
Motion detection and event triggered digital image or video recording – Use the Motion
Detection to take a snapshot or digital video record of objects that move through a selected area of
the video display.
Live audio for listen and speaking – The built-in mic is useful for listening for noise or voices in
front of the camera. The sensitivity can be adjusted to pick up faint noise. An audio output
connection allows use of external speakers for two way communication from the operator’s station.
Supports variety of platforms - The camera supports TCP/IP networking, SMTP e-mail, HTTP and
other Internet related protocols and can be integrated easily into other www/Intranet applications.
Web configuration - Applying a standard web browser, the administrator can configure and
manage the camera directly from its own web page via the Intranet or Internet. Up to 20 user
accounts are permitted with privilege settings controlled by the administrator.
Remote Utility - The powerful IPView Pro 2.0 application assigns the administrator with a pre-
defined user ID and password, allowing the administrator to modify the camera settings from the
remote site via Intranet or Internet. When new firmware is available, you can also upgrade
remotely over the network for added convenience. Users are also allowed to monitor the image,
and take snapshots.

8
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
CameraHardware Components
Below is a summary description of the camera hardware:
Frontand Side Components
Lens comes with 2 parts that’s adjustable, Focus (front) and Aperture (back).
Please adjust the aperture first then the focus.
Audio mic
Adjustable focus
camera lens
Link/Power
LED indicator

9
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
RearPanel Components
The power connection to the camera when fitted with the Infrared lens is split between the camera
body and lens using the power connection adapter cable attached to the infrared lens. All other
cables connect to the camera at the rear panel.
Rear Panel view of
TV-IP522P
LEDIndicators
LNK
This LED indicator lights green when the camera is powered on . It remains
dark when powered off.
PWR
This LED indicator lights steady green when a valid Ethernet link is
established. It blinks green when traffic is received or transmitted through
the Ethernet link.
GPIO Port
Power receptacle
Audio-
O
ut Port
Ethernet Port
A
udio-In Port
f
or mic
A
uto Iris Adjustment
Power indicator
GPIO Port
Reset button

10
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
Mic-In The camera is equipped with an internal microphone, however this can be augmented
by an external mic. Use this audio jack socket for an external microphone.
Line Out Use this audio jack socket to connect to external speakers for two-way audio
communication.
DC 12V Insert the power adapter shipped with the camera directly if using the regular
lens; or insert the power adapter cable on the infrared lens connected to the
power adapter cable if using the infrared lens. This
is used to supply power to the camera. The camera will boot up when connected to a
power source. There is no separate power switch.
Auto Iris Connector
(DC drive) Use this for fine-tuning adjustment of Auto Iris lens. Auto Iris lens are not included with the camera. Please see the instructions of the lens manufacturer for more
information.
Note: Auto Exposure should be turned off when using an Auto Iris lens.
Reset Use to reset device to factory default settings including IP address and administrator
user name and password.
Ethernet Connect the Ethernet cable here.
Ethernet (PoE) Connect the Ethernet cable here. PoE connection provides network and device power
on networks that support PoE.
GPIO The camera provides the I/O connectors on the rear panel (pins 1/2 are for DC12V +/-
, pins 3/4/5/6 are for Photo-Relay Inputs, pins 7/8 are for Photo-Relay Outputs and
pins 9/10 are for RS-485 +/-), which provides the physical interface to send and
receive digital signals to a variety of external alarm devices.
Auto-Iris Connector (DC drive)
The camera supports additional Auto Iris Lens(DC drive), and provides the power control signal
required for adjusting the lens through this Auto-Iris Connector(DC drive)(4-pin) .You can attach any
standard Auto Iris Lens(DC drive)(optional) for specific purposes such as outdoor applications.

11
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
2
Installing the Camera
The camera should be attached to the stand included in the package. The camera stand can be
mounted on a flat surface using the three screw holes on the base of the stand. The camera is
intended for indoor use. The camera, the power adapter and power source should be protected
from water and moisture, excessive heat, direct sunlight and cold. Make sure the power adapter
and cord and Ethernet cable are safely arranged so they do not create a tripping hazard and will
not be disturbed by people or objects moving past.
AttachCamera to Stand
Determine the location for the camera and assemble the camera stand. Secure the stand to the
flat surface or ceiling with the mounting screws included in the package. When the stand is
assembled and firmly attached to flat surface or ceiling, attach the camera. Do not attach
network cables or the power cord until the camera is firmly mounted in place.
Follow the assembly and installation instructions below to mount the
camera before connecting the power or network cables.
1. Determine where the camera will be located and assemble the camera stand. For wall
mounting, use both arm sections of the camera stand. For ceiling or flat top surface
mounting, use the straight section of the stand only.
2. Firmly attach the camera stand to a suitable flat surface by placing screws in the holes of the
mount plate and screwing them into place. Make sure the stand is securely attached before
attaching the camera.
3. Aim the camera at the area of coverage and hand tighten the nut to keep the camera in
position.
4. Attach the Ethernet cable (see below).
5. Attach the power adapter and connect it to a suitable power source (see below). Check
the power and Ethernet LED indicators to check for basic functionality.
The camera is shipped with a camera stand. The swivel ball screw head on the stand can be
attached to the bottom screw hole of camera. The swivel ball mount allows the camera to be
pointed in a direction and fixed in position. Three holes on the base of the
camera stand are used
to securely attach the stand to a wall or ceiling.

12
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
ConnectEthernet Cable
To connect the camera to your network, connect a Category 5 or better Ethernet cable to
the network cable connector located on the camera’s left side panel, and then attach it to the
network. The Ethernet port will automatically detect and adjust to the speed (10 or 100
Mbps) and polarity (MDI-II or MDI-X) of the connection.
ConnectPower using AC Adapter and Power On Camera
To provide power to the camera, connect the AC power adapter to the DC power input connector,
also located on the camera’s rear panel, and then plug it into a suitable power source. As with any
electrical device, make sure the power source and camera are located in an area where it is not
going to get wet or present an electrical hazard.
Note that there is a difference in how the power connection of the infrared lens assembly
connects compared with the 6mm CCTV lens. The infrared lens requires power and therefore it
is equipped with and special adapter to power both the camera and the lens.
CAUTION: The Camera must be used with the power
adapter included with the device.

13
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
ResetCamera
A manual reset can be conducted by following the procedure below. The reset button is located on
the rear panel of the camera. To reset the system settings to factory defaults, please follow these
steps:
1. Leave the camera powered on, do not disconnect the power.
2. Use a paper clip or similar object to press the reset button and hold. The reset button is
located on the rear panel of the device. See the Rear Panel Components picture above to
locate the reset button.
3. Keep the button pressed about 10 seconds.
4. Release the button.
The camera will then automatically reboot itself. Upon restarting the camera loads the factory
default configuration settings. The default IP address 192.168.10.30 and subnet mask
255.255.255.0 will be applied unless a DHCP server is actively connected to the network. The
administrator’s default user name is admin and the password is admin. Use the SetupWizard
shipped with the camera to reconfigure it or access it through the web-based management
software.

14
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
SDCard Slot
The built in SD card slot allows you to insert Secure Digital Cards. This enables images taken by the
camera to be saved to an external SD card.
S
D
C
ard
S
lot

15
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
3
SetupWizard
This section describes the how to setup a camera using the SetupWizard. To install the
SetupWizard on a system running Windows, launch the SetupWizard on the installation CD-ROM
and follow the setup instructions. Once the software is installed, the SetupWizard utility is ready for
use.
Launching the SetupWizard
To launch the SetupWizard, click Start > Programs > TRENDnet > SetupWizard > SetupWizard.
SetupWizard- Install Your Camera
• Connect the camera to your LAN using the provided RJ45 cable.
• Connect the AC Power Adapter to the back of the camera and to a live power socket.
• Click Next to continue.

16
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
SetupWizard- Select Your Camera
The following screen appears showing the cameras that have been found on your network:
• Click on the camera you want to configure.
• Click Next to continue.

17
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
SetupWizard- Authentication
On the following screen type in the ID and Password that you will use to configuring the camera
settings:
• Type a User ID in the ID field.
• Type the password of the User in the Password field.
• Click Next to continue.

18
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
SetupWizard- Change Password
The following screen allows you to change the default admin password:
Carry out the following if you want to change the admin password:
• Tick the Change Password checkbox
• Type in a New Password in the New Password field and confirm it in the Confirm
Password field
• Click the Next button to proceed to the next Setup window
If you don’t want to change the admin password, leave the checkbox un-ticked and click Next.

19
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
SetupWizard- Select a Connection Option
The following window allows you to specify the connection method used by your camera network.
Click the radio button of the network environment your camera is connected to. The available
options are:
• PPPoE
• DHCP
• Fixed IP

20
TV-IP522P ProView Me
g
a
p
ixel Internet Camera
SetupWizard- Select a Connection Option- PPPoE
If your connection method is PPPoE, click the PPPoE radio button and click Next:
The following window appears:
• Type the User Name used to connect to your PPPoE connection in the User Name field.
• Type the Password of the PPPoE User Name in the Password field and confirm it in the
Confirm Password field.
• Click Next to proceed to the next setup window.
