Panasonic aw-he40 series User manual

(Setting Procedure via AW-RP50)
<How to manually adjust the iris of AW-HE40 connected to CAM1>
① ress the button 1 at <CAMERA STATUS/SELECTION>. - (Fig. 1-A)
② Hold down the CAMERA OSD button - (Fig. 1-B) at the upper right of the panel. The button will light up and
the on-screen menu will be displayed on SDI (or HDMI) output image from the selected AW-HE40 camera.
* If CAMERA OSD button is held down again while it is lit, the on-screen menu will disappear and the button’s
light will go off.
③ Use F1 dial to change the following camera menu setting. - (Fig. 1-C)
【Location】
・ Camera ＞ Scene ⇒ ut the setting to [Manual1]. * The setting can be selected from [Manual1 – 3].
④ ress “IRIS AUTO” button (*1) on the front panel to switch between Auto and Manual. - (Fig. 1-D)
(*1) When this button’s light is ON, it indicates Auto Iris. When it is OFF, it indicates Manual Iris and the iris
can be adjusted using IRIS dial. - (Fig. 1-E)
The status of “IRIS AUTO” button is linked with the following camera menu setting.
・ Camera ＞ Scene ＞ Contrast ＞ Contrast Mode ⇒ [Auto], [Manual]
(Displayed On-Screen Menu)
Controlling Iris of AW-HE40 Ca era Manually
Turn F1 → Select “Camera” → ress F1 ress F1 → “Full Auto” blinks
（A）
（D）
（B）
（C）
(Figure 1)
Turn F1 → Select “Manual1” → ress F1
（E）

(Setting Procedure via Web Screen on PC)
- Start up the Web screen to change the following setting.
① Select [Man.1] (*2) from the pull-down menu at “Scene”, then press [Set] button. - (Fig. 2-A)
(*2) The setting can be selected from [Manual1 – 3].
② ress [Auto] button (*3) at “Brightness” to switch between Auto Iris and Manual Iris. - (Fig. 2-B)
(*3) When this button’s light is ON in green, it indicates Auto Iris.
When it is OFF, it indicates Manual Iris.
③ Adjust the iris using [-] and [+] buttons at “Brightness”. - (Fig. 2-B)
* For the connection between C and AW-HE40, please refer to the Manual 【Controlling AW-HE40 Camera
via C】.
(Figure 2: Web Screen)
（A）
（B）
