MICRO-EPSILON scanCONTROL 2500 User manual

1. Warnings
Avoid unnecessary laser radiation to be exposed to the human body.
Connect the power supply and the display-/output device according to the safety
regulations for electrical equipment. The power supply must not exceed the specified
limits.
> Risk of injury, damage to or destruction of the sensor
Avoid shocks and impacts to the sensor. Avoid exposure of sensor to aggressive
materials (detergents, cooling emulsions).
> Damage to or destruction of the sensor
Avoid constant exposure of the sensor to dust or splashes of water by appropriate
methods such as blowing or using a protective housing.
> Damage to or destruction of the sensor
Read the detailed instruction manual before operating the sensor. You will find this
manual online at www.micro-epsilon.com.
2. Notes on CE Identification
The following applies to the scanCONTROL 25xx:
- EU Directive 2014/30/EU
- EU Directive 2011/65/EU, “RoHS“ category 9
The sensor is designed for use in industry and satisfies the requirements. The sensor
fulfills the specifications of the EMC requirements, if the instructions in the manual are
followed.
3. Proper Environment
- Protection class: IP 65
- Operating temperature: 0 to +45 °C (+32 to +113 °F), by free circulation of air
- Storage temperature: -20 to +70 °C ( -4 to +158 °F)
- Humidity: 5 - 95 % (non condensing)
4. Scope of Delivery of scanCONTROL 25xx
- 1 Sensor scanCONTROL 25xx with integrated controller
- 1 Multifunction cable PCR3000-5, length 5 m; for power supply, trigger and RS422;
M12x1 screw connector and free cable ends
- Calibration final inspection / assembly instructions / 2 protective caps
Assembly Instructions
scanCONTROL 2500 / 2510

5. Laser Safety
The scanCONTROL 25xx sensors operate with a semiconductor laser having a wave-
length of 658 nm (visible/red). The laser operation is indicated visually by the LED on
the sensor.
When operating the scanCONTROL 25xx sensors, the relevant regulations according
to IEC 60825, Part 1 of 05/2014 and the applicable accident prevention regulations
must be followed.
Attach the following warning labels to the cover (front side) of the sensor housing. The
laser warning labels for Germany have already been applied. Those for other non Ger-
man-speaking countries an IEC standard label is included in delivery and the versions
applicable to the user’s country must be applied before the equipment is used for the
first time.
i
If the information labels are hidden in the installed state, the user must ensure
that additional labels are fitted at the point of installation.
scanCONTROL 25xx sensors with a maximum laser power up to 8 mW are classified in
Laser Class 2M (IIM). Attach the following warning labels to the cover (front side) of the
sensor housing.
LASER RADIATION
DO NOT STARE INTO BEAM
OR EXPOSE USERS OF
CLASS 2M LASER PRODUCT
TELESCOPE OPTICS
IEC 60825-1: 2014
P
0
≤ 8 mW; P
P
≤ 8 mW; H ≤ 52 W/m²;
 = 658nm; F = 0...4 kHz; t = 1 µs...∞
COMPLIES WITH 21 CFR 1040.10 AND 1040.11
EXCEPT FOR CONFORMANCE WITH
IEC 60825-1 ED. 3., AS DESCRIBED IN
LASER NOTICE NO. 56, DATED MAY 8, 2019
Only for USA
Hazard to the eye via laser radiation! Consciously close your
eyes or turn away if the laser radiation impinges on the eye.
iLaser areas must be marked duarably and clearly, if the laser beam runs through a work or traffic area.

6. Connections, LED Displays
1 2 1 Ethernet socket
2 Multifunction socket
(Power supply, IO)
Multifunction Port
Designation Sensor con-
nector Pin
Cable color
PCR3000-x
Notes
+Ub 9 red + 11 V - 30 V DC
(rated value 24 V); max. 500 mA
GND 2 blue 0 V
+Laser on/off 3 white available with SI option
-Laser on/off 1 brown
RS422 12 red-blue RS422
input respectively output
/RS422 11 gray-pink
In1 6 yellow Switching input In1
GND-In1 4 green Ground connection In1
In2 5 pink Switching input In2
GND-In2 8 grey Ground connection In2
In3 10 purple Switching input In3
GND-In3 7 black Ground connection In3
Screen Housing black Not electrically connected to GND
23
4
5
6
7
8
9
1
10
11
12
GND: galvanically isolated from IN1, 2, 3, RS422,
Laser on/off
Laser on/off: Input galvanically isolated from GND,
IN1…3, RS422
IN1, IN2, IN3, RS422: Inputs galvanically isolated from
GND and Laser on/off
12-pin screw connector, view on solder pin side (cable)

RS422, Synchronization
The RS422 connection (Pin 11 and 12 of the multifunction port) can be used with
either of the following configurations:
- RS422 (half-duplex): Load user modes, sensor control and transmit measurement
results (Modbus RTU or ASCII-Format).
- Synchronization/triggering: Synchronization respectively triggering using switching
signals.
Trigger, Encoder, Mode Switching
The switching inputs of the multifunction port can either be used for encoder-, trigger
input or for loading previously stored user modes.
The signal levels are switchable for all switching inputs between LLL (TTL logic) and
HLL (HTL logic):
- LLL level: Low 0 V … 0.8 V, high 2.4 V … 5 V, internal pull-up resistor 10 kΩ to 5V
- HLL level: Low 0 V … 3 V, high 11 V … 24 V (permitted to 30 V), internal pull-up
resistor 10 kΩ to 24 V
- Pulse duration: ≥ 5 µs
External Laser Switching, optional
The external laser switching-off is implemented as a hardware solution and is a top
priority. The laser can be switched off, in addition, also by software
Use a serial key switch inside the control circuit to switch off the laser.
You will find details for the wiring in the instruction manual, Chap. 5.2.6.
With standard sensors, connecting the supply voltage activates the laser light source
in the sensor.

Ethernet Connection, Standard Connection to PC
RJ45 connector 8-pin. screw connector (sensor side)
Pin no. Color stranded hook-up
wire SCR3000A-x
Pin no. 10BaseT,
100BaseTX
1000BaseT
1 white (orange) 5 Tx+ D1+
2 orange 6 Tx- D1-
3 white (green) 8 Rx+ D2+
4 blue 1 D3+
5 white (blue) 2 D3-
6 green 7 Rx- D2-
7 white (brown) 3 D4+
8 brown 4 D4-
1View on pin
side male cable
connector
23
4
5
6
7
8
1
View on solder pin side
(cable) screw connector
(A-coded)
- The sensor supports an automatically, sensor-adapted IP address in the
link-local-net (169.254.x.x). No collision detection is implemented.
This is also the default setting.
- The sensor supports DHCP. This setting is activated by default and has priority over
the retrieval in the link-local-net.
- The sensor scanCONTROL 25xx supports Power over Ethernet.
If the sensor is connected to a network adapter/switch that
is capable of POE and if you also use the power supply of
the multifunction port, these two power supplies have to be
galvanically isolated.
> Damage of the sensor and/or the Ethernet card!
- A fixed IP address can be assigned.
Use the program sensorFINDER to make the above-described sensor
settings. The program is available online on www.micro-epsilon.com/download/
software/SensorFinder.zip.

LED Displays
LED laser on Meaning
laser on
state
Green Laser is on
LED state Meaning
Green Measurement is active
Green, flashes long Data transmission is active
Green, flashes short Controller accesses
Red, flashes Error code
7. System Requirements
scanCONTROL Configuration Tools
The following minimum system specification is necessary:
- Windows 7 (32 bit and 64 bit), Windows 10 (32 bit and 64 bit)
- 800-MHz or faster (32 bit and 64 bit) processor / 512 MB RAM
- Screen resolution: 1024 x 768
scanCONTROL 3D-View
The following minimum system specification is necessary:
- Windows 7 (32 bit and 64 bit), Windows 10 (32 bit and 64 bit)
- 800-MHz or faster (32 bit and 64 bit) processor / 512 MB RAM
- Screen resolution: 1024 x 768
- Graphic card / GPU with OpenGL 3.1 or higher

8. Quick Start: Commissioning, Software
Mount the sensor according to the installation instructions.
Install the software.
You will find the software online on
the product website of the sensor or
in the download area: https://www.
micro-epsilon.com/2D_3D/laser-scan-
ner/Software/downloads/
Follow the dialog through the installa-
tion process.
A. Reading of installation help
B. Installation of software
C. Further information in the online
documentation
Connect the sensor to the PC via the optional available SCR3000A-x Ethernet
cable.
Connect the sensor to display or monitoring units.
Switch on the power supply.
The connectors for Ethernet and the multifunction port are fitted with a screw connec-
tor.
Loosen the screws before you remove the connector from the socket.
Connect the shield of the power supply cable to the PE protective earth conduc-
tor of the main power supply. Close unused connection plugs with the provided
protective caps. Switch on the power supply (24 VDC).
iOnly connect the sensor to the peripheral equipment, if it is disconnected from the power supply, i.e. only when the operating voltage is switched off. The sen-
sor needs a warm-up time of typically 20 minutes for high precision measure-
ments.
Please wait until the scanCONTROL device is recognized by the PC.
This may take a few seconds.
Now you can operate the scanCONTROL measurement system with the scanCON-
TROL software packages.
iOperating a scanCONTROL sensor via Ethernet may require a modification of the IP settings of the PC/sensor or a modification of the firewall settings, see
Chap. 5.2.5 of instruction manual.

9. First Profile
Now start the scanCONTROL Configuration Tools software. Click on Display
Profiles in the main window.
If the software shows the error message No scanCONTROL found in the status
line, please check the Ethernet connection between scanCONTROL and PC.
On the left side you can adjust the settings for your measurement task, the right side
shows the profile data and information about the measurement.
10. How to Access Profile Data
Profile data of scanCONTROL can be accessed via:
- GigEVision and GenICam for digital cameras via Ethernet interface
- SDK for fast application integration (C, C++, C# and others)
For details how to access profile data refer to the enclosed online manual.
11. Transmitting Measurement Results
scanCONTROL 2510 offers the following options for transmitting measurement
results:
- Ethernet interface
Modbus TCP protocol
UDP protocol
Analog output of measurement values (via optional Output Unit)
Digital output of switching signals (via optional Output Unit)
Fieldbus connection Profinet, Ethernet/IP, EtherCat (via optional Gateway)
- RS422 interface
Modbus RTU protocol
Measurement value transmission in ASCII format

12. scanCONTROL Gateway
scanCONTROL Gateway allows for scanCONTROL SMART sensors to be integrated
into various fieldbus systems:
- Profinet
- Ethernet IP
- EtherCat
All measurement results obtained from the profile evaluation carried out of a
scanCONTROL SMART sensor can be transmitted to a PLC via one of these fieldbus
systems. Furthermore, all scanCONTROL sensor settings can be set via scanCON-
TROL Gateway (e. g. Laser on/off or switch User Mode).
Sensor parame-
terization
Power supply
Triggering
Encoder
Synchronization
Mode control
Sensor control
Gateway parameterization
USB
Ethernet
Switch
scanCONTROL
Gateway
The scanCONTROL Gateway can connect up to four scanCONTROL SMART sensors
to the fieldbus. The transmission rate of measurement values is up to 500 Hz.
Please refer to the TechNote T026 (scanCONTROL fieldbus integration) for more
details.

L1
L2
L3
N
PE
OU Filter module
OU Fieldbus coupler
++
-
13 14
C
D
B
A
750-626
+
+ Ñ
-
-
253-057
LINK
ACT
MS
I/O
ETHERNET
NS
87654321
NO
LINK
ACT 1
2
X
1
X
2
8
1
ON
24V
X3
0V
0: WBM
255: DHCP
System supply
Field supply
230 V
24 V
230 V
24 V
13. scanCONTROL 2510 with scanCONTROL Output Unit for Connection to an SPS
++
-
13 14
C
D
B
A
750-626
+
+ Ñ
-
-
Power jumper
contacts
Supply via power
jumper contacts
24V
Status
voltage supply
- Power jumper contacts
- System
Data contacts
System supply (OUT)
24 V
0 V
0 V
System supply (In)
24 V
0 V
C
D
B
A
750-600
OU filter module
Bus terminationAnalog output module
253-057
LINK
ACT
MS
I/O
ETHERNET
NS
87654321
NO
LINK
ACT 1
2
X
1
X
2
8
1
ON
24V
X3
0V
0: WBM
255: DHCP
OU fieldbus coupler
A1 A2
13 14
750-536
A3 A4
A5 A6
A7 A8
DO 2
Power jumper
contacts
Data
contacts
DO 2
Status
D0 4
D0 6
DO8
DO 8
Digital output module
DO 1
Status
DO 7
DO 7
DO 1
DO 5
DO 3
A1 A2
13 14
C
D
B
A
MM
A3 A4
M M
750-555
AO 2
AO 1
AO 4
AO 3
V
0
V
0
V
0
V
0
Power jumper
contacts
Data contacts
Function
Error

Connect the supply voltage
Digital output modules need a field supply of 5 VDC or 24 VDC depending on the
module type.
After mounting of the modules install the required wiring.
Connect the “System supply (out)“ terminals of the OU-Filter module to the
“System supply (in)“ terminals of the OU-Fieldbus Coupler (0 V and 24 V).
Connect the system supply (in) of the OU-Filter module to the power supply
(0 V and 24 V).
Connect the field supply (in) of the OU-Filter module to the power supply
(0 V and 24 V resp. 0 V and 5 V).
iThe system supply and field supply should be separated to ensure the bus operation and electrical isolation in case of a short-circuit of an actor.
13. scanCONTROL 2510 with scanCONTROL Output Unit for Connection to an SPS
++
-
13 14
C
D
B
A
750-626
+
+ Ñ
-
-
Power jumper
contacts
Supply via power
jumper contacts
24V
Status
voltage supply
- Power jumper contacts
- System
Data contacts
System supply (OUT)
24 V
0 V
0 V
System supply (In)
24 V
0 V
C
D
B
A
750-600
OU filter module
Bus terminationAnalog output module
253-057
LINK
ACT
MS
I/O
ETHERNET
NS
87654321
NO
LINK
ACT 1
2
X
1
X
2
8
1
ON
24V
X3
0V
0: WBM
255: DHCP
OU fieldbus coupler
A1 A2
13 14
750-536
A3 A4
A5 A6
A7 A8
DO 2
Power jumper
contacts
Data
contacts
DO 2
Status
D0 4
D0 6
DO8
DO 8
Digital output module
DO 1
Status
DO 7
DO 7
DO 1
DO 5
DO 3
A1 A2
13 14
C
D
B
A
MM
A3 A4
M M
750-555
AO 2
AO 1
AO 4
AO 3
V
0
V
0
V
0
V
0
Power jumper
contacts
Data contacts
Function
Error

www.micro-epsilon.com
MICRO-EPSILON Messtechnik GmbH & Co. KG
Königbacher Str. 15
94496 Ortenburg / Germany, Tel. [phone]
*X9771413-A01* X9771413-A012020SWE
14. Further Information
Please refer to
- the enclosed online manual
- the section Status and Error Messages and Notes in the
scanCONTROL Configuration Tools manual.
You will find details to the separate programs in the respective instruction manuals or
in the instruction manual of this sensor, Chap. 6.2. You will find the instruction manuals
online on www.micro-epsilon.com
