Microlife BP 3AC1-1 PC User manual

IB BP 3AC1-1 PC VarB 1107
Europe / Middle-East / Africa
Microlife AG
Espenstrasse 139
9443 Widnau / Switzerland
Tel. +41 / 71 727 70 30
Fax +41 / 71 727 70 39
Email [email protected]
www.microlife.com
Asia
Microlife Corporation.
9F, 431, RuiGang Road, NeiHu
Taipei, 114, Taiwan, R.O.C.
Tel. [phone]
Fax.[phone]
Email [email protected]
www.microlife.com
North / Central / South America
Microlife USA, Inc.
424 Skinner Blvd., Suite C
Dunedin, FL 34698 / USA
Tel. [phone]
Fax [phone]
Email [email protected]
www.microlife.com

microlife BP 3AC1-1 PC
Automatic Blood Pressure Monitor
Instruction Manual (1-17)
Автоматический прибор для измерения артериального
давления и частоты пульса
Pуководство по пользованию
(18-35)
Automatyczny aparat do mierzenia ciśnienia
Instrukcja używania (36-53)
Automata vérnyomásmérő
Használati utasítás (54-71)

Automatic Blood Pressure Monitor
Instruction Manual

1
Table of Contents
1. Introduction
1.1. Features
1.2. Important information about self-measurement
2. Important Information on the Subject of Blood Pressure and its Measurement
2.1. How does high/low blood pressure arise?
2.2. Which values are normal?
2.3. What can be done, if regular high/low values are obtained?
2.4 MAM technology (Microlife Average Mode)
2.5. PAD - Pulse Arrhythmia Detection
3. Components of your Blood Pressure Monitor
4. Using your Blood Pressure Monitor
4.1. Inserting the batteries
4.2. Using an mains adapter (special accessory)
4.3. Cuff connection
4.4. Setting the time and date
5. Carrying out a Measurement
5.1. Before the measurement
5.2. Common sources of error
5.3. Fitting the cuff
5.4. Measurement mode selection
5.5. Measuring procedure
5.6. Discontinuing a measurement
5.7. Memory – recall of measurements
5.8. Memory – cancellation of all measurements
6. PC-Link Functions
6.1. Installation and Data Transmission
7. Error Messages/Malfunctions
8. Care and Maintenance, Recalibration
9. Guarantee
10. Reference to Standards
11. Technical Specifications
12. www.microlife.com

1. Introduction
1.1. Features
The blood pressure monitor is a fully automatic, digital blood pressure measuring device for use on the
upper arm with integrated MAM and PAD technology. This monitor enables very fast and reliable
measurement of the systolic and diastolic blood pressure as well your pulse by use of the oscillometric
method.
This device is easy to use and is proven in clinical studies to provide excellent accuracy. The large display
makes it easy to visualize operational status and cuff pressure during a measurement.
Before using, please read through this instruction manual carefully and then keep it in a safe place. For
further questions on the subject of blood pressure and its measurement, please contact your doctor.
Attention!
1.2. Important information about self-measurement
•Self-measurement means Control, not diagnosis or treatment. Your values must always be discussed
with your doctor. Never alter the dosages of any medication without direction from your
doctor.
•The pulse reading is not suitable for checking heart pacemakers!
•In cases of cardiac irregularity (Arrhythmia), measurements made with this instrument should only be
evaluated after consultation with the doctor.
Electromagnetic interference
The device contains sensitive electronic components. Therefore, avoid strong electrical or electromagnetic
fields in the direct vicinity of the device (e.g. mobile telephones, microwave ovens). These can lead to
temporary impairment of the measuring accuracy.
2

3
2. Important Information on the Subject of Blood Pressure and its Measurement
2.1. How does high/low blood pressure arise?
Your blood pressure level is determined in the circulatory center of your brain. Your nervous system allows
your body to adapt or alter blood pressure in response to different situations. Your body alters your pulse
and the width of blood vessels through changes in muscles in the walls of blood vessels.
Your blood pressure reading is highest when the heart pumps or ejects blood – this is called your Systolic
Blood Pressure. Your blood pressure reading is lowest when the heart rests (in-between beats) – this is
called your Diastolic Blood Pressure.
Note: Maintain blood pressure values within a «normal» range(s) in order to prevent particular diseases.
2.2. Which values are normal?
Blood pressure is too high if at rest, the diastolic pressure is above 90 mmHg and/or the systolic blood
pressure is over 140 mmHg. If you obtain readings in this range, consult your doctor immediately. High
blood pressure values over time damage blood vessels, vital organs such as the kidney and even your heart.
When blood pressure values are too low, i.e. systolic values under 100 mmHg and/or diastolic values under
60 mmHg, consult your doctor.
Even with normal blood pressure values, a regular self-check with your blood pressure monitor is
recommended. In this way you can detect possible changes in your values early and react appropriately.
If you are undergoing medical treatment to control your blood pressure, please keep a record of the level of
your blood pressure by carrying out regular self-measurements at specific times of the day. Show these
values to your doctor. Never use the results of your measurements to independently alter drug
doses prescribed by your doctor.
Table for classifying blood pressure values (units mmHg): according to World Health Organization:
☞Further information
• If your values are mostly «normal» under resting conditions but exceptionally high under conditions of
physical or psychological stress, it is possible that you are suffering from so-called «labile
hypertension». In any case, please discuss the values with your doctor.
• Correctly measured diastolic blood pressure values above 120 mmHg require immediate medical
treatment.
Range Systolic
Blood Pressure
Diastolic
Blood Pressure
Measures
Hypotension lower than 100 lower than 60 Consult your doctor
Normal range between 100 and 140 between 60 and 90 Self-check
Mild hypertension between 140 and 160 between 90 and 100 Consult your doctor
Moderate hypertension between 160 and 180 between 100 and 110 Consult your doctor
Severe hypertension higher than 180 higher than 110 Consult your doctor
immediately

2.3. What can be done, if regular increased/low values are obtained?
a) Please consult your doctor.
b) Increased blood pressure values (various forms of hypertension) over time are associated with
considerable risks to health. Blood vessels in your body are endangered due to constriction caused by
deposits in the vessel walls (Arteriosclerosis). This can result in a deficient supply of blood to important
organs (heart, brain, muscles). Additionally, the heart will become structurally damaged.
c) There are many different causes of high blood pressure. We differentiate between the common primary
(essential) hypertension, and secondary hypertension. Secondary hypertension can cause organ
malfunctions. Please consult your doctor for information about the possible origins of your own
increased blood pressure values.
d) There are lifestyle changes you can make to prevent and reduce high blood pressure. These measures
must be part of a healthy lifestyle and include:
A) Eating habits
• Strive for a normal weight as prescribed by your doctor. Reduce overweight!
• Avoid excessive consumption of common salt. (Many «packaged foods» contain high levels of salt).
• Avoid fatty foods. (Packaged foods are frequently high in fats).
B) Previous illnesses
Consistently follow any medical instructions for treating previous illness such as:
• Diabetes (Diabetes mellitus or sugar diabetes)
• Fat metabolism disorder
• Gout
C) Habits
• Eliminate smoking
• Drink only moderate amounts of alcohol
• Restrict your caffeine consumption (Coffee, tea, chocolate, etc.)
D) Physical conditioning
• After a preliminary medical examination, exercise regularly.
• Choose sports which require endurance and avoid those which require strength.
• Avoid reaching the limit of your performance.
• With previous illnesses and/or an age of over 40 years, please consult your doctor before beginning your
exercise activities. Your physician will help you develop an exercise routine that is appropriate for you.
2.4. MAM technology (Microlife Average Mode)
• «MAM technology» is a new type of concept for optimum reliability in self-measurement of blood
pressure.
• An advanced measurement accuracy is achieved by the automatic analysis of three successive
measurements.
• The new system provides reliable values for the doctor and can be used as the basis for reliable
diagnostics and medication therapy for high blood pressure.
A) Why MAM?
• Human blood pressure is not stable
• Scattering of devices
4

5
B) Key advantages
Reduction of:
• Device scattering
• Insufficient rest prior to measurement
• Movement artefacts
• Cuff positioning influences
C) Medical benefits
• Improved accuracy
• Reliable patient self-measurement data for the doctor
• Safe hypertension diagnostic
• Reliable therapy control
D) Measurement sequence
• With the full measurement cycles, the total measurement time remains less than 3 minutes, compared
to a single measurement time of 1.5 minute.
• Single results are not displayed.
• Due to the «Data Analysis» result, a 4th measurement may be applied.
2.5. PAD - Pulse Arrhythmia Detection
Appearance of the Arrhythmia indicator
The appearance of this symbol signifies that a certain pulse irregularity was detected during the
measurement. The result can vary from your normal blood pressure. As a rule this is not a cause for
concern; however, if the symbol appears more frequently (e.g. several times per week on measurements
performed daily) or if it suddenly appears more often than usual, we recommend you inform your doctor.
Please show your doctor the following explanation:
Information for the doctor on frequent appearance of the Arrhythmia indicator
This device is an oscillometric blood pressure measuring device that also analyses the pulse
frequency during measurement. The accuracy of this device has been clinically validated.
If pulse irregularities occur during measurement, the arrhythmia symbol is displayed after the
measurement. If the symbol appears more frequently (e.g. several times per week on
measurements performed daily) or if it suddenly appears more often than usual, we
recommend the patient to seek medical advice.
The device does not replace a cardiac examination, but serves to detect pulse irregularities at an
early stage.

3. Components of the Blood Pressure Monitor
The illustration shows the blood pressure monitor, consisting of:
a) Measuring unit
b) Upper arm cuff
Medium cuff (AC-1 M) for arm circumference 22-32 cm
Large cuff (AC-1 L) for arm circumference 32-42 cm
Note: The large cuff is available as special accessory
6
Mains adapter
power socket
USB port
Cuff connection O/I button
Single Mode /
MAM – Microlife Average Mode
MEMORY button
Time button

7
4. Using your Blood Pressure Monitor
4.1. Inserting the batteries
Insert batteries immediately after unpacking the device.
The battery compartment is located on the back of the
device (see illustration).
a) Remove cover as illustrated
b) Insert the batteries (4 x size AA 1,5V), thereby
observing the indicated polarity.
c) If the battery warning appears in the display, the
batteries are empty and must be replaced.
Attention!
• After the battery warning appears, the device is
blocked until the batteries have been replaced.
• Please use «AA» Long-Life or Alkaline 1.5 V Batteries.
The use of 1.2 V Accumulators is not recommended.
• If the blood pressure monitor is left unused for long
periods, please remove the batteries from the device.
4.2. Using an mains adapter (special accessory)
This blood pressure monitor can be operated with the Microlife mains adapter (output 6 V DC / 600 mA,
DIN plug).
a) Plug the plug into the socket at the back of the
instrument.
b) Plug the mains adapter into a 230 V or 110 V power
socket. Test that power is available by pressing the
O/I button.
Note:
• No power is taken from the batteries while the mains adapter is connected to the instrument.
• If the mains voltage is interrupted during the measurement (e.g. by accidental removal of the mains
adapter from the mains socket), the instrument must be reset by removing the plug from its socket and
re-inserting the connections.
• Please consult a specialist dealer if you have questions relating to the mains adaptor.

4.3. Cuff connection
Insert the cuff tube into the opening provided on the left
side of the instrument, as shown in the diagram.
4.4. Setting the time and date
This blood pressure monitor automatically records the time and date of each measurement. This is very
important information as blood pressure normally varies over the course of a day.
After new batteries have been inserted, the time/date display shows the following setting: 2000-01-01
00:00 O’clock. (year-month-day-time)
You must then re-enter the date and current time. For this, please proceed as follows (Example: Entering
(year-month-day-time) 2001-06-15 Time 09:30 O’clock):
1. Press the Time button for at least 3 seconds. The
display now indicates the set year, during which the
four characters blink.
2. The correct year can be entered by pressing the
MEMORY button. Once for each change.
(Example: 1 x press).
3. Press the Time button again. The display now switches
to the current date, during which the first character
(month) blinks.
Note:
Holding the button down speeds up the procedure.
4. The current month can now be entered by pressing
the MEMORY button. Example: pressing 6 x advances
6 months)
5. Press the Time button again. The last two characters
(day) are now blinking.
8
M
M

9
6. The current day can now be entered by pressing the
MEMORY button. (Example: 15 x presses advances
the day from the 1st to 15th)
7. Press the Time button again. The display now switches
to the current time, during which the first character
(hour) blinks.
8. The corresponding hour can now be entered by
pressing the MEMORY button. (Example: 9 x presses
advances from 0 hours to 9:00 )
9. Press the Time button again. The last two characters
(minutes) now blink.
10. The minutes can now be entered by pressing the
MEMORY button. (Example: 30 x presses advances
the time from 0 to 30 minutes)
11. Reading the set date:
After all settings have been entered, click the Time
button once. The date is briefly displayed and then
the time. The input is now confirmed and the clock
begins to run.
M
TIME
M
TIME
M

10
5. Carrying out a Measurement
5.1. Before the measurement
• Avoid eating, smoking as well as all forms of exertion directly before the measurement. All these
factors influence the measurement result. Try to find time to relax by sitting in an armchair in a quiet
atmosphere for about 5 minutes before measurement.
• Remove any garment that fits closely to your upper arm.
• Always measure on the same arm (normally left).
• Take measurements regularly at the same time of day, since blood pressure changes during the course
of the day.
5.2. Common sources of error
Note: Comparable blood pressure measurements always require the same conditions!
These are normally always quiet conditions.
• All efforts by the patient to support their arm can increase blood pressure. Make sure you are in a
comfortable, relaxed position and do not activate any of the muscles in the measurement arm during
the measurement. Use a cushion for support if necessary.
• If the arm artery lies considerably lower (higher) than the heart, an false reading will be obtained. Each
15 cm difference in height results in a measurement error of 10 mmHg!
• Cuffs that are too narrow or too short result in false measurement values. Selecting the correct cuff is
of extraordinary importance. The cuff size is dependent upon the circumference of the arm (measured in
the center). The permissible range is printed on the cuff. If this is not suitable for your use, please
contact your dealer.
Note: Only use clinically approved Microlife Cuffs!
• A loose cuff or a sideways protruding air pocket causes false measurement values.
• With repeated measurements, blood accumulates in the arm, which can lead to false results.
Consecutive blood pressure measurements should be repeated after a 1 minute pause or after the arm
has been held up in order to allow the accumulated blood to flow away.
5.3. Fitting the cuff
a) Push the cuff over the left upper arm so that the tube points in
the direction of the lower arm.
b) Lay the cuff on the arm as illustrated. Make certain that the
lower edge of the cuff lies approximately 2 to 3 cm above the
elbow and that the rubber tube leaves the cuff on the inner side
of the arm.
c) Tighten the free end of the cuff and close the cuff with the
Velcro.
d) The cuff should be snug on your upper arm, but not too tight. Any
clothing which restricts the arm (e.g. pullover) must be taken off.
e) Lay your arm on a table (palm upwards) so that the cuff is at the
same height as the heart. Make sure that the tube is not kinked.
2–3 cm
tube

11
Note:
If it is not possible to fit the cuff to the left arm, it can also be
placed on the right. However all measurements should be made
using the same arm.
5.4. Measurement mode selection
Clinical studies demonstrate taking multiple blood pressure readings and calculating an «average» is more
likely to determine your true blood pressure. This blood pressure monitor allows you to switch to the special
Microlife Average Mode – MAM – that automatically takes multiple readings!
MAM Mode:
a) If you would like to take a MAM measurement, please slide the
switch to the right toward no. 3.
b) MAM mode takes generally 3 measurements in succession and
calculates the result.
c) The « » symbol in the display indicates that the device is
set to the MAM mode.
Single mode:
a) If you would like to take single measurement, please slide the
switch toward no. 1.
b) Single mode only has 1 measurement.
5.5. Measuring procedure
After the cuff has been appropriately positioned, the measurement can begin:
a) Press the O/I button. The pump begins to inflate the cuff. The
rising pressure in the cuff is shown in the display.
b) After reaching the inflation pressure, the pump stops and the
pressure gradually falls. The cuff pressures are displayed. In
case that the inflation pressure is not sufficient, the monitor
automatically re-inflates to a higher level.
c) When the instrument detects a pulse, the heart symbol in the
display starts to flash and a beep is heard for every heartbeat.
d) A longer beep is sounded when the measurement has been
completed. The systolic, and diastolic blood pressures and pulse
rate now appear in the display.
e) The measurement results are displayed, until you switch the
device off. If no button is pressed for 5 minutes, the device
switches automatically off, to save the batteries.
f) When the device is set to MAM mode, generally 3 separate
measurements will take place in succession and calculates your
13
13
O/I
TIME
TIME
mmHg
TIME

detected blood pressure value. There will be 15 seconds resting time
in-between each measurement. A count down indicates the remaining
time and a beep will sound 5 seconds before the 2nd and 3rd readings
will begin. In case that the single data of each cycle differ too much
from each other, a fourth measurement is performed before the result
will be displayed. In rare cases the blood pressure is such unstable
that even after four measurements the data vary too much. In this
case «ERR 6» is shown and no result can be given.
If one of measurement causes an error message it is repeated.
5.6. Discontinuing a measurement
If it is necessary to interrupt a blood pressure measurement for any
reason (e.g. the patient feels unwell), the 0/I button can be pressed
at any time.
The device immediately lowers the cuff pressure automatically.
5.7. Memory – recall of measurements
This device automatically stores the last 99 measurements. By
pressing the MEMORY button, the number of stored measurements
is displayed (e.g. 30 set). By pressing again, the last measurement,
e.g. MR30 as well as previous 29 measurements (MR29, MR28,
…MR1) can be displayed one after the other. Data obtained in
MAM mode are indicated by a « » symbol.
30 sets of stored measurements – MR30: Value of the last measurement – MR29: Value of the measurement before MR 30
5.8.Memory– cancellation of all measurements
Attention!
Before you delete all readings stored in the memory, make sure you
will not need refer to the readings at a later date.
In order to delete all stored readings, depress the MEMORY button for
at least 7 seconds, the display will show the symbol «CL» and 3 short
beep sounds will be heard to indicate deletion of stored readings.
Note:
If your last stored measurement was taken in the MAM mode, you
will see the « » symbol approximately 3 seconds during the
deletion procedure. (The display will show this symbol during
deletion of all stored measurements, if the last measurement is
taken in the MAM mode).
12
O/I
M
1
MR
1
mmHg
MR
mmHg
MR
mmHg
MR
mmHg
MR
M

13
6. PC-Link Functions
This device can be used in connection with a persoanl computer (PC) running the Microlife Blood Pressure
Analyser (BPA) software. The memory data can be transferred to the PC by connecting the monitor via cable
with the PC.
6.1. Installation and Data Transmission
a) Insert CD into CD ROM drive of your PC. The installation will
start automatically. If not, please click on «SETUP.EXE»
b) Connect the monitor via cable with the PC – no need
to switch the device on.Three horizontal bars will
appear on the display and last for 3 seconds.
c) The bars will then flash to indicate that the
connection between computer and device is successfully made.
As long as the cable is plugged, the bars will keep flashing and
buttons are disabled.
During the connection, the device is completly controlled by the
computer. Please refer to the «help» file for software instructions.
7. Error Messages/Malfunctions
If an error occurs during a measurement, the measurement is
discontinued and a corresponding error code is displayed.
(Example: Error no. 1)
* Please consult your doctor, if this or any other problem occurs repeatedly.
Error No. Possible cause(s)
ERR 1 The systolic pressure was determined but afterwards the cuff pressure fell below 20 mmHg.
The tube may have become unplugged after the systolic blood pressure was measured.
Further possible cause: No pulse has been detected.
ERR 2 Unnatural pressure impulses influence the measurement result. Reason: The arm was moved
during the measurement (Artefact).
ERR 3 Inflation of the cuff takes too long. The cuff is not correctly seated or the hose connection is
not sealed.
ERR 5 The measured readings indicated an unacceptable difference between systolic and diastolic
pressures. Take another reading following directions carefully. Contact you doctor if you
continue to get unusual readings.
ERR 6 Single data differ too much during MAM mode even after 4 cycles. No average result can be
displayed.
HI The pressure in the cuff is too high (over 300 mmHg) OR the pulse is too high (over 200 beats
per minute). Relax for 5 minutes and repeat the measurement.*
LO The pulse is too low (less than 40 beats per minute). Repeat the measurement.*

14
Other possible malfunctions and possible solutions – If problems occur when using the device, the
following points should be checked and if necessary, the corresponding measures are to be taken:
☞Further information
The level of blood pressure is subject to fluctuations even in healthy people. It is important to compare
measurements taken under the same conditions and at the same time of day. (Quiet conditions)!
If you have any questions regarding the use of this blood pressure monitor, please ask your dealer or
pharmacist for the Microlife Service representative in your country. The Microlife Service Team will be
happy to help you. Never attempt to repair the instrument yourself!
Any unauthorized opening of the instrument invalidates all guarantee claims!
Malfunction Remedy
The display remains empty when the
instrument is switched on although the
batteries are in place.
1. Check whether the batteries are installed with the correct
polarity and correct if necessary.
2. If the display is unusual, remove the batteries and then
exchange them for new.
The pressure does not rise although the
pump is running.
• Check the connection of the cuff tube and connect properly
if necessary.
The device frequently fails to measure the
blood pressure values, or the values
measured are too low (too high).
1. Fit the cuff correctly on the arm.
2. Before starting the measurement make sure that the cuff is
not fitted too tightly and that there is no rolled-up sleeve
exerting pressure on the arm above the measuring position.
Take off articles of clothing if necessary.
3. Measure the blood pressure again in complete peace and
quiet.
Every measurement results in different
values although the device functions
normally and the values displayed.
• Please read the following information and the points listed
under «Common sources of error». Repeat the
measurement.
The blood pressure values measured differ
from those measured by the doctor.
• Record the daily development of the values and consult
your doctor about them.

15
8. Care and Maintenance, Recalibration
a) Do not expose the device to either extreme temperatures,
humidity, dust or direct sunlight.
b) The cuff contains a sensitive air-tight bubble. Handle the
cuff carefully and avoid all types of straining through
twisting or buckling.
c) Clean the device with a soft, dry cloth. Do not use gasoline,
thinners or similar solvents. Carefully remove spots on the
cuff with a damp cloth and soapsuds. Do not wash the
cuff in a clothes or dishwasher!
d) Handle the tube carefully. Avoid stress from pulling,
pinching and sharp edges.
e) Do not drop the instrument or treat it roughly in any way.
Avoid strong vibrations.
f) Never open the device! This can negatively impact the
calibration! (accuracy)
Periodical re-calibration
Sensitive measuring devices must be checked for accuracy from time to time. We recommend a periodical
inspection of your device by an authorized microlife dealer every 2 years.
Your factory authorized Microlife dealer would be pleased to provide more information regarding
calibration.
Gasoline

16
9. Guarantee
This blood pressure monitor is guaranteed for 3 years from date of purchase. This guarantee includes the
instrument and the cuff. The guarantee does not apply to damage caused by improper handling, damage
from leaking batteries, accidents, not following the operating instructions or alterations made to the
instrument by third parties.
The guarantee is only valid upon presentation of the guarantee card filled out by the dealer.
Name and company address of the responsible dealer:
10. Reference to standards
The stipulations of the EU-Guidelines 93/42/EWG for Medical Products Class IIa have been fulfilled.
Device standard: Device corresponds to the requirements of the European standard for
non-invasive blood pressure monitor
EN1060-1 / 12:95
EN1060-3 / 09:97
EN1060-4
US standard:
ANSI / AAMI SP10, NIBP - requirements
Electromagn. compatibility: Device fulfills the stipulations of the European standard EN 60601-1-2

17
11. Technical Specifications
Technical alterations reserved!
12. www.microlife.com
Detailed user information about our products as well as services can be found at www.microlife.com.
Weight: 503 g (with batteries)
Size: 118 (W) x 177 (L) x 77 (H) mm
Storage temperature: –20 to +50 °C
Humidity: 15 to 90% relative humidity maximum
Operation temperature: 10 to 40 °C
Display: LCD-Display (Liquid Crystal Display)
Measuring method: oscillometric
Pressure sensor: capacitive
Measuring range:
SYS/DIA:
Pulse:
30 to 280 mmHg
40 to 200 beats per minute
Cuff pressure display range: 0–299 mmHg
Memory: Automatically stores the last 99 measurements
Measuring resolution: 1 mmHg
Accuracy: Pressure within ± 3 mmHg
Pulse ± 5 % of the reading
Power source: DC 6 V / 600 mA
a) 4 dry cells (batteries) UM-3, size AA, 1.5 V
b) mains adaptor 6V DC 600 mA (optional)
Accessories: Medium cuff (AC-1-M) for arm circumference 22–32 cm
or
Large cuff (AC-1-L) for arm circumference 32–42cm
