Microlife BP3GY1-2N User manual

Premium
Blood
Pressure
Monitor
INSTRUCTION MANUAL
QUE S TION S ? 1 -8 0 0 -5 6 8 -4 1 4 7
Model # BP3 GY1 -2 N

1
Important Product and Safety Information
Follow Instructions for Use. This document provides
importantproductoperationandsafetyinformationregarding
this Blood Pressure Monitor. Please read this document
thoroughly before using the device and keep for future
reference.
This blood pressure monitor is an automatic digital blood pressure measur-
ing device for use by adults,on the upper arm athome or in the doctor’s
office.Itenablesaveryfastandreliablemeasurement ofthe systolicand
diastolic blood pressure, as well as the pulse rate, by way of the oscillo-
metric method during cuff inflation. This device detects the appearance of
irregularheartbeatsduringmeasurement andprovides awarning signal
when the irregular heartbeat is detected. The device can be connected via
Bluetooth to a smart mobile device running the App.
This blood pressure monitor IS intended to be used:
• For self-measurement/monitoring of blood pressure and pulse in adults;
whereasthepersonbeing measuredmay be theuser/operator ofthe
device.
• Within a home healthcare environment.
• Withacufflocated upontheuser’supperarm;½inchabovethe elbow
over the artery as indicated on the cuff.
This blood pressure monitor IS NOT intended for use with:
• Pregnancy
• Preeclampsia
• Children under12
• Neonatal patients
WARNING –Potentially hazardous situation that if not
avoided may result in serious injury or death.
• Self-measuring means monitoring, not diagnosis or treatment.Unusual
valuesmustalwaysbe discussedwithyourdoctor. Undernocircum-
stancesshouldyouindependentlyalterthedosagesofanydrugs
prescribed by your physician.
• Consultyourphysicianbefore usingthisdeviceif any of thefollowingor
similarconditionsarepresent:arrhythmiassuchasatrialor ventricular
prematurebeatsoratrialfibrillation,arterialsclerosis,poorperfusion,
diabetes, age, pregnancy, preeclampsia, renal diseases. Motion during

2
measurement, including trembling or shivering may affect the measurement.
• Thoughnotfor usewithchildrenunder12,ensurethatanychildren
aroundthisdevicearesupervised;somepartsaresmallenoughtobe
swallowedandanypresenttubesorcablesmayprovideariskof
strangulation.
• Ensurethe cuff tubing is notkinkedduringuseas harmful injury may
occurduetothe effectofbloodflow interferencecaused by highpressure
in the cuff not releasing.
DO NOT:
 Use thisdeviceifyouthinkitisdamagedor anythingappearsunusual
(e.g. sporadic operation, open packaging upon purchase).
 Use the displayed pulse for checking the frequency of heart pacemakers
as this device is not suitable for this action.
Open/modify this device; inaccuracy and/or harmful injury may result.
 Conduct many frequent measurements as this may result in harmful
injury due to blood flow interference.
 Place the Cuff over a wound as this may cause further injury.
 Place and pressurize the Cuff over/near any present intravascular access
or therapy, or arteriovenous shunt, as this may cause blood flow interfer-
ence and result in harmful injury.
 Place and pressurize the Cuffover alimbnear theside ofamastectomy
as this may cause harmful injury.
 Use the Blood Pressure Monitor on a limb simultaneously with other medical
equipment on the same limb due to possible interference with such medical
equipment.
 MaintainpressureintheCuffappliedtothelimbforaprolongedamount
of time.Ensure that circulation in the limb is not impaired by checking
circulation if prolonged/repeated exposure to pressure occurs.
 Service the device when being used orwhen power is supplied. When
thedeviceisnot inuse andpoweris removed,cuffassembly,batteries
andacadapter (if applicable)may be replacedby theuserwithMicrolife
suppliedreplacements.No other parts/components are accessible.
CAUTION –Potentially hazardous situation that if not avoided
may result in minor/moderate injury, property damage, and/or
damage to the device
• Thisdevice contains sensitive electronics components. Avoidstrong

3
electrical or electromagnetic fields in the direct vicinity of the device
(e.g., mobile telephones, microwave ovens). These can lead to temporary
impairment of the measuring accuracy. Move the device to another
location if interference is determined.
• When not using the Blood Pressure Monitor for extended lengths of
time,removethebatteriesto avoidpotentialbattery leakageand
damage to the monitor.
• Whenreplacingthebatteries,ensureallthebatteriesarereplaced
simultaneously toavoidbattery damageandpotentialdamagetothe
monitor.Microlife USA does not recommend using rechargeable batteries.
• To avoid inaccurate measurements and to lessen any discomfort from
Cuff pressure, ensurethe Cuff isplaced correctly on the limb and fits
correctly when snug (not tight), as indicated by markings with the Cuff.
• Consult your physician in cases of frequent irregular heartbeat
detections.
• This Risk Indicator feature is provided in order to help you understand
yourpotentialbloodpressurerisk.However,thisfeatureisneither a
diagnosisnorasubstituteforamedicalexamination.Itisimportantto
consult with your physician to determine your risk.
DO NOT:
 Drop this device or expose it to strong vibrations; sensitive components
may be affected resulting in inaccuracies and/or operational issues.
 Use the Blood Pressure Monitor outside of its specified operation
temperature and humidity rating, or if stored outside of its specified
storage temperature and humidity rating. Avoid storage in direct
sunlight.
 Use this device in a moving vehicle; inaccurate measurements may
result.
 Use thirdparty accessories.Only useMicrolifeauthorized accessories,
suchascuffsorACadapters,asthosenotapprovedforusewiththe
device may provide inaccurate measurements, injury, and/or damage the
device.

4
STANDARDS
In addition to the standards stated in the Instruction Manual:
• This medical device is compliant with medical device and non-invasive
blood pressure monitor standards IEC 60601-1, IEC 60601-1-2, IEC
60601-1-11, and AAMI/ANSI/IEC 80601-2-30, and
• Electromagnetic standards IEC 60601—1-2 along with FCC Part 15, and
• Clinical Testing per standard ISO 81060-2:2013 was conducted on blood
pressure device using the same measurement technology.
Please note: According to international standards, your monitor should be
checked for accuracy every 2 years.
TYPE
IP20 Protected against solid foreign particles with a diameter ofmore
than 12.5 mm, no protection against water. Keep Dry.
Type BF Applied Part
Batteries and electronic instruments must be disposed of in accordance
with the locally applicable regulations, not with domestic waste.
Expected Life
Monitor 5 Years
Cuff 2 Years
Trademark Usage:
Apple, the Apple logo, iPad, and iPhone are trademarks of Apple Inc.,
registeredintheU.S.andothercountries.AppStoreis aservicemark of
Apple Inc.
Android and Google Play are both trademarks of Google Inc.
TheBluetooth®Smartwordmarkandlogosareregisteredtrademarks
owned by Bluetooth SIG, Inc. and any use of such marks in this Blood
Pressure Monitor is under license. Other trademarks and trade names are
those of their respective owners.

5
Federal Communications Commission (FCC) Statement
15.21
You are cautioned that changes or modifications not expressly approved by
thepartresponsibleforcompliancecouldvoidtheuser’sauthorityto
operate theequipment.
15.105(b)
This equipment hasbeentested andfoundtocomply with the limits for a
ClassB digitaldevice,pursuanttopart15oftheFCCrules.These limitsare
designed to provide reasonable protection against harmful interference in a
residential installation.
This equipment generates uses and can radiate radio frequency energy and,
ifnotinstalledandusedinaccordancewiththeinstructions,maycause
harmful interference to radio communications. However, there is no
guaranteethatinterferencewillnotoccurinaparticularinstallation.Ifthis
equipment does cause harmful interference to radio or television reception,
whichcanbe determinedby turningtheequipment offand on,the user is
encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna.
-Increase the separation between the equipment and receiver.
-Connecttheequipment intoanoutletonacircuitdifferentfromthatto
which the receiver is connected.
-Consult the dealer or an experienced radio/TV technician for help.
Thisdevicecomplieswithpart15of theFCCRules.Operationissubjectto
the following two
conditions:
1) this device may not cause interference and
2) this device must accept any interference, including interference that may
cause undesired operation of the device.

6
Premium Automatic Blood Pressure Monitor
Instruction Manual
Table of Contents
1. Introduction
1.1. Your automatic blood pressure monitor
1.2. Diabetes validation
2. Components of your blood pressure monitor
2.1. Blood pressure monitor
2.2. Blood pressure cuff
3. How do I get started?
3.1. Screen film
3.2. Inserting the batteries
3.3. Power switch / screen lock
3.4. Using the interactive touch screen
3.5. Setting the date and time
3.6. Select the user
3.7. Selectthemeasuringmode: standardor Microlife Averaging Mode
3.8. Microlife Averaging Mode
3.9. Connecting the cuff and monitor
3.10.UsingtheACpoweradapter
4. How do I take ameasurement?
4.1. Preparing to take a measurement
4.2. Common errors
4.3. Using the cuff
4.4. Taking a measurement
4.5. Memory: Reviewing readings
4.6. Stopping a measurement
4.7. Hypertension risk indicator
4.8. Irregular heartbeat detector
4.9. Battery change indicator
5. Bluetooth functions and application (App)
5.1. Bluetooth® icon indicator (on monitor)
5.2. iOS devices
5.3. Android OS Phones
6. Error messages/troubleshooting
7. How is blood pressuremeasured?
7.1. What is blood pressure, and why does it fluctuate?

7
7.2. Measurement Guidelines
7.3. What can I do to change my blood pressure?
8. Careand maintenance
9. Limited warranty
10. Technical specifications
11. How to contact us

8
1. Introduction
1.1. Your Automatic Blood Pressure Monitor
Thank you for purchasing a fully automatic blood pressure monitor. Your
monitor is designed to provide fast and reliable digital readings of your
pulse, and systolic / diastolic blood pressure using the oscillometric method
on your upper arm. It offers clinically proven accuracy and has been
designed to be user friendly.
If you have additional questions regarding blood pressure measurements
please contact Microlife Customer Service at 1-800-568-4147 or contact
your doctor.
1.2. Diabetes validation
Microlife’s commitment to disease-state management has led to our
clinicalvalidationforusewithdiabetes. Thisisaworldwidefirstthat
reinforces our commitment to quality, accuracy and meaningful innovation.

9
2. Components of your blood pressure monitor
2.1. Measuring unit
Cuff Socket
(yellow)
Hypertension
Risk Indicator
Memory
User Switch
Start, Stop,
Enter
Date/Time
AC Adapter Port
MAM mode
switch
Select 1 or 3
Measurements
Power, Screen Lock

10
START
STOP
Systolic
Diastolic
Pulse
User 1 & 2
Guest
Bluetooth
Battery Indicator
Forward
Backward
Memory
Enter
MAM
Irregular Heartbeat
Pause
Heartbeat
Error 2
Error 3

2.2. Wide Range Cuff:
For arm circumference 8.7” - 16.5”(22 cm -42 cm)
Ifyou everneedto buy areplacementcuff,call
us toll-free at1-800-568-4147.
Anti-Slip Cuff:
Your wide range cuff is equipped anti-slip grips
that ease the process of correctly positioning the
cuff on your arm.
Cuff Sizing:
The proper fit is essential for accurate blood
pressure readings. The average arm circumference
forawomanis 11",andtheaverage foramanis
13". This cuff can accommodate arm circumferences
from 8.7" to 16.5" and fits most adults.
Armcircumferenceshouldbemeasuredwitha
measuringtapeinthemiddleoftherelaxedupper
arm.If thecuffistoosmall,call1-800-568-4147for
additional information.
Note:
• Do not force cuff connection into theopening.
• Makesurethecuffconnectionisnotpushedinto
the AC adapter port.
18”
16”
13”
12”
9”
medium M
L large
sure-fit
SF
S
F
+
su
re-fit
+

12
3. How do I get started?
3.1. Screen film
Thereisaprotectivepieceofstaticfilmcoveringthe
monitor’sscreen.Pleaseremoveitbeforeuse.
3.2. Inserting the batteries
After you have unpacked your device, insert the batter-
ies.Thebatterycompartmentislocatedonthebackof
the device.
a) Remove the battery cover.
b) Insertthebatteries(4x sizeAAA1.5 V), observ-
ing the indicated polarity.
c) Ifa battery warningappears inthedisplay,the
batteries are discharged and must be replaced.
Attention!
• Afterthe lowbattery indicator appears, the
device won’t function until the batteries have
been replaced.
• PleaseuseAAA1.5Vbatteriesandreplacethem
all at the same time.
• Ifthebloodpressuremonitorisnotusedforlong
periods,removethe batteriesfromthedevice.
3.3. Power switch / screen lock
To activate your monitor, push the switch on
the right hand side of the monitor to the
unlocked position.
Low Battery Indicator
unlocked
locked

13
3.4. Using the interactive touch screen
This monitor features an interactive screen
with 2 touch zones which operate similarly to
traditional buttons, but require only a light
touch of the finger to operate.
The following functions are made easier
through the interactive touch screen:
• Setting time and date
• Scrolling through memories
• Selecting the user
• Starting/stopping the blood pressure
measurement
3.5. Setting the date and time
1. Afterthenewbatteriesareactivatedand
the monitor is unlocked, the year number
flashesinthedisplay.Youcanadvance
theyearbypressingtheplusorminus
icon.To confirmandthensetthemonth,
press enter.
2. Youcannowsetthemonthusingthe
minusandplus.Toconfirmandthenset
the day, press enter.
3. Please follow the instructions above to
set the day,hour and minutes.
4. Once youhave set the lastminute and
pressedenter,thedateandtimeareset
and the time isdisplayed.
5. If you wantto change the date and time,
pressandholdthetimezonedownfor
approximately 3 seconds until the year
numberstartstoflash.Nowyoucan enter
the new values as described above.
6. Tobypasssettingdateandtime,pressthe
time.
Touch zones
Enter
Enter
TIM E P M

14
Guest Mod
3.6. Select the user
Thisbloodpressuremonitorisdesignedto
store120measurementsforeachoftwousers
Memories arenot storedinguest mode.
e
Before taking a measurement, be certain that
the correct user has been selected.
a) Withthemonitorunlocked,pressandholdthe usericon,thenrelease.
b) The user icon will begin to blink. Tap again to change users.
c) To confirm your selection wait 3 seconds, or press STOP.
3.7. Select measuring mode: standard or
Microlife Averaging Mode (MAM)
Thisinstrumentenablesyoutoselecteitherstandard
(singlemeasurement) or measurement averagingmode
(automatic triple measurement).
a) ToselectStandardmode, pushtheswitchon theside
of the monitor to Position"1."
b) ToselectAveragingmode,push theswitchto Position
"3."Notethe"MAM"iconwillilluminateonthescreen.
Ifyouselect1,thenonlyonemeasurementwillbetaken.
Ifyou select 3,the unitwill inflateanddeflatethreetimes
resulting in one final averaged measurement.
3.8. Microlife Averaging Mode (MAM)
• In Microlife Averaging Mode (MAM), three measure-
ments are automatically taken in succession and the
resultisthenautomaticallyanalyzedanddisplayed.
Because your blood pressure constantly fluctuates,a
resultdetermined inthisway is morereliable than
one produced by a single measurement.
• After pressing the STOP/START button the selected
MicrolifeAveragingModeappearsin thedisplay as
the MAM symbol.
• The bottom, right-hand section of the display shows
a1, 2 or 3to indicate which of the3 measurements
is currently being taken.

15
3.9. Connecting the cuff and monitor
Insert the yellow cuff tube connector into
the yellow socket on the left side of the
instrument.
If your cuff connector is another color, please
contact customer service as additional steps
areneededtoobtainanaccuratereading.
3.10. Using the AC power adapter
You may also operate this monitor using the
included AC adapter. Use only the included
AC adapter to avoid damaging the unit.
a) EnsurethattheACadapterandcableare
not damaged.
b) Plug the adapter cable into the AC
adapter port on the right side of monitor.
c) Plug the ACadapter into a 110V power
socket (U.S. or Canada).
d) Testthatpower isavailable by pressing
the STOP/START button.
Note:
• Nopoweristakenfromthebatteries
whiletheACadapter isconnected tothe
instrument.
• If the power is interrupted during a
measurement (e.g., by removal of the
adapter from the wall socket), the instru-
ment must be reset by removing the plug
from the instrument.
Ifyou haveany questionsregarding theAC
adapter,call us at 1-800-568-4147.

16
4. How do I take a measurement?
Please note: You should always be seated before and during
measurement.
4.1. Preparing to take a measurement
• Avoideatingandsmokingas wellasallformsof exertiondirectly
before measurement. These factors influence the measurement result.
Find time to relaxby sittingin an armchairin aquiet atmosphere for
about 5 minutes before yourmeasurement.
• Remove any garment that fits closely to your upperarm.
• Always measure on the same arm (normally left).
• Compare measurements at the same time of day, since bloodpressure
changesduringthecourseoftheday(asmuchas20–40mmHg).
4.2. Common errors
Note: Comparable blood pressure measurements always require
the same conditions. Conditions should always be quiet.
• Alleffortsby theusertosupportthearmcanincreasebloodpressure.
Makesureyouarein acomfortable,relaxedpositionanddonotflex
any of the muscles in the measurement arm during the measurement.
Use a cushion for support if necessary.
• Ifthe arm artery liesconsiderably lower orhigherthantheheart,an
erroneouslyhighorlowbloodpressurewillbemeasured.Each15cm
(6”)differenceinheightbetweenyourheartandthecuffresultsina
measurement error of 10 mmHg.
• Cuffs that are too narrow or too short result in false measurement
values. Selecting the correct cuff is extremely important. Cuff size is
dependent upon the circumference of the arm (measured in the center).
The permissible range is printed on the cuff. If this is not suitable for
your use, please call 1-800-568-4147.
• Aloosecuffor asidewaysprotrudingairpocketcausesfalsemeasure-
ment values.
• With repeated measurements, blood accumulates in the arm, which
canleadtofalseresults.Consecutivebloodpressuremeasurements
shouldberepeated aftera1minute pauseorafteryourarmhasbeen
heldupinordertoallowthe accumulated bloodtoflowaway.

17
4.3. Using the cuff
a) Pass the end of the cuff through the flat
metal ring so that a loop is formed. The
hookand loop material must befacing
outward. (Ignore this step if the cuff has
already beenprepared.)
b) Slidethecuff onto your upper left arm.
The rubber tube should be on the inside of
your arm extending downward to your
hand. Make certain the cuff lies approxi-
mately ½” (1 to 2 cm) above the elbow.
IMPORTANT: The red strip on the edge
of the cuff (Artery Mark) must lie over the
artery which runs down the inner side of
the arm.
TIP: Align red artery mark to pinky finger.
c) Tosecure the cuff, wrap itaroundyour
arm and press the hook and loop material
together. Check the position of the green
SIZING SEAM on the cuff. Ensuregreen
sizing seam overlaps green sizerange bar.
d) There should be little free space between
the arm and the cuff. Youshould beable
to fit 2 fingers between your arm and the
cuff. Clothing must not restrict the arm.
Any piece of clothing which does must be
removed. Cuffs thatdon’tfit properly
result in false measurement values.
Measure your arm circumference if you
are not sure of proper fit.
8.7” - 16.5”
Brachial Artery
½
”

18
e) Layyourarmonatablesothecuffis at
thesameheightasyourheart.Makesure
yourarmisrelaxedandthetubeisnot
kinked.
f) Remain seated quietly for 5 minutes
before you begin the measurement.
Comment
Ifitisnotpossibletofitthecufftoyourleftarm,it
can also be placed onyour rightarm.However, all
measurements should be made using the samearm.
Comparable blood pressure measurements always
requirethesameconditions(relaxforseveral
minutesbeforeareading).
Cuff on
right arm

19
4.4. Taking a measurement
After the cuff has been appropriately positioned the
measurement can begin. Remain still during your
measurement, do not flex muscles.
a) Remain seated quietly for 5 minutes beforeyou
begin the measurement.
b) Press the START/STOP button. After the system
check,themonitordisplays OKandthepump
beginstoinflatethecuff.Onthedisplay,the
increasingcuffpressureiscontinually shown.
c) After automatically reaching an individual
pressure, the pump stops andthe pressure will
release.Thecuffpressureisdisplayedduringthe
measurement.
d) When the device has detected your pulse, the
heart symbol in the display begins to blink.
e) When the measurement has been concluded, the
airwill automatically release from the cuff.The
measuredsystolicanddiastolicbloodpressure
values, as well as the pulse, are now displayed.
f) The measurement results are displayed until you
switchthedeviceoff. Ifnobutton ispressedfor1
minute,the device switches off automatically.
g) When the unit is set to the MAM (Microlife
Averaging Mode) setting, 3 separate measure-
ments will take place in succession, after which
your result is calculated and displayed as a single,
averaged measurement (individual results are not
displayed). There is a 15 second resting time
between each measurement. A count-down
indicatesthe remainingtimebetweenmeasurements.
If one of the measurements causes an error
message,itwillberepeated onemoretime.Ifany
additionalerroroccurs,themeasurementwillbe
discontinued and error code displayed.
Pumping
Pressure
Measuring
Systolic
Diastolic
Pulse
Measurement
Complete
