Micropack FS301 User manual

FS301
FLAME
SIMULATOR
SAFETY & TECHNICAL
MANUAL
Ref: 2301.6042
ECN:
4431

HELP US TO HELP YOU
Every effort has been made to ensure the accuracy in the contents of our documents; however,
Micropack (Engineering) Ltd can assume no responsibility for any errors or omissions in our
documents or their consequences.
Micropack (Engineering) Ltd would greatly appreciate being informed of any errors or omissions
that may be found in our documents. To this end we include a form, given in Appendix A, for
you
to photocopy, complete and return to us so that we take the appropriate action. Thank you.
CONTENTS
TABLE
OF
This document is strictly private and confidential, reproduction without Micropack approval is prohibited. © Micropack Engineering Ltd, 2015
FS301 Flame Simulator FS301 Safety and Technical Manual 2
Ref: 2301.6042 Rev: 2.3 ECN: 4553
1
Safety Instructions 3
1.1 Warnings 3
1.2 Cautions 3
1.3 Important Notices 3
2
Introduction 4
2.1 Features 4
2.2 Flame Simulator Enclosure 4
3
Operating Instructions 5
4
Maintenance and Testing 6
4.1 Routine 6
4.2 Battery Charging 6
5
Fault Finding 7
5.1 Diagnostics 7
5.2 Replacement and Repair 7
6
Technical Specification 8
6.1 Electrical Specification 8
6.2 Mechanical Specification 8
6.3 Environmental Specification 8
6.4 Certification and Approvals 9
Appendix A Help us to help you 10

1
Safety Instructions
For the correct and effective use of this equipment, to maintain safety and avoid hazards
it is essential that you read and understand these instructions fully and act accordingly
BEFORE operating this equipment.
1.1
Warnings
• This equipment is certified and intended for use in potentially hazardous areas.
• For installations in North America the National Electrical Code (NEC) should be strictly
observed.
• Where appropriate local or national regulations should be used.
• The enclosure lid and body should always be fully tightened and locked into position before
energising the equipment.
• Do not open the enclosure in the presence of a flammable atmosphere.
• All permits and proper site procedures and practices must be followed.
• Repair of equipment should never be performed by non-trained personnel.
1.2
Cautions
• Use only approved parts and accessories with this equipment.
• Do not attempt to replace the window as the glass and the front cover are
individually matched pairs to meet the stringent requirement of the Hazardous area
certification.
• The threaded portions of the detector are flame paths. These threads and the flame
paths around the window are not to be repaired.
• To maintain safety standards, regular maintenance should be performed by qualified
personnel.
1.3
Important Notices
• Pay attention to the guidelines given throughout this document.
• If in any doubt ask your local sales representative or contact Micropack (Engineering) Ltd.
• Micropack (Engineering) Ltd takes no responsibility for use of its equipment if this is not in
accordance with the appropriate issue and/or amendment of the manual.
• Micropack (Engineering) Ltd reserve the right to change or revise the information contained
herein without notice and without obligation to notify any person or organisation of such
action.
micropack.co.uk
PAY PARTICULAR ATTENTION TO ALL SAFETY WARNINGS,
CAUTIONS AND IMPORTANT NOTICES
FS301 Flame Simulator FS301 Safety and Technical Manual 3
Ref: 2301.6042 Rev: 2.3 ECN: 4553

2
Introduction
The Micropack FS301 Flame Simulator is used to test the correct operation of Micropack
FDS300 and FDS301 Visual Flame Detectors.
The simulator has been designed specifically to enable long range testing of FDS300 and
FDS301 Visual Flame Detectors. The device has been designed for hand held use by a single
operator. The device is a completely self contained, portable unit. A single charge is
sufficient to test up to fifty Flame Detectors.
The simulator has been designed specifically for use in the extreme marine environments
experienced offshore.
2.1
Features
• Long Range – The simulator can reliably operate FDS 300 and FDS301 Visual Flame Detectors
at distance between 3m & 8m.
• Portable – The flame simulator is a portable hand held unit designed for single operator
operation.
• Robust and Reliable – The flame simulator has been designed for extreme offshore
conditions.
• Reduced Maintenance Costs – Reduces the need for scaffold or ladder access to the
detector.
2.2
Flame Simulator Enclosure
The flame simulator electronics are housed in an enclosure which is certified for use in
hazardous areas. For the exact certification and conditions of use
see certification label on the
device, or the example drawing below:
The enclosure comprises of two enclosure covers (one with a faceplate window), the enclosure
body (with certification label) and fixing collars to connect the enclosure body and covers
together.
This document is strictly private and confidential, reproduction without Micropack approval is prohibited. © Micropack Engineering Ltd, 2015
FS301 Flame Simulator FS301 Safety and Technical Manual 4
Ref: 2301.6042 Rev: 2.3 ECN: 4553

3
Operating Instructions
The flame simulator operation is extremely simple. Once aligned, simply press the button,
maintaining alignment, and wait for the detector to go into alarm. The flame simulator LED’s will
flash when energised, and the detector response time should typically be less than 10 seconds.
The switch is spring loaded and releasing the pressure from the switch will disconnect the power.
Charging Socket inside end cap
Pushbutton
The picture above shows the FS301 flame simulator. The on/off pushbutton is shown to the
underside of the flame simulator. The charging socket is on the reverse end from the faceplate
window, inside the end cap. The FS301 flame simulator will operate for a maximum of 60 seconds
before timing out.
micropack.co.uk
FS301 Flame Simulator FS301 Safety and Technical Manual 5
Ref: 2301.6042 Rev: 2.3 ECN: 4553

4
Maintenance and Testing
4.1
Routine
There is no set maintenance routine for the flame simulator due to the simplicity of the device.
All internal maintenance or repair must be conducted by Micropack (Engineering) Ltd.
Therefore, routine maintenance is simply limited to ensuring the faceplate window is kept clean
and that no damage to the integrity of the enclosure or flame paths is caused.
4.2
Battery Charging
A charging unit is supplied with the flame simulator. Simply remove the reverse cover to reveal
the charging socket, and conduct the following:
•
•
•
•
•
•
Connect plug to flame simulator.
Connect Charger unit to mains socket (adaptors supplied for various world locations).
Switch on mains supply.
Wait until red LED (on charger unit) stops flashing.
Press yellow button on charger unit.
Wait until charger LED is green.
The yellow button causes the charger unit to completely discharge the battery pack prior to re-
charging. Unless this is done the battery pack will retain memory charge and charging capability
will be limited. Full re-charge will take between 3 and 10 hours.
A “fast” charge may be applied by simply not pressing the yellow button – however, as indicated
above, battery memory effects will result in the battery pack not maintaining a full charge and
limit the battery life. Charging in this way will take approximately 1 hour. Eventually, battery life
will be so limited that a full discharge / recharge cycle will be required.
This document is strictly private and confidential, reproduction without Micropack approval is prohibited. © Micropack Engineering Ltd, 2015
NOTE: BATTERY CHARGING SHOULD NEVER TAKE PLACE WITHIN A HAZARDOUS AREA.
FS301 Flame Simulator FS301 Safety and Technical Manual 6
Ref: 2301.6042 Rev: 2.3 ECN: 4553

5
Fault Finding
5.1
Diagnostics
Fault finding by personnel other than Micropack employees is prohibited and non-compliance
of this will invalidate the warranty. If the flame simulator fails to operate there are two simple
causes:
(a)
(b)
The flame simulator batteries need recharged, or
The unit is faulty and needs to be returned to Micropack.
5.2
Replacement and Repair
The flame simulator contains no user serviceable parts.
micropack.co.uk
FS301 Flame Simulator FS301 Safety and Technical Manual 7
Ref: 2301.6042 Rev: 2.3 ECN: 4553

6
Technical Specification
6.1
Electrical Specification
6.2
Mechanical Specification
6.3
Environmental Specification
This document is strictly private and confidential, reproduction without Micropack approval is prohibited. © Micropack Engineering Ltd, 2015
Parameter Units Min Max Comment
Operating Temperature °C -10 +50
Charging Temperature °C 0+45
Relative Humidity % RH 0100 Non Condensing
Parameter Units Value Comment
Enclosure
Overall Dimensions mm 100 Diameter x 200 Length
Shipping Weight Kg 2.5
Material LM25 Alloy
Coating Colour Red Epoxy Coated Finish
Pushbutton mm 1 x M25
Ingress Protection IP 66
Transit Case
Overall Dimensions mm 410L x 200H x 175W
Shipping Weight kg 4.5
Battery Pack Charger
4 cells 1.2 V each 100-240 Vac
Current 2.6 A 660mA Max
Capacity 1.8 Ahr 50/60Hz
Fast charge 1 hour
Full discharge / charge 10 hours
FS301 Flame Simulator FS301 Safety and Technical Manual 8
Ref: 2301.6042 Rev: 2.3 ECN: 4553

micropack.co.uk
FS301 Flame Simulator FS301 Safety and Technical Manual 9
Ref: 2301.6042 Rev: 2.3 ECN: 4553
Certification and Approvals
Parameter Authority/Standard Approval Certificate
Hazardous Area Certification EN 60079-1:2014 Ex II 2 (2) G Ex db
(op is T6 Gb) IIC T6 Gb IP66
FM09ATEX0034
Explosive Atmospheres EN 60079-28:2007 Ex II 2 (2) G Ex db
(op is T6 Gb) IIC T6 Gb IP66
FM09ATEX0034
6.4

Appendix A -
Help us to help you
TO:
QA Department
Micropack (Engineering) Limited
Fire Training Centre
Schoolhill, Portlethen
AB12 4RR
Tel: [phone]
Fax: [phone]
Email: [e-mail]
From:
Tel:
Fax:
Email:
I suggest the following corrections/changes be made to Section ……………
Marked up copies attached (as appropriate): Yes/No
Please inform me of the outcome of this change: Yes/No
For Micropack (Engineering) Limited :
Action by: Date:
Response: Date:
