Introduction
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 3
1. Introduction
1.1 About this manual
This manual provides supplementay information for the AutroFlame
X33AF multispectrum IR flame detector.
Digital communication with the X33AF allows the operator to monitor
the status of the detector, determine factory settings, adjust field
settings, and initiate field tests. This addendum provides guidance for
establishing HART communication, and describes the HART menu
structure when using the X33AF with a HART Handheld
Communicator, a PC, or other process interface device that supports
DDL.
1.2 The reader
This handbook is intended for Autronica personnel authorized to
install the AutroFlame X33AF multispectrum IR flame detector.
NOTE
A minimum level of understanding with regard to the
operation and navigation of the HART Communicator is required.
1.3 Other reference documents
For further information about the AutroFlame X33AF multispectrum IR
flame detector, refer to the following:
Manual Article no.
Datasheet 116-P-X33AF/CE
Handbook 116-P-X33AF/DE

Interconnecting the communicator with the detector
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 4
2. Interconnecting the
communicator with the detector
Point-to-Point Mode
The HART Communicator can connect to the X33AF at any wiring
termination point in the analog output signal loop. Connect the HART
communicator in parallel with the X33AF analog signal or load
resistor. The HART connections are non-polarized
IMPORTANT WIRING NOTE
The HART Communicator does not measure loop current directly, but
instead reads a voltage signal across a resistance (250 ohms) in the
loop. The recommended connection point is across the input
impedance of the signal receiver (PLC), which is a nominal 250 ohms.
See Figures 1 to 4. If testing/programming on a bench, a 250 ohm
load resistor must be used. See Figure 5.
Switch on the HART Communicator. If a device is found, the HART
Communicator displays the Main menu. If no device is found, check
the connections and verify the presence of a minimum of 250 ohms
load resistance in series in the loop.

Interconnecting the communicator with the detector
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 5
Figure 3—X33AF Detector Wired for Non-Isolated 4 to 20 mA
Current Output (Sinking)
Figure 2—X33AF Detector Wired for Isolated 4 to 20 mA
Current Output (Sourcing)
Figure 4—X33AF Detector Wired for Isolated 4 to 20 mA
Current Output (Sinking)
Figure 5—Wiring the X33AF for Benchtop Testing/Programming
Using HART Protocol
*Nominal input impedance of PLC = 250 ohms.
Maximum loop impedance including input impedance of PLC = 875 ohms.
Figure 1—X33AF Detector Wired for Non-Isolated 4 to 20 mA
Current Output (Sourcing)

Interconnecting the communicator with the detector
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 6
Multidrop Mode
Optical flame detectors are life safety devices and require the 4-20
mA loop for transmitting important detector status data. They should
not be used in conjunction with multidrop mode. If multidrop mode is a
requirement, the alarm and fault relay contacts must be connected
directly to the safety system or fire panel for signalling purposes.
NOTE
This addendum covers HART wiring only. Refer to the device
instruction manual for NFPA-72 compliant releasing wiring diagrams.

HART Device Description Language
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 7
3. HART Device Description
Language
The HART protocol incorporates a concept called the Device
Description Language (DDL) that enables all suppliers of HART
instruments to define and document their products in a single
consistent format. This format is readable by handheld
communicators, PCs and other process interface devices that support
DDL. DDL enables full interoperability of devices, regardless of
manufacturer, allowing full functionality from any HART device.
In the event that your Communicator does not establish
communications with the X33AF, ensure that the appropriate DDLs for
the X33AF have been programmed into your Communicator. To
review the DDLs programmed into your HART Communicator:
1. From the Main menu, access the Offline menu.
2. From the Offline menu, select New Configuration to
access the list of device descriptions programmed
into the HART Communicator.
3. Select Det-Tronics and review the list of models to
determine if the X33AF DDLs are installed in your
Communicator.
If the X33AF DDLs have not been programmed into the Memory
Module, you must use the generic interface built into your HART
Communicator.
The HART Communication Foundation manages a library of
Manufacturer Device Descriptions, which are distributed to
programming sites for inclusion in master devices. A complete listing
of the HCF DD Library is available for download in manufacturer and
device type sequence at www.ccsi.com/hart.

Detector Wiring
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 8
4. Detector Wiring
Refer to the X33AF instruction manual for complete instructions
regarding detector installation and wiring. However, note that the
device power consumption specifications for the HART model are
different than the standard model.
Power Consumption Specifications of X33AF Detector with HART
Communication
Without heater: 4.7 watts at 24 vdc nominal;
6.1 watts at 24 vdc in alarm.
5.5 watts at 32 vdc nominal;
7.4 watts at 32 vdc in alarm.
Heater only: 8 watts maximum.
Total power: 17 watts at 32 vdc with EOL resistor installed
and heater on maximum.
EOL resistor must be ceramic, wirewound type, rated 5 watts
minimum, with actual power dissipation not to exceed 1.5 watts.

HART Menu Structure
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 9
5. HART Menu Structure

X33AF Root Menu
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 10
6. X33AF Root Menu
When HART communication is established, the first menu displayed is
the X33AF Root menu:
When HART communication is established, the first menu displayed is
the X33AF Root menu:
1) Fire (Yes/No) Indicates “Y” if the device is in a fire alarm status —
analog output is at 20 mA, fire alarm relay is actuated and LED is red.
2) Fault (Yes/No) Indicates “Y” if a fault condition exists. Go to
“Device Info” and select “Status Info” to determine the nature of the
fault.
3) Device Info Menu Provides access to manufacturer and HART
information, current device status, factory settings, and history logs.
4) Command Menu This menu allows the operator to initiate a
manual Oi test and also to perform various reset/clear functions.
5) Device Setup Menu This menu allows various setup, configuration
and calibration functions.

Device Info Menu
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 11
7. Device Info Menu
This menu allows access to a variety of “read only” information.
1) General Info Menu Factory information.
2) HART Info Menu HART Specific Variables.
3) Status Info Menu Current operating status and/or diagnostic
information.
4) Detector Settings Factory settings relating to relay operation,
detector sensitivity and response.
5) History Menu Display log files: Alarm, Fault, General.

General Info Menu
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 12
8. General Info Menu
1) Manufacturer Det-Tronics.
2) Model X3301.
3) Serial Number Serial number of device.
4) Part Number Manufacturer’s part number for this device.
5) Manufactured Date Date of manufacture shown as XX/XX/XX
(month/day/year).
6) Snsr Fmwr Ver Firmware revision level of sensor module.
7) HART Fmwr Ver Firmware revision level of HART Interface Board
(HIB).
8) Real Time Clock Current time and date settings of real time clock.
9) Write Protect (Y/N) This indicates whether variables can be written
to the device, or whether commands that cause actions to be
performed in the device can or cannot occur.

HART Info Menu
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 13
9. HART Info Menu
1) Universal Rev HART universal revision.
2) Field Device Rev HART field device revision.
3) Final Asmbly No. A number that is used for identification
purposes, and is associated with the overall field device.
4) Tag Text that is associated with the field device installation. This
text can be used by the operator in any way.
5) Date Any date chosen by the operator to be used for any purpose.
6) Descriptor Text associated with the field device that can be used
by the operator in any way.
7) Message Text associated with the field device that can be used by
the operator in any way.
8) Num Req Preams HART specific synchronization messages.
9) HART PV Menu Display HART specific primary variable (PV)
items.
10) Condensed Status Device status condensed for HART handheld
display.

HART PV Menu
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 14
10. HART PV Menu
1) PV Unit Not implemented for X33AF.
2) PV Not implemented for X33AF.
3) PV SNSR Unit Not implemented for X33AF.
4) PV USL Not implemented for X33AF.
5) PV LSL Not implemented for X33AF.
6) PV MIN SPAN Not implemented for X33AF.
7) PV DAMP Not implemented for X33AF.
8) PV AO Analog Output. The value that tracks the Digital Value
representation, under normal operating modes.
9) PV AO ALRM TYP Not implemented for X33AF.
10) PV % RNGE Percent of Range. The variable that tracks the Digital
Value representation with respect to the range defined by the Lower
Range Value and Upper Range Value, for normal operating modes.
The units of this variable are always in percent.
11) PV XFER FNCTN Not implemented for X33AF.
12) PV RNGE Unit Not implemented for X33AF.
13) PV URV Not implemented for X33AF.
14) PV LRV Not implemented for X33AF.
15) PV SNSR S/N Not implemented for X33AF.

Condensed Status
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 15
11. Condensed Status
1) Xmtr Addstatus 0
Fire Alarm
Oi Cal Active
Manual Oi Active
Warmup
2) Xmtr Addstatus 1
Spare
3) Xmtr Addstatus 2
Fault
Auto Oi Fault
Manual Oi Fault
Oi Cal Fault
Dim Detect Fault (Diminished detection fault)
Detect Disable Flt (Detection disabled fault)
Temp Out of Range
Volt Out of Range (Operating voltage out of range)
4) Xmtr Addstatus 3
Snsr HW Fault (Sensor hardware fault)
HART HW Fault (HART hardware fault)
Intern Comm Fault (Modbus communication fault)
Incompatible Fault
5) Operating Mode
Fault
Fire Alarm
6) Operating Mode 2
Spare

Status Info Menu
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 16
12. Status Info Menu
This menu (read only) shows extensive status information about the
detector.
1) Warmup (Y/N) Device is in the power-up time delay (warm-up)
mode.
2) Fire (Y/N) Indicates “Y” if the device is in a fire alarm status —
analog output is at 20 mA, fire alarm relay is actuated and LED is red.
3) Auto Oi Fault (Y/N) Automatic Oi Fault. Check viewing windows
and Oi reflector plate for cleanliness.
4) Dim Detect Fault (Y/N) Diminished Detection Fault. Excessive
background IR radiation. Eliminate IR interference and/or re-
aim/orient detector.
5) Detect Disable Flt (Y/N) Flame detector function has been
disabled. Check viewing windows for cleanliness and/or presence of
excessive background IR signal.
6) Snsr Hdwr Fault (Y/N) Sensor hardware fault.
7) HIB Hdwr Fault (Y/N) HART Interface Board hardware fault.
8) Int Comm Fault Internal communication fault.
9) Incompatible Flt Sensor module firmware version is not
compatible with HART Interface Board.
10) Voltage Fault (Y/N) Detector operating voltage is out of tolerance.
11) Hardware Menu Refer to sub-menu.
12) Oi Menu Refer to sub-menu.

Hardware Menu
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 17
13. Hardware Menu
1) Heater Power Actual heater power (0 to 100%). Heater prevents
condensation and icing on the detector optics.
2) Heater Setpoint Maximum amount of heater power allowed (in
percent of full power).
3) Temperature Actual integral temperature of detector.
4) Temp Setpoint Temperature at which heater begins operating.
5) Temp Range Fault Detector integral temperature out of range —
Operating range: –40°F to +167°F (–40°C to +75°C).
6) Voltage Actual detector supply voltage (must be 18 to 32 Vdc).
7) Volt Range Fault Supply voltage is out of range. Operating voltage
must be 18 to 32 Vdc.

Oi Menu
Addendum, AutroFlame X33AF 116-P-X33AFADDENDUM/YGB, DEC P/N 95-8624, 2007-11-12, Autronica Fire and Security AS
Page 18
14. Oi Menu
1) Left Oi Percentage of calibrated Oi test signal returned by the left
sensor. Reading should be 90 to 100 percent. If reading is below 90
percent, go to “Device Setup”, select “Calibration”, and perform Oi
Calibration.
2) Middle Oi Percentage of calibrated Oi test signal returned by the
middle sensor. Reading should be 90 to 100 percent. If reading is
below 90 percent, go to “Device Setup”, select “Calibration”, and
perform Oi Calibration.
3) Right Oi Percentage of calibrated Oi test signal returned by the
right sensor. Reading should be 90 to 100 percent. If reading is below
90 percent, go to “Device Setup”, select “Calibration”, and perform Oi
Calibration.
4) Oi Fail Count Number of consecutive Oi failures counted (one
passed Oi test resets the counter).
5) No. Oi Failures Set (allowable) number of consecutive Oi failures
to produce a fault.
6) Oi Cal Active Oi calibration is in progress.
7) Oi Cal Fault An Oi calibration fault has occurred.
8) Manual Oi Active A manual Oi test is in progress.
9) Manual Oi Fail The detector has failed the last manual Oi test.
