Quick Start Guide
Commissioning the MS400991M
52-Port 10G Multi Fiber L3 Switch 19"
v0.1

Quick Start Guide
Commissioning the MS400991M
52-Port 10G Multi Fiber L3 Switch 19"
2 MICROSENS GmbH & Co. KG, Kueferstr. 16, 59067 Hamm, Germany
Table of Contents
Overview and Aim of this Quick Start Guide ........................................................................................ 3
0 Safety Information.................................................................................................................... 3
0.1 General Requirements.................................................................................................................3
0.2 Electric Safety ...........................................................................................................................3
0.3 Optical Safety ............................................................................................................................4
1 Hardware Introduction ............................................................................................................. 4
1.1 Status LEDs...............................................................................................................................4
1.3 Interfaces .................................................................................................................................5
2 Device Installation .................................................................................................................... 5
2.1 19 a Iaa ...................................................................................................................5
2.2 SFP/SFP+ Transceiver Installation.................................................................................................5
2.3 Ground cable connection .............................................................................................................6
2.4 Connecting power supply .............................................................................................................6
3 Connecting to console ............................................................................................................... 6
4 Access for Network Management .............................................................................................. 7
5 Firmware Updates and Further Information............................................................................... 7
5.1 Registration...............................................................................................................................7
5.2 Login ........................................................................................................................................7
5.3 Firmware Image File ...................................................................................................................7
5.4 MICROSENS Support ..................................................................................................................7

Quick Start Guide
Commissioning the MS400991M
52-Port 10G Multi Fiber L3 Switch 19"
3 MICROSENS GmbH & Co. KG, Kueferstr. 16, 59067 Hamm, Germany
Overview and Aim of this Quick Start Guide
This switch is a 48-Port Gigabit SFP+ and 4-Port 10G SFP+ L3 Managed Ethernet Switch. It is a full fiber stackable
routing switches with fixed, built-in 10GbE uplink ports.
The fully managed switch provides high availability, scalability, security, energy efficiency, and easy operation
with rich L3 features, ideal for aggregation or access layer of networks.
This guide will help you with
connecting the power supply and commissioning the device,
understanding the status LEDs and
setting up the network management access.
Note:
For comprehensive information about configuring the device please refer to the following documents:
Web manual: describes Web network management system configuration instructions.
CLI manual: describes CLI-based configuration instructions
0Safety Information
Before performing an operation, read the following operation instructions and precautions to be taken, and follow
them to prevent accidents.
0.1 General Requirements
Only qualified and skilled personnel must install, configure, and unmount the device. The device
must not be disassembled.
When operating the device, obey the local safety regulations. The safety precautions provided in
the document are supplementary and shall be in compliance with the local safety regulations.
When operating the device, in addition to the precautions (please see the notes below), follow the
specific safety instructions.
The installation and maintenance personnel need to understand the basic safety precautions to be
taken.
Do not block the ventilation while the device is running. Keep a minimum distance of 5 cm from
the ventilation to the walls or the other objects that block the ventilation.
Do not operate the device in an area that exceeds the maximum recommended ambient
temperature of 75°C.
Do not place the device in the environment that has inflammable and explosive air or fog. Do not
perform any operation in this environment.
0.2 Electric Safety
The unit is designed as class III device according to EN62368-1. The electrical safety relies on the
supply with an electrical power source of class ES1.
Ensure that the input voltage is safely electrical insulated (double or reinforced insulation) from
dangerous voltages.
Before touching the device or hand-operating parts, wear a grounded electrostatic discharge
(ESD) wrist strap. It can prevent the sensitive components from damage by the static electricity
in the human body.

Quick Start Guide
Commissioning the MS400991M
52-Port 10G Multi Fiber L3 Switch 19"
4 MICROSENS GmbH & Co. KG, Kueferstr. 16, 59067 Hamm, Germany
0.3 Optical Safety
When handling optical fibers, do not stand close to, or look at the optical fiber outlet directly with
unaided eyes.
Cutting and splicing fibers must be performed by the trained personnel only.
Before cutting or splicing a fiber, ensure the fiber is disconnected from the optical source. After
disconnecting the fiber, use protecting caps to protect all the optical connectors.
1Hardware Introduction
Fig. 1: Display and Connections
1.1 Status LEDs
T a LED      (. Fig. 1) have the following meaning:
Indicators
Status
Description
PWR
AC Power Indicator
On (Green)
AC power is operating normally
Off
AC power is not operating
RPS
DC Power Indicator
On (Green)
DC power is operating normally
Off
DC power is not operating
DIAG
System Indicator
Blink (Green)
System is loading
On (Green)
System is operating normally
MGMT
Management Port
Indicator
On (Green)
Network management port is
linking
Off
Network management port is not
linking
Blink
Data forwarding
Port Link Indicator
On
Link up
Blink
Port sending or receiving data
Off
Link down, no connection

Quick Start Guide
Commissioning the MS400991M
52-Port 10G Multi Fiber L3 Switch 19"
5 MICROSENS GmbH & Co. KG, Kueferstr. 16, 59067 Hamm, Germany
1.3 Interfaces
Interfaces
Description
SFP
100/1000 Base-X SFP
SFP+
10 GbE SFP+
RJ-45 port
MGMT. Ethernet management port
CONSOLE: Console port for web management
AC plug-in interface
Ra a: 100240 VAC, 50/60 H
Ma a: 90264 VAC, 47..63 H
DC plug-in interface
Removable 5-Pin terminal block
Va a 1113VDV
Current value 8.33 A
Ground screw
2Device Installation
Note:
All necessary mounting parts are provided with the enclosed mounting accessory set.
2.1 19” rack Installation
Please follow the steps below:
1. Attach the 2 brackets on the switch with screws provided in the accessory kit.
2. Put the bracket-    a aa 19 a. Fa     a  
screws provided. Leave enough space around the switch for good air circulation.
Keep the following points in mind:
The brackets a  a a a
Do not place anything on top of the switch.
It is suggested to install the rack tray on the bottom of the switch.
Keep a distance of at least 5 cm to walls or nearby devices to provide ventilation and to avoid
overheating.
Do not block the switch cooling openings to ensure proper ventilation.
Position the device the way that connected cables will not cause mechanical tension on the device
or its attachment.
2.2 SFP/SFP+ Transceiver Installation
The switch is equipped with 48 times 100/1000 MbE SFP transceiver slots and four 10 GbE SFP+ transceiver slots

Quick Start Guide
Commissioning the MS400991M
52-Port 10G Multi Fiber L3 Switch 19"
6 MICROSENS GmbH & Co. KG, Kueferstr. 16, 59067 Hamm, Germany
Put on a ESD wrist strap (or antistatic gloves)
Insert the SFP/SFP+ transceiver to the guide rail inside the fiber interface line card. Do not put
the SFP/SFP+ transceiver up-side-down.
Push the SFP/SFP+ transceiver along the guide rail gently until you feel the transceiver snap into
place at the bottom of the line card.
Note: the SFP/SFP+ transceiver is hot swappable.
2.3 Ground cable connection
Note:
The equipment is intended to be grounded to comply with emission and immunity requirements. Ensure that the
switch functional ground screw is connected to earth ground during normal use.
Use one end of GND cable to connect the grounding connector of the switch, the other end to a ground point. The
GND cable used is recommended to be plastic insulating one with copper core, with cross-sectional area greater
than AWG 12.
2.4 Connecting power supply
The switch is powered by a 100230 VAC  4857 VDC   (. Fig. 1)
S  100230 VAC
Insert the cold device plug of the power cable provided in the delivery into the socket on the back
panel of the switch
Connect the other end of the power cable to a power outlet
The switch startups after powering
S  4857 VDC
C /a   DC  aa   + a -  a, 
a screw driver to screwing stably.
C  a      supply network
The switch startups after powering
Note:
To switch off the device, disconnect the power supply.
3Connecting to console
The switch provides a serial RJ-45 console port.

Quick Start Guide
Commissioning the MS400991M
52-Port 10G Multi Fiber L3 Switch 19"
7 MICROSENS GmbH & Co. KG, Kueferstr. 16, 59067 Hamm, Germany
To gain access to console interface
Attach the RJ-45 end to console port of the switch.
Connect the other side of the console cable to a character terminal (PC).
Power on the switch and the character terminal. Configure the switch through the character terminal.
4Access for Network Management
Note:
For accessing the device after starting up successfully please refer to one of the following documents:
Web manual: describes Web network management system configuration instructions.
CLI manual: describes CLI-based configuration instructions
5Firmware Updates and Further Information
You have access to current firmware versions and further information once you have registered on our website.
5.1 Registration
1. I      a .. a aa   a Paner
L.
2. F   Pa  .
3. Fill out and submit the online user registration form.
4. You will receive an e-mail containing a user name and password for the partner login.
5.2 Login
1. I      a .. a aa   a Pa
L.
2. Enter your username and your password.
3. C   L.
4. To find your switch quickly, enter the item number of your switch into the search box on the website.
5.3 Firmware Image File
Please navigate to you  a   a S Maa. T a a  a 
for your device.
Upload the firmware image file to the device by using the Web Manager. For further information please refer to
the web manual of your device.
5.4 MICROSENS Support
For further questions please contact our support:
E-mail: [email protected]
Phone: [phone] (Mo.  Fr., 7:30 AM  04:00 PM CET)

Quick Start Guide
Commissioning the MS400991M
52-Port 10G Multi Fiber L3 Switch 19"
8 MICROSENS GmbH & Co. KG, Kueferstr. 16, 59067 Hamm, Germany
Disclaimer
A a      a  a   a  .
MICROSENS GmbH & Co. KG disclaims any liability for the correctness, completeness or quality of the
information provided, fitness for a particular purpose or consecutive damage.
Any product names mentioned herein may be trademarks and/or registered trademarks of their respective
owners.
©2023 MICROSENS GmbH & Co. KG, Kueferstr. 16, 59067 Hamm, Germany.
All rights reserved. This document in whole or in part may not be duplicated, reproduced, stored or
retransmitted without prior written permission of MICROSENS GmbH & Co. KG.
Document ID: QSG-21xxx_2023-mm-dd
