Middle Atlantic Products Display Station Series User manual

I-00551 Rev A
Installation Instructions
Reference Series Rolling Furniture Rack
(I)RFR-CABCOOL50
PRODUCT FEATURES
- Powerful, yet quiet way to remove heat from electronic components located in the furniture rack.
- Blowers exhaust 50 CFM of hot air while providing high static pressure to maintain airflow, even in
a crowded cabinet.
THANK YOU
Thank you for purchasing the (I)RFR-CABCOOL50 Cabinet Cooler. Please read these instructions
thoroughly before installing/operating this product.
BOTTOM VIEW
A) CONTROL CIRCUIT: NOTE: DO NOT BLOCK!
B) TURN ON TEMPERATURE: The blower will turn on at 87° F (30.5° C) and run proportionately
(speed increases with temperature) from 87° F (30.5° C) to 95° F (35° C). At 95° F and above,
the blower will run at full speed. The blower will stop running at 85° F (29.4° C).
C) PRODUCT REVISION LEVEL: Current revision level of your (I)RFR-CABCOOL50.
D) MANUFACTURING DATE CODE: Denotes the date the (I)RFR-CABCOOL50 was manufactured.
E) TEMPERATURE PROBE: Temperature detection probe, five feet long (permanently fixed to unit).
F) POWER CONNECTOR: Connects to a 12V 1A power supply (supplied).
G) POWER LED: Blue LED that illuminates when the unit is receiving power.
(C)
(D)
(B)
(A)
(F)
(E)
(G)
FRONT VIEW

INSTALLATION
1) Unfasten four (4) wood screws and remove rear vent panel. (FIGURE A)
2) Insert power cord into rear cutout and slide unit into rack until flush with back panel. (FIGURE B)
