Middle Atlantic Products ICOMP-COOL Quiet-Cool Series User manual

I-00245 Rev B
ICOMP-COOL
Quiet-Cool Series Component Cooler
Instruction Sheet
m i d d l e a t l a n t i c . c o m
7.5VDC @ 70MA
middleatlantic.com
7.5VDC @ 70MA
TM
THANK YOU
Thank you for purchasing the Quiet-Cool Series™ ICOMP-COOL Component Cooler.
Please read these instructions thoroughly before installing this product.
PRODUCT FEATURES
- Extends equipment life.
- Removes heat directly from the source.
- Up to ten individual ICOMP-COOLs can
be run from one power supply. 3-1/8”
[79 mm]
3-3/16”
[81 mm]
5/8” [16 mm]
SPECIFICATIONS
MODEL POWER
REQUIREMENTS CFM dBA @ 1 METER
ICOMP-COOL 7.5 VDC @ 70mA 8
Per Fan 19
ICOMP-COOL-E 7.5 VDC @ 70mA 8
Per Fan
ICOMP-COOL-3 7.5 VDC @ 210mA 8
Per Fan
19
24
- Fan turns on at 87ºF [30.5ºC] and turns off at 85ºF [29.4ºC]
- LED illuminates green when fan activates, and
red when fan deactivates
LED

Page 2
middleatlantic.com
7.5VDC@ 70MA
middleatlantic.com
7.5VDC@ 70MA
PARTS
FAN UNIT
QTY
- ICOMP-COOL 1
- ICOMP-COOL - 3 3
- ICOMP-COOL - E 0
ADHESIVE BACKED FEET
QTY
- ICOMP-COOL 8
- ICOMP-COOL - 3 24
- ICOMP-COOL - E 8
WIRE TIE MOUNT
- ICOMP-COOL 5
- ICOMP-COOL - 3 15
- ICOMP-COOL - E 5
QTY
POWER SUPPLY
QTY
- ICOMP-COOL 1
- ICOMP-COOL - 3 1
- ICOMP-COOL - E 0
WIRE TIE
- ICOMP-COOL 5
- ICOMP-COOL - 3 15
- ICOMP-COOL - E 5
QTY
JUMPER CORD
- ICOMP-COOL 0
- ICOMP-COOL - 3 2
- ICOMP-COOL - E 1
QTY
1) Locate the hot spot on your component. (FIGURE A)
2) Clean area with provided alcohol wipe.
3) Remove paper covering adhesive ring. (FIGURE B)
4) Position ICOMP-COOL with power jack facing rear of component.
(FIGURE C) Press down to adhere.
TIP: If your cabinet does not have doors or sides, you may prefer to
position the unit so the air flows in a different direction.
5) Select appropriate wall plug for your region and install in provided
power supply.
6) Connect ICOMP-COOL to power source using provided Power
Supply.
NOTE: Wire Ties and Wire Tie Mounts are provided for cable
management.
FIGURE A
ADHESIVE
RING
FIGURE B
FIGURE C
INSTALLATION

Page 3
NOTE: If extra clearance between components is required to
accommodate the ICOMP-COOL, apply Adhesive
Backed Feet on the feet of the upper component with
adhesive side up. (FIGURE D)
Two Feet are provided for each location, but only one
per location may be required.
ADHESIVE
FOOT
FIGURE D
ICOMP-COOL-3 INSTALLATION (FIGURE E)
1) Install individual ICOMP-COOL units on equipment as required.
2) Using provided Jumper Cords, chain individual ICOMP-COOL units together.
3) Connect Power Supply to power source.
FIGURE E
ICOMP-COOL-E INSTALLATION (FIGURE F)
1) Using provided Jumper Cord,
connect ICOMP-COOL-E to
pre-installed ICOMP-COOL.
FIGURE F

Page 4 30% Recycled Paper
WARRANTY
Middle Atlantic Products (the "Company") warrants the Quiet-Cool Series™ ICOMP-COOL to be free
from defects in material or workmanship under normal use and conditions for a period of (3) years
from date of shipment by the Company.
The Company's entire liability to the purchaser, and the purchaser's (or any other party's) sole and
exclusive remedy, under this warranty shall be limited, at the Company's option, to either (a) return of
and refund of the price paid for, or (b) repair or replacement at the Company's factory of the products
purchased, or any part or parts thereof, which the Company has determined to be defective after
inspection thereof at the Company's factory.
This warranty does not cover damage due to acts of God, accident, misuse, abuse or negligence by
parties other than the Company, or any modification or alteration of the products. In addition, this
warranty does not cover damage due to improper handling, assembly, installation or maintenance.
THIS WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES OF ANY KIND, EITHER EXPRESSED OR
IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OF MERCHANTABILITY AND
FITNESS FOR A PARTICULAR PURPOSE.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL THE COMPANY
BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES
WHATSOEVER (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR LOSS OF BUSINESS PROFITS,
BUSINESS INTERRUPTION OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE OF THE
PRODUCTS PURCHASED, EVEN IF THE COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF
SUCH DAMAGES. THE COMPANY'S LIABILITY TO THE PURCHASER (OR ANY OTHER PARTY)
HEREUNDER, IF ANY, SHALL IN NO EVENT EXCEED THE PURCHASE PRICE OF THE PRODUCTS
PAID TO THE COMPANY.
