Midea 7000 btu Quick start guide

R410A Remote type--
WINDOW TYPE ROOM AIR CONDITIONER
R410A 遥控式--窗口式冷氣機
Owner’s Manual &Installation Manual
使用說明書及安裝說明書
Before using your air conditioner, please read
this manual carefully and keep it for future
reference.
在使用冷氣機之前，請仔細閱讀該說明書，並保
存好以備所需。

1
CONTENTS
1.
SAFETY PRECAUTIONS
3
2.
UNIT PARTS IDENTIFICATION
6
3.
OPERATING INSTRUCTIONS
7
4.
INSTALLATION INSTRUCTIONS
11
5.
TROUBLESHOOTING
16
6.
SPECIFICATIONS
17
Read This Manual
Inside you will find many helpful hints on how to use and maintain your air conditioner properly. Just
a little preventive care on your part can save you a great deal of time and money over the life of
your air conditioner. You'll find many answers to common problems in the chart of troubleshooting
tips. If you review our chart of Troubleshooting Tips first, you may not need to call for service at all.
ENVIRONMENT
From 31 December 2018, the disposal licensing control, import and export permit control and
landfill disposal ban in respect of abandoned regulated electrical equipment (REE) have
commenced. Any person who is engaged in the storage, treatment, reprocessing or recycling of
abandoned REE must obtain a waste disposal licence; a permit is required for the import and
export of abandoned REE; and abandoned REE is no longer be accepted for disposal
at the landfills and other designated waste disposal facilities (e.g. refuse transfer stations).

2
WARNING
Plug in power plug properly. Otherwise, it may cause electric shock or fire due to excess heat
generation.
Do not operate or stop the unit by inserting or pulling out the power plug. It may cause electric
shock or fire due to heat generation.
Do not damage or use an unspecified power cord. It may cause electric shock or fire. If the
power cord is damaged, it must be replaced by the manufacturer or an authorized service
centre or a similarly qualified person in order to avoid a hazard.
Do not modify power cord length or share the outlet with other appliances. It may cause
electric shock or fire due to heat generation.
Do not operate with wet hands or in damp environment. It may cause electric shock.
Unplug the unit or disconnect the power supply to the unit, if strange sounds, smell, or smoke
comes from it. It may cause fire and electric shock.
Do not use the socket if it is loose or damaged. It may cause fire and electric shock.
Leave the door closed while the air conditioner is running. It is not designed to cool the entire
house.
Do not use the power cord close to heating appliances. It may cause fire and electric shock.
Do not use the power cord near flammable gas or combustibles, such as gasoline, benzene,
thinner, etc. It may cause an explosion or fire.
Ventilate room before operating air conditioner if there is a gas leakage from another
appliance. It may cause explosion, fire and burns.
Do not disassemble or modify unit. It may cause failure and electric shock.
The appliance shall be installed in accordance with national wiring regulations.
If connecting power to fixed wiring, an all-pole disconnection device which has at least 3mm
clearances in all poles, and have a leakage current that may exceed 10mA, the residual
current device(RCD) having a rated residual operating current not exceeding 30mA, and
disconnection must be incorporated in the fixed wiring in accordance with the wiring rules.
The unit s circuit board (PCB) is designed with a fuse to provide overcurrent protection. The
specifications of the fuse are printed on the circuit board, such as: T 3.15A/250V, etc.
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Children shall not play the appliance. Cleaning and user
maintenance shall not be made by children without supervision. (EN Standard requirements)
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for
their safety. (IEC Standard requirements)
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
The appliance shall be installed in accordance with national wiring regulations.
Do not operate this appliance in a wet room such as a bathroom or laundry room.
The appliance with electric heater shall have at least 1-meter space to the combustible
materials.
Contact the authorized service technician for repair or maintenance of this unit.

3
SAFETY PRECAUTIONS...
To prevent injury to the user or other people and property damage, the following instructions must
be followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The
seriousness is classified by the following indications.
WARNING
This symbol indicates the possibility of death or serious injury.
CAUTION
This symbol indicates the possibility of injury or damage to property.
Meanings of symbols used in this manual are as shown below.
Never do this.
Always do this.
WARNING
Plug in power plug
properly.
Do not operate or stop
the unit by inserting or
pulling out the power plug.
Do not damage or use an
unspecified power cord.
Otherwise, it may cause
electric shock or fire due
to excess heat
generation
It may cause electric shock
or fire due to heat
generation.
It may cause electric shock or fire.
If the power cord is damaged, it must
be replaced by the manufacturer or an
authorized service centre or a similarly
qualified person in order to avoid a
hazard.
Do not modify power
cord length or share the
outlet with other
appliances.
Do not operate with
wet hands or in damp
environment.
Do not direct airflow at room
occupants only.
It may cause electric
shock or due to heat
generation.
It may cause electric
shock.
This could damage your health.
Always ensure
effective earthing.
Do not allow water to
run into electric parts.
Always install circuit breaker and a
dedicated power circuit.
Incorrect earthing may
cause electric shock.
It may cause failure of
machine or electric shock.
Incorrect installation may cause fire
and electric shock.
Unplug the unit if
strange sounds, smell, or
smoke comes from it.
Do not use the socket
if it is loose or damaged.
Do not open the unit during
operation.
It may cause fire and
electric shock.
It may cause fire and
electric shock
It may cause electric shock.
Leave the door
closed while the air
conditioner is running.
Do not use the power
cord close to heating
appliances.
Do not use the power cord near
flammable gas or combustibles, such
as gasoline, benzene, thinner, etc.
It is not designed to cool
the entire house.
It may cause fire and
electric shock.
It may cause an explosion or fire.
Ventilate room before operating air
conditioner if there is a gas leakage from
another appliance.
Do not disassemble or modify unit.
It may cause explosion, fire and, burns.
It may cause failure and electric shock.

4
CAUTION
When the air filter is
to be removed, do not
touch the metal parts of
the unit.
Do not clean the air
conditioner with water.
Ventilate the room well when
used together with a stove, etc.
It may cause an injury.
Water may enter the unit and
degrade the insulation. It may
cause an electric shock.
An oxygen shortage may occur.
When the unit is to
be cleaned, switch off,
and turn off the circuit
breaker.
Do not put a pet or house
plant where it will be exposed
to direct air flow.
Do not use for special purposes.
Do not clean unit when
power is on as it may
cause fire and electric
shock, it may cause an
injury.
This could injure the pet or
plant.
Do not use this air conditioner to
preserve precision devices, food,
pets, plants, and art objects. It may
cause deterioration of quality, etc.
Stop operation and
close the window in
storm or hurricane.
Hold the plug by the
head of the power plug when
taking it out.
Turn off the main power switch
when not using the unit for a long
time.
Operation with windows
opened may cause
wetting of indoor and
soaking of household
furniture.
It may cause electric shock
and damage.
It may cause failure of product or
fire.
Do not place obstacles
around air-inlets or inside
of air-outlet.
Ensure that the
installation bracket of the
outdoor appliance is not
Always insert the filters
securely. Clean filter once every two
weeks.
It may cause failure of
appliance or accident.
If bracket is damaged, there
is concern of damage due to
falling of unit.
Operation without filters may cause
failure.
Do not use strong
detergent such as wax or
thinner but use a soft
cloth.
Do not place heavy
object on the power cord and
ensure that the cord is not
compressed.
Do not drink water drained from
air conditioner.
Appearance may be
deteriorated due to
change of product color
or scratching of its
surface.
There is danger of fire or
electric shock.
It contains contaminants and could
make you sick.
Use caution when unpacking and
installing. Sharp edges could cause injury.
If water enters the unit, turn the unit off at the
power outlet and switch off the circuit breaker. Isolate
supply by taking the power-plug out and contact a
qualified service technician.

5
Preparing for operation
1. Contact an installation specialist for installation.
2. Plug in the power plug properly.
3. Do not use a damaged or non-standard power cord.
4. Do not share the same outlet with other appliances.
5. Do not use an extension cord.
6. Do not start/stop operation by plugging/unplugging the power cord.
Usage
1. Exposure to direct airflow for an extended period of time could be hazardous to your health.
Do not expose occupants, pets, or plants to direct airflow for extended periods of time.
2. Due to the possibility of oxygen deficiency, ventilate the room when used together with stoves
or other heating devices.
3. Do not use this air conditioner for non-specified special purposes (e.g. preserving precision
devices, food, pets, plants, and art objects). Usage in such a manner could harm such property.
Cleaning and maintenance
1. Do not touch the metal parts of the unit when removing the filter. Injuries can occur when
handling sharp metal edges.
2. Do not use water to clean inside the air conditioner. Exposure to water can destroy the
insulation, leading to possible electric shock.
3. When cleaning the unit, first make sure that the power and circuit breaker are turned off.
Operating Temperature
Cooling operation
Outdoor temp:
18-43 ºC
Indoor temp:
17-32 ºC
Heating operation
Outdoor temp:
-5-24 ºC
Indoor temp:
0 -27 ºC
Note: Performance may be reduced outside of these operating temperatures.

6
UNIT PARTS IDENTIFICATION
NOTE: The front panel and cabinet may be slightly different according to the models, but the
functions are the same. The following illustration is for explanation purpose only, the actual shape
of the machine you purchased may be slightly different.
1. Front panel
2. Air filter
3. Frame
4. Cabinet
5. Air inlet grille (outdoor side)
6. Air outlet grille
7. Electronic control keypad
8. Power supply cord
9. Control panel cover
10. Remote control
1. Power cord conductors are distinguished according to color as follows (see Fig.1)
2. For your safety and protection, this unit is earthed through the power cord (see Fig.2)
Please contact the manufacturer or its service agent or a similar qualified person if you
want to replace it.
3. Be sure that the unit being correctly grounded. The wall outlet (Air-break switch) should be
provided with reliable earth wire.
4. The unit should be provided with an individual circuit and the circuit breaker/fuse rating
should be the same as that of the power cord and wall outlet.
Accessories
NOTE: Optional parts ( ), depending on model you purchased.
NOTE: All the illustrations in the manual are for explanation purpose only.
Your air conditioner may be slightly different. The actual shape shall prevail.
POWER
CORD
L
E
N
E-Earth wire, yellow/green
N-Neutral wire, blue
L-Active wire, brown
Fig.1
Fig. 2
Wall outlet
Air-break switch

7
OPERATING INSTRUCTIONS
Controls
The electronic control keypad will look like one of the following:
7000~9000Btu/h 11000~24000Btu/h
NOTE: The outline of the operation panel is based on typical model, the function is the same with your air
conditioner while some difference may exist in appearance.
Vent Control
The vent control is located above the control knobs. The operation method is different on different
models (see the following figures).
For maximum cooling efficiency, CLOSE the vent. This will allow internal air circulation.
OPEN the vent to discharge stale air.
To open the vent, set the lever to the right position.
To close it, set the lever in the left position.
To open the vent, pull the lever toward you
To close it, push it in.

8
OPERATING INSTRUCTIONS
POWER:
Press the POWER keypad to turn the unit on/off.
(The TIMER keypad controls the auto start/stop feature of the unit.)
MODE:
Press the "MODE" keypad to select the appropriate operating mode. The mode selection
will alternate between AUTO, HEAT, COOL, FAN and DRY. The green indicator light
beside the "MODE" option will illuminate, identifying the mode selected.
When using the DRY and AUTO mode, you cannot select a fan speed. The fan motor
operates on LOW speed in DRY mode and on MED speed in AUTO mode. Some models
without MED speed, the fan motor operates on HIGH speed in AUTO mode.
TEMPERATURE SETTINGS UP:
Press the keypad to increase the set (operating) temperature of the unit.
Each time the keypad is pressed the temperature increases as follows:
1 ºC (Celsius Scale) Maximum Setting 30 ºC
TEMPERATURE SETTINGS DOWN:
Press the keypad to decrease the set (operating) temperature of the unit.
Each time the keypad is pressed the temperature decreases as follows:
1 ºC (Celsius Scale) Minimum Setting 17 ºC
FAN:
Press this keypad to activate the appropriate fan speed setting. Each depression of the
keypad will alternate through LOW, MED (some models without), HIGH fan speed options.
The green indicator light beside the FAN speed option will illuminate, identifying the fan
speed selected.
SWING
Press the "SWING" keypad to activate the automatic air swing (oscillation) feature. The
green indicator light adjacent to the "SWING" keypad will illuminate, identifying to the
selected mode is operational. The vertical louvers will oscillate back and forth (side to
side) automatically sweeping air alternately for comfortable cooling. To stop the air swing
feature, press the "SWING" keypad again, the green indicator light adjacent to the keypad
will go off. Press the "SWING" keypad for 2 seconds will activate the SLEEP mode which
can reduce noise creating a comfortable sleeping environment.
When the SLEEP mode is activated, the green indicator light beside the "SLEEP" function
will illuminate.
TIMER:
Press the "TIMER" keypad to activate the "auto start/auto stop" timer function. Auto
start/stop programs can be set from 0~24 hours. Each depression of the "TIMER" keypad
will increase or decrease the selected time in 0.5 hour increments up to 10 hours, then by
1 hour increments up to 24 hours.

9
DRY:
This mode is used to decrease the humidity in the room. Under this mode, you cannot
select a fan speed. The fan motor operates at LOW speed. Keep windows and doors
closed for the best dehumidifying effect.
COOLING:
The temperature setting are adjustable between 17ºC to 30ºC. You can select your
desired fan speed.
HEATING:
The temperature setting are adjustable between 17ºC to 30ºC. You can select your
desired fan speed.
AUTO:
The fan motor remains on MED speed in AUTO mode. The unit will select the appropriate
operating mode from FAN, COOL or HEAT (For reverse cycle models only) based upon
the temperature difference between the actual and desired room temperature. Some
models without MED speed, the fan motor operates on HIGH speed in AUTO mode.
SLEEP:
For the models with SWING feature, press and hold the "SWING" keypad for 2 seconds
or use the remote control to activate the "SLEEP" feature.
Press and hold the "SWING" keypad for 2 seconds again or use the remote control
again to deactivate the "SLEEP" feature. For units without “SWING" feature, use the
remote control to activate the "SLEEP" feature.
In the Cooling mode, the cooling temperature set point will increase 1ºC per hour after the
“SLEEP" mode is selected. Two hours later, the set point will continue at this temperature
and the fan motor will remain on LOW speed.
In the Heating mode, the heating temperature set point will decrease 1ºC per hour after
the "SLEEP" mode is selected. Two hours later, the set point will continue at this
temperature and the fan motor will remain on LOW speed.
Using the "SLEEP" mode will reduce noise creating a comfortable sleeping environment.
Note: This feature is not available under DRY and FAN ONLY operation.
LED Display:
Shows the temperature setting or Auto-timer setting, after 10 seconds, shows the
room temperature (on some models) or set temperature (on some models).

10
Horizontal air flow adjustment (manually)
To adjust vertical air flow direction of the up or low horizontal
louvers, adjust any one of the up or low horizontal louver blades.
Air Filter
The air filter behind the inlet grille should be checked and
cleaned at least once every 2 weeks (or as necessary) to
maintain optimal performance of the air conditioner.
How to remove the air filter
1. Hold the tabs under the front panel, then uplift it outwards,
and remove the front panel.
2. Pinch the handle under the air filter and make the air filter
arched, remove it from the slot from underside to upside.
3. Clean the filter with warm, soapy water. The water should be
below 40OC to prevent distortion of the filter.
4. Rinse off and gently shake off excess water from the filter.
Allow the filter to dry before replacing it. To prevent distortion of
the filter, do not dry in direct sunlight.
CAUTION
NEVER operate the air conditioner without the
air filter, as dust/dirt particles can contribute to
equipment failure.
CONTROL PANEL COVER
Grasp the right of the control panel cover and
pull it upwards to open it.
Close the control panel cover and press the
right of the cover again until it snaps into the
locked position.

11
INSTALLATION INSTRUCTIONS
Select the best location
1. To avoid vibration and noise, make sure the unit is installed securely and firmly.
2. Install the unit where the sunlight does not shine directly on the unit. If the unit receives
direct sunlight, build an awning to shade the cabinet. The awning is at least 15cm away from
the air inlet at the top of the unit.
3. There should be no obstacle, such as a fence or wall, within 50cm from the back of the
cabinet because it will prevent heat radiation of the condenser.
Restriction of outside air will greatly reduce the cooling and heating efficiency of the air
conditioner.
4. Install the unit a little obliquely outward not to leak the condensed water into the room (about
10mm or 1/4 bubble with level).
5. Install the unit with its bottom portion 75~150cm above the floor level.
6. The power cord must be connected to an independent circuit. The yellow/green wire must be
grounded.
All side louvers of the cabinet must remain exposed to the outside of the structure.
Installation of the Housing
Step 1
Remove the air conditioner from it's packaging, remove
fixing screws and slide the air conditioner out of it's
housing (Refer to Installation Steps).
Step 2
Prepare the hole in the wall so that the bottom of the
housing is well supported, the top has minimum clearance
and the air inlet louvers have clearance as shown below
in options A and B. Holes from the outside through to
the cavity should be sealed. The housing should slope
down towards the rear by about 5mm to allow water
formed during operation to drain.
CAUTION

12
Step 3
Install the housing into the wall and secure. Ensure the
foam seals are not damaged. Flash, seal or fill gaps
around the inside and outside to provide satisfactory
appearance and protection against the weather, insects
and rodents.
Installation of the unit into the Housing
1. Slide the unit into the housing until it is firmly
against the rear of the housing. Care is required to
ensure the foam sealing strips on the housing remain in
position.
2. Connect the air conditioner to the power and
position excess cord length beneath the air conditioner
base.
3. Engage the chassis fixing brackets into the bottom
housing rail and secure to the base with the screw
provided.
4. Remove the front panel from it's carton and plastic
bag and fit as per the Installation instruction.
5. Switch unit on. Check for operation of the unit and
check for vibration in the installation.
6. Fit the drain pan to the housing and run a drain line
to a suitable location if required.
Installations of the unit into the wall

13
Installation Steps
Step 1. Remove the front panel and the air filter
1. Hold the tabs under the front panel, then uplift it outwards, and remove the front panel (See
Fig.1).
2. Pinch the handle under the air filter and make the air filter arched, remove it from the slot from
underside to upside (See Fig.2).
Step 2. Remove the frame.
1. Remove the two fixing screws from the frame (See Fig.3).
2. Grasp the left corner of the frame's underside, release the coupler plugs, then loosen the
frame (See Fig.4).
Step 3. Installation.
1. Remove the two fixing screws on the chassis fixing brackets, then remove the chassis fixing
brackets (See Fig.5).
2. Grasp the handle on the chassis and carefully slide the air conditioner out of the cabinet (See
Fig.6).
3. Remove shipping pad from around compressor before operation and make sure the discharge
points to the drain pan are aligned before the chassis is pushed into the cabinet (See Fig.7).
4. Push the unit chassis into the cabinet (See Fig.8).
5. Install the two chassis fixing brackets using the two fixing screws (See Fig.5).
Step 4. Install the frame.
1. Install the frame and connect the coupler plugs, making sure
not to interfere with the temperature sensor cable (See Fig.9).
2. Fix the screws on the frame (See Fig.3).
Step 5. Install the air filter and front panel.
1. Install the air filter into the frame's slot from upside to underside
(See Fig.2).
2. Hang the front panel on the frame's buckle, then press the front
panel into the frame's slot until you hear a click (See Fig10).

14
Installation Steps Option: Power Cord Come Out from Left Side
Step 1. Install the power cord
1. Pull the power cord to the left side straightly (See Fig.1C 2C.).
2. Wrap the PVC protecting sheath on the power cord with ribbing in the hole position (See
Fig.3C).
Step 2. Tie up the power cord on the frame (Just for the body dimension 600*380*560)
1. Tie up the power cord on the frame (See Fig.5C 6C.).
Step 3. Install the frame the front panel
1. These steps is same as right side. (See Fig.4C.).

15
Drainage
To treat condensed water will be as follows:
1. Bottom drainage. Connect drain hose to the bottom drain tray. It
will slightly affect cooling performance, but will reduce the noise
caused by spraying the condensed water.
Note: Only optional for models with bottom drain hole.
For pump heating, the bottom drainage must be choosing.
2. Back drainage. Connect drain hose to the back drainage hole.
It will slightly affect cooling performance, but will reduce the noise caused by spraying the condensed water.
3. Non-drainage. Block the drain hole(s) by rubber plug(s).
The condensed water will be sprayed to condenser, and will improve the cooling performance.
Installation procedures of bottom drainage:
-Remove the rubber plug from the bottom of cabinet (if installed).
-Take out the drain tray and screws from accessary.
-Fix the drain tray onto the bottom of cabinet by screws.
-Connect an extension drain hose (locally purchased) to the outlet of drain tray.
Installation procedures of back drainage:
-Fit the seal (provided as accessory) onto the drain joint.
-Insert the drain joint to the back drainage hole, and rotate it by 90°to be well fitted.
-Connect an extension drain hose (locally purchased) to the drain joint.
-Make sure block the bottom drain hole by rubble plug.
Note: Drain hose is locally purchased according to installation length request.
NOTE: If you choose non-drainage when cooling, both the bottom
and the back drain holes of the unit should be inserted with
rubber plugs. When you choose non-drainage the air conditioner
will be perfect cooling efficiency, but big noise may be caused by
spraying the condensed water. Does not recommend to use.
NOTE: The rated cooling performance is tested under non-
drainage status.
NOTE: Make sure that water will not leak from the
surrounding area when rubber plug and joint were used.
Please seal it in case leakage is found.

16
TROUBLESHOOTING
Troubleshooting Tips
Save time and money! Review the chart below first and you may not need to call for service.
Normal Operation
You may hear a pinging noise caused by water being picked up and thrown against the
condenser on rainy days or when the humidity is high. This design feature helps remove
moisture and improve efficiency.
You may hear the thermostat click when the compressor cycles on and off.
Water will collect in the base pan during high humidity or on rainy days .The water may
overflow and drip from the outdoor side of the unit.
The fan may continue to operate when the compressor has cycled off.
Problem
Possible Causes
What To Do
Air conditioner
does not start
The air conditioner is
unplugged.
Make sure the air conditioner plug is
pushed completely into the outlet and
switched on.
The fuse is blown/
circuit breaker is
tripped.
Check the house fuse/circuit breaker box
and replace the fuse or reset the breaker.
Power failure.
If power failure occurs, switch off and
disconnect /unplug the power cord. When
power is restored, reconnect (plug in) the
power cord, switch on the power and wait 3
minutes to restart the air conditioner to
prevent tripping of the compressor
overload.
Air conditioner
does not cool
as it should
Airflow is restricted.
Make sure there are no curtains, blinds, or
furniture blocking the front of the air
conditioner.
The air filter is dirty.
Clean the filter at least every 2 weeks.
See the operating instructions section.
The room may have
been hot.
When the air conditioner is first turned on
you need to allow time for the room to cool
down.
Cold air is escaping.
Check for open furnace floor registers and
cold air returns.
Set the air conditioner's vent to the closed
position.
Cooling coils have
iced up.
See Air Conditioner Freezing Up below.
Air conditioner
freezing up
Ice blocks the air flow
and stops the air
conditioner from
cooling the room.
Set the fan at MED or HIGH until the ice
melts.

17
Failure Indicator Display:
Indicates a malfunction of the indoor room temperature sensor.
Indicates a malfunction of the evaporator temperature sensor.
Indicates a malfunction of the outdoor condenser temperature sensor.
Indicates frosting protection (Turn off the unit and restart it to return to normal operation).
Note:
When one of the above malfunctions occurs, turn off the unit, and check for any obstructions.
Restart the unit, if the malfunction is still present, turn off the unit and unplug the power cord.
Contact the manufacturer or its service agents or a similar qualified person for service.
SPECIFICATIONS
Unit dimensions:
MODEL(Btu/h)
BODY DIMENSION(mm)
(W x H x D)
WIRING SIZE
(mm 2)
7000
450x346x585
≥ 3*1.5
9000
600x380x560
≥ 3*1.5
12000
660x428x680
≥ 3*1.5
18000
660x428x780
≥ 3*2.5
Minimum nominal cross-sectional area of conductors:
Nominal cross-sectional area
(mm2)
Rated current of
appliance (A)
0.75
>3 and ≤6
1.0
>6 and ≤10
1.5
>10 and ≤16
2.5
>16 and ≤25

18
目錄
1.
安全預防措施
20
2.
冷氣機零件名稱
23
3.
操作指引
25
4.
安裝指引
27
5.
故障處理
31
6.
技術參數
32
閱讀本手冊
本手冊提供了許多有關冷氣機正確使用與維護的實用提示。衹要稍加注意，就能延
長冷氣機的使用壽命，大大節省時間與金錢。在故障處理提示表中，您可以找到許
多常見問題的解答。事先瀏覽以下故障處理提示，也許就不必進行維修了。
環境保護
2018 年12 月31 日起，被棄置受管制電器處置管制、進出口管制及堆填區棄置
禁令正式實施。任何人貯存、處理、再加工或循環再造被棄置受管制電器，均須取
得廢物處置牌照；輸入及輸出被棄置受管制電器均須領有許可證。堆填區及其他指
定廢物處置設施（例如廢物轉運站）則不會再接收和處置被棄置受管制電器。
