Midea MAP05R1WT User manual

Portable
MAP05R1WT
MAP08R1CWT
www.midea.com
USER MANUAL
en
PH
Before using this product,
please read this manual carefully
and keep it for future reference.
The design and specifications
are subject to change without
prior notice for product
improvement. Consult with
your dealer or the manufacturer
for details.
Rated voltage: 115V
Frequency: 60Hz
WARNING

Page 2
Read This Manual
Inside you’ll find many helpful hints on how to use and maintain your air conditioner
properly. Just a little preventive care on your part can save youagreat deal of time
and money over the life of your air conditioner. You’ll find many answers to common
problems in the chart of troubleshooting tips - you should be able to fix most of
them quickly before calling service. These instructions may not cover every possible
condition of use, so common sense and attention to safety is required when installing,
operating and maintaining this product.
Owner’s Manual
Safety Precautions ....................................................................................... 3
Unit Specifications and Features .............................................................. 8
Operating Instructions ................................................................................ 9
Installation Instructions ............................................................................... 12
Care and Cleaning ....................................................................................... 17
Troubleshooting Tips .................................................................................. 18
Remote Control Instructions ..................................................................... 19
27
Warranty ...................................................................and Return Policy ...
• For support, please call the Service Center at 1-866-646-4332.
• This appliance is not intended for use by people (including children) with reduced
physical, sensory or mental capabilities or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by
a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the air conditioner.
• The appliance shall be installed in accordance with national wiring regulations.
• Do not operate your air conditioner in a humid room such as a bathroom or laundry
room.
CAUTION

Page 3
Safety
Precautions
Safety Precautions
To prevent injury to the user or other people and property damage, the instructions
shown here must be followed. Incorrect operation due to ignoring of instructions may
cause harm or damage. The level of risk is shown by the following indications.
• Plug in power cord plug properly.
Otherwise, it may cause electric shock or fire due to excess heat generation.
• Do not modify power cord length or share the outlet with other appliances as it
may cause electric shock or fire due to overheating.
• Always ensure effective grounding.
Incorrect grounding may cause electric shock.
• Unplug the unit if you notice unusual sounds or smells, or smoke comes from it.
A damaged product may cause fire and electric shock.
• Keep firearms away from the unit.
• Ventilate room before operating the air conditioner if there is a gas leakage from
another appliance.
• Do not operate or stop the unit by inserting or pulling out the power cord plug.
• Do not operate with wet hands or in very humid enviroments.
It may cause electric shock.
• Do not allow water to come into contact with any electric parts.
It may cause failure or electric shock.
• Do not use the socket if it is loose or damaged.
It may cause fire and electric shock.
• Do not place the power cord close to heating appliances.
It may cause fire and electric shock
• Do not disassemble or modify unit.
It may cause failure and electric shock.
WARNING
WARNING This symbol indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
This symbol indicates a hazardous situation, which, if not
avoided, could result in minor or moderate injury.
NOTICE
This symbol addresses practices not related to physical
injury.

Page 4
Safety
Precautions
WARNING
• Do not damage or use an alternate power cord.
It may cause fire and electric shock.
If the power cord is damaged, it must be replaced by the manufacturer or an
authorized service center or a similarly qualified person in order to avoid a hazard.
• Do not direct airflow straight into persons to avoid possible health hazard.
• Do not open the unit during operation.
It may cause electric shock.
• Do not use the power cord near flammable gas or combustibles, such as gasoline,
benzene, thinner, etc.
It may cause an explosion or fire.
• Avoid fire hazard or electric shock. Do not use an extension cord or an adaptor
plug. Do not remove any prongs from the power cord.
• Be sure the air conditioner is properly grounded. To minimize shock and fire
hazards, proper grounding is important. The power cord is equipped with a
three-prong grounding plug for protection against shock hazards.
• Your air conditioner must be used in a properly grounded wall receptacle. If the
wall receptacle you intend to use is not adequately grounded or protected by a
time delay fuse or circuit breaker, have a qualified electrician install the proper
receptacle. Ensure the receptacle is accessible after the unit installation.
• Be sure the electrical service is adequate for the model you have chosen. This
information can be found on the serial plate, which is located on the side of the
cabinet and behind the grille.
CAUTION
• When the airfilter is to be removed, do not touch the metal parts of the unit.
It may cause injury.
• When the unit needs cleaning, switch off, and turn off the circuit breaker.
Do not clean unit when power is on as it may cause fire, electric shock or injury.
• Do not place obstacles around air inlets or inside of air outlet.
It may cause failure or accident.
• Clean with a soft cloth only. Do not use strong detergents that contain wax or
thinners as it may damage the product.
• Use caution when unpacking and installing. Sharp edges could cause injury.
• Do not clean the air conditioner with water.
Water may enter the unit and degrade the insulation which could lead to
electric shock.
• D o not drink water drained from the air conditioner.

Page 5
Safety
Precautions
CAUTION
• Do not put a pet or house plant where it will be exposed to direct air flow.
This could injure the pet or harm the plant.
• Hold the plug by the head of the power plug when taking it out.
Otherwise, it may cause electric shock and damage.
• Ensure that the installation is properly secured to prevent the product from
potentially falling.
• Do not place heavy objects on the power cord and ensure that the cord is not
compressed.
Otherwise, there is danger of fire or electric shock.
• If water is spilled on the unit, turn off the unit and switch off the circuit breaker.
Isolate supply by taking the power-plug out and contact a qualified service
technician.
• Do not use near gas stove or other gas burning appliances, as air flow may affect
gas combustion.
• Do not use for any purpose other than room comfort.
Do not use this air conditioner to preserve precision devices, food, pets, plants,
and art objects. It may cause deterioration.
• Turn off the main power switch if the unit is not to be used for an extended time.
• Always insert the filters securely. Clean filter once every two weeks.
Operation without filters may cause failure.

Page 6
Safety
Precautions
NOTICE
• Do not use this device to turn the unit on or off.
• Always make sure the RESET button is pushed in for correct operation.
• The power supply must be replaced if it fails to reset when either the TEST button
is pushed, or it can not be reset. Please contact Customer Service.
NOTICE
The power supply cord with this
air conditioner contains a current
detection device designed to reduce
the risk of fire.
In the event that the power supply
cord is damaged, it can not be
repaired. It must be replaced with a
cord from the manufacturer.
Grounding type wall receptacle
Do not, under any
circumstances, cut,
remove or bypass
the grounding prong.
Power supply cord with 3-prong grounding
plug and current detection device.
The power supply cord contains a
measurement current device that senses
damage to the power cord. Test your power
supply cord as follows:
1. Plug in the air conditioner.
2. The power supply cord will have TWO
buttons on the plug head. Press the
TEST button. You will notice a click as
the RESET button pops out.
3. Press the RESET Button. You will
notice a click as the button engages.
4. The power supply cord is now
supplying electricity to the unit. (On
some products this is also indicated
by a light on the plug head.)
RESE T
TEST
Plug in &
press RESET
Operation of Current Device

Page 7
Safety
Precautions
WARNING
This symbol shows that this appliance used a flammable
refrigerant. If the refrigerant is leaked and exposed to an
external ignition source, there is a risk of fire.
CAUTION This symbol shows that the operation manual should be read
carefully.
CAUTION This symbol shows that a service personnel should be handling
this equipment with reference to the installation manual.
CAUTION This symbol shows that information is available such as the
operating manual or installation manual.
EXPLANATION OF SYMBOLS DISPLAYED ON THE UNIT
• Do not try to accelerate the defrosting process or methods of cleaning that are
not recommended by the manufacturer.
• The appliance shall be stored in a room without a continuously operating ignition
source (for example, open flames or an operating gas appliance) or an ignition
source (for example, an operating electric heater) close to the appliance. The
appliance shall also be stored in a room without ignition sources.
• Do not pierce or burn.
• Be aware that the refrigerants may not contain an odor.
• Keep ventilation openings clear of obstruction.
• Unit is only to be serviced by a Midea authorized servicer, please call Customer
Service at 1-866-646-4332 for support.
• Flammable refrigerant R32 is used within air conditioner. Please follow the
instructions carefully to handle, install, clean, and service the air conditioner
to avoid damage or hazard. Do not dispose of air conditioner in regular trash.
Contact qualified agency for proper disposal.
• No open fire or devices that generate spark/arcing shall be around the air
conditioner to avoid causing ignition of the flammable refrigerant used. Please
follow theinstructions carefully to store or maintain the air conditioner to
prevent mechanical damage from occurring.
WARNING (for using R32 refrigerant only)
Caution: Risk of fire/
flammable materials
(Required for R32/R290 units only)
IMPORTANT NOTE:Read this manual
carefully before installing or operating
your new air conditioning unit. Make sure
to save this manual for future reference.

Preparation
Design and Compliance Notes
Unit
Specifications
and Features
Design Notice:
In order to ensure the optimal performance of our products, the design specifications of
the unit and remote control are subject to change without prior notice.
Energy Rating Information:
This product is tested in accordance to the DOE SACC capacity energy rating test.
Unit Temperature Range:
Mode Temperature Range
Cool 17°C ~ 35°C (62°F ~ 95°F)
Dry 13°C ~ 35°C (55°F ~ 95°F)
raeRtnorF
control panel
remote signal receptor handle
(both sides)
outlet louver - vertical
direction control lever
(adjust manually)
NOTE: PHA cannot be
adjusted.
outlet louver - horizontal
direction control lever
(adjust manually)
NOTE: PHA cannot be
adjusted.
panel
Caster
bottom tray
drain outlet
air filter
(behind the grille)
upper air intake
air outlet
lower air intake
drain outlet
Unit Specifications and Features
Page 8
The exhaust hose and adaptor must be installed or removed in accordance with the
usage mode.
For COOL or AUTO mode, exhaust hose must be installed.
For FAN or DEHUMIDIFY exhaust hose must be removed.
EXHAUST HOSE INSTALLATION:

Cool
Fan
Dry On | OffMode
Operating
Instructions
Control Panel Features
Mode Button
Selects the desired operating mode.
Each time you press the button, a mode
is selected in a sequence that goes from
COOL, FAN and DRY. The mode light
illuminates and indicates the selected
mode.
Up (+) and Down (-) Buttons
Used to adjust (increasing/decreasing)
temperature settings in 1°C/1°F increments
in a range of 17°C/62°F to 30°C/86°F.
NOTE
The control is capable of displaying
temperature in degrees Fahrenheit or
degrees Celsius. To convert from one
to the other, press and hold the Up
and Down buttons at the same time
for 3 seconds.
NOTE
On above modes, the unit operates
the auto fan speed automatically. You
can set fan speed only by the remote
controller on COOL and FAN modes.
Power Button
Power switch on/off.
Power
indicator light
Timer mode indicator
light (set only by
remote controller)
LED display
Shows the set
temperature while on cool
mode. While on DRY and
FAN modes, it shows the
room temperature.
NOTE
When one of the above malfunctions
occurs, turn off the unit and check for
any obstructions. Restart the Unit. If the
malfunction persists, turn off the unit
and unplug the power cord. Contact
the manufacturer or its service agents
or a similar qualified person for service.
LED Display
Up (+) and Down (-) Control
Power
Button
Mode
Selector
Shows Error codes:
E1 - Room temperature sensor error.
E2 - Evaporator temperature sensor error.
E3 - Condenser temperature sensor error.
E4 - Display panel communication error.
Shows protection code:
P1 - Bottom tray is full - Connect the drain
hose and drain the collected water
away. If protection code repeats, call
for service.
Operating Instructions
Page 9
Constant Fan

Operating
Instructions
COOL operation
• Press the “MODE” button until the “COOL”
indicator light comes on.
• Press the UP and DOWN buttons “+” or “-” to
select your desired room temperature. The
temperature can be set within a range of
17°C~30°C/62°F~86°F.
• The fan speed is automatically set to auto.
Use the remote to adjust the fan speed if
desired.
DRY operation
• Press the “MODE” button until the “DRY”
indicator light comes on.
• While in this mode, you cannot select a
fan speed or adjust the temperature. The
fan motor operates at LOW speed.
• Keep windows and doors closed for the
best dehumidifying effect.
FAN operation
• Press the “MODE” button until the ”FAN“
indicator light comes on.
• Press the “FAN SPEED” button to choose
the fan speed. The temperature cannot
be adjusted.
Operating Instructions
SLEEP/ECO operation
This feature can be activated from
the remote control ONLY. To activate
SLEEP feature, the set temperature will
increase by 1°C/2°F in 30 minutes. The set
temperature will then increase by another
1°C/2°F after an additional 30 minutes.
This new temperature will be maintained
for 7 hours before it returns to the
originally selected temperature. This ends
the Sleep mode and the unit will continue
to operate as originally programmed.
NOTE
This feature is unavailable in FAN or
DRY mode.
Other Features
NOTE
This feature can be activated from
the remote control ONLY. The remote
control serves as a remote thermostat
allowing for the precise temperature
control at its location.
COMFORTSENSE
Feature (only for some models)
To activate the Temp Sensing feature, point
the remote control towards the unit and
press the Temp Sensing button. The remote
display is actual temperature at its location.
The remote control will send this signal to
the air conditioner every 3 minutes until the
ComfortSense button is pressed again.
If the unit does not receive the Temp
Sensing signal during any 7 minutes interval,
the unit will exit the Temp Sensing mode.
Constant Fan button
Feature (optional) in cooling or Dry mode,
press the button for 3 seconds to turn on or
off the constant fan function. When the
function is turned on, the constant fan light
will illuminate, identifying the fan continuous
run for cooling. When the function is turned
off, the constant fan light will go out,
identifying the fan cycle run with
compressor stop.
AUTO-RESTART
If the unit shuts off unexpectedly due to a
power outage, it will restart with the previous
set function when the powerresumes.
WAIT 3 MINUTES BEFORE RESUMING
OPERATION
After the unit has stopped, it cannot be
restarted until 3 minutes time has elapsed.
This is to protect the unit. Operationwill
automatically resume after 3 minutes.
AIRFLOW DIRECTION ADJUSTMENT
Adjust the air flow direction manually:
- The louver can be set to the desired
position manually.
- Do not place any heavy objects or
other loads on the louver, doing so will
cause damage to the unit.
- Keep the louver fully opened during
operation.
Page 10
