Midea MDT24P5AST User manual

Dishwasher
version B - 03 - 2021 www.midea.com
USER MANUAL
en
Warning:
Before using this product,
please read this manual carefully
and keep it for future reference.
are subject to change without
prior notice for product
details.
Capacity: 14 Place Settings
Free 3 months
extension* of the
original limited warranty
period! Simply text a
picture of your proof of
purchase to:
1-844-2 2 4-1 6 1 4
three months immediately following
MDT24P5AST

Dear user
DISHWASHER SAFETY ......................................................................3
OPERATING REQUIREMENTS ...........................................................7
8
START UP GUIDE .............................................................................. 11
12
LED Indicator Lights...............................................................................16
Cycle and Option Charts ......................................................................17
Upper Rack ..............................................................................................22
Load Upper Rack ....................................................................................24
Lower Rack ...............................................................................................25
Recommended Load Patterns ..........................................................29
Thank you for letting Midea help you "make yourself at home."
This manual is part of our commitment to your total satisfaction.
Please read this manual carefully before use and keep it in a
convenient place for future reference.
By using the text option you will earn an additional 3 month
warranty extension immediately following the completion of
the product's original warranty.
To help us serve you better, please consider registering your
product using our convenient Midea app MSmartlife, by visiting
HYPERLINK http://www.midea.com, or by texting a picture of
your proof of purchase to 1-844-224-1614 .
11
11
11
21
27

3
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher
YOUR SAFETY AND THE SAFETY OF OTHERS ARE VERY
IMPORTANT
CAUTION
WARNING
WARNING
This symbol indicates the possibility of injury or damage
property.
This
injury.
DISHWASHER USE ......................................................................... 31
DISHWASHER CARE .......................................................................35
Storing .......................................................................................................37
TROUBLESHOOTING ..................................................................... 38
43
WARRANTY .....................................................................................44
Cleaning ................................................................................................... 35
32
34

4
Safety
Precautions
Operating
Requirements
Parts and
Features
Start Up
Guide Controls
Dishwasher
Loading
Dishwasher
Use
Dishwasher
CareTroubleshooting
When using your dishwasher, follow basic precautions, including the
following:
•Read all instructions before using the dishwasher.
•Use the dishwasher only for its intended function.
•Use only detergents or rinse/wetting agents recommended for use in
a dishwasher and keep them out of the reach of children.
•When loading items to be washed:
•Locate sharp items so that they are not likely to damage the door
seal.
•Load sharp knives with the handles up to reduce the risk of cut-
type injuries.
•Do not wash plastic items unless they are marked “Dishwasher
Safe” or the equivalent. For plastic items not so marked, check the
manufacturer’s recommendations.
•Items that are not dishwasher safe may melt and create a potential
fire hazard.
•Do not touch the heating element during or immediately after use.
•Do not operate your dishwasher unless all enclosure panels are
properly in place.
WARNING/GROUNDING INSTRUCTIONS
Improper connection of the equipment-grounding conductor can result
in a risk of electric shock. Check with a qualified electrician or service
representative if you are in doubt whether the appliance is properly
grounded. Do not modify the plug if provided with the appliance. If the
plug will not fit the outlet, have a proper outlet installed by a qualified
electrician.
For a grounded, cord-connected appliance:
This appliance must be grounded. In the event of a malfunction or
breakdown, grounding will reduce the risk of electric shock by providing
a path of least resistance for electric current. If this appliance is equipped
with a cord having an equipment-grounding conductor and a grounding
plug, the plug must be plugged into an appropriate outlet that is installed
and grounded in accordance with all local codes and ordinances.
For a permanently connected appliance:
This appliance must be connected to a grounded metal, permanent wiring
system, or an equipment-grounding conductor must be run with the
circuit conductors and connected to the equipment-grounding terminal or
lead on the appliance.
IMPORTANT SAFETY INSTRUCTIONS
WARNING

5
Safety
Precautions
Operating
Requirements
Parts and
Features
Start Up
Guide Controls
Dishwasher
Loading
Dishwasher
Use
Dishwasher
Care Troubleshooting
•Do not tamper with controls.
•Do not abuse, sit on, or stand on the dishwasher door, or dish racks.
•To reduce the risk of injury, do not allow children to play in or on a
dishwasher.
•Under certain conditions, hydrogen gas may be produced in a
hot-water system that has not been used for two weeks or more.
HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not
been used for such a period, before using the dishwasher turn on
all hot-water faucets and let the water flow from each for several
minutes. This will release any accumulated hydrogen gas. As the gas
is flammable, do not smoke or use an open flame during this time.
•Severe product damage and/or injury could result from the use of
unqualified service technicians or non-original replacement parts.
All repairs must be performed by a qualified service technician using
only original equipment factory replacement parts.
•Do not store or use combustible materials, gasoline or other
flammable vapors and liquids in the vicinity of this or any other
appliance.
•Keep young children and infants away from dishwasher when it is
operating.
•Do not use the dishwasher if it has a damaged power line or plug,
and do not plug the dishwasher into a damaged outlet. Failure to
observe these instructions may result in electrical shock.
•This manual does not cover every possible condition or situation that
may occur.
•Remove the door to the washing compartment when removing an
old dishwasher from service or discarding it.
SAVE THESE INSTRUCTIONS
THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY
Tip Over Hazard
•Do not use dishwasher until completely installed.
•Do not push down on open door.
•Doing so can result in serious injury or cuts.
WARNING

6
Safety
Precautions
Operating
Requirements
Parts and
Features
Start Up
Guide Controls
Dishwasher
Loading
Dishwasher
Use
Dishwasher
CareTroubleshooting
State of California Proposition 65 Warnings:
Suffocation Hazard
•Before you throw away your old appliance, remove the door or lid so
that children cannot hide or get trapped inside your old appliance.
•Failure to follow these instructions can result in death or brain
damage.
•Never use harsh chemicals to clean your dishwasher. Some chloride-
containing products can damage your dishwasher and may present
health hazards!
•Never use steam cleaning products to clean your dishwasher. The
manufacturer will not be responsible for the possible damages or
consequences.
•To avoid possible dishwasher damage, do not use harsh chemicals,
abrasive cleaners, scouring pads (metal or plastic), or abrasive
cloths/paper towels to clean your dishwasher’s exterior door panel.
Your dishwasher’s exterior door panel can be damaged by doing so.
•It is highly recommended that the user become familiar with the
procedure to shut off the incoming water supply and the procedure
to shut off the incoming power supply. See the Installation
Instructions or contact your installer for more information.
•If the dishwasher drains into a food disposer, make sure disposer is
completely empty before running dishwasher.
•NSF/ANSI 184 Certified residential dishwashers are not intended for
licensed food establishments.
•Protect your dishwasher from the elements. Protect against freezing
to avoid possible damage to the fill valve. Damage caused by
freezing is not covered by the warranty.
•Not for outdoor use.
WARNING
WARNING:Cancer and Reproductive
Harm-www.P65Warnings.ca.gov.
CAUTION

7
Safety
Precautions
Operating
Requirements
Parts and
Features
Start Up
Guide Controls
Dishwasher
Loading
Dishwasher
Use
Dishwasher
Care Troubleshooting
OPERATING REQUIREMENTS
ELECTRICAL REQUIREMENTS
Electrical Shock Hazard
•Electrically ground dishwasher.
•Connect ground wire to green ground connector in terminal box.
•Do not use an extension cord.
•Failure to follow these instructions can result in death, fire, or
electrical shock.
This dishwasher is designed for operation on an adequately wired
individual 120 V, 60 Hz, 15- or 20-amp fused electrical supply with copper
wire only. It is recommended that a time-delay fuse or circuit breaker is
used, and that a separate circuit serving only this appliance is provided. If
an outlet is used, the outlet should be placed in adjacent cabinet.
LOCATION REQUIREMENTS
•Install where dishwasher is protected from the elements. Protect
against freezing to avoid possible rupture of fill valve. Such ruptures
are not covered by the warranty. For winter storage information, see
“Storing” in the “Dishwasher Care” section.
•Install and level dishwasher on a floor that will hold the weight and in
an area suitable for its size and use.
WATER SUPPLY REQUIREMENTS
•The water supply temperature should be 120°F to 150°F (49°C to
66°C).
•The water supply must maintain water pressure between 20 and 80 psi
for sufficient flow.
WARNING

8
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher
PARTS AND FEATURES
Upper Spray Arm
Upper Rack
A
B
C
D
E
F
A
B
C
D
E
F
G
H
I
J
K
M
N
Cup Shelf
Middle Spray Arm
Heating Element
Angle Wash Spray
H
I
J
K
LSilverware Basket
MLower Rack
Detergent Dispenser
Cutlery Shelf
Third Rack
Utensil Wash Spray
L
GRinse Aid Dispenser NLower Spray Arm

9
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher
SPECIFICATIONS
Capacity: 14 Place Settings
Dimensions (WxDxH): 237/8 1/2" x 333/4
99 lb
Power Supply:
Filter Location
A
A
120 V, 60 Hz
20 - 80 psi (138 - 55 2 kPa)

ADJUSTABLE UPPER RACK
The Adjustable Upper Rack feature allows you to load taller items in either
the upper or lower rack.
The upper rack of your dishwasher can be adjusted 2" (5.08 cm).
Adjusting the clearance of the Upper Rack increases or decreases the
clearance of the lower rack, as shown.
For instructions, see the “Adjustable Upper Rack” section.
10
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher
2" (5.08 cm)

11
Safety
Precautions
Operating
Requirements
Parts and
Features
Start Up
Guide Controls
Dishwasher
Loading
Dishwasher
Use
Dishwasher
Care Troubleshooting
START UP GUIDE
IMPORTANT:
•Properly dispose of/recycle all packing material.
•Read this entire User Manual. You will find important safety information
and useful operating tips.
HOW YOUR DISHWASHER CLEANS
Your dishwasher cleans by spraying a mixture of hot water and detergent
through the spray arms against soiled surfaces.
The dishwasher fills with water covering the filter area. Water is then
pumped through the multiple filters and spray arms. Soil particles are
separated from the water and go down the drain as the water is pumped
out and replaced with clean water.
The number of water fills will vary depending on the cycle selected.
BEFORE USING YOUR DISHWASHER
1. Check the filters for debris that may have been introduced from the
packaging or during installation. See the “Clean Filters” section.
2. Add Rinse Aid. See “Proper Use of Rinse Aid.”
USING YOUR NEW DISHWASHER
NOTE: To decrease cycle time and possibly improve performance, turn on
the hot water faucet nearest to the dishwasher until the water runs hot.
Turn off the water.
1. Load dishwasher. See “Dishwasher Loading.”
2. Add detergent. See “Proper Use of Detergent.”
3. Select desired CYCLE and OPTIONS. See “Cycle and Option Charts.”
•Only the Options available for the Cycle selected will illuminate.
•The controls of the selected Cycle and Options will glow to indicate
they are selected.
4. Press START.
IMPORTANT: For the dishwasher to begin operating, the door must be
closed within 4 seconds after pressing Start/Cancel.
5. Close the door firmly to latch.

CONTROLS
the dishwasher is open.
CYCLES
HEAVY
or baked on soil.
NORMAL
to completely wash and dry a full load of normally soiled dishes. The
the upper rack in the raised position.
QUICK
RINSE
A
B
The light above the
selected wash cycle illuminates to indicate the cycle selected.
AB C ED FG
D
12
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher
DELICATE
Delicate cycle is for items that need special care such as stemware or
porcelain.

OPTIONS
SANITIZE
the Sanitize option is completed. The light will turn off after the door
HI TEMP
C
The light above the selected
option(s) illuminates to indicate which option(s) have been selected.
Customizable wash cycle. Wash parameters such as Wash Temp,
Dry Level, Angle Wash time and Utensil Wash time can be set in the
MSmart APP. Multiple My Wash Cycles can be defined.
MY WASH
NOTE: MY WASH will be unavailable until the parameters have been set
in the MSmart APP and the cycle Uploaded to the dishwasher. The
dishwasher must be connected to a WiFi network.
When the Hi Temp option is selected, the water temperature will be
increased to achieve better results during the wash portion, compared
to the cycle without Hi Temp option.
the drying process. The Heated Dry process adds time to the
wash cycle.
13
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher
NOTE: It is possible that the dishwasher may not achieve the required
parameters for NSF/ANSI 184, if the temperature of the incoming hot
water does not meet the minimum requirement of 120°F (49°C).
When the Extended Dry option is selected, the heater and fan
operation will be extended to further improve drying performance.
The final rinse will be elevated and extend the heated dry time.

ANGLE WASH
Angle Wash will spray wash water from the left corners of the lower
rack onto the dishes. The Angle Wash works in conjunction with the
lower spray arm to aid in the removal of tough soils.
UTENSIL WASH
Utensil Wash will add a direct spray at the silverware basket to aid in
the removal of tough soils and improve the cleaning effect of cutlery.
W IFI
D
This button is used for network connections. To connect the appliance
to the network, first, switch on the appliance, and press WIFI button for
more than 3 seconds. After a short beep the WIFI icon in the panel will
start to blink slowly, the unit is connecting to the APP. The WiFi icon on
the panel will remain lit when the network connection is successful.
IMPORTANT:
If the Start Button is pressed during the network connection process,
the process will be canceled.
Turning Off the Network Connection: (temporarily)
With the power on and the door open. Press the WIFI button to turn
off the WIFI radio, the WIFI icon will turn off. To turn back on the
WIFI radio press the WIFI button with power on and door open,
the WIFI icon will illuminate.
Canceling or Resetting the Network Connection:
With the power on and the door open. Press and hold the WIFI
button for 15 seconds to turn off the WIFI radio and reset it to
factory default.
WIFI ICON
The WIFI icon indicates the status of the network connection.
WIFI icon states:
Quick Flash-Connecting to the router
Slow Flash-Connecting to the sever
Light on-Link successfully
Light off-WIFI model power off
A DDITIONAL FEATURES
DELAY
The Delay Time feature allows you to program the dishwasher to begin
the selected wash cycle 1 to 24 hours later. Press the DELAY button
until the desired hours of delay is shown on the display.
NOTE: Pressing the delay button for 3 seconds will reset the delay back
to zero, canceling the delay. until the desired hours of delay is shown on
the display.
E
14
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher

F
1.
action stops.
2.
3.
4.
START
G
Sanitize option is finished.
The light turns off 30 seconds after the door is opened.
Rinse Aid
Rinse Aid should be added to the Rinse Aid dispenser.
Sanitized
SCREEN
icon
icon
icon
15
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher
QUICK and RINSE

LED INDICATOR LIGHTS
Located on the front of the dishwasher is a row of four LED lights. These
lights will either indicate the progress of the current cycle or alert you to a
malfunction by indicating an Error Code.
CYCLE PROGRESS INDICATOR
Status Description
Power On
Blinking
The dishwasher is on, but the cycle has not started.
Wash
Slow Blinking
The dishwasher is in the Wash stage of the cycle.
Rinse
Slow Blinking
The dishwasher is in the Rinse stage of the cycle.
Dry
Slow Blinking
The dishwasher is in the Drying stage of the cycle.
Completed
Solid
The dishwasher has completed all stages of a cycle
including Dry.
The lights will turn off 30 seconds after opening
the door.
ERROR INDICATOR
In situations, which are critical to dishwasher function and safe operation,
the control will shut down and indicate an Error code in the display. See
“Error Codes” in the Troubleshooting section. If an Error code is displayed,
contact Midea Customer Service. They will be able to provide assistance
with troubleshooting the problem or locating an authorized service
technician.
16
Safety
Precautions
Operating
Requirements
Parts and
Features
Start Up
Guide Controls
Dishwasher
Loading
Dishwasher
Use
Dishwasher
Care Troubleshooting

and options selected.
the main wash.
required to clean the load.
“O”: Can be selected, but cannot be selected if the other Dry option is
selected
Wash
Second
Wash
Main
Wash
Rinse Rinse Final
Heated
Rinse
Dry
(min)
Water
Usage
(gal. [L])
••
113° -
140°F
(45° -
3.01 to
5.94 gal.
(11.4 to
22.5 L)
AVAILABLE OPTIONS
Sanitize Hi Temp Extended Dry
X X
Heated Dry
O O
60
136.4 -°
149°F
(58 -°
65 )°C
98-141
Angle Wash Utensil Wash
X X
17
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher

HEAVY
Wash
Second
Wash
Main
Wash
Rinse Rinse Final
Heated
Rinse
Dry
(min)
Water
Usage
(gal. [L])
•• •
140°F •
(60°C)
• •
6.92 gal.
(26.2 L)
NORMAL
Wash
Second
Wash
Main
Wash
Rinse Rinse Final
Heated
Rinse
Dry
(min)
Water
Usage
(gal. [L])
••3.01 to
5.94 gal.
(11.4 -
22.5 L)
149°F
(65°C)
149
AVAILABLE OPTIONS
Sanitize Hi Temp Extended Dry
X X
Heated Dry
O O
Angle Wash Utensil Wash
X X
AVAILABLE OPTIONS
Sanitize Hi Temp Extended Dry
X X
Heated Dry
O O
Angle Wash Utensil Wash
X X
113° -
131°F
(45° -
55°C)
136.4 -°
143.6°F
(58 -°
6 )2°C
98-136
18
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher

QUICK
Wash
Second
Wash
Main
Wash
Rinse Rinse Final
Heated
Rinse
Dry
(min)
Water
Usage
(gal. [L])
••
131°F
(55°C)
•
4 gal.
(15.1 L)
Wash
Second
Wash
Main
Wash
Rinse Rinse Final
Heated
Rinse
Dry
(min)
Water
Usage
(gal. [L])
••
120°F
(50 °C)
5.9 gal.
(22.5 L)
AVAILABLE OPTIONS
Sanitize Hi Temp Extended DryHeated Dry
O O
136.4°F
( )62°C
118
Angle Wash Utensil Wash
AVAILABLE OPTIONS
Sanitize Hi Temp Extended DryHeated Dry
O O
Angle Wash Utensil Wash
DELICATE
Use this cycle for lightly soiled or rinsed glassware and fine china.
136.4°F
( )58°C
131°F
( )55°C
•
19
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher

RINSE
Wash
Second
Wash
Main
Wash
Rinse Rinse Final
Heated
Rinse
Dry
(min)
Water
Usage
(gal. [L])
20
•2.03 gal.
(7.7 L)
Wash
Second
Wash
Main
Wash
Rinse Rinse Final
Heated
Rinse
Dry
(min)
Water
Usage
(gal. [L])
••3.01 to
5.94 gal.
(11.4 to
22.5 L)
136.4 -°
149°F
(58 -°
65 )°C
98-141
AVAILABLE OPTIONS
Sanitize Hi Temp Extended DryHeated Dry Angle Wash Utensil Wash
AVAILABLE OPTIONS
Sanitize Hi Temp Extended DryHeated Dry Angle Wash Utensil Wash
MY WASH
This is a customed cycle. Before using it ,you need to define it on APP.
122°F/
31°F/1
40°F1
(50°C/
55°C/
60°C)
20
Safety Parts and Start Up
Guide
Dishwasher
Loading
Dishwasher
Use
Dishwasher
