Midea MAE50-S1102 User manual

1.6/2.1 CU. FT. 11/15LBS. PROTABLE TOP LOAD WASHER
USER MANUAL
MODEL MAE50-S1102 & MAE70-S1402
Midea America Corp.
4 Campus Drive Parsippany, NJ 07054, U.S.A
www.mideaamericacorp.com
Cusomer Service 1866-646-4332

2

CONTENTS
Important Safeguards..........................................................................................................................3
Installation Instructions.......................................................................................................................8
Before Washing Preparation..............................................................................................................10
Parts and Features..............................................................................................................................11
Washing Cycle Guide..........................................................................................................................13
Maintenance and Care / Error Codes.................................................................................................17
Troubleshooting...................................................................................................................................18
Warranty Information...........................................................................................................................19
Reqistration info and registratton card..............................................................................................20
Before using your washing machine, please read this manual carefully and keep it for future
reference.
READ THIS USER MANUAL
Inside this manual, you will find many helpful information on how to properly use and maintain your washing machine.
Just a little preventative care on your part can save you a great deal of time and money over the life of your washing
machine. You will find many answers to common problems in the troubleshooting tips section. If you review thissection
first, you may not need to call for service.
UNPACKING YOUR WASHING MACHINE
1. Inspect and remove all packaging material.
2. Inspect and remove all remaining packing, tape, or printed materials before powering on your washing machine.
WARNING
!
RISK OF CHILD ENTRAPMENT. CHILD SUPERVISION IS NECESSARY. THIS
APPLIANCE IS TO BE USED ONLY FOR ITS INTENDED PUPROSE AS DESCRIBED
IN THIS MANUAL. READ ALL RECOMMENDED SAFEGUARDS THOROUGHLY.

3


IMPORTANT SAFEGUARDS
WARNING
!
To reduce the risk of fire, electric shock, or personal injury when using your appliance,
follow these basic precautionary guidelines, which includes the following:
14. Read all instructions before using the appliance.
15. Use this appliance only for its intended purpose as described inuser manual.
10. Use only detergents or softeners as recommended for use in this manual and keep
them out of the reach of children.
2. This appliance must be properly installed in accordance with theinstallation instructions
before it is to be used.
12. Never unplug your appliance by pulling on its power cord. Alwaysgrasp the plug firmly
and pull it straight out from the outlet.
13. Immediately replace any power cords, loose plugs, and power outlets in poor condition.
Consult a certified electrician when replacing wall outlets.
3. Unplug your appliance before any maintenance and care duties, orbefore making any
repairs to the appliance.
1. If your old appliance is not being used, we recommend that you remove the door or properly
dispose your old appliance according to local law ordinances.
9. Do not operate your appliance in the presence of explosive fumes.
4. Do not wash or dry articles that have been previously spotted, cleaned in, washed in, or
soaked in food oils, gasoline, dry cleaning solvents, chemicals, and any other flammable
or explosive substance, as they give off vapors that could ignite or explode.
11. Clothes or rags used to clean flammable or explosive substances should not be washed
in this appliance until all traces of this material have been removed.
5. Do not add or mix any flammable or explosive substances to the washer.
6. Do not try to remove clothes while the washer tub is moving. Wait for it to come to a
complete stop before removing clothes.
16. The loading door of the washer must be closed when the tub is spinning.
7. Do not operate your appliance when parts are either missing or broken.
8. Do not use this appliance for commercial purposes. For household use only.

4
17. Do not operate this washer unless all enclosure panels are properly installed.
18. Do not tamper with the controls.
19. Do not allow any children to play on or in the appliance. Close supervision of children is necessary
when the appliance is used around them.
20. This appliance must be connected to a proper electrical outlet with the correct amount of electrical
supply, as specified on the rating label.
21. Proper grounding must be ensured to reduce the risk of electric shock and fire. Do not cut or
remove the grounding plug. If you do not have a three-prong electric receptacle wall outlet, have a
certified electrician install the proper receptacle wall outlet. The wall outlet must be properly
grounded.
22. Under certain conditions, hydrogen gas may be produced in a household hot water system that has
not been used for two weeks or more. Hydrogen gas is highly explosive. If the hot water system
has not been used for more than two weeks, turn on all hot water faucets and let the water flow for
several minutes prior to using your compact washer.
2 . Do not repair or replace any part of the appliance or attempt any servicing unless specifically
recommended by the user-repair instructions, which you fully understand and have the ability to
carry out.
NOTE: If for any reason this product requires servicing, we strongly recommend that a certified
technician performs the service.
24. To reduce the risk of electric shock or fire, do not use an extension cord or outlet adapters to
connect the unit to an electrical power source. The appliance must be properly grounded using a
three-prong electric receptacle wall outlet.
SAVE THESE INSTRUCTIONS
GROUNDING INSTRUCTIONS
This appliance must be properly grounded. In the event of malfunction or breakdown,
grounding will reduce the risk of electric shock by providing a path of least resistance for
electric current. This appliance is equipped with a power cord with a three-pronged plug for
grounding purposes. This three-pronged plug must be plugged into an appropriate outlet
that is properly installed and grounded in accordance with all local codes and ordinances.
Improper connection of the power cord can result in a risk of electric shock. Check with a qualified
electrician or serviceman if you are in doubt as to whether the appliance is properly grounded. o not
modify the provided plug with the appliance – even if it will not fit into the outlet. Have a qualified
technician install the proper wall outlet for you.
To reduce the risk of electric shock, disconnect this appliance from the power supply before
attempting any user maintenance and care. Turning the controls to the OFF position does not
disconnect this appliance from the power source.
WARNING
!WARNING !
WARNING
!WARNING !

5
SAFETY AND PRECAUTIONS
In order to prevent injury to yourself and others, or property damage, observe the following items:
!
!
Warning
Caution
This symbol indicates the possibility of death or serious injuey.
This symbol indicates the possibility of injury or property damage.
Observe the following visual guidelines:
NEVER DO THIS.
ALWAYS DO THIS.
!
!Warning
Do not directly rinse the machine with
water when cleaning.
Do not install the washer in moisture
enriched environment in order to avoid
electric shock, fire, or other electrical
accidents.
Do not disassemble and reassemble
the washer without
authorization.
Do not insert your hand and take
out clothes inside the spinning
tub before it stops.

6
Warning & Caution
!
Do not let children climb onto the
machine or peer into the spinning
tub, in order to avoid injury.
Prohibit from washing clothes that
came in contact with kerosene,
gasoline,alcohol, or any other
flammable chemicals.
Do not damage the power cord orplug
to avoid electric shock, fire, and/or
short-circuiting the appliance.
Do not place any incense, flammable
items, and other heating sources
ontothe washing machine.
Please do not pull out or insert the
plug with wet hands to avoid electric
shocking.
Customers are not allowed to change
the power line without permission.
> C
5 5
The water temperature shall not exceed
55 when washing
with warm water.
℃
It is strictly prohibited to place and sit
children or lay
weights on the
washer.

7
Insert the 3-pronged power plug
securely into the electrical outlet.
!
Properly connect the ends of the
power cord and water hose to avoid
anyaccidental leakage and electric
shock.
Pull out the 3-pronged plug from
the socket when the machine is
not in use.
Regularly clean the power plug
toremove dust and dirt, in order
to preventelectrical failure.
!
Please use correct power source.
!
Please ensure that the water inlet pipe
is connected and the tap is opened
before washing
clothes.
!
Please do not pull the electric cord
plug.
!
Please do not wash down raincoat,
fishing coat and similar
clothes in the
washer.
when pulling out the

8
INSTALLATION INSTRUCTIONS
REMOVE PACKAGING
•Remove packaging, foam cushions, and bottom cardboard.
•Open the washer door and take out the accessories.
•Use of washer with the foam cushion is strictly prohibited. Foam
Cushion
Base
The height of the drain hose (A) should be between ~34 to
40”.Its diameter (B) should not be less than 1.20”, and its
flow capacity should not be less than 40 L/Min.
FOR U PPER DRAIN SYSTEM ONLY
34~40''
PLACEMENT OF UPPER WATER DRAIN HOSE
Before starting the washer, users should properly hang the drain
pipe ~34 to 40”above the floor.
INSTALLATION OF WATER INLET HOSE
•Place the water inlet hose screw onto the tap. Water inlet hose
Clamping nut
ONLY FOR WATER INLET HOSE
WITH DOUBLE THREADED SCREW
•Tightly screw the other end of the hose to the
water inlet valve using the rubber seal ring
inside.
NOTE:When tightening the clamping nut, evenly
apply force and avoid twisting the water inlet valve
to prevent breakage of the water inlet valve joint.

9
QUICK SINK ADAPTER INSTALLATION
QUICK SINK ADAPTER INSTALLATIONQUICK SINK ADAPTER INSTALLATION
QUICK SINK ADAPTER INSTALLATION
When installing the quick sink adapter to the sink faucet, follow these guidelines:
1. Remove the aerator from your faucet nozzle and determine the size and type of the faucet
(Outside Threaded End or Inside Threaded End).
2. Once you determine the size and type of the faucet, place the proper sized rubber washer into
the silver faucet adapter.
. Attach the silver faucet adapter to the sink faucet.
4. Attach the faucet adapter to the water inlet hose and ensure that the rubber washer is placed
between the adapter and the water inlet hose.
5. Attach the other end of the water inlet hose to the water inlet on the washer, and ensure that
the rubber washer is placed between the water inlet hose and the washer.

10
PREPARATION BEFORE WASHING
PREPARATION BEFORE WASHINGPREPARATION BEFORE WASHING
PREPARATION BEFORE WASHING
ADJUST THE FOOT TO STABILIZE
THE WASHING MACHINE.
INSTALL THE WATER
INLET HOSE.
CONNECT TO A
POWER SOURCE.
ENSURE PROPER
PLACEMENT OF
DRAIN HOSE FOR
WATER DRAINING.
TURN ON THE
WATER SUPPLY.
PLACE
CLOTHES
INTO THE
WASHER
AND ADD A
SUITABLE
AMOUNT OF
WASHING
POWDER
BASED ON
LAUNDRY
VOLUME,
AND SELECT
WASH
CYCLE
PROGRAM.
Before washing clothes, take out any coins,
keys, and other hard items, while zipping up
zippers to prevent any damage.
NOTE: The water will overflow when the
height of the drain hose is under 4”.
UPPER DRAINAGE
~34-40”
TWO WATER INLET HOSES
Adjustable foot. Rotating clockwise
will extend the foot, and rotating
counterclockwise will shorten the foot. Slightly incline
the washer first and loosen the adjustable foot knob
prior to rotating. Adjust all four corners of the washer
to ensure an even, stable surface with the ground.
Then tighten the adjustable foot knob and lock it. If
the ground is not flat, make corrections on the ground
surface, otherwise the washer barrel will spin on an
incline and knock into the washer cabinet.

11
PARTS AND FEATURES
PARTS AND FEATURESPARTS AND FEATURES
PARTS AND FEATURES
POWER LINE
WATER INLET
DRAIN HOSE
(UPPER DRAIN ONLY)
CONTROL PANEL
ADJUSTABLE LEG
CABINET
FRAME
TOP LID
WATER
INLET HOSE
FOR LOWER DRAIN SYSTEM USE ONLY
INCLUDED WITH WASHING MACHINE

12
CONTROL PANEL
CONTROL PANELCONTROL PANEL
CONTROL PANEL
WATER LEVEL
FUNCTION
DELAY
PROGRAM
CHILD LOCK
TEMPERATURE
START/PAUSE
POWER
Press this button to select water
level. The indicator lights will move
each time the button is depressed.
• Press this button to select wash time.
• Press this button to select rinse time.
• Press this button to select spin time.
Press this button to preset the
delay function. For less than
24 hours, each time the button
is depressed, the time delay is
an hour. For 24+ hours, each
time the button is depressed,
the time delay is 6 hours.
After 48 hours, the preset
indicator will reset.
Press this button to select fully
automatic programs like:
Normal (Light) Quick (Flash)
Jeans (Light) Anti-Wrinkle (Flash)
Cotton (Light) Air Dry (Flash)
Press the “Water Level” button
and “Function” buttons at the
same time to engage the lock
feature. Press the “Water Level”
And “Spin” button at the same
Time to disengage the child lock.
Press this button to set either HOT
or COLD water for the wash cycle.
When the HOT and Cold indicator
lights are both lit, both water inlets
are activated for WARM water.
• ON/OFF Power
• Automatic Power
Press this button after program
selection to start the washer.
Press this button again to pause
the current program. Press this
button once more to continue
the currently selected program.

1
QUICK START GUIDE
QUICK START GUIDEQUICK START GUIDE
QUICK START GUIDE
1. Install the Washing Machine
2. Load the Washer
3. Add Measured
Detergent
4. Close Washer Door
5. Properly Hang
the Drain Pipe
6. Turn on the
Water Supply
7. Plug-in the Power
Supply
8. Select the Desired
Wash Cycle Program
9. Press the START/PAUSE Button
END OF WASH CYCLE
• When the washing machine stops, the buzzer will sound for 6 seconds, and then the washer will
automatically power down.
• Turn off the water tap afterwards.
• Although the washer powers down automatically, the power cord needs to be pulled out for safety
and precautionary measures.

14
MAIN WASHING PROCEDURE
MAIN WASHING PROCEDUREMAIN WASHING PROCEDURE
MAIN WASHING PROCEDURE
INSTRUCTIONS FOR NORMAL WASH PROGRAM
• The NORMAL wash cycle program is the easiest, most convenient and common wash cycle
program to use. When the user presses the POWER button and then immediately presses
the START/PAUSE button, the NORMAL wash cycle program is activated.
• When the washing machine begins the program, the digital display will show the remaining time. The
indicator light will flicker to show the remaining time for the wash cycle program.
STEPS IN DETAIL
1. Press the POWER button to turn the washer ON.
2. Determine the laundry load and select the appropriate water level.
. Press the START/PAUSE button to begin the wash cycle program.
INSTRUCTIONS FOR SINGLE WASH CYCLE PROGRAM
• The user can select any single wash cycle program, or any combination of programs from the WASH,
RINSE, and SPIN options according to laundry load requirements. Deselect any one or two of the
three indicators that are not needed, while the remaining indicator displays the currently activated
wash program selected by the user.
STEPS IN DETAIL FOR SINGLE WASH
1. Press the POWER button to turn the washing machine ON.
2. Turn OFF RINSE and SPIN indicators by pressing their respective buttons.
. The operation for single RINSE and single SPIN are similar in format.
USING THE MULTI-BATCH WASHING SOLUTION
1. Load the first batch of laundry into the washing machine, add washing powder, and press the
FUNCTION button to set the single WASH to run.
2. Unload the first batch of laundry after hearing the end of wash buzzer.
. Load the second batch of laundry into the washer, and select WASH, RINSE, or SPIN.
4. Unload the second batch of laundry after hearing the end of wash buzzer.
5. Load the first batch of laundry into the washing machine and press the FUNCTION button to set the
RINSE and SPIN to run.
NOTE:
•Close the lid after loading the washing machine, otherwise it will automatically stop working, and an
abnormal warning indicator is issued.
•The washing machine will not work when the amount of water does not reach the selected water level.
•After pressing the P WER button, if the START/PAUSE button is not pressed, the washing machine
will automatically power down after 10 minutes.

15
SPECIAL FUNCTIONS
SPECIAL FUNCTIONSSPECIAL FUNCTIONS
SPECIAL FUNCTIONS
DELAY FUNCTION
The washing machine can be delayed by using this preset feature:
1. Switch the power to ON.
2. Open the water tap and hang the drain hose.
. Load the laundry and detergent into the washer.
4. Select the appropriate water level according to the
laundry load (quantity of clothing articles).
5. Select the appropriate functions and programs.
6. Press the DELAY button to select the amount of
time to delay the washing cycle.
7. Close the washer lid and press the START/PAUSE
button.
QUICK
Use this function for short washing times. This
function is suitable to wash lightly stained clothes
or clothing made from lightweight materials.
COTTON
Use this function to wash clothes or linens
made from cotton.
JEANS
Use this function to wash heavy or seriously
stained clothes.
DELAY FUNCTION CONFIRMATION
When the delay function is activated, the
corresponding delay light will flash, and all
other lights will turn off. To check the preset
program and function, press and hold the
DELAY button. Release the DELAY button
to return to the delay status.
CHANGES TO THE DELAY FUNCTION
Press the POWER button to cancel the set delay
function. To change the time on the delay function,
cancel the delay time first, and then press the
DELAY button to reset the program. Follow the
procedures listed above to program a new preset.
ANTI-WRINKLE
Use this function for short washing times.
Using the high water level, this function thoroughly
rinses and washes garments to prevent wrinkling.
AIR DRY
For easily fading, deforming, and non-waterproof
garments, use this function to dry these garments
without regular heating, achieving similar results
when hang-dried.
POWER LOSS MEMORY FUNCTION
The washing machine will automatically resume operation from the previous function prior to power outage.
Press the DELAY button to add ONE
HOUR to the digital delay indicator.
After the number reaches 24, press
the DELAY button to add SIX HOURS
to the delay function. After the number
reaches 48, the digital delay indicator
will turn off and reset to default status.
TIME REMAINING
DELAY (HOUR)
(MINUTES)
DELAY LIGHT
DELAY FUNCTION LAYOUT

16
FULL AUTOMATIC WASH PROGRAM GUIDE
FULL AUTOMATIC WASH PROGRAM GUIDEFULL AUTOMATIC WASH PROGRAM GUIDE
FULL AUTOMATIC WASH PROGRAM GUIDE
NOTE: The time required may vary depending on water pressure from inlet pipe, garment materials, and
different water draining conditions.
WASHER
FUNCTION
WATER LEVEL WASH TIME RINSE
TIME
SPIN
TIME
TOTAL
TIME
NOTES
DEFAULT SCOPE
NORMAL 4 1-6 11 MIN 0 SEC 2 MIN 5 MIN
00 SEC
42 MIN WASH TIME
INCLUDES
SOAK TIME
QUICK 1- 2 MIN 00 SEC 1 MIN 00 MIN
30 SEC
10 MIN WASH TIME
INCLUDES
SOAK TIME
COTTON 1- 1 MIN 00 SEC (SOAK)
MIN 40 SEC (WASH)
1 MIN 7 MIN
00 SEC
9 MIN WASH TIME
INCLUDES
SOAK TIME
JEANS 4 1-6 1 MIN 00 SEC (SOAK)
MIN 0 SEC (WASH)
2 MIN 1 MIN
10 SEC
42 MIN WASH TIME
INCLUDES
SOAK TIME
ANTI-WRINKLE 4 1-6 11 MIN 0 SEC 2 MIN 00 MIN
00 SEC
4 MIN WASH TIME
INCLUDES
SOAK TIME
AIR DRY 4 1-6 00 MIN 00 SEC 0 MIN 57 MIN
00 SEC
60 MIN WASH TIME
INCLUDES
SOAK TIME
WATER
LEVEL
WATER
VOLUME
LAUNDRY
WEIGHT
CONCENTRATED
WASHING POWDER
COMMON SYNTHETIC
DETERGENT
CONCENTRATED
LIQUID DETERGENT
6 ~52 L < 11.0 lbs 1.05 oz 1.89 oz 1.05 oz
5 ~47 L < 8.8 lbs 0.91 oz 1.62 oz 0.91 oz
4 ~ 9 L < 7.7 lbs 0.78 oz 1. 2 oz 0.78 oz
~ 2 L < 5.5 lbs 0.64 oz 1.08 oz 0.64 oz
2 ~26 L < 4.4 lbs 0.61 oz 1.18 oz 0.61 oz
1 ~20 L < 2.2 lbs 0.44 oz 0.88 oz 0.44 oz
NOTE:
•It is recommended to use low or mid foaming powder
•The volume of washing powder changes with different volume and weight.
•Water volume will differ because of clothing varieties. If the washer is not running properly, adjust the
clothing volume or water level.
•The water volumes listed above are based on normal clothing volumes.

17
MAINTENANCE AND CARE
MAINTENANCE AND CARE MAINTENANCE AND CARE
MAINTENANCE AND CARE / ERROR CODES
ERROR CODESERROR CODES
ERROR CODES
END OF PROGRAM MAINTENANCE
The washing machine will sound off a buzz at
the end of any program operation to remind
the user to take out the laundry or to operate it
again.
After the sound, the washing machine returns
to its OFF state with no display and all
indicator lights turned off.
Please shut off the water tap, pull out the
power plug when not in use to avoid water
leakage or accidental fire.
Use gentle wash cloths to wipe off any water
and dirt residues from the surface of the
washing machine after every use.
Detergent, propellants, and other chemicals
are prohibited in order to avoid any possible
damage to the washing machine and its
plastic accessories.
Clean the water inlet hose and drain filter to
prevent any possible draining problems (after
every ~10 washes).
Clean any filters to maintain optimal
performance (after every use).
NOTE:
1. Overflow alarm: washer water drain valve remains open until manual intervention (shutoff).
2. Once the alarm stops, the washer returns to its previous status prior to the alarm indication.
PROBLEM CAUSE OF PROBLEM CODE ALARM
SOUND
STOPPING
ALARM
Water
Hose
Alarm
Fails to reach preset water
level, after injecting water for
about 16 minutes.
CODE: E1
Other lights are
turned off
Buzzer
10 Seconds
Every 16
Minutes
Open lid to fix fault.
Then close lid to
stop the alarm.
Open Lid
Alarm
Opening the lid after starting
the delay function. Opening
the lid when the washer is
running a program.
CODE: E2
Other lights are
turned off
Buzzer
10 Seconds
Every 16
Minutes
Open lid to fix fault.
Then close lid to
stop the alarm.
Imbalance
Alarm
Washing machine imbalance
checked three times.
CODE: E3
Other lights are
turned off
Buzzer
10 Seconds
Every 16
Minutes
Open lid to fix fault.
Then close lid to
stop the alarm.
Drain
alarm
Draining fails to finish, after
draining for 4 minutes.
CODE: E4
Other lights are
turned off
Buzzer
10 Seconds
Every 16
Minutes
Open lid to fix fault.
Then close lid to
stop the alarm.
Overflow
Alarm
Water inlet hose. CODE: E5
Other lights are
turned off
Buzzer
10 Seconds
Every 16
Minutes
Open lid to fix fault.
Then close lid to
stop the alarm.

18
TROUBLESHOOTING
TROUBLESHOOTINGTROUBLESHOOTING
TROUBLESHOOTING
When the washing machine needs servicing, please contact our customer service department, and a
representative will try and diagnose issues regarding your appliance. Please do not dismantle the washing
machine without prior permission. Doing so will void your warranty.
If the washing machine fails to operate properly, or it sounds an alarm, please check the follow guidelines
for possible solutions to common problems or alarm indicators.
LIST OF PROBLEMS AND POSSIBLE SOLUTIONS
NOTE: During the spin cycle process, if the laundry is loaded onto one side of the washing tub, there will be
an imbalance in the washing tub’s spin trajectory, resulting in it striking the housing of the washing machine.
The washing machine will compensate for this phenomenon by automatically correcting it with more water.
However, if the imbalance is not resolved after three continuous corrections, the auto-correction system will
stop. The user is then required to manually correct the imbalance by evenly distributing the laundry inside
the tub, in order to resolve this problem.
PROBLEMS MAKE THESE INSPECTIONS
Water Fails to Flow In - The power is off or the fuse has burned out.
- Water supply is cutoff or low pressure.
- Inlet hose and water tap is connected and open.
- Filter of inlet valve is blocked by dirt buildup.
- Coil of inlet valve is damaged.
- The START/PAUSE button is activated.
Washing Machine Fails to Run - The power is off or the fuse has burned out.
- The power supply voltage is too low.
- Water needs to reach required water level.
- The DELAY function is activated.
Abnormal Drainage - The drain hose is placed too high (See Installation Guide).
- The drain hose end is sealed or blocked.
- The internal rubber ring of valve is blocked.
Abnormal Spin - The door lid is not closed.
- Laundry is improperly or excessively loaded.
- The ground is not flat or its feet are not leveled.
- The washing machine’s motor belt is loose.

19
LIMITED WARRANTY
Midea Amerca corp Corporation warrants each new 1.6 / 2.1 CU. FT. Washing Machine to be free from defects in material
and workmanship, and agrees to remedy any such defect or to furnish a new part(s), at the company’s option, for any
part(s) of the unit that has failed during the warranty period. Parts and labor expenses are covered on this unit for a
period of one year from the date of purchase. A copy of the dated sales receipt or invoice is required to receive warranty
service by an authorized service agent.
This warranty covers appliances in use within the continental United States, Puerto Rico, and Hawaii. The warranty does
not cover the following:
� Damages due to shipping damage or improper installation.
� Damages due to misuse or abuse.
� Content losses due to failure of the unit.
� Inside components such as filters, etc.
� Repairs performed by unauthorized service agents.
� Service calls that do not involve defects in material and workmanship such as instructions on proper use of the product or
improper installation.
� Replacement or resetting of house fuses or circuit breakers.
� Failure of this product if used for other than for its intended purpose.
� Disposal costs for any failed unit not returned to our factory.
� Any delivery costs incurred as the result of a unit that fails to perform as specified.
� Expenses for travel and transportation for product service if your appliance is located in a remote area where service by an
authorized service technician is not available.
� The removal and reinstallation of your appliance if it is installed in an inaccessible location or is not installed in accordance
with published installation instructions.
Limitations of Remedies and Exclusions:
Product repair in accordance with the terms herein, is your soleand exclusive remedy under this limited warranty. Any and all
implied warranties including merchantability and fitnessfor a particular purpose are hereby limited to one year or the shortest
period allowed by law. Midea Amerca Corporation is not liable for incidental or consequential damages and no representative
or person is authorized to assume for us any other liability in connection with the sale of this product. Under no circumstances
is the consumer permitted to return this unit to the factory without prior written consent of Midea Amerca Corporation.
Some states prohibit the exclusion or limitation of incidental or consequential damages, or limitations on implied warranties.
This warranty gives you specific legal rights, and you may also have other rights which very from state to state.
Model Parts Labor Type of Service
MAE50-S1102 & MAE70-S1402 1 Year 1 Year Carry In / In Home
For Service or Assistance, please call 1866-646-4332. Or visit us on the web at www.mideaamericacorp.com.

20
Registration Information
Midea America Corp. 11800 NW 100th Rd. Suite 4 Medley, FL 33178
Protect your product:
We will keep the model number and date of purchase of your new Midea product on file to
help you refer to this information in the event of an insurance claim such as fire or theft.
Promote better products:
We value your input. Your responses will help us develop products designed to best meet
your future needs.
-------------------------------------------------------(detach here)--------------------------------------------------------------
Midea Registration Card
Name
Model # Serial #
Address
Date Purchased Store / Dealer Name
City State Zip
E-mail Address
Area Code Phone Number
Occupation
Did You Purchase An Additional Warranty
As your Primary Residence, Do You:
Extended
Own Rent
None
Your Age:
under 18 18-25 26-30
31-35 36-50 over 50
Marital Status:
Married Single
Is This Product Used In The:
Home Business
How Did You Learn About This Product:
Advertising
In-Store Demo
Personal Demo
Comments:
Information collected or submitted to us is only available to company internal employees for purposes of contacting
you or sending you emails, based on your request for information and to company service providers for purposes of
providing services relating to our communications with you. All data will not be shared with other organizations for
commercial purposes.
Please fill it out and return it to the following address:
