Midea MFWS512 User manual

MFWS512
Front Load Washer 5kg
USER MANUAL

CONTENTS
1
Safety information ........................................ 2-3
Identifying parts of the Washer ........................................ 4
Installation ........................................ 5-7
Control Features and Functions ........................................ 8
Wash Programs ........................................ 9
Wash Guide ........................................ 10-12
Cleaning & Maintenance ........................................ 13-14
Troubleshooting Guide ........................................ 15-16
Repairs, Service & Warranty ........................................ 17
Specifications ........................................ 18

SAFETY INFORMATION
Congratulations on your new Midea washer. This manual contains important information
on the installation, use and care of your appliance. Please read this manual carefully
before use. Follow instructions and keep the manual for future reference.
WARNING
The WARNING symbol indicates information that concerns your personal safety
WARNING
CAUTION
CAUTION The CAUTION symbol indicates information on avoiding damage to the appliance
Before using your appliance
Before using your washing machine, we recommend you read through this manual which
provides a description of your appliance and its functions. To avoid risk to yourself or
others, it is important that the washing machine is installed correctly and that you read
the safety instructions carefully.
Do not remove the attached adhesive identification label containing model number, serial
number and other information as this label will be used by the Midea authorized service
representative in the event that your washing machine needs servicing.
Information on disposal
Most of the packing material used is recyclable. Please separate the plastic and
cardboard and dispose through your local recycling depot or place in appropriate
recycling collection bins.
If disposing of this appliance, please contact your local authority for safe disposal.
Incorrect disposal may cause injury to the user.
2
WARNING
Keep packaging materials away from children to eliminate risk of suffocation.
This appliance is not intended for use by persons (including children with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.

SAFETY INFORMATION
Safety precautions
-Young children should be supervised to ensure that they do not play with the appliance.
-Keep ventilation openings in the appliance enclosure or in the built in structure clear of obstruction.
-Choose a location that is indoors, completely dry and away from damp environments.
-The washer is designed to operate on a single phase power supply within a voltage range of
220~240V/50Hz.
-Please keep the appliance away from substances which could cause ignition.
-Do not store inflammable materials such as ether, benzene, LP gas and glue etc near the appliance.
-Do not splash water on the rear of the appliance, for it may cause malfunction or electric
shock.
-Before cleaning the appliance, always switch off and unplug it.
-Do not disassemble any part of the clothes washer.
-Do not insert your hand and remove items from the washer until it has come to a complete stop.
-Do not splash, wet or hose down the appliance. It is recommended to use a damp cloth when
cleaning the cabinet.
-Do not attempt to wash fabrics that contain latex or rubber material.
-Do not place items that have come in contact with any flammable materials such as
petrol/gasoline, kerosene, cleaning solvents, vegetable oil, cooking oil or any explosive
substances.
-Do not place heat sources (candle, heater, etc.) on top of or near the washer.
-Do not sit children or heavy object on top of the washer.
-Do not pull the power cord out of the power socket by the cord. Always unplug the washer holding
the plug.
-If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid hazard.
3

IDENTIFYING PARTS OF THE WASHER
4
Accessories
cold water inlet hose drain hose support transit bolt caps (x4)
detergent dispenser
drawer
service panel
door
control panel
detergent dispenser
power cord with plug
drain hose
adjustable feet (x4)
cabinet

Unpack the clothes washer
INSTALLATION
Remove the clothes washer from the carton. Please dispose of packaging and plastic
bags responsibly.
Open the washer door and remove the accessories from inside the washer (as listed
on page 4).
Select the location
Remove transit bolts
Before installing & using this washing
machine, the transit bolts must be removed
from the backside.
The clothes washer should be located on a firm and flat surface. An uneven surface may
cause excess operating noise or vibration and effect the performance of the washer.
-The noise may be increased if the floor is not firm.
-It is not recommended to place on carpeted flooring. If this can not be avoided, place a
solid sheet under the appliance.
-Choose a location which is indoors, dry & away from high temperature and high
humidity.
-Ensure room temperature is not below 0°C.
-Make sure that air circulation around the machine is not impeded by carpets, rugs etc.
-Check that the machine does not touch the wall or cupboard.
CAUTION
All transit bolts & packaging must be removed before using the appliance.
1.
Loosen all 4 bolts with a spanner to
remove them.
Plug the holes with transit hole caps
provided.
Keep the transit bolts for future use to
protect the drum during transportation.
1.
5
2.
2.
3.

6
INSTALLATION
Install the water inlet hose
CAUTION
Be sure to install the inlet hose to COLD water only. Incorrect installation can
reduce performance or damage the clothes washer.
Level the washer
For optimal washing performance, reduced noise
and to minimise vibration, it is important to ensure
the washer is completely flat and level before use.
Use a sprit level to check both horizontal and
vertical stability.
To adjust the feet:
Loosen the lock nut(A).
Adjust each foot(B). Turn left to raise or right to
lower as necessary. Once levelled, try to rock it
from corner to corner. If the washer rocks,
continue to adjust the feet until it is levelled and
no longer rocks.
Once all four feet have been adjusted and the
washer is completely level, tighten the lock
nut(A).
1.
Fasten one end of the inlet hose to the tap.
Ensure there is a rubber washer inside the
hose before fastening. The washer prevents
water leakage.
Securely tighten the other end of the inlet hose
to the clothes washer inlet valve. Ensure the
rubber washer is inside the hose before
tightening.
When tightening the clamping nut, apply even
pressure. Do not apply too much force or twist
the valve as this may damage or break the
valve joint.
1.
2.
3.
2.
3.

7
INSTALLATION
WARNING
Ensure the clothes washer is securely plugged
into the mains power supply and it is switched to
the ON position.
Ensure your hands are completely dry
before touching the mains outlet, any
electrical plugs or cables.
Connect to a power source
Ensure the water mains are in the open position
and a steady water supply is available to the
clothes washer.
Open the main water supply
Position drain hose
When placing the drain hose, ensure it is above
600m and below 1000mm. Otherwise, the
washer may not drain correctly and an error will
occur.
Ensure the drain hose is placed in a drain with a
diameter of at least 30mm to meet minimum
drainage flow requirements.
Secure the drain hose in place to avoid leaking
and spilling as the water drains.
Do not immerse the drain hose in water.
sink/basin
secure in
place here
bind
drain at least 30mm
diameter
Max. 1000mm
Min. 600mm
Max. 1000mm Min. 600mm

1
Program Selector Dial
Turn this dial to select a wash program, the machine will
automatically select the spin speed and temperature for the
selected program. The selector dial can be turned either clockwise
or anticlockwise.
2
Spin Speed Button
Press this button repeatedly to increase or decrease the spin
speed if you want your laundry spun at a different speed from the
machines default setting on the selected program.
3
Temperature Button
Press this button repeatedly to increase or decrease the water
temperature if you want your laundry washed at a different
temperature to the machines default setting of the selected
program.
Note: When the light is off, the water temperature will be COLD.
4
Start/Pause Button
Press this button to start the selected wash program. Once a
wash has begun, press this button to pause the program. Press
again to resume.
5
Power Button
Press this button to switch the washer on and off. Press once to
switch on, when finished a wash program, press to switch off.
8
CONTROL FEATURES AND FUNCTIONS
Foam Detection
Excess soap suds will occur when too much detergent has been added. The Foam
Detection function will automatically sense this and increase the rinse to eliminate
excess suds.
Buzzer Sound
The buzzer sounds once a program has completed. To disable the buzzer function,
power on the washer, press the "Temp" button for 3 seconds, you will hear a
beep, the buzzer will now be disabled. Repeat this process to restore the buzzer
function.

WASH PROGRAMS
9
Please note: the table above is intended as a reference guide only, individual results may
vary. Total time includes filling and draining of water. The times mentioned are based on
averages and can be effected by water pressure and drainage speed.
(* See diagram page 11)
Program
Description
Max.
load
(Kg)
Detergent dispenser*
Temp.
Default
Spin
Speed
(RPM)
Total
time
Case
I
Case
II
Case
Softener
Cotton
For moderately soiled everday
cottons, bedsheets and towels.
5.0
X
●
○
90°C
60°C (default)
40°C
20°C
cold
1200
2:10
Synthetic
Normally soiled synthetic and
polycotton fibres. This is a shorter
and gentler wash to the cotton cycle
and suitable for delicate clothes
washing. The detergent quantity
may need reducing due to the nature
of the fabrics.
2.5
X
●
○
60°C
40°C (default)
20°C
cold
800
1:45
Wool
For woollen articles and silk fabrics
labelled as machine washable. This
program may also be used for
handwash articles. Use detergent
specific to woollens and delicates.
1.5
X
●
○
40°C (default)
20°C
cold
400
1:25
Underwear
Specifically designed for underwear
with a stronger rinse setting and
extra wash cycle.
5.0
X
●
○
90°C
60°C
40°C (default)
20°C
cold
1200
1:48
Drum
Clean
Use this program for drum cleaning.
With a high temperature wash at 90°
it cleans the drum of detergent
residue, dirt and bacteria. Do not
add any detergent or clothes to the
washer when using this program. It
is recommended you perform a
drum clean after every 40 washes.
-
X
X
X
90°C (default)
400
1:30
Spin
This separate spin program will drain
any excess water and spin only.
5.0
X
X
X
-
1200
0:15
Cotton
Intensive
Similar to the cotton wash, this
program offers an additional wash
and rinse cycle to ensure no
detergent residue remains on the
laundry. Suitable for baby clothes
and those with skin allergies.
5.0
X
●
○
90°C
60°C
40°C (default)
20°C
cold
1200
2:20
Quick
A quick wash for small loads of
lightly soiled articles.
1.5
X
●
○
40°C
20°C
cold (default)
1200
0:15
● must ○ optional X not available
