Midea D10-15VDO User manual

Storage Electric Water Heater
The diagram above is just for reference. Please take the
appearance of the actual product as the standard.
Instruction Manual
Congratulations! You are now a proud owner of Midea water heater. We assure you that this
product conforms to the highest standards of quality. Before installing and operating your water
heater, please read this manual carefully and keep it for future reference.
For Model: D10-15VDO
D10-15VDU
D15-15VDO
D15-15VDU
D30-15VDO
D30-15VDU

1
The installation and maintenance has to be carried out by qualified professionals or Midea
authorized technicians.
The manufacturer shall not be held responsible for any damage or malfunction caused by wrong
installation or failing to comply with following instructions included in this pamphlet.
For more detailed installation and maintenance guidelines, please refer to below chapters.
TABLE OF CONTENTS
TITLE PAGE
1.Cautions ...........................................................................................................................(2)
2.Product introduction .........................................................................................................(3)
3.Unit installation .................................................................................................................(5)
4.Methods of using ..............................................................................................................(7)
5.Maintenance.....................................................................................................................(8)
6.Troubleshooting................................................................................................................(9)
7.PRODUCE INFORMATION WITH EU REGULATION ...................................................(10)
●
●
●
General Remark

2
Before installing this water heater,check and confirm that the earthing on the supply socket is
reliably grounded. Otherwise, the electrical water heater can not be installed and used. Do not use
extension boards. Incorrect installation and use of this electrical water heater may result in serious
injuries and loss of property.
Special Cautions
1. CAUTIONS
The water heater is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instructions concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the heater.
The wall in which the electrical water heater is installed must be able to bear the load more than
two times of the heater filled fully with water without distortion and cracks. Otherwise, other
strengthening measures must be adopted.
The supply socket must be earthed reliably. The installation height of the supply socket must not
be lower than 1.8m. The rated current of the socket must not be lower than 16A. The socket and
plug must be kept dry to prevent electrical leakage. If the flexible power supply cord is damaged, the
special supply cord provided by the manufacturer must be selected, and replaced by the professional
maintenance personnel.
The maximum inlet water pressure is 0.5MPa; the minimum inlet water pressure is 0.1MPa, if this
is necessary for the correct operation of the appliance.
When using the heater for the first time (or the first use after maintenance), the heater can not be
switched on until it has been filled fully with water. When filling the water, at least one of the outlet
valves at the outlet of the heater must be opened to exhaust the air. This valve can be closed after
the heater has been filled fully with water.
The pressure relief valve attached with the heater must be installed at the cold water inlet of this
heater, and make sure it is not exposed in the foggy. The water may be outflowed from pressure
relief valve, so the outflow pipe must open wide in the air. In order to drain away the water inside
the inner container, it can be drained away from the pressure release valve. Twist the thread screw
of the pressure release valve off, and lift the drain handle upwards(See Fig.1) . The drainage pipe
connected to the pressure release hole must be kept sloping downwards and in a frost-free
environment. The water may drip from the discharge pipe of the pressure-relief device and that this
pipe must be left open to the atmosphere.
During heating, there may be drops of water dripping from the pressure release hole of the
pressure relief valve, this is a normal phenomenon. The pressure release hole shall not be blocked
under no circumstances, otherwise, the heater may get damaged, even resulting in accidents. If
there is a large amount of water leak, please contact customer care center for repair.
The pressure relief valve need to be checked and cleaned regularly, so as to make sure it will not
be blocked.
Since the water temperature inside the heater can reach up to 75℃, the hot water must not be
exposed to human bodies when it is initially used. Adjust the water temperature to a suitable
temperature to avoid scalding.
If any parts and components of this electrical water heater are damaged please contact customer
care center for repair.

3
2. PRODUCT INTRODUCTION
2.1 Nomenclature
D -
NOTE
This manual is applicable to the storage electric water heaters (D *-***) manufactured by
this company.
is the product code of the storage electric water heater;
is the capacity (L);
represents the rated power (*100W);
represents the pattern code (eg : A,B,C...);
represents the extension of pattern (eg : 1,2,3...);
①
①
②
②
③
③
④
④
⑤
⑤
2.2 Technical Performance Parameters
(Fig.1)
Hot water Cold water
Pressure
relief valve
Thread screw
Drain handle
Pressure
release hole
Hot water Cold water
Pressure
relief valve
D10-15VDO
D10-15VDU
Rated
Voltage
(ACV)
220-240
220-240
220-240
220-240
Model
IPX4
IPX4
75 75
75
75
1500
1500
Rated
Power
(W)
10
10
Volume
(L)
0.8
0.8
0.8
0.8
0.8
0.8
Rated
Pressure
(MPa)
Rated Of Water
Temperature
(°C)
Rated
Thermostat
SET(°C)
Protection
Class
Waterproof
Grade
I
I
D15-15VDO
D15-15VDU
IPX4
IPX4
75 75
75
75
1500
1500
15
15
I
I
220-240
D30-15VDO IPX4
75
75
1500
30 I
220-240
D30-15VDU IPX4
75
75
1500
30 I

4
2.3 Brief introduction of product structure
2.4 Internal Wire Diagram
WIRING DIAGRAM
E
N
L
QQ
Heating Element Heating Indicator light
Thermal
Cut Out
Thermostat
Power
Indicator
Brown
Blue
Yellow/Green
(Note:All dimensions are in mm)
D10-15VD D15-15VD
A
B
C
D
368
368
312
66
D30-15VD
440
440
388
66
324
324
282
66
C
A
B
D

5
3.2 Pipelines Connection
3.1 Installation Instruction
①
②
③
3. UNIT INSTALLATION
This electrical water heater shall be installed on a solid wall. If the strength of the wall cannot bear
the load equal to two times of the total weight of the heater filled fully with water, it is then
necessary to install a special support.
In case of hollow bricks wall, ensure to fill it with cement concrete completely.
After selecting a proper location, install the mounting bracket to a solid wall.
Methods of installation: Follow the installation as shown in Fig.3. Use the anchors and fasteners
provided along with the product for securing the bracket(Fig.2) firmly in the wall.
Align the slots on the back of the water heater with the projections on the bracket and mount the
water heater on the bracket. Thereafter slide the water heater gently towards the bottom side on
lock the water heater.
①
②
③
The dimension of each pipe part is G1/2” ; The massive pressure of inlet should use Pa as the
unit; The minimum pressure of inlet should use Pa as the unit.
Connection of pressure relief valve with the heater on the inlet of the water heater.
In order to avoid leakage when connecting the pipelines, the rubber seal gaskets provided with the
heater must be added at the end of the threads to ensure leak proof joints (see Fig.5).
(Fig.2) (Fig.3)
If the bathroom is too small, the heater can be installed at another place. However, in order to
reduce the pipeline heat losses, the installation position of the heater shall be closed to the
location shall be as near as possible to the heater.
④
Install the supply socket in the wall. The requirements for the socket are as follows: 250V/10A, single
phase, three electrodes. It is recommended to placed the socket on the right above the heater.
The height of the socket to the ground shall not be less than 1.8m (see Fig.4).
(Fig.4)
⑤
100
36
20
66
2-Φ8.5
2.2
N (Blue)
L (Brown) E (Yellow/Green)
Ground
≥1.8m

If the users want to realize a multi-way supply system, refer to the method shown in fig.6 for
connection of the pipelines.
④
6
(Fig.5)
Power supply cord
Hot water
Adjusting handle for
mixing valve
Hot water outlet
Rubber seal gaskets
Joint screw for cold water inlet
Pressure release hole
Pressure relief valve
Cold water inlet
Rubber seal gaskets
Hot water outlet Cold water inlet
Pressure relief valve
Pressure release hole
Joint screw for cold water inlet
Adjusting handle for
mixing valve
Hot water
Rubber seal gaskets
Rubber seal gaskets
Power cord
Pressure relief valve
Water inlet valve
Water inlet valve
Running water pipe
Mixing valve
Water pool
Triple joint Shower nozzle
Hot water
outlet Cold water
inlet
Power supply cord

NOTE
Please be sure to use the accessories provided by our company to install this electric
water heater. This electric water heater can not be hung on the support until it has been
confirmed to be firm and reliable. Otherwise, the electric water heater may drop off from
the wall, resulting in damage of the heater, even serious accidents of injury. When
determining the locations of the bolt holes, it shall be ensured that there is a clearance
not less than 0.2m on the right side of the electric heater, to convenient the maintenance
of the heater, if necessary.
7
(Fig.6)
Power supply cord
Shower nozzle
Mixing valve
Water inlet valve
Running water pipe
Cold water
inlet
Hot water
outlet
Triple joint
Pressure relief valve
Water inlet valve

8
(Fig.7)
4. METHODS OF USING
NOTE
During normal operation, the inlet valve shall be always kept open.
First, open any one of the outlet valves at the outlet of the water heater, then, open the inlet valve.
The water heater gets filled with water. When water flows out of the outlet pipe it implies that the
heater has been filled fully with water, and the outlet valve can be closed.
Insert the supply plug into the socket.
●
●
If the indicator lights up, the thermostat will automatically control the temperature. When the water
temperature inside the heater has reached the set temperature, it will switch off automatically,
when the water temperature falls below the set point the heater will be turned on automatically to
restore the heating.
●
①
②
Rotate the knob according to the marking on the knob to increase or decrease the setting
temperature.
The White (up) LED is the power light. The White (down) LED is the heating light. The power light
remains ON when machine is connected to power. The heating light will be ON once the knob is
rotated to adjust the temperature and will be OFF when the heating process is finished.
1

9
Manual reset button
Check the power plug and outlet as often as possible. Secure electrical contact and also proper
grounding must be provided. The plug and outlet must not heat excessively.
If the heater is not used for a long time, especially in regions with low air temperature(below 0℃),
it is necessary to drain water from the heater to prevent damage of the water heater, due to water
freezing in the internal tank.(Refer Cautions in this manual for the method to drain away the water
from the inner container).
To ensure long reliable water heater operation, it is recommended to regularly clean the internal
tank and remove deposits on the electric heating element of the water heater, as well as check
condition (fully decomposed or not) of the magnesium anode and, if necessary, replace it with a
new one in case of full decomposition.Tank cleaning frequency depends on hardness of water
located in this territory. Cleaning must be performed by special maintenance services. You can ask
the seller for address of the nearest service center.
●
●
●
●
5. MAINTENANCE
WARNING
Do cut off power supply before maintenance, to avoid danger like electric shock.
!
WARNING
Non-professionals are not allowed to disassemble the thermal switch to reset.
Please contact professionals to maintain. Otherwise our company will not take
responsibility if any quality accident happens because of this.
!
The water heater is equipped with a thermal switch, which cuts off power supply of the heating element upon
water overheating or its absence in the water heater. If the water heater is connected to the mains, but water
is not heated and the indicator doesn’t light up, then the thermal switch was switched off or not switched on.
To reset the water heater to the operating condition, it is necessary to:
1. De-energize the water heater, remove the plate of the side/lower cover.
2. Press the button, located at the center of the thermal switch, see Fig.8;
3. If the button is not pressed and there is no clicking, then you should wait until the thermal switch
cools down to the initial temperature.
(Fig.8)

10
6. TROUBLESHOOTING
NOTE
Parts illustrated in this use and care manual are indicative only, parts provided with the
product may differ with illustrations.This product is intended for household use only.
Specifications are subject to change without notice.
Failures Reasons Treatment
The heating indicator
light is off.
Failures of the temperature
controller.
Contact with the professional
personnel for repair.
Contact with the professional
personnel for repair.
No water coming out
of the hot water outlet.
The water temperature
is too high.
Water leak.
1. The running water supply
is cut off.
2. The hydraulic pressure is
too low.
3. The inlet valve of running
water is not open.
1. Wait for restoration of
running water supply.
2. Use the heater again
when the hydraulic
pressure is increased.
3. Open the inlet valve of
running water.
Failures of the temperature
control system.
Seal problem of the joint of
each pipe. Seal up the joints.

11
7. PRODUCE INFORMATION WITH EU REGULATION
The electrical storage water heater D10-15VDO of the company Midea was tested with a
declared load profile of the size
that correspond to the water heating efficiency class
The product fulfills and corresponds to the requirements of the commission regulation standards (No
814/2013) for electrical storage water heater and achieved a water heating energy efficiency of
In accordance with AnnexⅡEnercy Efficiency Classes article 1 of the commission regulation (No
812/2013)
The evaluation of the result of this report with respect of conformity with the related commission
regulation (No 812/2013 and 814/2019) is only a part of the conformity assessment to achieve the
ErP-Label.
Electricity consumption Qelec、water heating energy efficiency ηwh and mixed water at 40℃（V40）
“XXS”
“A”
ηwh=36%
kWh
kWh
kWh
kWh
kWh
℃
℃
kg
L
kWh
kWh
℃
℃
℃
℃
L
L
Description Parameter Value Unit
k-Value k
Smart control compliance smart
Smart control factor SCF
Conversion coefficient CC
Ambient correction term Q
cor
Referenct energy Q
ref
Useful energy content Q
H2O
Correction ratio of reference and useful energy Q
ref/
Q
H2O
Daily electricity consumption (measured) Q
test_elec
Water temperature at the beginning of the 24h measurement cycle
T3
Water temperature at the end of the 24h measurement cycle T5
Storage volume M
act
Storage volume C
act
Daily electricity consumption (corrected) Q
elec
Water heating energy efficiency
η
wh
Annual Electricity Consumption AEC
Water heating energy efficiency class
Water temperature without tapping T
set
Average water temperature of outlet warm water θ'
p
Average water temperature of inlet cold water θ
c
Normalised value of the average temperature θ
p
Volume that delivered water of at least 40℃V
40exp
Calculated volume that delivered hot water of at least 40℃V
40
0.23
0
0
2.5
-0.173
2.1
2.131
0.985
2.469
48.7
51.4
10.3
10.3
2.401
36.0
512
A
48
46.4
10.4
46.4
8
9

12
The electrical storage water heater D10-15VDU of the company Midea was tested with a
declared load profile of the size
that correspond to the water heating efficiency class
The product fulfills and corresponds to the requirements of the commission regulation standards (No
814/2013) for electrical storage water heater and achieved a water heating energy efficiency of
In accordance with AnnexⅡEnercy Efficiency Classes article 1 of the commission regulation (No
812/2013)
The evaluation of the result of this report with respect of conformity with the related commission
regulation (No 812/2013 and 814/2019) is only a part of the conformity assessment to achieve the
ErP-Label.
Electricity consumption Qelec、water heating energy efficiency ηwh and mixed water at 40℃（V40）
“XXS”
“B”
ηwh=32%
kWh
kWh
kWh
kWh
kWh
℃
℃
kg
L
kWh
kWh
℃
℃
℃
℃
L
L
Description Parameter Value Unit
k-Value k
Smart control compliance smart
Smart control factor SCF
Conversion coefficient CC
Ambient correction term Q
cor
Referenct energy Q
ref
Useful energy content Q
H2O
Correction ratio of reference and useful energy Q
ref/
Q
H2O
Daily electricity consumption (measured) Q
test_elec
Water temperature at the beginning of the 24h measurement cycle
T3
Water temperature at the end of the 24h measurement cycle T5
Storage volume M
act
Storage volume C
act
Daily electricity consumption (corrected) Q
elec
Water heating energy efficiency
η
wh
Annual Electricity Consumption AEC
Water heating energy efficiency class
Water temperature without tapping T
set
Average water temperature of outlet warm water θ'
p
Average water temperature of inlet cold water θ
c
Normalised value of the average temperature θ
p
Volume that delivered water of at least 40℃V
40exp
Calculated volume that delivered hot water of at least 40℃V
40
0.23
0
0
2.5
-0.348
2.1
2.142
0.980
2.805
60.7
62.0
9.8
9.8
2.735
32.44
569
B
61.8
60.2
10.3
60.2
10
17

13
The electrical storage water heater D15-15VDO / D15-15VDU of the company Midea was tested
with a declared load profile of the size
that correspond to the water heating efficiency class
The product fulfills and corresponds to the requirements of the commission regulation standards (No
814/2013) for electrical storage water heater and achieved a water heating energy efficiency of
In accordance with AnnexⅡEnercy Efficiency Classes article 1 of the commission regulation (No
812/2013)
The evaluation of the result of this report with respect of conformity with the related commission
regulation (No 812/2013 and 814/2019) is only a part of the conformity assessment to achieve the
ErP-Label.
Electricity consumption Qelec、water heating energy efficiency ηwh and mixed water at 40℃（V40）
“XXS”
“B”
ηwh=35%
kWh
kWh
kWh
kWh
kWh
℃
℃
kg
L
kWh
kWh
℃
℃
℃
℃
L
L
Description Parameter Value Unit
k-Value k
Smart control compliance smart
Smart control factor SCF
Conversion coefficient CC
Ambient correction term Q
cor
Referenct energy Q
ref
Useful energy content Q
H2O
Correction ratio of reference and useful energy Q
ref/
Q
H2O
Daily electricity consumption (measured) Q
test_elec
Water temperature at the beginning of the 24h measurement cycle
T3
Water temperature at the end of the 24h measurement cycle T5
Storage volume M
act
Storage volume C
act
Daily electricity consumption (corrected) Q
elec
Water heating energy efficiency
η
wh
Annual Electricity Consumption AEC
Water heating energy efficiency class
Water temperature without tapping T
set
Average water temperature of outlet warm water θ'
p
Average water temperature of inlet cold water θ
c
Normalised value of the average temperature θ
p
Volume that delivered water of at least 40℃V
40exp
Calculated volume that delivered hot water of at least 40℃V
40
0.23
0
0
2.5
-0.208
2.1
2.134
0.984
2.478
49.6
48.3
15.6
15.6
2.462
35.3
522
A
50
49.2
10.6
49.2
12
16

14
kWh
kWh
kWh
kWh
kWh
℃
℃
kg
L
kWh
kWh
℃
℃
℃
℃
L
L
Description Parameter Value Unit
k-Value k
Smart control compliance smart
Smart control factor SCF
Conversion coefficient CC
Ambient correction term Q
cor
Referenct energy Q
ref
Useful energy content Q
H2O
Correction ratio of reference and useful energy Q
ref/
Q
H2O
Daily electricity consumption (measured) Q
test_elec
Water temperature at the beginning of the 24h measurement cycle
T3
Water temperature at the end of the 24h measurement cycle T5
Storage volume M
act
Storage volume C
act
Daily electricity consumption (corrected) Q
elec
Water heating energy efficiency
η
wh
Annual Electricity Consumption AEC
Water heating energy efficiency class
Water temperature without tapping T
set
Average water temperature of outlet warm water θ'
p
Average water temperature of inlet cold water θ
c
Normalised value of the average temperature θ
p
Volume that delivered water of at least 40℃V
40exp
Calculated volume that delivered hot water of at least 40℃V
40
0.23
0
0
2.5
-0.330
2.1
2.137
0.983
2.654
58.3
56.3
29.7
29.7
2.674
33.0
558
C
58
57.5
10.4
57.5
18
28
The electrical storage water heater D30-15VDO / D30-15VDU of the company Midea was tested
with a declared load profile of the size
that correspond to the water heating efficiency class
The product fulfills and corresponds to the requirements of the commission regulation standards (No
814/2013) for electrical storage water heater and achieved a water heating energy efficiency of
In accordance with AnnexⅡEnercy Efficiency Classes article 1 of the commission regulation (No
812/2013)
The evaluation of the result of this report with respect of conformity with the related commission
regulation (No 812/2013 and 814/2019) is only a part of the conformity assessment to achieve the
ErP-Label.
Electricity consumption Qelec、water heating energy efficiency ηwh and mixed water at 40℃（V40）
“S”
“C”
ηwh=33%

www.midea.com/global
The product is subject to change without notice.
Please keep this manual properly.
Midea Italia S.r.l.
A Socio Unico Viale
Bodio 29 20158 Milano
(MI) www.midea.com/it

Scaldabagno elettrico
Manuale Utente e di installazione
Grazie per aver acquistato uno scaldacqua Midea! Questo prodotto è conforme ai più elevati
standard di qualità disponibili. Prima di installare ed utilizzare il prodotto, leggere questo
manuale e conservarlo per le future necessità di consultazione.
Modello: D10-15VDO
D10-15VDU
D15-15VDO
D15-15VDU
D30-15VDO
D30-15VDU
L'immagine sopra è indicativa e ha il solo scopo di descrivere il prodotto. Considerare le
informazioni del manuale e le specifiche di riferimento per le informazioni effettive.

1
L'installazione e la manutenzione del prodotto devono essere effettuate da personale qualificato o
da centri assistenza tecnica autorizzati da Midea.
Il produttore non deve essere ritenuto responsabile per qualsiasi danno o malfunzionamento
causato da installazione errata o dal mancato rispetto delle istruzioni incluse in questo libretto.
Per maggiori informazioni sulle condizioni di installazione e manutenzione dei prodotti, fare
riferimento a quanto segue.
TABLE OF CONTENTS
Titolo Pagina
1.Precauzioni.......................................................................................................................(2)
2.Introduzione al prodotto....................................................................................................(3)
3.Installazione dell'unità ......................................................................................................(5)
4.Metodi di utilizzo...............................................................................................................(7)
5.Manutenzione...................................................................................................................(8)
6.Risoluzione dei problemi ..................................................................................................(9)
7.INFORMAZIONI SUL PRODOTTO IN MERITO ALLE NORMATIVE EU....................... (10)
●
●
●
Indicazioni generali

2
Prima di installare questo scaldabagno, verificare che l'alimentazione elettrica sia correttamente
connessa e che il collegamento di messa a terra sia adeguato. In caso contrario, lo scaldabagno
non può essere installato e utilizzato. Non utilizzare prolunghe. La non corretta installazione e lo scorretto
utilizzo di questo scaldabagno possono essere causa di lesioni e danni materiali alle proprietà.
Avvertenze speciali
1. Precauzioni
Lo scaldabagno non è destinato all'utilizzo da parte di persone (inclusi bambini) con capacità
motorie, sensoriali o mentali ridotte, o mancanza di competenza o esperienza, a meno che non
siano supervisionati o guidati nell'uso dell'elettrodomestico da una persona responsabile per la
loro sicurezza. Assicurarsi che i bambini non giochino con lo scaldabagno.
La parete in cui deve essere installato lo scaldabagno elettrico deve poter sorreggere il doppio del
peso dell'elettrodomestico completamente pieno d'acqua senza deformazioni o crepe.
In caso contrario, è necessario adottare delle misure di rinforzo della parete.
La presa di alimentazione deve essere collegata alla messa a terra. La corrente nominale della
presa non deve essere inferiore a 16A. La presa e la spina non devono venire in contatto con
liquidi o vapore per evitare cortocircuiti. Assicurarsi che la spina sia in ben in contatto con la presa.
Verificare che la spina ed il cavo di alimentazione non si surriscaldino durante il funzionamento del
prodotto. Il mancato rispetto delle prescrizioni relative a presa, spina e cavo di alimentazione può
causare incendio, scosse elettriche o danni a persone o cose.
La pressione massima per l'adduzione acqua è pari a 0.5Mpa. La pressione minima di adduzione
acqua è pari a 0.1Mpa. Utilizzare gli adeguati accorgimenti per assicurare l'erogazione di acqua
entro questi limiti di pressione.
In corrispondenza del primo avviamento del prodotto o dopo un'attività di manutenzione,
l'apparecchio non può essere attivato se non è completamente riempito di acqua. Durante il
riempimento, il rubinetto dell'acqua calda deve essere mantenuto costantemente aperto per far
fuoriuscire l'aria dal prodotto. Chiudere il rubinetto quando il prodotto è pieno di acqua e procedere
all'accensione dell'unità.
La valvola di sicurezza collegata allo scaldabagno deve essere installata in prossimità della presa
di ingresso dell'acqua fredda. Assicurarsi che la valvola non sia non sia esposta a vapore.
Il prodotto può essere svuotato mediante lo scarico della valvola di sicurezza: agire sulla leva per
aprire la valvola e consentire lo scarico dell'acqua (Vedi Fig. 1). Durante l'esercizio del prodotto è
possibile che dalla valvola di sicurezza fuoriesca dell'acqua: la connessione di scarico deve essere
libera, rivolta verso il basso e deve essere previsto un sistema di scarico che non sia soggetto a
congelamento.
Durante il riscaldamento dell'acqua è possibile che alcune gocce di acqua fuoriescano dalla
valvola di sicurezza.
La valvola di scarico deve essere controllata e pulita regolarmente, assicurandosi che non
sia ostruita.
La temperatura dell'acqua nello scaldacqua può raggiungere valori prossimi a 75°C. Utilizzare un
sistema di miscelazione termostatica dell'acqua per i punti di prelievo, al fine di evitare ustioni e
ferite.
Se una o più componenti del sistema necessitano di sostituzione perchè danneggiate o degradate,
contattare l'assistenza tecnica Midea.
●
●
●
●
●
●
●
●
●
●

3
2. Introduzione al prodotto
2.1 Nomenclatura
D -
NOTE
Questo manuale si riferisce esclusivamente ai prodotti commercializzati da Midea Italia
S.r.l. a socio unico.
Codice Prodotto: D=Scaldacqua elettrico
Capacità (L)
Potenza elettrica (W moltiplicato 100)
Codice identificativo telaio prodotto
Indicativo serie produttiva
①
①
②
②
③
③
④
④
⑤
⑤
2.2 Dati tecnici prodotti
(Fig.1)
Perno della valvola
Leva
Condotto di
scarico
D10-15VDO
D10-15VDU
Tensione
nominale
(ACV)
220-240
220-240
220-240
220-240
Modello
IPX4
IPX4
75 65
65
75
1500
1500
Potenza
nominale
(W)
10
10
Volume
(L)
0.8
0.8
0.8
0.8
0.8
0.8
Pressione
massima
(MPa)
Temperatura
massima acqua
(°C)
Impostazione
massima
termostato
(°C)
Classe di
protezione
Grado di
protezione
IP
I
I
D15-15VDO
D15-15VDU
IPX4
IPX4
75 75
75
75
1500
1500
15
15
I
I
220-240
D30-15VDO IPX4
75
75
1500
30 I
220-240
D30-15VDU IPX4
75
75
1500
30 I
Acqua Calda
Valvola di
sicurezza
Acqua Fredda
Acqua Calda Acqua Fredda
Valvola di
sicurezza
