Midea RSJ-100/N1-540V-D User manual

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
1
Midea High-temperature Direct-heating
Heat Pump Water Heater
Technical Manual
Applicable Models:
RSJ-100/N1-540V-D
RSJ-200/SN1-540V-D
RSJ-380/SN1-820-D
Midea reserves the right to discontinue, or change at any time, specifications or designs without notices and
without incurring obligations.

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
2
Contents
Part 1 General Information .......................................................................3
1. Measurements....................................................................................................... 4
2. External Appearance............................................................................................ 4
3. Nomenclature........................................................................................................ 5
4. Features................................................................................................................. 6
Part 2 Outdoor Units.................................................................................7
1. Specifications ....................................................................................................... 8
2. Capacity tables ................................................................................................... 10
3. Dimensions ......................................................................................................... 13
4. Service Space ..................................................................................................... 14
5. Wiring Diagrams................................................................................................. 15
6. Piping Diagrams ................................................................................................. 20
Part 3 Installation ....................................................................................21
1. Precautions......................................................................................................... 22
2. Installation information...................................................................................... 23
3. Accessories......................................................................................................... 24
4. Inspecting and Handling the Unit...................................................................... 24
5. Connection Diagram........................................................................................... 25
6. Operation Instruction ......................................................................................... 27
7. Installation Instruction ....................................................................................... 28
8.Electric Wiring...................................................................................................... 31
Part 4 Trial Operation..............................................................................34
1. Confirmation before the trial operation............................................................ 35
2. Water Pump Air Extraction................................................................................. 35
3. Wired Controller and Operation ........................................................................ 36
4. Water tank cleaning............................................................................................ 43
5. Schematic Diagram of the Unit System............................................................ 43
6. Error Code Cause Analysis and the Solutions................................................. 44
7. Main control board spot check.......................................................................... 46
8. Failure without Code .......................................................................................... 46
9. Troubleshoot of abnormal phenomena ............................................................ 47

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
3
Part 1
General Information
1. Measurements.......................................................................................4
2. External Appearance.............................................................................4
3. Nomenclature ........................................................................................5
4. Features .................................................................................................6

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
4
1. Measurements
Model
Dimension (mm)
Net/ Gross Weight
Power Supply
RSJ-100/N1-540V-D
Width: 750
Height: 1100
Depth: 750
121/129
220~240V-1ph-50Hz
RSJ-200/SN1-540V-D
Width: 750
Height: 1100
Depth: 750
145/152
340~420V-3ph-50Hz
RSJ-380/SN1-820-D
Width: 992
Height:1750
Depth:893
290/297
340~420V-3ph-50Hz
2. External Appearance
RSJ-380/SN1-820-D
RSJ-200/SN1-540V-D
RSJ-100/N1-540V-D

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
5
3. Nomenclature
Commercial Water Heating Unit
12 3 4 5 678
-
Installation type code
Water heating unit code
Export model code
/
-910
Power supply specification code
Heating mode code
Rated hot water output, unit: 100 W
Water tank volume, unit: L
Other functions code
Water supply pump lift code
Refrigerant code
11
-
Design code
For example:
S820
RSJ -B
- -
/
380
Configuration code
Power supply specification cod
Water heating unit code
Rated hot water output, unit: 100 W
Refrigerant code

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
6
4. Features
4.1 Safety
a. Complete isolation between water and electricity. No electric shock problem, more safety.
b. No fuel tubes and storage, no potential danger from oil leakage, fire, explosion etc.
4.2 Easy operation
The system can be controlled simply through the wired controller.
4.3 Automatic control:
Automatic start-up and shutdown, automatic defrosting. Save you much extra operation.
4.4 Rapid speed to produce hot water.
4.5 High efficiency and energy saving.
The unit adopts heat pump principle, which absorbs heat from outdoor air and produce heat water, thermal
efficiency can be approximately 4.9.
4.6 All-the-weather running.
Within the temperature range from -15℃to 43℃, it will not be affected by night, overcast sky, rain and
snow.
4.7 Modular design, maximum connection 16sets basic unit

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
7
Part 2
Outdoor Units
1. Specifications........................................................................................8
2. Capacity tables....................................................................................10
3. Dimensions..........................................................................................13
4. Service Space......................................................................................14
5. Wiring Diagrams..................................................................................15
6. Piping Diagrams..................................................................................20

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
8
1. Specifications
HPWH SPECIFICATION
Model
RSJ-100/N1-540V-D
RSJ-200/SN1-540V-D
RSJ-380/SN1-820-D
Power supply
Ph-V-Hz
1-220-50
3-380-50
3-380-50
Water
Heating
Capacity
kW
11.2
20.4
43
Input
kW
2.85
5.2
10.5
Rated current
A
13.8
9.5
15.9
Max. input consumption
kW
3.97
7.5
15.26
Max. input current
A
18.2
13
26.7
starting current
A
98
74
74
Compressor
Model
ZP36KSE-PFZ-522
ZP67KCE-TFD-522
ZP67KCE-TFD-420
Type
SCROLL
SCROLL
SCROLL
Brand
COPELAND
COPELAND
COPELAND
Supplier
EMERSON
EMERSON
EMERSON
Capacity
kW
8.8
16.2
16.2
Input
kW
2.94
5.2
5.2
Rated current(RLA)
A
13.6
9.1
9.1
Locked rotor Amp(LRA)
A
98
74
74
Thermal protector
℃
145
135
135
Capacitor
uF
80μF/440V
/
/
Refrigerant oil
POE
POE
POE
outdoor fan
motor
Model
YDK140-6N
YDK220-6R
YDK550-6E
Brand
welling
Changzhouyongan
Changzhouyongan
Input
W
230×1
360
810/680
Capacitor
uF
12
12
25

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
9
Speed(hi/lo)
r/min
735 / 530
905/730
850/750
outdoor coil
a. Number of rows
1
2
2×2
b. Tube pitch(a)x row pitch(b)
mm
25.4X0
25.4X22
25.4X22
c. Fin spacing
mm
1.8
1.8
1.8
c. Fin type
Hydrophilic
aluminum
Hydrophilic
aluminum
Hydrophilic
aluminum
d. Tube outer diameter and type
mm
Ф9.52 inner groove
tube
Ф9.52 inner groove
tube
Ф9.52 inner groove
tube
e. Coil length x height x width
mm
1378×1016×22
1378×1016×44
855×969×22*2
G .Number of circuits
8
18
12*2
Outdoor noise level
dB(A)
61
61
62
Outdoor
unit
Dimension (W×H×D)
mm
750×1100×750
750×1100×750
992×1750×893
Packing (W×H×D)
mm
770×1160×770
770×1160×770
1075×1920×920
Net/Gross weight
kg
121 / 129
145 / 152
290 / 297
Refrigerant type/Quantity
Kg
R410a 1.5
R410a 2.8
R410a 5.7
Design pressure
MPa
4.4/2.6
4.4/2.6
4.4/2.6
Ambient temp
℃
（-15~43）
（-15~43）
（-15~43）
water pipe
Diameter, water inlet pipe
mm
DN25
DN25
DN25
Diameter, water outlet pipe
mm
DN25
DN25
DN25
Hot Water Yield
m3/h
0.25
0.52
1.0
Wire controller
KJR-51/BMKE-A
KJR-51/BMKE-A
KJR-51/BMKE-A
Out water Temp
℃
（default）56℃，
40℃～60℃
（default）56℃，
40℃～60℃
（default）56℃，
40℃～60℃
1．The test conditions: outdoor temp. 20/15℃(DB/WB), inlet water temp. 15℃, outlet water temp. 55℃.
2．The operation range:-15℃~43℃.
3．The specification may be changed for product improvement, please refer to the nameplate.

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
10
2. Capacity tables
Note: OT –Outdoor Temperature (DB);
Mode
OT(℃)
Inlet water
temperature (℃)
Outlet water
temperature(℃)
Capacity(kW)
COP
DB
WB
RSJ-100/N1-540V-D
20
15
15
40
11.37
4.56
15
45
11.48
4.36
15
50
11.47
4.09
15
55
11.41
3.82
15
60
11.30
3.53
15
12
9
40
10.50
4.23
9
45
10.88
4.29
9
50
10.89
4.03
9
55
10.81
3.76
9
60
10.67
3.48
10
8
9
40
9.67
3.84
9
45
9.63
3.43
9
50
10.05
3.60
9
55
9.96
3.45
9
60
9.22
3.04
5
4
9
40
8.91
3.46
9
45
9.06
3.39
9
50
9.16
3.24
9
55
9.22
3.13
9
60
8.85
2.90
0
–
9
40
7.69
3.14
9
45
7.69
2.99
9
50
6.62
2.51
9
55
6.53
2.34
9
60
6.51
2.20
-5
–
9
40
6.68
2.86
9
45
6.64
2.67
9
50
6.67
2.49
9
55
6.15
2.22
9
60
5.59
1.86
-10
–
9
40
5.40
2.34
9
45
5.18
2.06
9
50
5.05
1.91
9
55
4.95
1.78
-15
–
9
40
4.22
1.84
9
45
4.21
1.73
9
50
4.19
1.62
9
55
3.06
1.20

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
11
Mode
OT(℃)
Inlet water
temperature (℃)
Outlet water
temperature(℃)
Capacity(kW)
COP
DB
WB
RSJ-200/SN1-540V-D
20
15
15
40
20.88
4.75
15
45
21.00
4.48
15
50
20.99
4.20
15
55
21.85
4.00
15
60
20.05
3.76
15
12
9
39
19.62
4.45
9
45
19.90
4.28
9
50
19.89
4.02
9
55
19.54
3.90
9
60
18.96
3.60
10
8
9
41
17.56
3.85
9
45
17.47
3.91
9
50
18.09
3.75
9
55
17.97
3.57
9
60
17.34
3.32
5
4
9
40
16.21
3.80
9
45
16.63
3.66
9
50
16.51
3.42
9
55
16.20
3.31
9
60
15.98
3.14
0
–
9
41
14.42
3.27
9
45
14.67
3.17
9
50
13.98
2.99
9
55
13.83
2.73
9
57
13.47
2.58
-5
–
9
40
13.14
3.14
9
45
13.10
2.97
9
50
12.75
2.73
9
55
11.04
2.42
9
57
10.42
2.24
-10
–
9
40
10.48
2.67
9
45
10.08
2.41
9
50
9.69
2.18
9
53
9.10
2.04
-15
–
9
40
8.72
2.29
9
45
8.57
2.09
9
50
8.59
1.96
9
53
7.99
1.72

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
12
Mode
OT(℃)
Inlet water
temperature (℃)
Outlet water
temperature(℃)
Capacity(kW)
COP
DB
WB
RSJ-380/SN1-820-D
20
15
15
40
43.00
5.07
15
45
42.88
4.70
15
50
42.41
4.35
15
55
42.21
4.12
15
60
40.72
3.79
15
12
9
40
40.32
4.90
9
45
40.04
4.53
9
50
39.56
4.19
9
55
38.46
3.96
9
60
37.04
3.61
10
8
9
40
36.48
4.48
9
45
35.84
4.07
9
50
34.89
3.69
9
55
33.67
3.36
9
60
32.15
3.08
5
4
9
40
31.71
3.89
9
45
30.58
3.48
9
50
30.04
3.19
9
55
29.21
2.97
9
60
28.01
2.71
0
–
9
40
25.51
3.16
9
45
25.43
2.95
9
50
24.94
2.74
9
55
24.89
2.55
9
60
23.99
2.39
-5
–
9
40
21.77
2.75
9
45
20.92
2.47
9
50
20.79
2.33
9
55
20.12
2.20
9
60
19.71
2.05
-10
–
9
40
18.51
2.38
9
45
18.10
2.19
9
50
17.37
1.99
9
53
16.55
1.84
-15
–
9
40
14.81
1.95
9
45
14.41
1.80
9
50
14.02
1.66
9
53
13.23
1.35

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
13
3. Dimensions
RSJ-380/SN1-820-D
RSJ-100/N1-540V-D RSJ-200/SN1-540V-D
998
865 1765
998
865 1765
998
865 1765

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
14
4. Service Space
Make sure that enough space for maintenance and air inlet is left when installing (as
diagrams below)
Model
RSJ-100/N1-540V-D
RSJ-200/SN1-540V-D
RSJ-380/SN1-820-D
Maintenance
space
>600
>1000
>400
Heat pump water heating unit
>600
>1000
>400
Heat pump water heating unit
>600
>400
Heat pump water heating unit
Note: The air outlet of the unit at the top cannot be blocked. If there are obstacles above it, keep the unit at least 2000 mm
away from them.

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
15
5. Wiring Diagrams
Internal wiring schematic diagram of RSJ-380/SN1-820-D

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
16
Internal wiring schematic diagram of RSJ-200/SN1-540V-D

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
17
Internal wiring schematic diagram of RSJ-100/N1-540V-D

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
18
Main Control Board Interface

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
19
Ports explanation
No.
Port explanation
No.
Port explanation
1
Low-Pressure Protection Short Connection
2
Digital Tube
3
Defrosting Cycle Select
4
E-Heater Select
5
Reserved
6
Address Setting Dip
7
Electric-Heating Temperature Setting Dip
8
Heat-Exchanger Temp. Sensor And Ambient
Temp. Sensor
9
Outlet Water Temperature Sensor
10
Water Tank Temperature Sensor
11
Refrigerant Heater Temperature Sensor
12
Inlet Water Temperature Sensor
13
Compressor Air Exhaust Temperature
Sensor
14
1# Compressor Current Transformer
15
2# Compressor Current Transformer
16
Power Interface
17
Fuse(5A)
18
Transformer Input Port
19
Controlling Wire (Defrosting Valve, By-Pass
Solenoid Valve, Circulating Water Pump And
Crankcase Heating Zone)
20
Inspection Button
21
Model Selection Dip
22
Alarm Controlling Wire
23
Main Chip
24
E-Heater And Circulating Pump Controlling
Wire
25
Refrigerant Electric Heating Stick Controlling
Wire
26
Fan Low Wind Controlling Wire
27
Fan High Wind Controlling Wire
28
Warm Water Valve Port
29
Transformer Output Port
30
Electric Expanding Valve Controlling Wire
31
Protection Of HYD
32
Power 1
33
Alarm Controlling Wire
34
PQE Communication Port
35
PQE Communication Port (To Wire
Controller)
36
The Exhaust Temperature Protection Port
37
High-Pressure Protection Port

MCAC-RTSM-2013-12 Midea High-temperature Direct-heating Heat Pump Water Heater Technical Manual
20
Tap water
Pressure-bearing
tank
To the user
Used for pipe
network water
returning
6. Piping Diagrams
RSJ-100/N1-540V-D RSJ-200/SN1-540V-D RSJ-380/SN1-820V-D
