Midea LRSJ-60/NYN1-A1 User manual

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
1
Midea R410A
Domestic Pools & Spas
Heat Pump Water Heater 50Hz
A1 Series Technical Manual
Applicable Model: (New CE safety directive)
LRSJ-60/NYN1-A1
LRSJ-80/NYN1-A1
LRSJ-120/NYN1-A1
LRSJ-140/NYN1-A1
Midea reserves the right to discontinue, or change specification or designs at any time without notices and
without incurring obligations.

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
2
Content
Part. 1 General information........................ 3
Part. 2 Performance.................................... 5
Part. 3 Installation..................................... 25

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
3
Part. 1 General information
1. Model Names of Units...........................................................4
2. External Appearance.............................................................4
3. Nomenclature .......................................................................4

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
4
1. Model Names of Units
Model
Power supply
Domestic pools & spas
HPWH
LRSJ-60/NYN1-A1
220-240V~, 1Ph, 50Hz
LRSJ-80/NYN1-A1
220-240V~, 1Ph, 50Hz
LRSJ-120/NYN1-A1
220-240V~, 1Ph, 50Hz
LRSJ-140/NYN1-A1
220-240V~, 1Ph, 50Hz
2. External Appearance
LRSJ-60/NYN1-A1
LRSJ-80/NYN1-A1
LRSJ-120/NYN1-A1
LRSJ-140/NYN1-A1
3. Nomenclature
LRSJ -60 / NYN1 –A1
A1 series
Refrigerant type - N1:R410A
Swimming pool & spas type
Water cycle type without water pump
Nominal heating capacity (60×100W)
Midea heat pump water heater with cooling

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
5
Part. 2 Performance
1. Features .............................................................................6
2. Specifications....................................................................7
3. Dimensions (Unit: mm) ...................................................10
4. Service Space..................................................................11
5. Refrigerant circuit............................................................12
6. Wiring Diagrams..............................................................13
7. Electric Characteristics...................................................16
8. Capacity Curve ................................................................17
9. Accessories .....................................................................24

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
6
1. Features
Titanium heat-exchanger
Titanium heat-exchanger has highly resistant to corrosion.
High strength and durability, pressure test at water side (0.5MPa, water temperature 45°C,
60,000 times).
No need secondary heat-exchanger, reduce the cost of installation.
Because of titanium heat-exchanger of anti-corrosion, the water system of HPWH can be
directly connected with poor.
Without secondary heat-exchanger, it is can improve the efficiency of whole system.
Easy operation and automatic control, the system can be controlled simply through the wired
controller with LCD display which is installed in the unit.
Environment friendly refrigerant R410A is used. No discharge of poisonous gas. No pollution to
atmosphere and environment.
Automatic start-up and shutdown, automatic defrosting. Save much extra operation.
Within temperature range from -7 °C to 38°C, it will not be affected by night, overcast sky, rain
and snow.
Multi-temperature sensors always monitor the unit operating status.

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
7
2. Specifications
Model
LRSJ-60/NYN1-A1
LRSJ-80/NYN1-A1
Power supply
\
220-240V~, 1Ph, 50Hz
220-240V~, 1Ph, 50Hz
Outlet water
temperature
Heating mode
\
Default 28°C, 20°C～35°C
Default 28°C, 20°C～35°C
Cooling mode
\
Default 28°C, 10°C～30°C
Default 28°C, 10°C～30°C
Ambient
temperature
Heating mode
\
-7°C～38°C
-7°C～38°C
Cooling mode
\
15°C～43°C
15°C～43°C
Water heating
Capacity
kW
6.00
8.00
Input
kW
1.150
1.158
COP
W/W
5.22
5.27
Water cooling
Capacity
kW
4.00
5.80
Input
kW
1.25
1.50
COP
W/W
3.20
3.87
Rated power input
W
1.45
1.90
Noise level
dB(A)
58
58
Refrigerant Type/Discharged
\
R410A /1.00kg
R410A /1.25kg
Refrigerant control
\
Capillary
Capillary
Fan
Type
\
Axial fan
Axial fan
Motor model
\
YDK85-6
YDK85-6
Motor brand
\
Welling
Welling
Quantity
\
1
1
Motor input
kW
160/85
160/85
Capacitor
\
5μF/450V
5μF/450V
Speed (Hi/lo)
r/min
835/470
835/470
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7.94
Ф7.94
No. of rows
\
2
2
Fin spacing
mm
1.6
1.6
Tube pitch(a)×row pitch(b)
mm
22×19
22×19
Length×height
mm
820×660
820×660
Number of circuits
\
5
5
Compressor
Model
\
PA145G1C-4FT1
PA200X2CS-4KU1
Type/ Quantity
\
Rotary / 1
Rotary / 1
Brand
\
GMCC
GMCC
Capacity
kW
3.580
4.920
Input
W
1,240
1,670
Capacitor
\
35μF/440-450V
50μF/440-450V
Rated current (RLA)
A
5.82
7.81
Locked rotor Amp.(LRA)
A
26.7
34.5
Thermal protector
\
Internal
Internal
Refrigerant oil
ml
400
750

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
8
Continues
Model
LRSJ-60/NYN1-A1
LRSJ-80/NYN1-A1
Water pipe
Inlet pipe
mm
Ф50
Ф50
Outlet pipe
mm
Ф50
Ф50
Drainage pipe
mm
Ф25
Ф25
Max/Min resisting pressure
\
0.15MPa/0.4MPa
0.15MPa/0.4MPa
Hot water
yield
Min. volume flow
m3/h
0.8
0.8
Max. volume flow
m3/h
20
20
Dimension (W×H×D)
mm
1,015×705×385
1,015×705×385
Packing (W×H×D)
mm
1,095×840×445
1,095×840×445
Net/Gross weight
kg
58.5/67.5
66/75
Notes:
The test conditions:
Water heating: outdoor temperature 24/19ºC (DB/WB), inlet water temperature 27ºC , outlet water temperature
29ºC . Water cooling: outdoor temperature 35/24ºC (DB/WB), inlet water temperature 27ºC . Water flow volume
has been defined.
Model
LRSJ-120/NYN1-A1
LRSJ-140/NYN1-A1
Power supply
\
220-240V~, 1Ph, 50Hz
220-240V~, 1Ph, 50Hz
Outlet water
temperature
Heating mode
\
Default 28°C, 20°C～35°C
Default 28°C, 20°C～35°C
Cooling mode
\
Default 28°C, 10°C～30°C
Default 28°C, 10°C～30°C
Ambient
temperature
Heating mode
\
-7°C～38°C
-7°C～38°C
Cooling mode
\
15°C～43°C
15°C～43°C
Water heating
Capacity
kW
11.70
13.60
Input
kW
2.350
2.550
COP
W/W
4.98
5.33
Water cooling
Capacity
kW
8.25
10.35
Input
kW
2.50
2.90
COP
W/W
3.30
3.57
Rated power input
W
3.30
3.50
Noise level
dB(A)
58
58
Refrigerant Type/Discharged
\
R410A /1.60kg
R410A /1.85kg
Refrigerant control
\
Capillary
Capillary
Fan
Type
\
Axial fan
Axial fan
Motor model
\
YDK76-6H-1
YDK76-6H-1
Motor brand
\
Welling
Welling
Quantity
\
1
1
Motor input
W
168/146
168/146
Capacitor
\
5μF/450V
5μF/450V
Speed (Hi/lo)
r/min
877/749
877/749

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
9
Continues
Model
LRSJ-120/NYN1-A1
LRSJ-140/NYN1-A1
Coil
Type
\
Copper tube and aluminum fin
Tube size
mm
Ф7.94
Ф7.94
No. of rows
\
2
2
Fin spacing
mm
1.6
1.6
Tube pitch(a)×row pitch(b)
mm
22×19
22×19
Length×height
mm
766×792
766×792
Number of circuits
\
8
8
Compressor
Model
\
PA290X3CS-4MU1
PA330X3CS-4MU1
Type/ Quantity
\
Rotary / 1
Rotary / 1
Brand
\
GMCC
GMCC
Capacity
kW
7.180
8.150
Input
W
2,430
2,760
Capacitor
\
50μF/440-450V
55μF/440-450V
Rated current (RLA)
A
11.40
13.10
Locked rotor Amp.(LRA)
A
61
63
Thermal protector
\
Internal
Internal
Refrigerant oil
ml
950
1,100
Water pipe
Inlet pipe
mm
Φ50
Φ50
Outlet pipe
mm
Φ50
Φ50
Water circulation pipe
mm
Φ25
Φ25
Max/Min resisting pressure
\
0.15/0.4
0.15/0.4
Hot water yield
Min. volume flow
m3/h
1.5
1.5
Max. volume flow
m3/h
20
20
Dimension (W×H×D)
mm
1,050×855×315
1,050×855×315
Packing (W×H×D)
mm
1,160×980×410
1,160×980×410
Net/Gross weight
kg
75/85
75/85
Notes:
The test conditions:
Water heating: outdoor temperature 24/19ºC (DB/WB), inlet water temperature 27ºC , outlet water temperature
29ºC . Water cooling: outdoor temperature 35/24ºC (DB/WB), inlet water temperature 27ºC . Water flow volume
has been defined.

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
10
3. Dimensions (Unit: mm)
Top view
Unit: mm
Model
A
B
C
D
E
F
LRSJ-60/NYN1-A1
610
390
170
1,015
385
705
LRSJ-80/NYN1-A1
610
390
170
1,015
385
705
LRSJ-120/NYN1-A1
590
333
165
1,050
315
855
LRSJ-140/NYN1-A1
590
333
165
1,050
315
855

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
11
4. Service Space

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
12
5. Refrigerant circuit

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
13
6. Wiring Diagrams
LRSJ-60/NYN1-A1, LRSJ-80/NYN1-A1

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
14
LRSJ-120/NYN1-A1, LRSJ-140/NYN1-A1

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
15
LRSJ-60/NYN1-A1, LRSJ-80/NYN1-A1
LRSJ-120/NYN1-A1, LRSJ-140/NYN1-A1
Item
Detail
N.C.
No need connect.
Tout
Outlet water temperature sensor.
T3
Heat-exchanger temperature sensor.
T4
Outdoor ambient temperature sensor.
T6
Inlet water temperature sensor.
Tp
Temperature sensor of compressor discharge.
Pro_H
High-pressure switch.
Pro_L
Low-pressure switch (Reserved).
Pro-Hyd.O
Water flow switch.

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
16
7. Electric Characteristics
Model
LRSJ-60/NYN1-A1
LRSJ-80/NYN1-A1
Outdoor unit
Hz
50
50
Voltage
220-240V, 1Ph
220-240V, 1Ph
Min.
198V
198V
Max.
254V
254V
Power supply
MCA
26.7
34.5
TOCA
16
18
MFA
20
20
Compressor
MSC
26.7
34.5
RLA
8.5
9
OFM
kW
0.16
0.16
FLA
0.71
0.71
Note:
MCA: Min. Current Amps. (A) MFA: Max. Fuse Amps. (A)
TOCA: Total Over-current Amps. (A) MSC: Max. Starting Amps. (A)
RLA: Rated Locked Amps. (A) OFM: Outdoor Fan Motor
kW: Fan Motor Rated Output (kW) FLA: Full Load Amps. (A)
Model
LRSJ-120/NYN1-A1
LRSJ-140/NYN1-A1
Outdoor unit
Hz
50
50
Voltage
220-240V, 1Ph
220-240V, 1Ph
Min.
198V
198V
Max.
254V
254V
Power supply
MCA
61
63
TOCA
20
22
MFA
25
25
Compressor
MSC
61
63
RLA
11.4
13.1
OFM
kW
0.168
0.168
FLA
0.77
0.77
Note:
MCA: Min. Current Amps. (A) MFA: Max. Fuse Amps. (A)
TOCA: Total Over-current Amps. (A) MSC: Max. Starting Amps. (A)
RLA: Rated Locked Amps. (A) OFM: Outdoor Fan Motor
kW: Fan Motor Rated Output (kW) FLA: Full Load Amps. (A)

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
17
8. Capacity Curve
LRSJ-60/NYN1-A1
Heating mode:
Test condition, inlet water temperature of the units is 27°C ; outlet water temperature is 29°C.
Relation between heating capacity and outdoor ambient temperature:
Relation between COP and outdoor ambient temperature:

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
18
Cooling mode:
Test condition, inlet water temperature of the units is 27°C ; water volume is 2.6m3/h.
Relation between cooling capacity and outdoor ambient temperature:
Relation between EER and outdoor ambient temperature:

Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual MCAC-HTSM-201409
19
LRSJ-80/NYN1-A1
Test condition, inlet water temperature of the units is 27°C ; outlet water temperature is 29°C.
Relation between heating capacity and outdoor ambient temperature:
Relation between COP and outdoor ambient temperature:

MCAC-HTSM-201409 Midea R410A Domestic Pools & Spas HPWH 50Hz Technical Manual
20
Cooling mode:
Test condition, inlet water temperature of the units is 27°C ; water volume is 3.5m3/h.
Relation between cooling capacity and outdoor ambient temperature:
Relation between EER and outdoor ambient temperature:
