Miele CVA 2662 Specification sheet

Operating and Installation
Instructions
Coffee System
CVA 2662
To prevent accidents
and appliance damage
read these instructions
before
installation or use. M.-Nr. 07 357 080
en - US, CA

IMPORTANT SAFETY INSTRUCTIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Guide to the coffee system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
First steps to use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Filling water and coffee capsules. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Allocating various coffee types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Making coffee / espresso . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Coffee and Espresso ...............................................18
Preparing hot milk, frothed milk, and Cappuccino ........................19
After use.........................................................22
Setting serving sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
User profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Selecting a user profile .............................................25
Setting a user profile ...............................................25
Making coffee / espresso with user profiles .............................27
Setting serving sizes for user profiles ..................................27
Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Selecting a language...............................................28
Time of day ......................................................28
Setting the timer...................................................29
Steam system ....................................................31
Lighting: Adjusting the brightness.....................................31
Lighting: Setting the switch-off time....................................32
Display ..........................................................32
Volume ..........................................................33
Info (displaying No. of drinks) ........................................33
System lock ......................................................34
Water hardness ...................................................34
Restore factory default settings .......................................35
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Overview ........................................................37
Descaling the coffee system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Frequently asked questions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Removing a jammed capsule . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Contents
2

Installation instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Caring for the environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Electrical connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Coffee glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
The Espresso range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
The "Pure Origin" Espresso range. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
The Lungo range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Contents
3

When using electrical appliances basic safety precautions should always be
followed, including the following:
Read all instructions before installation or use of the coffee system.
Please read these instructions
carefully to prevent accidents and
machine damage.
This appliance complies with current
safety requirements. Improper use
of the appliance can cause personal
injury and material damage.
Read this safety information carefully
before operating the appliance.
They contain important information
on the safe installation, operation,
and care of your coffee system. To
avoid the risk of personal injury or
damage to the coffee system, it is
important that you carefully read the
instructions.
Keep them in a safe place and pass
them on to any future user.
Proper use
~This coffee system is for household
use only (up to 20 cups per day), for
the preparation of coffee beverages
such as espresso, cappuccino, latte
macchiato, etc.
Do not use this machine other than for
its intended use. Any other use could
be hazardous.
~Persons which lack physical,
sensory or mental abilities or
experience with the machine should not
use it without supervision or instruction
by a responsible person.
Children
~Close supervision is necessary
when any appliance is used by or near
children. They could easily be scalded
or burned.
~Never let children play with the
coffee system.
~Install the appliance in an area
where it will not be accessible to
children.
IMPORTANT SAFETY INSTRUCTIONS
4

Technical safety
~Before installing the appliance
check for externally visible damage.
Do not operate a damaged appliance.
~Before connecting the appliance to
the electrical supply make sure that the
voltage and frequency listed on the
data plate correspond with the
household electrical supply. If in doubt,
consult a qualified technician.
~Be certain your appliance is
properly installed and grounded by a
qualified technician. To guarantee the
electrical safety of this appliance,
continuity must exist between the
appliance and an effective grounding
system. It is imperative that this basic
safety requirement be met. If there is
any doubt, have the electrical system of
the house checked by a qualified
electrician.
~The appliance must be properly
installed before operation to ensure that
no electrical components are
accessible. Ensure that power is not
supplied to the appliance while
installation work, repairs or
maintenance is performed.
~Do not use an extension cord to
connect the appliance to electricity.
Extension cords do not guarantee the
required safety of the appliance
(danger of overheating).
~This appliance must not be installed
or operated outdoors.
~If the appliance is installed behind a
door front, use the appliance only when
the door front is open. Do not close the
door front when the appliance is in
operation.
~Before service or maintenance
disconnect the power supply by either
removing the fuse, “tripping” the circuit
breaker or unplugging the unit.
~This appliance must not be used in
a non-stationary location (e.g. on a
boat).
~Installation work and repairs must
only be performed by a trained
technician in accordance with national
and local safety regulations. Repairs
and other work by unauthorized
persons could be dangerous and may
void the warranty.
~While the appliance is under
warranty repairs should only be
performed by an authorized service
technician. Otherwise the warranty is
void.
~Defective components should be
replaced by Miele original spare parts
only. Only with these parts can the
manufacturer guarantee the safety of
the appliance.
~To protect against fire, electric
shock and injury to persons do not
submerge the cord or plugs in water or
other liquids.
IMPORTANT SAFETY INSTRUCTIONS
5

~Do not let the cord hang over the
edge of a table or counter, or touch hot
surfaces.
~Do not operate any appliance with a
damaged cord or plug, or after the
appliance malfunctions or has been
damaged in any manner. Contact
Miele.
~Always attach the cord to the
appliance first, then plug it into the wall
outlet. To disconnect, turn the machine
off, then remove the plug from the wall
outlet.
~Never open the outer casing of the
appliance. Tampering with electrical
connections or components and
mechanical parts is dangerous and
may cause machine damage.
~If the machine is installed in
combination with other appliances, a
protective base should be installed
between the appliance and the unit
(except for combinations with a plate
warmer).
~Install or locate this appliance only
in accordance with the provided
installation instructions.
Use
~Use only Nespresso-coffee
capsules with this machine. The use of
other products will damage the
appliance.
Caution! Risk of burns when
dispensing hot beverages, they are
extremely hot.
Caution! Do not look directly or, with
an optical instrument into the
lighting - laser radiation.
~Do not reach into the brew unit
unless the appliance is disconnected
from the power supply. Danger of
injury.
~The water lines must be rinsed and
the machine cleaned thoroughly before
the first coffee is prepared. The
cappuccinatore should also be
cleaned.
~Only fill the water tank with cold,
fresh tap water. Warm or hot water, or
any other liquids may damage the
machine. The water should be changed
daily to prevent bacteria or mold
growth.
~Do not use deionized or mineral
water. Mineral water leads to heavy
calcium buildup in the machine that
can damage the unit.
~Only use cold plain milk in the
cappuccinatore. Flavored milk products
contain substances that can clog the
machine.
IMPORTANT SAFETY INSTRUCTIONS
6

~Do not place anything other than
Nespresso capsules un the capsule
carousel.
~Do not use damaged, broken or
dented capsules! They may jam in the
machine and damage it.
~Never place a cup with an
alcohol-coffee mixture underneath the
coffee dispenser. Plastic parts of the
unit could catch fire!
~The hot water and steam dispensed
could cause scalding. These functions
must be used carefully. Never hold any
parts of the body under the steam
nozzle or the hot water dispenser. The
machine must never be used to clean
objects.
~Never use a steam cleaner to clean
the appliance. Pressurized steam could
damage electrical components and
cause a short circuit.
~Clean the coffee system daily to
prevent bacterial growth. All parts of
the coffee system are dishwasher-safe
except for the capsule plate and the
plastic drip tray. Failure to properly
maintain machine may cause health
issues.
~Do not clean inside the capsule
plate opening. Danger on injury.
~Do not reach into the perforator.
Injuries may occur.
~Do not touch hot surfaces. Use
buttons or steam lever.
~To avoid injuries allow the coffee
system to cool before cleaning or
before putting on or taking off parts.
Turn the machine off at the main switch
when not in use and before cleaning.
~The water in the drip tray can be
very hot. Use caution when emptying it.
Danger of burns.
~The coffee system must be
descaled regularly with the supplied
descaling tablets. In areas with very
hard water the machine needs to be
descaled more often.
~The capsule plate will soil more or
less depending on the coffee capsule
used. Clean the capsule plate every 1
to 2 months with a cleaning tablet,
available from Miele.
~Only use the descaling tablets
provided by Miele and be sure to use
the correct mixture of water and
descaler. Otherwise appliance damage
may occur.
~Do not hang, lean, sit or place heavy
items on the door. The machine may be
damaged.
~The use of accessories not
recommended by the appliance
manufacturer may result in fire, electric
shock or injury to persons.
~The appliance is designed for use
in room temperatures between 59°F
and 140°F (15°C and 60°C). Do not use
the appliance outside of this range of
temperatures.
SAVE THESE INSTRUCTIONS
AND REVIEW THEM
PERIODICALLY
IMPORTANT SAFETY INSTRUCTIONS
7

Front view
aOn/Off stouch control
bDisplay
cLeft arrow <, to scroll through program options
dOK touch control, to confirm selected program options and save settings
eRight arrow >, to scroll through program options
frDrink selection touch control to select the beverage type (coffee or
espresso)
gDoor grip
hPlastic drip tray
iMetal drip tray
jCoffee dispenser
kInset for Cappuccinatore
lValve / Lever for steam and hot water
Guide to the coffee system
8

Interior view
mMain Switch
nCapsule plate (replace with descaling funnel when descaling is performed)
oBrew unit
pCapsule carousel
qCarousel tray
rWater tank
sDrip tray with grid
(with no-spill grid for transport)
tWaste container
Guide to the coffee system
9

Touch controls
Select a touch control with your
fingertip to use the machine.
Display
COSI oEspresso
K1K2K3K4K5Lon GkC
The main menu in the display shows
the following symbols:
KUp to 5 different coffee types
LSteam
oHot water
nUser profile for up to 9 different
users
GMaintenance program - rinse
kMaintenance program - descale
CSettings - customize appliance
^Use < or > to select a program item
in the display. When the desired
program item is highlighted, select
OK.
Display
10
