Miele ProLine Teppanyaki CS 1327 User manual

Operating and installation instructions
ProLine Teppanyaki
To prevent the risk of accidents or damage to the appliance, it is
essential to read these instructions before it is installed and used for
the first time.
en-AU, NZ M.-Nr. 09 054 600

Contents
2
Warning and Safety instructions.......................................................................... 3
Caring for the environment ................................................................................ 12
Overview............................................................................................................... 13
Teppanyaki ............................................................................................................ 13
Indicators............................................................................................................... 13
Before using for the first time ............................................................................ 14
Cleaning the ProLine appliance for the first time .................................................. 14
Switching on the ProLine appliance for the first time ........................................... 14
Operation.............................................................................................................. 15
Operating controls................................................................................................. 15
Switching on.......................................................................................................... 15
Switching off.......................................................................................................... 15
Residual heat indicator.......................................................................................... 15
Tips on cooking..................................................................................................... 16
Cleaning and care ............................................................................................... 17
Cooking surface .................................................................................................... 18
Stainless steel frame/control panel ....................................................................... 18
Control knob(s)...................................................................................................... 18
Problem solving guide ........................................................................................ 19
Optional accessories .......................................................................................... 20
Safety instructions for installation..................................................................... 21
Safety distances .................................................................................................. 22
Installation notes ................................................................................................. 24
Building-in dimensions ....................................................................................... 25
Installing several ProLine appliances ................................................................ 26
Installation............................................................................................................ 28
Electrical connection .......................................................................................... 32
Service.................................................................................................................. 35
Contact in case of fault ......................................................................................... 35
Data plate .............................................................................................................. 35
Warranty ................................................................................................................ 35

Warning and Safety instructions
3
This appliance complies with all current local and national safety
requirements. However, inappropriate use can lead to personal
injury and damage to property.
Read the operating and installation instructions carefully before
using the Teppanyaki. They contain important information on the
safety, installation, use and maintenance of the appliance. This
prevents both personal injury and damage to the appliance.
Miele cannot be held liable for damage caused by non-compliance
with these instructions.
Keep these instructions in a safe place and pass them on to any
future owner.

Warning and Safety instructions
4
Correct application
 This Teppanyaki is designed for domestic use and for use in
similar environments by guests in hotel or motel rooms, bed &
breakfasts and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts.
 The Teppanyaki is not suitable for outdoor use.
 The Teppanyaki is intended only to cook food and keep it warm.
Any other use is not permitted.
 This Teppanyaki is not intended for use by people (including
children) with reduced physical, sensory or mental capabilities or
lack of experience and knowledge, unless they have been given
supervision and instruction concerning its use by a person
responsible for their safety. They may only use the appliance
unsupervised if they have been shown how to use it in a safe way.
They must be able to recognise and understand the dangers of
misuse.

Warning and Safety instructions
5
Safety with children
 Young children must not be allowed to use this appliance.
 Older children may only use the Teppanyaki if its operation has
been clearly explained to them and they are able to use it safely.
They must be aware of the potential dangers caused by incorrect
operation.
 Cleaning may only be carried out by older children under the
supervision of an adult.
 Children should be supervised in the vicinity of the Teppanyaki.
Do not allow them to play with it.
 The Teppanyaki gets hot when in use and remains hot for quite a
while after being switched off. Keep children well away from the
Teppanyaki until it has cooled down and there is no danger of
burning.
 Danger of burning!
Do not store anything which might arouse a child's interest in
storage areas above or next to the Teppanyaki. Otherwise children
could be tempted to climb onto the Teppanyaki with the risk of
burning themselves.
 Danger of suffocation! Whilst playing, children may become
entangled in packaging material (such as plastic wrapping) or pull it
over their head with the risk of suffocation. Keep packaging material
away from children.

Warning and Safety instructions
6
Technical safety
 Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and
repairs must only be carried out by a Miele authorised technician.
 Damage to the Teppanyaki can compromise your safety. Check
the appliance for visible signs of damage. Never use a damaged
Teppanyaki.
 Reliable and safe operation of this appliance can only be assured
if it has been connected to the mains electricity supply.
 The electrical safety of this appliance can only be guaranteed
when continuity is complete between it and an effective earthing
system. It is essential that this basic safety requirement is present
and tested regularly. If in doubt, the electrical installation should be
checked by a qualified electrician.
 Before connecting the Teppanyaki to the electricity supply, ensure
that the connection data on the data plate (voltage and frequency)
match the mains supply.
Compare this data before connecting the appliance. If in any doubt,
consult a qualified electrician.
 Multi-socket adapters and extension leads do not guarantee the
required safety of the appliance (fire hazard). Do not use these to
connect the Teppanyaki to the mains electricity supply.
 For safety reasons, the Teppanyaki may only be used after it has
been built in.
 This appliance must not be installed and operated in mobile
installations (e.g. on a ship).
 Any contact with live connections or tampering with the electrical
or mechanical components of the Teppanyaki will endanger your
safety and may lead to appliance malfunctions.
Do not open the appliance housing under any circumstances.

Warning and Safety instructions
7
 While the Teppanyaki is under warranty, repairs should only be
undertaken by a Miele authorised service technician. Otherwise the
warranty is invalidated.
 Faulty components must only be replaced by genuine Miele spare
parts. The manufacturer can only guarantee the safety of the
appliance when Miele replacement parts are used.
 The Teppanyaki is not intended for use with an external timer
switch or a remote control system.
 If the plug is removed from the connection cable or if the cable is
supplied without a plug, the Teppanyaki must be connected to the
electricity supply by a suitably qualified and competent electrician.
 If the mains connection cable is damaged, it must be replaced
with a special connection cable type H 05 VV-F (PVC insulated),
available from Miele, by a Miele authorised service technician or
suitably qualified and competent electrician in order to avoid a
hazard (see “Electrical connection”).
 During installation, maintenance and repair work, the Teppanyaki
must be completely disconnected from the mains electricity supply.
It is only completely isolated from the electricity supply when:
– the mains circuit breaker has been disconnected, or
– the screw-out fuse is removed (in countries where this is
applicable), or
– it is switched off at the wall socket and the plug is withdrawn from
the socket. Do not pull the mains connection cable but the mains
plug to disconnect the appliance from the mains electricity
supply.
 Danger of electric shock!
Do not use the Teppanyaki if it is damaged or not working. Switch it
off immediately. Disconnect it from the electricity supply. Contact
Miele.

Warning and Safety instructions
8
 If the Teppanyaki is installed behind a furniture door, do not close
the door while the appliance is in operation. Heat and moisture will
build up behind the closed door, potentially causing damage to the
appliance, the furniture unit and the flooring. Do not close the door
until the appliance has cooled down and the residual heat indicators
have gone out.

Warning and Safety instructions
9
Correct use
 The Teppanyaki gets hot when in use and remains hot for quite a
while after being switched off. There is a danger of burning until the
residual heat indicators go out.
 Due to the high temperatures radiated, objects left near the
Teppanyaki could catch fire.
Do not use the Teppanyaki to heat up the room.
 Oils and fats can ignite if allowed to overheat. Never leave the
Teppanyaki unattended when cooking with oil or fats. Never attempt
to put out oil or fat fires with water. Switch the Teppanyaki off.
Extinguish the flames carefully with a lid or fire blanket.
 Flames could set the grease filters of a rangehood on fire. Do not
flambé under a rangehood.
 Spray cans, flammable liquids, aerosols, or combustible materials
can ignite when heated. Therefore do not store such items or
substances in a drawer under the Teppanyaki. Cutlery inserts must
be heat-resistant.
 Heating up food in closed containers e.g. tins or sealed jars,
results in an increase in pressure which can cause them to explode.
Do not use the Teppanyaki for canning food or for heating up food in
tins.
 Do not cover the Teppanyaki, e.g. with a cooktop cover, a cloth or
protective foil. The material could catch fire, shatter or melt if the
Teppanyaki is switched on by mistake or if residual heat is still
present.
 When the Teppanyaki is switched on, either deliberately or by
mistake, or when there is residual heat present, there is a risk of any
metal items left on the Teppanyaki heating up. Depending on the
material, other items left on the appliance could also melt or catch
fire. Do not use the Teppanyaki as a resting place. Always switch the
Teppanyaki off after use.

Warning and Safety instructions
10
 You could burn yourself on the hot surface. Protect your hands
with heat-resistant pot holders or oven gloves when using the
Teppanyaki. Do not let them get wet or damp. This causes heat to
transfer through the material more quickly with the risk of scalding or
burning yourself.
 When using an electrical appliance, e.g. a hand-held food mixer,
near the Teppanyaki, ensure that the cable of the electrical appliance
cannot come into contact with the hot Teppanyaki. The insulation on
the cable could become damaged.
 The Teppanyaki gets very hot. Do not use coated barbecue
utensils. Heat-resistant, coated cutlery is also not suitable.
 Where several ProLine appliances are installed side by side:
Hot objects can damage the seal of the cover strip. Do not place hot
pans near or on the cover strip.

Warning and Safety instructions
11
Cleaning and care
 The steam from a steam cleaning appliance could reach electrical
components and cause a short circuit.
Do not use a steam cleaner to clean the Teppanyaki.

Caring for the environment
12
Disposal of the packing
material
The transport and protective packaging
has been selected from materials which
are environmentally friendly for
disposal, and can normally be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain specific materials,
compounds and components, which
were essential for their correct function
and safety. These could be hazardous
to human health and to the environment
if disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre for electrical and electronic
appliances. You are also responsible for
deleting any personal data that may be
stored on the appliance prior to
disposal. Please ensure that your old
appliance poses no risk to children
while being stored prior to disposal.

Overview
13
Teppanyaki
aRear Teppanyaki zone
bFront Teppanyaki zone
cSymbol for Teppanyaki zone
dIndicators
eControl knob for the rear Teppanyaki
zone
fControl knob for the front Teppanyaki
zone
Indicators
gIn-operation indicator
hTemperature indicator light
iResidual heat indicator

Before using for the first time
14
Please stick the extra data plate for
the appliance supplied with this
documentation in the space provided
in the “Service” section of this
booklet. Alternatively, the additional
label can be stuck near the appliance
if the appliance markings are not
visible after installation.
Remove any protective wrapping and
stickers (except the data plate).
Cleaning the ProLine appliance
for the first time
Clean all surfaces with a damp cloth,
and then wipe dry.
Switching on the ProLine
appliance for the first time
The metal components have a
protective coating which when heated
for the first time will give off a slight
smell and possibly some vapours.
The smell and any vapours given off do
not indicate a faulty connection or
appliance and they are not hazardous
to health.

Operation
15
The Teppanyaki is divided into two
cooking zones that can be switched on
and controlled separately. The entire
area can be used when cooking large
quantities of food. When cooking
smaller quantities, the front zone can be
used for cooking whilst the rear zone
can be used to keep food warm using a
lower power setting.
Operating controls
The controls must not be turned past
12 to 0.
Switching on
Risk of fire due to overheated
food!
Unattended food can overheat and
ignite.
Do not leave the Teppanyaki
unattended whilst it is being used.
Turn the control knob clockwise to
the required power level.
The in-operation indicator and the
temperature indicator will light up. The
residual heat indicator will light up after
a certain temperature has been
reached.
The temperature indicator light will
switch on and off intermittently in
conjunction with the heating element
of the Teppanyaki, i.e. it only lights up
when the heating is operating.
Switching off
Turn the control knob anti-clockwise
to the 0position.
Residual heat indicator
If the Teppanyaki is still hot, the residual
heat indicator will light up after it has
been switched off.
The residual heat indicator remains on
until the Teppanyaki is cool enough to
touch.
Risk of burning due to hot
surfaces!
The surfaces will be hot after use.
Do not touch the surfaces while the
residual heat indicators are on.

Operation
16
Tips on cooking
Wipe the surface of the Teppanyaki
before each use with a damp cloth to
remove any dust or other soiling
which may have settled on it since it
was last used.
– Always preheat the Teppanyaki for
8-10 minutes before use. To do this,
set the power level that you are going
to be using for cooking. Preheat at
power level 12 if you are going to be
cooking at levels 9 to 12.
– It is important that the Teppanyaki
gets sufficiently hot before use,
particularly when browning and
sealing meat. If it is not hot enough,
the meat will lose too much juice and
become tough.
– Very little fat is required for cooking
on the Teppanyaki, and no fat is
required for marinated food. Wait until
the temperature indicator light has
gone out before adding cooking fat.
– Use only fats and oils that can
withstand high temperatures.
– We recommend that you marinate the
food to be cooked. This will improve
the flavour of the food.
– Pat wet food dry with kitchen paper
before cooking to prevent it spitting.
– To prevent meat drying out, do not
season with salt until after it has been
cooked.

Cleaning and care
17
Risk of burning due to hot
surfaces!
The surfaces will be hot after use.
Switch off the Teppanyaki.
Allow the surfaces to cool down
before cleaning the Teppanyaki.
Risk of damage due to moisture
ingress.
The steam from a steam cleaning
appliance could reach electrical
components and cause a short
circuit.
Do not use a steam cleaner to clean
the Teppanyaki.
The use of unsuitable cleaning
agents can cause the surfaces to
discolour or alter. All surfaces are
susceptible to scratching.
Remove any residual cleaning agent
immediately.
Never use abrasive sponges or
cleaning agents.
Allow the ProLine appliance to cool
down before cleaning.
Clean the ProLine appliance and
accessories after each use.
Dry the ProLine appliance thoroughly
after every cleaning to avoid
limescale residue.
Unsuitable cleaning agents
To avoid damaging the surfaces of the
appliance, do not use:
– cleaning agents containing soda,
alkalines, ammonia, acids or
chlorides,
– cleaning agents containing descaling
agents,
– stain or rust removers,
– abrasive cleaning agents, e.g.
powder cleaners and cream cleaners,
– solvent-based cleaning agents,
– dishwasher cleaner,
– grill and oven cleaners,
– glass cleaning agents,
– hard, abrasive brushes or sponges,
e.g. pot scourers, brushes or
sponges which have been previously
used with abrasive cleaning agents,
– dirt erasers.

Cleaning and care
18
Cooking surface
Remove coarse soiling immediately
using a spatula.
Allow the cooking surface to cool
down until it can be touched by hand,
and then use a solution of hot water
and washing-up liquid to soften the
soiling. Clean the cooking surface
with the rough side of a non-scouring
dishwashing sponge and a few drops
of Miele ceramic and stainless steel
cooktop cleaner (see “Optional
accessories”). Finally wipe the
surface with water and dry it
thoroughly with a clean cloth.
Always use clean water to wipe the
surface to ensure that every trace of
cleaning agent has been removed.
Any remaining traces of cleaning
agent could affect the food the next
time you use the appliance.
Important: Conditioning agents for
stainless steel must not be used on
the cooking surface.
Stainless steel frame/control
panel
Clean the frame and the control panel
with a solution of warm water and a
little washing-up liquid applied with a
soft sponge.
You can also use a ceramic and
stainless steel cleaning agent. We
recommend using a stainless steel
conditioning agent to help prevent
resoiling (see “Optional accessories”).
Do not use a ceramic and stainless
steel cleaner or stainless steel
conditioning agent on the printing.
This would rub the printing off.
These areas should only be cleaned
with a solution of warm water and a
little washing-up liquid applied with a
soft sponge.
Control knob(s)
Clean the control knob(s) using a
solution of warm water and a little
washing-up liquid applied with a soft
sponge. Stubborn soiling should be
soaked first.
Dry the control knob(s) with a clean
cloth.

Problem solving guide
19
With the help of the following guide, minor faults in the performance of the
appliance, some of which may result from incorrect operation, can be remedied
without contacting Miele. This will save you time and money because you won't
need a service call.
Please note that a call-out charge will be applied to unnecessary service visits
where the problem could have been rectified as described in these operating
instructions.
Problem Possible cause and remedy
The Teppanyaki is not
heating up.
There is no power to the Teppanyaki.
Check if the circuit breaker has tripped. Contact
an electrician or Miele (for the minimum fuse
rating, see data plate).

Optional accessories
20
Miele offers a range of useful
accessories, as well as cleaning and
conditioning products for your
appliance.
These products can be ordered from
the Miele online shop.
They can also be ordered directly from
Miele (see end of this booklet for
contact details).
Original Miele ceramic and
stainless steel cooktop cleaner
250ml
Removes heavy soiling, limescale
deposits and aluminium residues.
Original Miele all purpose
microfibre cloth
Removes finger marks and light soiling.
