Miele T 8001 WP User manual

Quick Start Guide
for heat pump tumble dryer
T 8001 WP
These short instructions are not a substitute
for the Operating instructions supplied with the appliance.
Please read the Operating instructions supplied with
your tumble dryer before using it for the first time and
take note of the Warning and Safety instructions as well
as the full descriptions on how to use your machine. M.-Nr. 09 148 240
en - AU, NZ

aMiele{home
The appliance is compatible with the
Miele|home system (available in
selected countries).
b:sensor (Information)
If the sensor is lit up, information is
available for the menu displayed.
cPC interface
Used by service technicians to run
diagnostic checks on your
appliance, or to update
programming data in the future.
dSelector sensors
If a selector sensor is illuminated, it is
active.
eDisplay
For displaying:
–The selected functions.
–The programme sequence.
–Info texts.
–Fault messages.
fUsensor (Clear)
–Returns to the previous menu
screen.
–Returns to the main menu if pressed
twice.
– Discards previously set values.
– Cancels a programme.
gStart sensor
The selected programme is started
via the sensor illuminated in green.
hKbutton
For switching the dryer on and off.
To save energy, the dryer will switch
off automatically 15 minutes after the
end of a programme/Anti-crease, or
if no other function is selected after
switching on.
i/button
For opening the door, even if the
dryer is switched off.
Control panel
2

Preparing the laundry
,Make sure that objects, e.g. detergent dispensing
balls, have been removed from the laundry.
^Sort the laundry (e.g. according to the drying level
required, the type of fibre or weave).
Pay attention to the manufacturers' information on the care
labels:
sDo not tumble dry.
r/qSuitable for all programmes.
Loading the tumble dryer
^Press the abutton and open the door.
^Load the laundry loosely into the drum.
^Close the door.
Check the laundry is right inside the drum so that it cannot
get trapped or damaged when the door is shut.
1. Switch the dryer on by pressing K.
2. Selecting a programme
\
\
\
Main menu 10:21 [
[
$Favourite programmes
#Cottons
!Minimum iron m
^Select the programme you want.
– Programmes with drying levels
\
\
\
Cottons 1-7 kg 2:03 h 10:21 [
[
$Drying level: Normal
#Extras
#Start at m
^Touch the sensor for Drying level.
Brief instructions
3

\
\
\
Drying levels 10:21 [
[
[
$Normal (
#Hand ironrp
!Hand ironrr OK !
^There are more than 3 drying levels available for selection:
Touch the right sensor on the right to display other
programmes.
^Touch the sensor on the left for the drying level required.
^Confirm with OK.
– Timed drying programmes
\
\
\
Warm air 1-7 kg 0:20 h 10:21 [
[
[
$Duration 0:25 h:min +$
#Extras –#
#Start at OK !
^Touch the sensor for Duration.
^The +und –sensors on the right can be used to change
the highlighted time.
^Confirm the set time with OK.
Cool air: 20min -1h
Warm air: 20 min - 2 h
Basket programme: 40 min - 2:30 h
– Other programmes
\
\
Gentle smoothing 1 kg 1:06 h 10:21
$Start at
#Finish at
Brief instructions
4

Selecting Extras
\
\
Extras 10:21
[
$9Freshen up
#8Gentle tumble
OK !
^Select a desired Extra.
Programme Freshen up
= normally aired
Gentle tumble
= less mechanical action
Cottons ##
Minimum iron ##
Shirts ##
Denim ##
Sportswear #
Warm air #
The Extra selected is shown by a tick 9.
^Confirm with OK.
3. Starting the programme
^Confirm with the green Start sensor.
4. Programme end - removing the laundry
OAnti-crease and Finish will appear in the display to
indicate that the programme has finished. The buzzer will
sound at intervals.
15 minutes after programme end/Anti-crease the dryer will
switch off automatically.
^Press the abutton and open the door.
^Remove the laundry.
^Switch off the tumble dryer with the sbutton.
^Clean the fluff filters.
^Close the door.
^Empty the condensed water container.
Brief instructions
5

Condensed water container
After every programme
(or if Empty the container* appears
in the display)
Aremove Bempty
* To delete the message in the display:
switch the dryer off and then back on
again.
Fluff filters
After every programme
Aremove
1 = Fluff filter
2 = Clean seal
with a damp
cloth
Bclean
Cclean
Fine filter
Only clean if Clean the plinth filter
which is located in front of the heat
exchanger appears in the display.*
Aopen Bremove
Cdisassemble/
clean
Dclean
Eclean FStick the handle
with the filter
attached onto
the two guide
pins:
yellow dot must
be on the left
* To delete the message in the display:
select OK.
Cleaning and care
6

Cottons Max. load 7 kg*
Extra dry, Normal+, Normal
Fabric type Single and multi-layered cotton fabrics such as
towelling, jerseywear, T-shirts, underwear.
Hand iron r, Hand iron rr, Machine iron
Fabric type Cotton and linen fabrics. For example: table linen, bed linen,
starched laundry.
Minimum iron Max. load 3.5 kg*
Normal+, Normal, Hand iron r
Fabric type Minimum iron items made of cotton, synthetic or mixed fibres. For
example: dresses, trousers, skirts or table cloths.
Delicates Max. load 2.5 kg*
Normal+, Normal, Hand iron r, Hand iron rr
Fabric type Delicate items made of synthetic fibres, easy care cotton, blended
fabrics or rayon, e.g. shirts, blouses and evening wear with sequins
and beading.
Automatic plus Max. load 5 kg*
Normal+, Normal, Hand iron r
Fabric type Mixed loads of garments suitable for the Cottons and Minimum iron
programmes. Sort according to colour.
Shirts Max. load 2 kg*
Normal, Hand iron r
Fabric type Shirts and blouses.
Denim Max. load 3 kg*
Normal, Hand iron r
Fabric type Denim garments, e.g. trousers, jackets, skirts or shirts.
Express Max. load 3.5 kg*
Extra dry, Normal+, Normal,
Hand ironr, Hand iron rr, Machine iron
Fabric type Tougher fabrics for the Cottons programme.
Woollens Max. load 2 kg*
Fabric type Woollen fabrics. Fabrics containing wool blends.
* Weight of dry laundry
Programme chart
7

Silks Max. load 1 kg*
Fabric type Silks (which are suitable for drying in a tumble dryer), e.g. blouses
and shirts.
Sportswear Max. load 3 kg*
Normal+, Normal, Hand iron r
Fabric type Sportswear which is suitable for drying in a tumble dryer.
Outerwear Max. load 2.5 kg*
Normal, Hand iron r
Fabric type Outerwear which is suitable for drying in a tumble dryer.
Standard pillows 1-2 pillows up to 80 x 40 cm
Large pillows 1 pillow up to 80 x 80 cm
Fabric type Pillows suitable for drying in a tumble dryer, with feather, down or
synthetic fillings.
Gentle smoothing Max. load 1 kg*
Fabric type – Cotton and linen fabrics.
– Minimum iron items made of cotton, synthetic or mixed fibres. For
example: trousers, anoraks, shirts.
Cool air Max. load 7 kg*
Fabric type Any item which only needs airing.
Warm air Max. load 7 kg*
Fabric type –e.g. jackets, pillows. Also for drying individual items, e.g. bath
towels, swimwear, tea towels and small loads.
Basket programme Max. load for basket: 3 kg
Notes –Only use with drying basket.
–See the operating instructions supplied with the drying basket.
Proofing Max. load: 2 kg*
Fabric type For drying microfibre fabrics, ski wear, fine, closeweave cotton
garments (poplin) or tablecloths which are suitable for drying in a
tumble dryer and have been treated to provide a water and dirt
resistant finish.
Hygiene Max. load: 3.5 kg*
Fabric type Cottons and linen fabrics, which will be in direct contact with the
skin, e.g. underwear, nappies, towelling, bed linen, pillow and
mattress covers.
* Weight of dry laundry
Programme chart
8
