Miele CS 1411 User manual

Operating and installation instructions
ProLine deep fat fryer
To avoid the risk of accidents or damage to the appliance it is essential
to read these instructions before it is installed and used for the first time.
en-GB M.-Nr. 07 180 430

Contents
2
Warning and Safety instructions.......................................................................... 4
Caring for the environment ................................................................................ 13
Guide to the appliance........................................................................................ 14
Deep fat fryer......................................................................................................... 14
Indicators............................................................................................................... 15
Accessories supplied ............................................................................................ 15
Before using for the first time ............................................................................ 16
Cleaning the ProLine element for the first time ..................................................... 16
Switching on the ProLine element for the first time .............................................. 16
Operation.............................................................................................................. 17
Fryer lid.................................................................................................................. 17
Rotary control........................................................................................................ 17
Switching on.......................................................................................................... 17
Switching off.......................................................................................................... 17
Residual heat indicator.......................................................................................... 18
Before frying.......................................................................................................... 18
Deep/shallow frying............................................................................................... 19
Tips for frying ........................................................................................................ 22
After frying............................................................................................................. 23
Safety features..................................................................................................... 24
Safety switch-off ................................................................................................... 24
Cleaning and care ............................................................................................... 25
Stainless steel frame/control panel and lid ........................................................... 26
Rotary controls...................................................................................................... 26
Frying basket ......................................................................................................... 26
Oil reservoir ........................................................................................................... 27
Problem solving guide ........................................................................................ 28
Optional accessories .......................................................................................... 29
After sales service............................................................................................... 30
Contact in case of malfunction ............................................................................. 30
Data plate .............................................................................................................. 30
Warranty ................................................................................................................ 30
Installation............................................................................................................ 31
Safety instructions for installation ......................................................................... 31
Safety distances.................................................................................................... 32
Installation notes ................................................................................................... 35

Contents
3
Building-in dimensions ......................................................................................... 36
Installing several ProLine elements ....................................................................... 37
Installation ............................................................................................................. 39
Electrical connection ............................................................................................. 43

Warning and Safety instructions
4
This deep fat fryer complies with all relevant safety requirements.
Inappropriate use can, however, lead to personal injury and dam-
age to property.
To avoid the risk of accidents and damage to the deep fat fryer,
please read these instructions carefully before installation and be-
fore using it for the first time. They contain important notes on in-
stallation, safety, use and maintenance.
Miele cannot be held liable for damage caused by non-compliance
with these instructions.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.

Warning and Safety instructions
5
Correct application
 This deep fat fryer is intended for use in domestic households and
similar environments including, for example:
– in kitchens used by employees in shops, offices and other com-
mercial settings
– by customers in hotels, motels and other residential settings
– in bed and breakfast accommodation
 This deep fat fryer is not intended for outdoor use.
 This deep fat fryer is intended for domestic use only to cook food.
Any other use is not supported by the manufacturer and could be
dangerous.

Warning and Safety instructions
6
Safety with children
 Children between the ages of 0and8years old are not permitted
to use this deep fat fryer. Children 8years and older are permitted to
use this deep fat fryer but must be supervised at all times. This deep
fat fryer can be used by people with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they are
supervised at all times or if they have been shown how to use it in a
safe way and recognise and understand the consequences of incor-
rect operation. Children younger than 8years old must be kept away
from the appliance and its connection cable. Children must not be
allowed to carry out cleaning or maintenance work.
 Please supervise children in the vicinity of the deep fat fryer and
do not let them play with it.
 The deep fat fryer gets hot when in use and remains hot for a
while after being switched off. Keep children well away from the ap-
pliance until it has cooled down and there is no danger of burning.
 Ensure that children cannot reach the drain tap where hot liquid
could be drained out.
 Danger of burning.
Do not store anything which might arouse a child’s interest in storage
areas above or behind the deep fat fryer. Otherwise they could be
tempted into climbing onto the appliance with the risk of burning
themselves.
 Danger of suffocation! Whilst playing, children may become en-
tangled in packaging material (such as plastic wrapping) or pull it
over their head with the risk of suffocation. Keep packaging material
away from children.

Warning and Safety instructions
7
Technical safety
 Unauthorised installation, maintenance and repairs can cause
considerable danger for the user. Installation, maintenance and re-
pairs must only be carried out by a Miele authorised technician.
 A damaged deep fat fryer can be dangerous. Check it for visible
signs of damage. Do not use a damaged appliance.
 Reliable and safe operation of the deep fat fryer can only be as-
sured if it has been connected to the mains electrical supply.
 The electrical safety of this deep fat fryer can only be guaranteed
when correctly earthed. It is essential that this standard safety re-
quirement is met. If in any doubt please have the electrical installa-
tion tested by a qualified electrician.
 Before connecting the deep fat fryer to the mains supply, ensure
that the connection data on the data plate (voltage and frequency)
match the mains electricity supply.
This data must be checked before connecting the appliance. Consult
a qualified electrician if in any doubt.
 Do not connect the deep fat fryer to the mains electricity supply
by a multi-socket unit or an extension lead. These do not guarantee
the required safety of the appliance (fire hazard).
 For safety reasons, this deep fat fryer may only be used after it
has been built in.
 This deep fat fryer must not be used in a non-stationary location
(e.g. on a ship).
 Never open the casing of the deep fat fryer.
Touching or tampering with electrical connections or components
and mechanical parts is highly dangerous to the user and can cause
operational faults.

Warning and Safety instructions
8
 While the deep fat fryer is under warranty, repairs should only be
undertaken by a Miele authorised service technician. Otherwise the
warranty is invalidated.
 Miele can only guarantee the safety of the appliance when genu-
ine original Miele replacement parts are used. Faulty components
must only be replaced by Miele spare parts.
 The deep fat fryer is not intended for use with an external timer
switch or a remote control system.
 If the plug is removed from the connection cable or if the cable is
supplied without a plug, the deep fat fryer must be connected to the
electrical supply by a suitably qualified electrician.
 If the mains connection cable is damaged, it must be replaced
with a special mains connection cable by a qualified electrician (see
“Electrical connection” in the “Installation” chapter).
 During installation, maintenance and repair work, the deep fat
fryer must be completely disconnected from the mains electricity
supply. It is only completely isolated from the electricity supply
when:
– The mains fuse is disconnected.
– The screw-out fuse is removed (in countries where this is applic-
able).
– The plug (if present) is removed from the socket. To do this, pull
the plug and not the mains connection cable.
 If the deep fat fryer is built in behind a furniture front (e.g. a door),
do not close the furniture door while the deep fat fryer is in use. Heat
and moisture can build up behind the door when closed. This can
result in damage to the deep fat fryer, the housing unit and the floor.
Do not close the furniture door until the residual heat indicators have
gone out.

Warning and Safety instructions
9
 Risk of electric shock.
Do not use the deep fat fryer if it is damaged. If you detect a fault
during use switch it off immediately. Disconnect it from the mains
electricity supply. Contact Miele Service.

Warning and Safety instructions
10
Correct use
 The deep fat fryer gets hot when in use and remains hot for some
time after being switched off. The risk of burning is present until the
residual heat indicators have gone out.
 Do not use the deep fat fryer to heat up the room. Due to the high
temperatures radiated, objects left near the deep fat fryer could
catch fire.
 Overheated fat and oil can ignite and catch fire. Never leave the
deep fat fryer unattended. Do not attempt to extinguish burning oil or
fat with water.
Switch the appliance off and carefully smother the flames with a fire
blanket or with the fryer lid.
 Fire hazard.
Never use naked flames, e.g. an ignited lighter, near the deep fat
fryer.
 Do not cover the deep fat fryer, e.g. with a cloth or protective foil.
The material could catch fire, shatter or melt if the appliance is
switched on by mistake or if residual heat is still present.
The frying basket must only be covered using the cover supplied
with the appliance.
 You could burn yourself on the hot deep fat fryer. Protect your
hands with heat-resistant pot holders or gloves when handling hot
pots and pans. Do not let them get wet or damp, as this causes heat
to transfer through the material more quickly with the risk of scalding
or burning yourself.
 When using an electrical appliance, e.g. a hand-held food blender,
near the deep fat fryer, ensure that the cable of the electrical appli-
ance cannot come into contact with the hot deep fat fryer. The insu-
lation on the cable could become damaged.
 The heater element must be lowered before the deep fat fryer is
switched on.

Warning and Safety instructions
11
 Do not pour hot fat from frying into plastic containers. These will
melt at high temperatures. Only use heat-resistant containers for hot
fat.
 The deep fat fryer must only be used when it has been filled with
oil and without the cover on it.
 Clean or change dirty oil or fat in good time. Oil or fat containing
impurities is liable to catch fire.
 Do not dispose of used cooking oil down the sink. It can damage
pipework and cause blockages in the water pipes.
Dispose of it safely with your household food waste, or ask your
local authority about disposal schemes in your area.
 Handling and cooking food correctly is essential for maintaining
good health. Please pay careful attention to the information provided
in “Tips for frying” in the “Operation” chapter.
 Where several ProLine elements are installed side by side:
Hot objects can damage the seal on the spacer bars. Do not place
hot pans near or on the spacer bar.

Warning and Safety instructions
12
Cleaning and care
 Do not use a steam cleaning appliance to clean this deep fat fryer.
The steam could reach electrical components and cause a short cir-
cuit.

Caring for the environment
13
Disposal of the packing mater-
ial
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur-
ing process and also reduces the
amount of waste in landfill sites.
Disposing of your old appli-
ance
Electrical and electronic appliances of-
ten contain valuable materials. They
also contain specific materials, com-
pounds and components, which were
essential for their correct function and
safety. These could be hazardous to hu-
man health and to the environment if
disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local com-
munity waste collection / recycling
centre for electrical and electronic ap-
pliances, or contact your dealer or
Miele for advice. You are also respons-
ible (by law, depending on country) for
deleting any personal data that may be
stored on the appliance being disposed
of. Please ensure that your old appli-
ance poses no risk to children while be-
ing stored prior to disposal.

Guide to the appliance
14
Deep fat fryer
a
b
d
e
f
i
h
c
g
aFrying basket
bHandle (folds away, removable)
cHanging facility
dBracket for hanging the frying basket
on
eHeating element (can be raised up)
fDrain tap
gIndicators
hControl knob
iOil reservoir

Guide to the appliance
15
Indicators
jIn-operation indicator
kTemperature indicator light
lResidual heat indicator
Accessories supplied
The accessories supplied with your ap-
pliance as well as a range of optional
ones are available to order from Miele
(see “Optional accessories”).
Frying basket
Fryer lid
Cover to protect the oil reservoir after
use.

Before using for the first time
16
Please stick the extra data plate for
the appliance supplied with this doc-
umentation in the space provided in
the “After sales service” section of
this booklet.
Remove any protective wrapping and
stickers.
Cleaning the ProLine element
for the first time
Fill the oil reservoir to the max.
marker with water (approx. 4litres)
and add a little washing-up liquid.
Turn the rotary control in a clockwise
direction to 130°C and bring the wa-
ter briefly to the boil.
Switch the deep fat fryer off and drain
the water off into a heat-resistant
container (see “After frying” in the
“Operation” chapter).
Leave the appliance to cool down
and then raise the heating element.
Wipe the oil reservoir and all other
surfaces of the appliance with a
damp cloth and then dry them.
Close the drain tap.
Switching on the ProLine ele-
ment for the first time
The metal components have a protect-
ive coating which when heated for the
first time will give off a slight smell and
possibly some vapours.
The smell and any vapours given off do
not indicate a faulty connection or ap-
pliance and they are not hazardous to
health.

Operation
17
Fryer lid
To remove the fryer lid press the
cover on the left or right hand side
with your finger.
Use your other hand to lift the cover
off the fryer.
Hot fat or oil.
Risk of burning due to hot fat or oil.
Do not replace the lid until the deep
fat fryer is cold.
Rotary control
Do not turn the control to “0” by
turning it past 200°C.
Switching on
Risk of fire with overheated food.
Unattended food can overheat and
catch alight.
Do not leave the deep fat fryer unat-
tended when you are using it.
Do not switch the deep fat fryer on
when it is empty or with the heating
element raised up.
Turn the control clockwise to the re-
quired temperature.
The in-operation indicator and the tem-
perature indicator will light up. The re-
sidual heat indicator will light up after a
certain temperature has been reached.
The temperature indicator light will
switch on and off intermittently in con-
junction with the heating element. It
will only light up when the heating ele-
ment is on.
Switching off
Turn the control anti-clockwise to the
0position.

Operation
18
Residual heat indicator
If the deep fat fryer is still hot, the resid-
ual heat indicator will light up after it
has been switched off.
The residual heat indicator remains on
until the deep fat fryer is cool enough to
touch.
Danger of burning due to hot
surfaces.
The surfaces will be hot after cook-
ing.
Do not touch the surfaces while the
residual heat indicators are on.
Before frying
Do not use the fryer lid when deep
fat frying.
Only use oil and fat that has a high
flash point. Liquid or solid fat can be
used.
Never mix different types of oil or fat
together.
The oil reservoir must be filled with suf-
ficient oil or fat for frying (at least 3litres
or 3kg, maximum 4litres or 4kg).
Check that the drain tap is closed.
Fill the oil reservoir with oil or fat.
Solid fat should be cut up into small
pieces first.
When re-using fat that has solidified
in the reservoir, make a hole in the fat
as far as the heating element. This al-
lows any water which has collected
under the fat to evaporate.
Turn the control to 100°C and wait
until the fat has melted.
Check the level in the reservoir. This
needs to be between the minimum
and maximum level markers at the
back of the reservoir.

Operation
19
Deep/shallow frying
Set the temperature required (see
chart) and wait until the temperature
indicator goes out for the first time.
The oil has now reached the set tem-
perature.
Carefully lower the frying basket con-
taining the food to be fried into the
hot oil. If the oil froths a lot, lift the
basket out of the oil briefly and then
slowly lower it into the hot oil again.
When the food has cooked, lift the
basket out of the hot oil. Shake the
basket a little to remove any excess
oil, and then hang it on its bracket.
Do not leave food suspended over
the reservoir for too long as steam
from the oil can cause the food to
lose it crispness. Finally, place the
food onto kitchen paper towel to
soak up any excess oil.
Whilst frying food make sure you do
not touch the hot oil. Protect your
hands in particular, e.g. by wearing
heat-resistant oven gloves.

Operation
20
Food, fresh Quantity  [°C]  [min]*
Doughnuts Qty4 170 6–8
Camembert 4 x 1/2 pieces 170 2–3
Raw battered vegetables 400g 170 7–9
Chicken quarters, breaded 2pieces, each
250g
170 8–10
Croquette potatoes 400g 170 pre-fry 2–4
fry 3–5
Apple turnovers Qty 5 170 6–8
Parsley 180 1–2
Chips 400g 170 pre-fry 4–6
fry 2–4
Turkey steaks, unbreaded 2pieces, each
250g
180 3–5
Escalopes 200g 180 5–7
Drop cookies Qty4 170 6–8
Banana fritters Qty 2 170 3–4
Temperature / Frying times in min.
*The frying times given in the chart are only a guide.
