Miele ELECTRIC BARBECUE CS 1322 User manual

Operating and Installation
Instructions
Electric Barbecue
CS 1322
To prevent accidents and
machine damage,
read the Operating Manual
before
installation or use. M.-Nr. 07 374 400
en-CA

Warning and safety instructions .....................................3
Description of the unit..............................................8
Before using for the first time........................................9
Use ............................................................10
Prepare the appliance ..............................................10
Turning On/Off ....................................................10
Grilling ..........................................................11
After grilling ......................................................11
Grilling times .....................................................12
Safety Feature ...................................................13
Overheat protection ................................................13
Safety cut-out feature...............................................13
Cleaning and care ................................................14
Frequently asked questions .......................................16
Technical Service, Data Plate .......................................17
Optional accessories..............................................18
Safety instructions for installation...................................20
Installation ......................................................23
Installation dimensions .............................................24
Cutout..........................................................25
Installation of multiple appliances .....................................26
Attaching the spring clips and support bars...........................29
Installing the appliance(s)..........................................31
General installation tips ...........................................32
Electrical connection..............................................33
Help protect our environment.......................................34
Contents
2

This electric barbecue complies with
all applicable safety codes and
regulations.
To avoid the risk of accidents and
damage to the appliance:
Please read these instructions
carefully before installation and
before using the barbecue for the
first time.
Follow important notes on the
installation, safety, operation and
care of the appliance. This will
prevent injury and appliance
damage.
Keep these operating instructions in
a safe place and pass them on to
any future user.
Correct usage
~This electric barbecue is intended
for domestic and similar uses only,
such as
–stores, offices and other similar work
environments,
–in farming estates,
–by customers in hotels, motels, bed
& breakfasts and other typical
residential environments.
~Use the electric barbecue only in
household-type situations for the
preparation and warming of food.
All other types of use are not permitted.
Miele cannot be held liable for damage
resulting from incorrect or improper
use.
~This electric barbecue is not
intended for outdoor use.
~Individuals who are incapable of
using the appliance safety because of
their physical, sensory or mental
capabilities, or their lack of experience
or knowledge, must not use this
appliance without supervision or
instruction by a responsible person.
Warning and safety instructions
3

Children
~Always supervise any children in the
vicinity of the barbecue. Never let
children play with the appliance.
~Children may use the appliance only
if they have received sufficient
instruction to operate it safely. Children
must then be able to recognize the
potential dangers of improper use.
~The barbecue is hot during use and
remains so for some time after being
switched off. Keep children away from
the appliance until it has cooled down.
Danger of burns.
~Keep the spaces above and behind
the barbecue clear of any items that
could draw the interest of a child.
Otherwise, a child might be tempted to
climb on the appliance. Danger of
burns!
~Be sure that children cannot access
the drain valve on the appliance,
potentially releasing hot water.
~Packing materials (e.g. cling wrap,
styrofoam) can be dangerous for
children because of the danger of
suffocation. Ensure that any packing
material is disposed of safely and kept
out of the reach of children.
Technical safety
~Before installation, check the
electric barbecue for visible signs of
external damage. Do not operate a
damaged appliance. A damaged
appliance may endanger your safety!
~The electrical safety of the barbecue
can only be guaranteed when there is
proper grounding that complies with
applicable safety regulations. It is
imperative that this basic safety
requirement be met.
In case of doubt, have the electrical
system checked by a qualified
electrician. Miele cannot be held liable
for damages resulting from an
inadequate grounding system (for
example, electric shock).
~Before installing the electric
barbecue, make sure that the electrical
rating (voltage and frequency) shown
on the data plate corresponds to the
household electrical supply.
These ratings must match, in order to
avoid damaging the appliance. If in
doubt, consult a qualified electrician.
~To ensure safe operation, use the
barbecue only after it has been
properly installed in place.
~Do not under any circumstances
open the housing of the electric
barbecue.
Any contact with connections carrying
voltage, or changes in the electrical or
mechanical set-up, will endanger you
and may impair the functioning of the
appliance.
Warning and safety instructions
4

~Installation, repair and maintenance
work should be performed by a Miele
authorized service technician.
Installation, maintenance or repair work
by unqualified persons could pose
serious risks to the user for which Miele
will not be held liable.
~When performing installation or
maintenance work or repairs, the
electric barbecue must be
disconnected from the power supply. It
is only completely isolated from the
electrical supply when one of the
following conditions is met:
– the circuit breaker in the electrical
panel is tripped,
– the plug fuse is removed from the
electrical panel,
– the power cable is disconnected
from the power supply.
Pull the plug, not the cord, to
disconnect the appliance from the
power supply.
~Repair of the electric barbecue
during the warranty period should be
performed only by a service technician
who is authorized by Miele; otherwise,
should damage result, it will not be
covered by the warranty.
~The electric barbecue is not
intended for use with an external timer
or a remote control system.
~Defective components should be
replaced by Miele original spare parts
only. Only with these parts can Miele
guarantee the safety of the appliance.
~If the power cord is damaged, it
must be replaced by a qualified
electrician with a special power cord
(type H 05 VV-F, PVC-insulated), which
is available from Miele or from
Technical Service.
~Do not connect the electric
barbecue to the power supply by a
power bar or an extension cord, as they
do not ensure the required safety of the
appliance (danger of overheating, for
example).
~If the plug is removed from the
power cord to hardwire the electric
barbecue, it must be installed and
connected by a qualified electrician.
This should be performed by a qualified
electrician in compliance with all local
and national codes, and requirements.
Miele will not be held liable for
damages resulting from improper
installation or connection.
Warning and safety instructions
5

Correct use
~The barbecue is hot during use and
remains so for some time after being
switched off.
Caution: Danger of burns!
~Never leave the barbecue
unattended when cooking with oil or fat.
Overheated fat or oil, grease and food
scraps on the lava rocks can ignite and
spark a fire.
~If hot fat or oil catches fire, NEVER
use water to douse the flames. Use a
pot lid, wet dishtowel, or similar item to
smother the fire.
~Do not use the electric barbecue to
heat rooms, and never turn the
barbecue on when the heating element
is flipped up. The high temperatures
can cause nearby easily flammable
objects to catch fire. In addition, the life
span of the appliance would be
reduced.
~Protect your hands with
heat-resistant oven mitts or potholders
when using the appliance. Use only dry
potholders, make sure they are not
damp or wet, as this causes heat to
transfer through the material more
quickly with the risk of scalding or
burning yourself.
~Do not flambé on the barbecue
under any circumstances. Fire hazard!
~Do not use the barbecue as a
storage surface.
If the barbecue is on or accidentally
turned on or there is residual heat,
metallic objects can heat up and cause
burns.
Other items may melt or catch fire.
Always turn the barbecue off after use!
~Installation of several units
Do not place hot pots or pans on the
spacing strips because they could
damage the seal of the spacing strips.
~Do not cover the barbecue with, for
example, a cover, a cloth or protective
film. If the barbecue is turned on by
mistake or there is residual heat there is
a danger that the material will ignite,
explode or melt.
~NEVER use grilling bowls, grilling
pans, pots and pans or other such
items to grill or warm food, and NEVER
cover the barbecue during operation
(e.g., with aluminum foil). The resulting
build-up of heat can damage the
barbecue.
~NEVER use the barbecue to heat up
closed containers, e.g., canned foods.
The increased pressure can cause the
containers/cans to explode, and this
carries the danger of injury and burns.
~Clean the hot lava rocks on a
regular basis and change them when
needed. Fat-saturated rocks can easily
catch fire.
Warning and safety instructions
6

~The grill basin must always be filled
with water when the barbecue is being
used.
~If you use an electric small
appliance, such as a hand mixer, in the
vicinity of the barbecue, make sure that
the power cord does not come into
contact with the hot barbecue. This
could damage the insulation on the
cord. Danger of electric shock.
~Always cook food thoroughly.
Temperatures must be high enough,
and the cooking times long enough, to
kill any germs in the food.
~If the electric barbecue is built in
behind a panelled door, it should only
be operated with the door open.
Close the door only when the appliance
is shut off and has cooled down.
Miele cannot be held liable for
damage caused by failure to comply
with these safety instructions and
warnings.
Warning and safety instructions
7

aGrates
bHeating element, front
cHeating element, rear
dLava rock container
eDrain valve
fCooking area indicators
gDisplay
Control knobs:
hfront
irear
Display
jOn/Off indicator
Description of the unit
8

Attach the data plate found in the
documents for your appliance in the
locations indicated in "Data Plate."
Clean the appliance
^Clean the water trough and the grill
with a mild solution of warm water
and liquid dish liquid, then dry with a
soft cloth (see "Cleaning and care").
^Wipe the other surfaces down with a
damp cloth and dry.
Heat the appliance
Metal components of the appliance
have a protective coating which may
give off a slight odor the first time the
appliance is heated.
The smell will dissipate after a short
time and does not indicate a faulty
connection or appliance defect.
Before using for the first time
9

Prepare the appliance
You can use the electric barbecue with
or without the lava rocks.
Without the lava rocks: food will stay
more moist, from the rising steam.
With the lava rocks: the food will have a
more pronounced grilled aroma and
flavor.
^Check that the drain valve is closed.
^Remove the grate, raise the heating
element, and remove the lava rock
container (if desired).
^If grilling without lava rocks fill the
water trough with water up to mark
a, with approx. 4.0 liters of water.
If grilling with lava rocks, fill the
water trough with approx. 1.8 liters of
water.
^Return the filled lava rock container
to the water trough (if desired).
^The heating element can now be
turned down.
^Replace the grates.
Turning On/Off
,Do not leave the appliance
unattended while in use.
The electric barbecue is divided into
two heating areas, which can be used
and adjusted separately. For large
quantities, you can use the entire
surface for cooking. For smaller
quantities, you can, for example, cook
in the front and keep food warm at the
back, using a lower setting.
The heating elements can be switched
on and off by turning the appropriate
knob left or right.
When the appliance is switched on, the
On/Off indicator Ncomes on. It goes out
when it is switched off.
Use
10

Grilling
While grilling, watch the level of
water in the trough. If necessary,
add more water.
Do not use aluminum dishes, pans,
pots or foil on the grill. Never cover
the grill grate with aluminum foil.
Aluminum will cause overheating
and may damage the grill grate.
^Turn one or both operating knobs to
power level "12".
Pre-heat the grill with both racks in
place for approx. 10 minutes.
Make sure the operating knob(s) are
set precisely to power level 12.
If the knobs are not set to the exact
position, the heating will not work with
maximum power.
^Set the power level.
^Grill food as desired.
Tips
–To minimize splattering, dry moist
foods with paper towels before
grilling.
–Marinate food before grilling, to
enhance the flavors.
–To prevent sticking non-marinated
items should be brushed lightly with
oil before grilling. Only use oils that
can tolerate high temperatures.
–You can shorten the grilling time for
potatoes in foil and corn on the cob,
by pre-cooking the potatoes for
approx. 15 - 40 minutes (depending
on the size) and the corn for approx.
10 - 15 minutes.
After grilling
^Turn the appliance off.
^After each use, clean the appliance
while it is still somewhat warm to the
touch (see "Cleaning and care").
^After grilling with the lava rocks
check the condition of the rocks. If
they are dark in color, they are
saturated with fat and need to be
cleaned or replaced. See "Cleaning
and Care - Lava rocks".
Use
11

Grilling times
Food item Grilling time
in minutes
Meat and sausage
Boneless steak 8 - 10
Chicken breasts 16 - 18
Cutlets 8 - 12
Filet steak 4 - 10
Hamburgers 12 - 16
Kebabs 14 - 18
Lamb chop 4 - 8
Sausages 6 - 8
Spare Ribs 15 - 20
T-Bone Steak 10 - 20
Turkey cutlet 8 - 10
Fish / seafood
Salmon steak 10 - 12
Shrimp 2 - 4
Trout 12 - 16
Tuna steak 6 - 8
Food item Grilling time
in minutes
Vegetables
Corn (parboiled) 5 - 8
Eggplant 6 - 8
Potatoes in foil
(parboiled)
10-20
Tomato halves 2 - 4
Onions 14 - 16
Pepper strips 2 - 3
Vegetable kebabs 5 - 6
Fruit
Apple slices 2 - 3
Peach halves 2 - 3
Pineapple slices 2 - 3
Other
Toast/bread 2 - 3
Tofu 4 - 6
The times shown in the table serve as
guide only and apply for grilling at
power level 9 -12 on a pre-heated grill.
The grilling time depends on the type,
preparation, and thickness of the food
item.
Use
12

Overheat protection
If there is not enough water in the water
trough, the overheat protection
automatically switches the appliance
off.
^Pour in cold water.
Once the appliance has cooled down
and the heating element switches back
on, you can continue grilling as normal.
Safety cut-out feature
The safety cut-off ensures that the
heating element will only work if it is
lowered.
Safety Feature
13

,Under no circumstances use a
steam cleaner to clean this
appliance. Pressurized steam could
cause permanent damage to the
surface and to components for
which the manufacturer cannot
accept responsibility.
Never use strong cleaners e.g. oven
sprays, stain or rust removers.
Scouring pads and abrasive
cleaning agents should only be
used on the heating element.
Do not use any sharp pointed
objects which could damage the
seal between the ceramic surface
and the surrounding frame, and
between the frame and the
countertop.
When using cleaning agents for
stainless steel always follow the
manufacturer’s instructions on the
packaging.
After cleaning use a soft, dry cloth to
remove any moisture. This way you
will prevent the build up of limescale
deposits.
Stainless steel
Clean stainless steel surfaces with
warm water and liquid dish soap
applied with a non-abrasive sponge
and then wipe dry with a soft cloth.
Soak baked or hardened spills first to
loosen them.
Stainless steel surfaces can be cleaned
using a non-abrasive stainless steel
cleaner.
To help prevent resoiling, a conditioner
for stainless steel can also be used.
Apply sparingly with even pressure.
Do not use stainless steel cleaner on
or around the printing, it may rub
off. Use only a soft sponge with
some dish liquid and warm water to
clean this area.
Grates and lava rock container
After each use, clean the grates and
lava rock container with warm water
and liquid dish soap. Pre-soak any
heavy soiling, then remove with a
brush. Dry throughly.
Do not use stainless steel
conditioner on the lava rock
container.
Heating element
Grill residue can best be removed from
the heating element using a scouring
pad.
Cleaning and care
14

Lava rocks
Clean the lava rocks on a regular basis.
To do so, put the rocks in a container
with mild solution of warm water and
liquid dish soap. Let them soak briefly,
stirring occasionally. Drain water and
rinse rocks. Repeat this process 2 to 3
times with fresh water. Lay the rocks on
a large kitchen towel to dry.
Clean the pumice stones to remove
the used layer. The stones will wear
down depending on how often they
are used.
Once the volume in the pumice
stone container has fallen by half, it
will need to be re-filled.
Water trough
^Let the water cool to a safe
temperature to prevent burns.
^Place a container (large enough to
hold all water in the trough) under the
drain valve.
^Slowly open the drain valve by
turning it counterclockwise,a.
^Once the water has drained, close
the drain valve by turning it
clockwise,buntil the water flow
stops.
^Fill the water trough with a mild
solution of liquid dish soap and warm
water, and rinse it out thoroughly.
Use a bottle brush to clean the drain
^Allow the solution to drain.
^Rinse with warm water and dry.
Do not use stainless steel
conditioner on the water trough.
Make sure that the underside of the
appliance is always accessible for
draining away the water. Remember
to let the water cool down before
draining to prevent burns.
Cleaning and care
15

,Repairs should only be carried out by an authorized technician in
accordance with local and national safety regulations. Unauthorized repairs
could cause injury or appliance damage. The manufacturer cannot be held
responsible for unauthorized work.
What if the appliance does not heat up after it is turned on?
Possible fault Solution
The overheat protection was triggered. See "Overheat protection"
The fuse or breaker was tripped. Contact a qualified electrician or Miele
Technical Service for assistance.
What if the food does not get brown, even though the appliance was
pre-heated for 10 minutes at level 12?
The knob is not exactly set to level 12,
and the appliance is not opretaing at
full power.
Correct the setting.
Frequently asked questions
16

In the event of a fault which you cannot
easily fix yourself, please contact the
Miele Technical Service Department at
the address on the back of this booklet.
When contacting Technical Service
please quote the serial number and
model of the appliance. This
information is visible on the silver data
plate supplied with the appliance.
Adhere the included data plate and make sure the model designation matches up
details on the cover page of this manual.
Technical Service, Data Plate
17

Miele offers a variety of additional accessories for its
appliances including Miele-branded cleaning and
conditioning products.
Some of these products can be easily ordered from the Miele
webshop.
These products are also are available from Miele Customer
Service (see overleaf) and from your Miele dealer.
Griddle CSGP 1400
Cast grill plate,
with one smooth side and one ridged side, for CS 1322
Wire rack for grill plate CSGP1400
Handle
Lava rocks
Optional accessories
18

Installation Instructions
IMPORTANT: SAVE FOR THE LOCAL ELECTRICAL INSPECTOR'S USE
To prevent accidents
and machine damage
read these instructions
before
installation or use.

To avoid damage to the appliance, it
should not be installed until the
upper cabinet and exhaust hood
have already been mounted.
~The countertop veneers must be
affixed with heat-resistant glue (100°C),
so that they do not become deformed
or detached.
The backsplash must be heat-resistant
as well.
~This electric barbecue grill is not to
be used in mobile installations such as
ships.
~The CS 1312 (barbecue) and
CS 1322 (barbecue) must not be
installed directly next to the CS 1421
(salamander). It is essential to maintain
a distance of at least 150 mm between
an electric barbecue and a salamander
grill.
~It is essential to ensure that the
network power cable will not be
subjected to any mechanical strain
after installation, e.g., while the water is
draining.
~Also be sure that the power cord will
not come into contact with any hot
spots on the appliance after installation.
Otherwise, the cord could suffer heat
damage.
~Make sure to carefully observe the
clearance distances listed on the
following pages.
~Never use joint sealant unless it is
explicitly called for in the instructions.
The seal underneath the appliance
provides sufficient seal with the counter
top.
Safety instructions for installation
20
