Miele KM 411 User guide

NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010802
Product and Cut-out Dimensions
Modular Combiset Program
Electric Barbeque
KM411
1 1/2" min.
19 11/16"
2 3/16"
10 13/16"
6"
20 1/4"
11 3/8"
E
23 5/8" min
Notes
E - 5 foot - 208-240 Volt - 15 Amp 3-wire
power supply connects rear right
bottom.
Location Codes
• All installations must be done in
accordance with local codes.
• Unit height includes 2" for drain valve.
• Recommend 13" space below drain valve
for cleaning unit.
