NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 020204
Product Dimensions
Decorator Wall Hood
DA211
110 Volt - 15 Amp 3-wire power
supply connects through top or rear of
chimney.
Standard 110 Volt Oultlet
42"
19 11/16"
27 15/16" - 37 3/16"
See Notes
9 7/8"
Notes
• All installations must be done in
accordance with local codes.
• Recirculation: 31 1/2" - 40 3/4"
• 6" duct connects to blower system inside
chimney.
Location Codes
E -
O -
E
9 1/16"
11 7/16"
9 7/8"
Front Perspective
O

NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 020204
Front Perspective
Notes
• Center unit over cooking surface
• Distance "S" is determined by the cooking
surface. Minimum distance "S" is:
- 18" for electric surfaces
- 26" for gas surfaces
• Area behind mounting plates MUST be
reinforced using a minimum of 1/2"
plywood. Reinforcing material should be
affixed to structural wall members
Mounting plate "B"
Installation Dimensions
Decorator Wall Hoods
DA211
Mounting plate "C"
Mounting plate "A"
Ceiling Line
14 3/8"
Center Line
S + 4"
Area must be reinforced
with a minimum of
1/2" plywood backing
Structural member
