Miele PWM 908 User manual

Operating and installation Instructions
Washing machine
To avoid the risk of accidents or damage to the appliance, it is essential
to read these instructions before it is installed and used for the first time.
en-AU, NZ M.-Nr. 11 213 030

Contents
2
Caring for the environment .................................................................................. 6
Warning and Safety instructions.......................................................................... 7
Operating the washing machine ........................................................................ 15
Control panel......................................................................................................... 15
Sensor controls and touch display with sensor controls ...................................... 16
Main menu............................................................................................................. 16
Examples on how to operate the appliance.......................................................... 17
Operating the laundrette version........................................................................... 19
Using for the first time ........................................................................................ 20
Reference to external appliances.......................................................................... 21
Setting the brightness of the display..................................................................... 21
Setting the date..................................................................................................... 21
Selecting programme packages ........................................................................... 22
1. Preparing the laundry...................................................................................... 25
2. Loading the washing machine ....................................................................... 26
3. Selecting a programme .................................................................................. 27
4. Selecting programme settings....................................................................... 28
5. Adding detergent............................................................................................. 29
Adding fabric softener or liquid starch separately............................................ 30
Adding starch separately.................................................................................. 30
6. Starting the programme - the end of the programme ................................. 33
Timer..................................................................................................................... 34
Programme chart ................................................................................................ 35
Extra options........................................................................................................ 51
Pre-wash......................................................................................................... 51
Pre-rinse.......................................................................................................... 51
Rinse plus....................................................................................................... 51
Soak................................................................................................................ 51
Intensive........................................................................................................... 51
Water plus ....................................................................................................... 51
Pre-ironing ........................................................................................................ 51
Rinse hold....................................................................................................... 51
Starch stop...................................................................................................... 51

Contents
3
Special features in the programme sequence.................................................. 52
Spinning ................................................................................................................ 52
Anti-crease ............................................................................................................ 52
Changing the programme sequence................................................................. 53
Changing a programme......................................................................................... 53
Cancelling a programme ....................................................................................... 53
Switching on the washing machine after an interruption to the power supply ..... 53
Adding or removing laundry .................................................................................. 54
Cleaning and care ............................................................................................... 55
Cleaning the external casing and fascia panel...................................................... 55
Cleaning the detergent dispenser drawer ............................................................. 55
Cleaning the drum, suds container and drainage system..................................... 57
Cleaning the filters in the water inlet ..................................................................... 57
Problem solving guide ........................................................................................ 59
The programme does not start.............................................................................. 59
Programme cancellations and fault messages ..................................................... 60
A fault message appears in the display ................................................................ 61
An unsatisfactory wash result ............................................................................... 62
General problems with the washing machine ....................................................... 63
The door will not open........................................................................................... 65
Opening the door in the event of a blocked drain outlet and/or power cut .......... 66
After sales service............................................................................................... 69
Contact in case of fault ......................................................................................... 69
Optional accessories............................................................................................. 69
Installation............................................................................................................ 70
Front view.............................................................................................................. 70
Rear view............................................................................................................... 71
Installation locations.............................................................................................. 72
Installation notes ................................................................................................... 72
Transporting the washing machine to its installation site...................................... 73
Installation surface ................................................................................................ 74
Removing the transit bars ..................................................................................... 74
Refitting the transit bars ........................................................................................ 76
Aligning the washing machine............................................................................... 76
Securing the washing machine against slippage............................................. 77
External control equipment ................................................................................... 77
Payment system............................................................................................... 77

Contents
4
Water connection .................................................................................................. 78
Cold water connection .................................................................................... 78
Hot water connection*...................................................................................... 79
Drainage ................................................................................................................ 80
Drain valve........................................................................................................ 80
Drain pump....................................................................................................... 80
Electrical connection ............................................................................................. 81
Technical data...................................................................................................... 82
Supervisor level ................................................................................................... 83
Opening the Supervisor level ................................................................................ 83
Code-based access .............................................................................................. 83
Changing the code................................................................................................ 83
Closing the settings menu..................................................................................... 83
Operation/display .................................................................................................. 84
Language.......................................................................................................... 84
Language menu................................................................................................ 84
Set languages................................................................................................... 84
Display brightness............................................................................................ 84
Time.................................................................................................................. 85
Date .................................................................................................................. 85
Volume.............................................................................................................. 85
Visibility parameters ......................................................................................... 85
"Display" off status........................................................................................... 86
"Machine" off status......................................................................................... 86
Delay start ........................................................................................................ 86
Memory ............................................................................................................ 86
Temperature unit............................................................................................... 87
Weight unit ....................................................................................................... 87
Logo ................................................................................................................. 87
Change code.................................................................................................... 87
Programme selection ............................................................................................ 87
Controls............................................................................................................ 87
Programme packages ...................................................................................... 88
Favourite programmes ..................................................................................... 88
Special programmes ........................................................................................ 89
Sort programmes ............................................................................................. 89
Prog. colour allocation ..................................................................................... 89
Hygiene ............................................................................................................ 89
Disinfection prog. code .................................................................................... 89

Contents
5
Process technology............................................................................................... 90
Anti-crease ....................................................................................................... 90
Water level Cottons .......................................................................................... 90
Water level Minimum iron ................................................................................. 90
Pre-wash temp. Cottons .................................................................................. 90
Wash time......................................................................................................... 90
Pre-rinse Cottons ............................................................................................. 91
Pre-rinse Minimum iron .................................................................................... 91
Pre-wash Cotton/M.iron ................................................................................... 91
Cottons rinses .................................................................................................. 91
Minimum iron rinses ......................................................................................... 91
Disinfection rinse.............................................................................................. 91
Auto load control .............................................................................................. 91
Controlled energy cons. ................................................................................... 92
Service................................................................................................................... 92
Clean drain pump............................................................................................. 92
Service interval ................................................................................................. 92
External applications ............................................................................................. 93
Empty sensor ................................................................................................... 93
Early warning counter....................................................................................... 93
Peak load signal ............................................................................................... 93
Peak load prevention........................................................................................ 93
COM module selection..................................................................................... 94
Wi-Fi ................................................................................................................. 94
Network time .................................................................................................... 94
Remote............................................................................................................. 95
RemoteUpdate ................................................................................................. 95
SmartGrid ......................................................................................................... 96
Machine parameters.............................................................................................. 96
Suds cooling..................................................................................................... 96
Water intake ..................................................................................................... 96
Low water pressure .......................................................................................... 97
Automatic dispensing....................................................................................... 97
CapDosing........................................................................................................ 98
Legal information.............................................................................................. 98
Payment system.................................................................................................... 99
Settings for payment systems.......................................................................... 99
F-back signal to pay system ............................................................................ 99
Clear paid signal............................................................................................... 99
Payment system lock ..................................................................................... 100
FOC programmes........................................................................................... 100

Caring for the environment
6
Disposal of the packing
material
The transport and protective packaging
has been selected from materials which
are environmentally friendly for
disposal, and can normally be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain specific materials,
compounds and components, which
were essential for their correct function
and safety. These could be hazardous
to human health and to the environment
if disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre for electrical and electronic
appliances. You are also responsible for
deleting any personal data that may be
stored on the appliance prior to
disposal. Please ensure that your old
appliance poses no risk to children
while being stored prior to disposal.

Warning and Safety instructions
7
This washing machine complies with all current local and national
safety requirements. However, inappropriate use can lead to
personal injury and damage to property.
Read the operating instructions carefully before using the washing
machine. They contain important information on safety,
installation, use and maintenance of the appliance. This prevents
both personal injury and damage to the washing machine.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in
“Installation”, as well as in the “Warning and Safety instructions”.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these operating instructions in a safe place and pass them
on to any future owner.
When instructing other people how to use the washing machine,
they must be made aware of these Warning and Safety
instructions.
Correct application
 The washing machine is only suitable for washing fabrics with a
care label stating that they are suitable for machine washing. Any
other applications may be dangerous. The manufacturer cannot be
held liable for damage resulting from incorrect or improper use or
operation of the machine.
 This washing machine must be used as described in the operating
instructions and must be checked on a regular basis to make sure it
is functioning correctly. Maintenance must be carried out when
necessary.
 The washing machine is not suitable for outdoor use.

Warning and Safety instructions
8
 This washing machine is intended for commercial use in small
businesses, care homes, sports clubs, hospitals and other similar
commercial environments. This machine may also be operated by
lay persons in public areas such as laundrettes, communal laundry
rooms or similar.
 This washing machine is not intended for use by persons
(including children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning its use by a person
responsible for their safety.
 Young children must not be allowed to use this appliance.
 Older children may only use the appliance when its operation has
been clearly explained to them and they are able to use it safely.
They must be able to understand and recognise the possible
dangers caused by incorrect operation.
 Cleaning or maintenance on the washing machine may only be
carried out by older children under the supervision of an adult.
 Always supervise any children in the vicinity of the washing
machine. Never allow children to play with the washing machine.
 Disinfection programmes must not be interrupted, as this can
have a limiting effect on the disinfection result. It is the operator's
responsibility to ensure that the standard of disinfection in thermal as
well as chemo-thermal procedures is maintained by carrying out
suitable validation tests.

Warning and Safety instructions
9
Technical safety
 Before installing and operating the washing machine, check it for
any visible exterior damage. Do not set up or use a damaged
washing machine.
 The electrical safety of this washing machine can only be
guaranteed when continuity is complete between it and an effective
earthing system which complies with current local and national
safety regulations.
It is most important that this basic safety requirement is present and
regularly tested and, when there is any doubt, the on-site wiring
system should be inspected by a qualified electrician.
Miele cannot be held liable for the consequences of an inadequate
earthing system (e.g. electric shock).
 Unauthorised repairs could result in unforeseen dangers for the
user, for which the manufacturer cannot accept liability. Repairs
must only be carried out by a Miele authorised service technician,
otherwise any subsequent damage will not be covered by the
warranty.
 Do not make any alterations to the machine, unless authorised to
do so by Miele.
 In the event of a fault or for cleaning purposes, the washing
machine must be isolated from the electricity supply. It is only
completely isolated if:
– it is switched off at the wall socket and the plug is withdrawn, or
– the mains fuse is disconnected, or
– it is switched off at the mains circuit breaker.
For further information see “Installation - Electrical connection”.

Warning and Safety instructions
10
 If the electrical connection cable is faulty, it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
 The washing machine must be connected to the water supply
using the new hose set supplied with the appliance. Old hose sets
should not be re-used. Check the hose regularly for signs of wear.
Replace it in good time to avoid the risk of leaks and water damage.
 Faulty components must only be replaced by genuine Miele
original spare parts. Miele can only guarantee the safety standards of
the machine when Miele replacement parts are used.
 Do not connect the machine to the mains electricity supply by a
multi-socket adapter, extension lead or similar. These do not
guarantee the required safety of the machine (fire hazard due to the
risk of overheating).
 The machine must not be installed and operated in mobile
locations (e.g. on a ship).
 Please observe the instructions in “Installation” and “Technical
data”.
 If the washing machine is equipped with a mains plug, it must be
easily accessible after installation so that the machine can be
disconnected from the electricity supply if necessary.

Warning and Safety instructions
11
 If the appliance is hard wired, an on-site dual circuit breaker must
be accessible at all times in order to disconnect the washing
machine from the mains supply. The means of disconnection must
be incorporated in the fixed wiring in accordance with the wiring
rules.
 This washing machine is supplied with a special lamp to cope
with particular conditions (e.g. temperature, moisture, chemical
resistance, abrasion resistance, and vibration). This special lamp
must only be used for the purpose for which it is intended. It is not
suitable for room lighting. Replacement lamps may only be installed
by a Miele authorised technician or by Miele.
 Reliable and safe operation of this washing machine is only
ensured if it has been connected to the mains electricity supply.
Correct use
 The maximum load is 8.0kg (dry laundry). See the “Programme
chart” for the maximum recommended loads for individual
programmes.
 Do not install your washing machine in a room where there is a
risk of frost. Frozen hoses may burst or split, and the reliability of the
electronic control unit may be impaired at temperatures below
freezing point.
 Before using the machine for the first time, check that the transit
bars at the rear of the washing machine have been removed (see
“Installation and connection – Removing the transit bars”). During
spinning, transit bars which are still in place can cause damage to
both the machine and adjacent furniture or appliances.
 Turn off the tap if the machine is to be left for any length of time
(e.g. while on holiday), especially if there is no floor drain (gully) in the
immediate vicinity.

Warning and Safety instructions
12
 If the ventilation openings are in the base of the washing
machine, ensure that they are not obstructed by deep-pile carpet or
similar.
 Danger of flooding! If hooking the drain hose into a wash basin,
check that the water can drain away fast enough to prevent the sink
from overflowing. Secure the drain hose against slipping. The force
of the water flowing out of the hose can dislodge it.
 Make sure that no foreign objects (e.g. nails, pins, coins, paper
clips) find their way into the machine with the laundry. Foreign
objects can damage components of the machine (e.g. suds
container, drum). Damaged components can, in turn, result in
damage to the laundry.
 If the correct amount of detergent is dispensed, the machine
should not need to be descaled. If, however, you do wish to descale
it, only use special non-corrosive descaling agents and strictly
observe the instructions on the packaging. Special descaling agent
is available from your Miele dealer or from Miele. Strictly observe the
instructions for the packaging.
 For textiles that have been treated with solvent-based cleaning
agents, always check whether they can be washed in a washing
machine. To check whether this is possible, refer to safety notes,
information concerning the product's environmental compatibility,
and other information.
 Never use solvent-based detergents, e.g. those containing
benzine, in this washing machine. This may result in damage to
component parts and create toxic fumes. Risk of fire and explosion!
 Gasoline, petroleum, kerosene, paraffin, or any easily flammable
liquid must not be stored or used near the washing machine. Risk of
fire and explosion!

Warning and Safety instructions
13
 Only use dyes suitable for use in a washing machine. Always
observe the manufacturer's instructions carefully.
 Dye removers contain sulphur compounds which can cause
damage such as corrosion. Dye removers must not be used in the
washing machine.
 Avoid contact between stainless steel surfaces (front, lid, casing)
and liquid detergents or disinfecting agents which contain chlorine or
sodium hypochlorite. These agents can cause corrosion on stainless
steel. Aggressive vapours containing chlorine can also be corrosive.
Do not store open containers of these agents near the machine.
 Do not use a high-pressure cleaner or water jet to clean the
washing machine.
 It is particularly important to observe the manufacturer's
instructions when using a combination of cleaning agents and
special application products. Products must only be used for
applications approved by the manufacturer to avoid any material
damage or the occurrence of strong chemical reactions.
 If detergent has come into contact with the eyes, rinse out
immediately with plenty of lukewarm water. If detergent has
accidentally been ingested, seek medical advice immediately. People
with damaged or sensitive skin should avoid contact with detergent.
 When adding or removing laundry during the main wash, your skin
may come into contact with detergent, particularly if the detergent is
dispensed externally. Take care when placing your hands inside the
drum. If suds have come into contact with the skin, rinse off
immediately with lukewarm water.

Warning and Safety instructions
14
Accessories
 Only use genuine Miele spare parts and accessories with this
machine. Using spare parts or accessories from other manufacturers
will invalidate the warranty, and Miele cannot accept liability.
 Miele tumble dryers and Miele washing machines can be installed
as a washer-dryer stack. This requires a Miele washer-dryer stacking
kit which can be purchased separately. Please ensure that the
washer-dryer stacking kit is suitable for your Miele tumble dryer and
your Miele washing machine.
 If installing the machine on a Miele plinth (available as an optional
accessory), please make sure you order the correct one for this
washing machine.
Miele cannot be held liable for damage caused by non-compliance
with these Warning and Safety instructions.

Operating the washing machine
15
Control panel
aLanguage  sensor control
For selecting the current user
language.
The operator language is displayed
again at the end of the programme.
bBack  sensor control
Takes you back one level in the
menu.
cTouch display
dStart/Stop sensor control
For starting the selected programme
and cancelling a programme that has
already started. The programme
selected can be started as soon as
the sensor starts flashing.
eOptical interface
For service technicians.
fButton
For switching the washing machine
on and off. To save energy, the
washing machine will switch off
automatically. This occurs 15 minutes
after the end of a programme/anti-
crease phase, or after being switched
on if no further selection is made.

Operating the washing machine
16
Sensor controls and touch
display with sensor controls
The, andStart/Stopsensor
controls and the sensor controls in the
display react to finger contact. Every
touch of a sensor is confirmed by an
audible tone. You can adjust the volume
of the keypad tone or switch it off (see
“Supervisor level”).
The control panel with the sensor
controls and the touch display can
be scratched by pointed or sharp
objects, e.g. pens.
Only touch the display with your
fingers.
Main menu
After switching on the washing
machine, the main menu will appear in
the display.
You can access all important submenus
from the main menu.
Touch the  sensor at any time to
return to the main menu. Values that
have not yet been confirmed with the
OK sensor are not saved when you
return to the main menu.
 11:02
  
Programmes Favourites Supervisor
Help
 Programmes
For selecting wash programmes.
Favourites
For selecting one of 12 favourite wash
programmes which can be set up and
saved by the operator (see “Supervisor
level - Favourite programmes”).
 Supervisor
At the Supervisor level you can alter the
washing machine's electronics to suit
changing requirements (see “Supervisor
level”).

Operating the washing machine
17
Examples on how to operate
the appliance
Selection lists
Programme menu (single selection list)
 11:02
White items Minimum iron Express
Coloured
items Delicates Woollens
Programmes
You can scroll to the right or the left by
swiping your finger across the screen.
To do this, place your finger on the
touch display and swipe it in the
direction you want.
The orange bar under the pictures
shows that there are further options to
choose from.
Touch a programme name to select a
wash programme.
The display will change to the standard
display for that programme.
Extras menu (multiple selection)
 11:02
Pre-wash
Soak
Rinse plus
Intensive




Extras
OK
Touch one or several Extras to select
them.
Currently selected Extras are marked
orange.
To deselect an Extra, simply touch the
Extra again.
Use the OK sensor to activate the
selected Extras.
Setting numerical values
You can set numerical values in some
menus.
OK
12 00
10 58
14 02
Time


11 59
13 01
Enter the numbers by swiping upwards
or downwards. Place your finger on the
number that you want to change and
move your finger in the desired
direction. Use the OK sensor to accept
the set numerical value.
Useful tip: With some settings, a value
can also be entered using a numerical
keypad.

Operating the washing machine
18
OK
Time

12 00
11 59
10 58
13 01
14 02
Briefly touching the number between
the two lines will bring up the numerical
keypad.
OK
12:00
3
4
21
Time

5 6
7

8
0
9
Once a valid number has been entered,
the OK sensor will be highlighted green.
Pull-down menu
The pull-down menu can be used to
display information, e.g. about a wash
programme.
 11:02

Coloured
items
Status
Time left h2:27

Main wash
Add laundry


If an orange bar appears at the top of
the screen in the middle of the display,
you can open the pull-down menu.
Touch the bar and drag it down with
your finger on the display.
Exiting a menu
Touch the sensor to return to the
previous screen.
Entries you have made before this
which have not yet been confirmed
withOK will not be saved.
Help display
With some menus Help appears in the
bottom line of the display.
Touch the Helpsensor to display the
text.
Touch the Closesensor to return to
the previous screen.

Operating the washing machine
19
Operating the laundrette
version
The entry menu will vary depending on
the programming status (see
“Supervisor level - Controls”).
Shortcuts are the easiest way to
operate the machine. Operators cannot
change the preset programmes.
Laundrette basic (4 programmes)
 11:02




Coloured
items
Woollens Delicates
Minimum iron
Help
4 preset programmes are available.
These cannot be changed by the
operator.
Laundrette extended (12
programmes)
 11:02
 
Coloured
items WoollensMinimum iron
Help Further

Up to 12 preset programmes are
available. The first three programmes
can be selected directly. The remaining
programmes are selected via another
list. These cannot be changed by the
operator.

Using for the first time
20
Damage resulting from incorrect
installation and connection.
Installing and connecting the
washing machine incorrectly will
cause serious damage to property.
Please observe the instructions in
“Installation and connection”.
Emptying the drum
A swivel elbow for the drain hose and/
or assembly material may be stored in
the drum.
Pull open the door.
Remove the swivel elbow and
assembly material.
Shut the door with a gentle swing.
Switching on the washing
machine
Press the  button.
The welcome screen will light up.
When commissioning the washing
machine for the first time, you will
have to define the settings for the
daily use of the appliance. Some
settings can only be configured
during the initial commissioning
process. After that, they must be
changed by Miele.
Complete the initial commissioning
process.
These settings are also described in
“Supervisor level”.
Setting the display language
You will be asked to select the language
for the display. You can change the
language at any time (see “Supervisor
level - Language”).
deutsch
Language
OK
english
(AU)
english
(CA)
english
(GB)
english (US)
español
Scroll to the left or the right until the
language you want appears.
Touch the sensor for the required
language.
The selected language will be
highlighted in orange and the display
will change to the next setting.
