Miele TDB120WP User manual

Operating Instructions
Heat-pump Dryer
It is essential to read these operating instructions before installing,
starting up, and using the appliance. This prevents both personal injury
and damage to the appliance.
en-US M.-Nr. 10 974 050

Contents
2
Caring for the environment ................................................................................. 5
IMPORTANT SAFETY INSTRUCTIONS ................................................................ 6
Operating the tumble dryer ................................................................................ 14
Control panel......................................................................................................... 14
How the display works .......................................................................................... 15
Energy saving tips ............................................................................................... 17
Functioning of the heat-pump dryer.................................................................. 18
Initial set-up ......................................................................................................... 19
Removing the protective film and stickers ........................................................... 19
1. Notes on correct laundry care ....................................................................... 20
Points to note regarding washed laundry.............................................................. 20
Preparing the laundry before drying...................................................................... 20
Drying .................................................................................................................... 21
Understanding the care label symbols............................................................. 21
Selecting the correct drying level..................................................................... 21
2. Loading the tumble dryer ............................................................................... 22
Loading the laundry............................................................................................... 22
3. Selecting a program and starting it ............................................................... 23
Selecting a program .............................................................................................. 23
Selecting drying levels during drying level programs....................................... 23
Time-controlled and other programs................................................................ 24
Selecting Gentle .................................................................................................... 24
Selecting Delay Start............................................................................................. 25
4. Removing the laundry at the end of the program ........................................ 27
End of program/Anti-crease .................................................................................. 27
Removing the laundry ........................................................................................... 27
Program chart...................................................................................................... 28
Changing the program sequence ...................................................................... 31
Condensed water container ............................................................................... 33
Emptying the condensed water container ............................................................ 33

Contents
3
Fragrance flacon.................................................................................................. 34
Using the fragrance flacon .................................................................................... 34
Removing the protective seal from the fragrance flacon.................................. 34
Inserting the fragrance flacon........................................................................... 35
Opening the fragrance flacon................................................................................ 36
Closing the fragrance flacon ................................................................................. 36
Removing/replacing the fragrance flacon ............................................................. 37
Cleaning and care ............................................................................................... 38
Lint filters............................................................................................................... 38
Removing the fragrance flacon ........................................................................ 38
Removing visible lint......................................................................................... 38
Cleaning the lint filters and air flow openings thoroughly ................................ 39
Cleaning the lint filters with water .................................................................... 40
Cleaning instructions when using fabric softener sheets................................. 41
Cleaning the plinth filter......................................................................................... 42
Removing the plinth filter ................................................................................. 42
Cleaning the plinth filter.................................................................................... 43
Cleaning the plinth filter flap............................................................................. 43
Checking the heat exchanger unit.................................................................... 44
Inserting the plinth filter.................................................................................... 44
Cleaning the dryer ................................................................................................. 45
Frequently Asked Questions .............................................................................. 46
Indicator lights or information on the time display ................................................ 46
Unsatisfactory drying results................................................................................. 48
The drying cycle duration is very long................................................................... 49
Other problems ..................................................................................................... 50
Technical Service................................................................................................. 51
Contact in case of fault ......................................................................................... 51
Warranty ................................................................................................................ 51
Optional accessories............................................................................................. 51
IMPORTANT SAFETY INSTRUCTIONS .............................................................. 53
Installation............................................................................................................ 55
Front view .............................................................................................................. 55
Rear view............................................................................................................... 56
Transporting the tumble dryer ............................................................................... 56
Transporting the tumble dryer to its installation site ........................................ 56

Contents
4
Installation ............................................................................................................. 57
Leveling the tumble dryer................................................................................. 57
Ventilation......................................................................................................... 57
Before moving the tumble dryer again ............................................................. 57
Additional installation requirements ...................................................................... 58
Product dimensions .............................................................................................. 60
Dimensions....................................................................................................... 60
Installation on a plinth ...................................................................................... 60
Washer-dryer stack .......................................................................................... 60
Electrical connection ............................................................................................. 61
Connection adapter for NEMA 14-30 socket................................................... 61
External draining of condensed water................................................................... 62
Arranging the drain hose .................................................................................. 62
Condensate drain ............................................................................................. 62
Changing the door hinging.................................................................................... 63
Changing the hinging over ............................................................................... 63
Refitting ............................................................................................................ 68
Technical data...................................................................................................... 69
Programmable functions .................................................................................... 70
Programming......................................................................................................... 70
 Drying levels “Normal” .................................................................................... 72
 Drying levels “Wrinkle-free”............................................................................ 72
 Buzzer volume................................................................................................ 72
 Keypad tone................................................................................................... 72
 Code............................................................................................................... 73
 Conductivity ................................................................................................... 73
 Display switch-off status .................................................................................. 74
 Appliance switch-off........................................................................................ 74
 Memory............................................................................................................ 75
 Anti-crease ...................................................................................................... 75
 Buzzer on......................................................................................................... 75
 Airway indicator.............................................................................................. 76
 Display brightness dimmed ............................................................................ 76

Caring for the environment
5
Disposal of the packing
material
The cardboard box and packing
materials protect the appliance during
shipping. They have been designed to
be biodegradable and recyclable.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of children.
Danger of suffocation!
Disposal of your old appliance
Electrical and electronic appliances
contain valuable materials. They also
contain certain substances, compounds
and components which were essential
for the proper functioning and safe use
of the equipment. Handling these
materials improperly by disposing of
them in your household waste can be
harmful to your health and the
environment. Therefore, please do not
dispose of your old appliance with
regular household waste and follow
local regulations on proper disposal.
Consult with local authorities, dealers or
Miele in order to dispose of and recycle
electrical and electronic appliances.
Miele assumes no responsibility for
deleting any personal data left on the
appliance being disposed. Please
ensure that your old appliance is kept
away from children until removal.
Observe safety requirements for
appliances that may tip over or pose an
entrapment hazard.

IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, or injury to persons when
using your appliance, follow basic precautions, including the
following:
WARNING
This tumble dryer is intended for use in domestic households and
similar working and residential environments.
 It is essential to read all instructions before using the appliance.
 Do not allow children to play on or in the appliance. Close
supervision is necessary when the appliance is used near children.
Always close the door after use to prevent child hazards.
 Before this appliance is removed for service or discarded, remove
the door to the drying compartment.
 Do not install or use a dryer with visible damage.
 Do not reach into the dryer if the drum is moving.
 Do not install or store this appliance where it will be exposed to
the weather.
 Do not tamper with the controls.
 Do not repair or replace any part of the appliance or attempt any
servicing unless specifically recommended in these operating
instructions. Repairs to electrical appliances should only be
performed by qualified personnel. Incorrectly repaired machines may
pose a considerable risk to the user.
6

IMPORTANT SAFETY INSTRUCTIONS
 Important information regarding use of fabric softener sheets:
We do not recommend use of fabric softener sheets. Use of fabric
softener sheets can clog the surfaces of the lint filters, extending the
drying time and increasing energy consumption. During subsequent
cleaning, the plastic and surfaces of the lint filters can be damaged!
The best results are obtained by using liquid fabric softener in the
washing machine. Follow the manufacturer's instructions.
If you still wish to use fabric softener sheets, be sure to follow the
cleaning instructions under “Cleaning and care” in the “Cleaning
instructions when using fabric softener sheets” section.
Tip:
Using a fragrance flacon (optional accessory) will add a pleasant
fragrance to your laundry.
When a fragrance flacon is used, the fragrance is acquired by the
entire load of laundry. The disadvantage of fabric softener sheets is
that under certain circumstances the fragrance is acquired by only a
few items of laundry, especially when drying a full load.
When you use a fragrance flacon, always follow the warnings
in this section as well as those under “Fragrance flacon”.
7

IMPORTANT SAFETY INSTRUCTIONS
 To prevent the risk of fire, the following textiles must not be dried
in this dryer:
– items which have not been washed.
– items, such as work-wear, exposed to grease, oils, or other
deposits (such as lotions or cosmetics) in your dryer. If these
items have not been thoroughly cleaned there is a danger that
they may contribute to a chemical reaction that could cause the
laundry to ignite when heated even after being removed from the
dryer.
– items that have been previously cleaned, washed, soaked or
spotted with gasoline, dry-cleaning solvents or other flammable
or explosive substances. They may give off vapors that could
ignite or explode.
– items treated with flammable cleaning agents or items containing
acetone, alcohol, petrol, stain remover, wax or chemicals from
buffing, etc.
– items which have been splashed with hair spray, nail polish
remover, etc.
When washing heavily soiled items ensure that sufficient
detergent is used with a high temperature. If in doubt wash the
item several times.
– items containing foam rubber or similarly textured rubber-like
materials.
– items with padding or filling (e.g. pillows or jackets) which have
been damaged. Loose filling could catch fire.
8

IMPORTANT SAFETY INSTRUCTIONS
 Allow the dryer to complete each stage of the program selected,
including the cooling down phase. This will ensure that the items
being removed are not too hot to handle.
 Clean the lint filter before or after each load.
 Keep the area around the air intake (toe kick) and adjacent
surrounding areas free from lint, dust and dirt.
 The interior of the machine should be cleaned periodically by
qualified personnel.
 GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of malfunction or
breakdown, grounding will reduce the risk of electric shock by
providing a path of least resistance for electric current. This
appliance is equipped with a cord having an equipment grounding
conductor and a grounding plug. The plug must be plugged into an
appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
 WARNING – Improper connection of the equipment-grounding
conductor can result in a risk of electric shock. Contact a qualified
electrician if you are in doubt as to whether the appliance is properly
grounded.
9

IMPORTANT SAFETY INSTRUCTIONS
 Do not modify the plug provided with the appliance: if it will not fit
the outlet, have a proper outlet installed by a qualified electrician.
 Before installation, disconnect the tumble dryer from the electrical
supply by shutting off the power main, unplugging the power cord or
tripping the circuit breaker. Do not restore power until the installation
is complete.
 Miele tumble dryers and Miele washing machines can be installed
as a washer-dryer stack. A Miele washer-dryer connection kit is
required as an optional accessory for this. Please ensure that the
washer-dryer connection kit is suitable for the Miele tumble dryer
and the Miele washing machine.
 If you order a plinth for this tumble dryer (available from Miele as
an optional accessory), make sure it is the correct one.
 The maximum dry laundry weight is 17.6 lbs (8.0kg).
See the “Program chart” for the maximum recommended loads for
individual programs.
 Do not place shoes inside the drum for drying. Placing shoes
inside the drum for drying can cause the belt to tear, requiring a
service call.
You must always use the dryer basket (optional accessory) when
drying/airing shoes. Follow the additional operating instructions for
the dryer basket.
 This tumble dryer is supplied with a special lamp to cope with
particular conditions (e.g., temperature, moisture, chemical
resistance, abrasion resistance, and vibration). This special lamp
must only be used for the purpose for which it is intended. It is not
suitable for room lighting. Replacement lamps may only be fitted by
a Miele authorized person or by Miele Technical Service.
10

IMPORTANT SAFETY INSTRUCTIONS
 Heat-pump technology and refrigerant:
The heat pump in this tumble dryer uses a gaseous refrigerant which
is condensed by the compressor. The refrigerant, which is brought to
a higher temperature level and liquified by condensing, is led in a
closed circuit through the heat exchanger unit where heat exchange
with the circulating drying air takes place.
– The humming noises caused by the heat pump during the drying
process are normal. This does not impair the efficient functioning
of the dryer.
– The refrigerant is not flammable or explosive.
– This tumble dryer contains fluorinated greenhouse gases.
Hermetically sealed.
Designation of refrigerant: R134a
Amount of refrigerant: 16.6 oz (0.47) kg
Global warming potential of refrigerant: 1430 kg CO2 e
Global warming potential of appliance: 672 kg CO2 e
 This product may contain chemicals known to the state of
California to cause cancer or birth defects or other reproductive
harm.
11

IMPORTANT SAFETY INSTRUCTIONS
Using a fragrance flacon (optional accessory)
 Only use genuine Miele original fragrance flacons.
 Store the fragrance flacon in its original packaging.
 Caution: The fragrance can leak out of the flacon! Make sure that
you always keep the flacon, or the lint filter with the flacon inserted in
it, in a horizontal position when carrying and do not tip or place it
down on any surface.
 Use an absorbent cloth to wipe up any fragrance which has
leaked out of the flacon onto the floor, the dryer or any dryer
components (e.g. the lint filter) immediately.
 If fragrance comes in contact with the body: Wash skin
thoroughly with soap and water. Flush eyes with clean water for at
least 15minutes. If swallowed, rinse mouth thoroughly with clean
water. Seek medical attention if the fragrance comes in contact with
the eyes or is swallowed!
 Immediately change clothes that have come in contact with the
fragrance. Thoroughly wash clothing or fabric using a large amount
of water and detergent.
 There is the risk of fire or damage to the tumble dryer if the
following instructions are not observed:
– Never refill a flacon with fragrance or any other substance.
– Never use a faulty fragrance flacon.
 Dispose of an empty fragrance flacon with the household waste
and never use it for any other purpose.
 Please also observe the information supplied with the fragrance
flacon.
12

IMPORTANT SAFETY INSTRUCTIONS
FCC Declaration of Conformity
 This appliance complies with Part 15 of the FCC regulations. This
appliance has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules and is
subject to the following conditions: This appliance does not cause
harmful interference. The appliances may be interconnected as
desired.
FCC Radiation Exposure Statement
 This appliance complies with FCC RF radiation exposure limits set
forth for an uncontrolled environment. These appliances should be
installed and operated with a minimum distance of 8" (20cm)
between the radiator and body.
Industry Canada Statement
 This digital device does not exceed the Class B limits for radio
noise emissions from digital devices specified in the radio
regulations of the Canadian Radio-television and
Telecommunications Commission. This appliance complies with the
Class B specification of the Canadian ICES-003.
SAVE THESE INSTRUCTIONS
13

Operating the tumble dryer
Control panel
aDisplay
bSensor buttons for the drying
levels
cIndicator lights   
light up when necessary
dGentle sensor button
for gentle drying
eTime display
for the program duration
fSensor buttons   
for the time selection
gStart/Stop sensor button
for program start/cancellation
hOptical interface
for service technicians
iProgram selector
for selecting program and for
switching off. The tumble dryer is
switched on when you select a
program and switched off by turning
the program selector to the 
position.
14

Operating the tumble dryer
15
How the display works
The , , , and  sensor buttons
react to fingertip contact. Selection is
possible as long as the respective
sensor button is illuminated.
If a sensor button is brightly lit, this
means: currently selected
If a sensor button is dimly lit, this
means: selection possible
 Sensor buttons for the drying
levels
After a drying level program is selected
with the program selector, the proposed
drying level lights up.
Drying levels that can be selected are
dimly lit.
 Indicator lights
–
lights up when the condensed water
container needs to be emptied.
–
lights up when the plinth filter needs
to be cleaned.
– Perfect Dry
The Perfect Dry system measures the
residual moisture present in the
laundry in programs with selectable
drying levels and provides a more
precise drying result.
After starting the program, this
message . . .
. . . will flash until the program
duration has been determined and
then go out.
. . . will light up again when the
selected drying level is reached and
remain on until the end of the
program.
. . . remains off with the following
programs: Woolens/Silks, Time Dry.
 Gentle sensor button
For drying temperature-sensitive textiles
with the  symbol. When the sensor
button is touched, Gentle will light up
brightly.
With some programs, Gentle is always
active (lights up) or inactive (does not
light up).

Operating the tumble dryer
16
 Time display
The remaining program duration will be
displayed in hours and minutes.
With most program, the duration
displayed may vary or “jump”. The
following factors, among others, affect
the program duration displayed: the
quantity of laundry, the type of fabric,
and the residual moisture in the laundry.
The electronic control continually
assesses conditions in the appliance
and then adjusts the program duration
with increasing accuracy.
    sensor buttons
–
After touching the sensor button,
a later start time for the program
(Delay Start) can be selected. Once
selected,  lights up brightly.
– 
The  or  sensor buttons are used
for selecting the duration of the delay
start period or the duration of the
Time Dry program.
 Start/Stop sensor button
Touching the Start/Stop sensor button
starts the selected program or cancels
a program that has already been
started. The sensor button flashes
slowly as soon as it is possible for a
program to be started and then lights
up constantly after the program has
started.
Drum lighting
The inside of the drum lights up so that
you don't forget any items of laundry
when you empty it.
The drum lighting switches off
automatically (energy saving).

Energy saving tips
17
This dryer with heat-pump technology
is designed for energy-saving drying
cycles. However, you can save a little
more energy with the following
measures as the drying time is not
extended unnecessarily.
– Make sure your laundry is spun at the
maximum spin speed before drying.
The higher the spin speed, the
greater the savings that can be made
in energy and time during drying, e.g.,
approx. 20% energy can be saved if
spun at 1,600rpm instead of
1,000rpm.
– Load according to the optimum
amount of laundry recommended for
the program being used. This will
mean that the energy consumption
for the amount of laundry is at its
most economical.
– Make sure that the room temperature
is not too high. If there are other heat-
producing appliances in the room in
which the dryer is located, make sure
the room is well ventilated and switch
the other appliances off, if possible.
– Clean the lint filters in the door
opening after every drying cycle.

Functioning of the heat-pump dryer
18
Two separate circuits ensure that the
laundry is dried:
Dry air circuit
The drying air flows through a heat
exchanger, the drum, and several
filters. This is ensured by a blower in
the dryer.
– The drying air flows through the heat
exchanger in the longitudinal
direction and is heated in the rear
area.
– The drying air is then blown into the
drum, where it absorbs the moisture
of the laundry.
– The damp drying air is blown back
through the heat exchanger via
several filters in the fill area and the
plinth area of the dryer.
– The drying air cools down in the
front, cool area of the heat
exchanger, and loses its moisture.
– The circuit begins again.
Refrigerant circuit
The refrigerant circuit regulates the
heating and cooling of the drying air
through the heat exchanger. The heat
pump is the central component: This
is a compressor that is connected to a
pipeline system which is filled with
refrigerant.
– The pipeline system surrounds the
heat exchanger in several bends.
– The compressor draws in the
gaseous refrigerant and compresses
it, causing the temperature to rise.
– The hot refrigerant is passed through
the pipeline system to the rear of the
heat exchanger. The heat is released
into the drying air, which flows
through the heat exchanger.
– The refrigerant liquifies by dissipating
the heat.
– The liquid refrigerant then flows
through a capillary tube (a very thin
tube) to the front area of the heat
exchanger. This changes the
pressure of the refrigerant.
– The refrigerant cools and reverts to
its gaseous state. This in turn cools
the front area of the heat exchanger
and dehumidifies the drying air.
– The circuit begins anew.

Initial set-up
19
Removing the protective film
and stickers
Remove:
– The protective film from the door
– Any stickers (if present) from the front
and the lid
Please do not remove any labels
(e.g., the data plate) which are visible
when you open the door.
Carrying out the procedure for
initial commissioning outlined
in these instructions
Read “1. Notes on correct laundry
care” and “2. Loading the tumble
dryer”.
You can then load the tumble dryer
and select a program as described in
“3. Selecting a program and starting
it”.

1. Notes on correct laundry care
20
Points to note regarding
washed laundry
– When washing very heavily soiled
items, ensure that you use sufficient
detergent and select a high
temperature. If in doubt, wash the
items several times.
– Do not load the drum with items that
are still soaking wet. Make sure your
laundry is spun at the maximum spin
speed before drying. The higher the
spin speed, the greater the savings
that can be made in energy and time
during drying.
– New dark colored garments should
be washed and dried separately from
light colored garments. There is the
risk of colors running and discoloring
other garments or even plastic
components in the dryer. Dark
colored fibers can also settle on light
colored garments and vice versa.
– Starched laundry can be tumble
dried. To achieve the usual finish,
double the amount of starch should
be used.
Preparing the laundry before
drying
Damage due to foreign objects
which were not removed from the
laundry.
Foreign objects can melt, burn, or
explode.
Ensure that any foreign objects (e.g.,
detergent dispensing balls, lighters,
etc.) have been removed from the
laundry.
Risk of fire due to incorrect use
and operation.
The laundry can burn and destroy
the dryer and the surroundings.
Read and observe “IMPORTANT
SAFETY INSTRUCTIONS”.
– Sort the laundry according to the type
of fiber and weave, size, garment
care label symbol, and the drying
level required.
– Check seams and stitching to ensure
that padding and linings are intact.
This way you will avoid the danger of
fillings coming out. These could catch
fire when being dried.
– Untangle the laundry.
– Tie together textile belts and apron
ties.
– Fasten duvet covers and pillow cases
to prevent small items from being
rolled up inside them.
– Fasten hooks and eyes.
– Leave jackets open and undo any
long zippers so that textiles dry
evenly.
– Sew in or remove underwiring from
bras.
– If necessary, reduce the size of the
load for these types of fabric. Easy
care fabric tends to crease more, the
larger the load. This is particularly the
case for garments made from very
fine weave fabric, such as dress
shirts or blouses.
