Miele WKH 130 WPS User manual

WKH 130 en - AU, NZ M.-Nr. 10 028 130/03
Before the first use Operating the washing machine
OPERATING THE WASHING MACHINE
Washing
WASHING
Changing the programme sequence
CHANGING THE PROGRAMME SEQUENCE
Programme chart
6 7
1 2 345 8 9
10 11 12 13 14 15
əBefore using the machine for the first
time, ensure that it is correctly installed
and connected.
Please read the separate operating
instructions supplied with the appliance.
When the washing machine is switched
on for the first time with the button, the
welcome screen ("Willkommen") will appear.
Setting the language
You will be asked to select the language
you require for the display.
ĺTouch the  or sensor until the lan-
guage you want appears in the display.
ĺConfirm the language with the OK sensor.
Messages
Two messages about removing the tran-
sit bars and preparing the washing machine
for use will appear in the display.
ĺEnsure the feet of the washing machine
are aligned and the transit bars have
been removed, and confirm with the OK
sensor.
Running the first programme
The TwinDos unit needs to be activated
before running the first programme.
ĺPlease see "TwinDos" in the operating
instructions.
ĺTurn on the tap.
ĺTurn the programme selector to Cottons.
After the load appears in the display, the
display changes to the standard display.
ĺTouch the Dos  sensor.
ĺSelect the Heavy degree of soiling set-
ting with the sensor and confirm your
selection with the OK sensor.
ĺConfirm the For white items option with the
OK sensor.
ĺPress the Start/Stop button.
ĺSwitch the washing machine off at the
end of the programme.
The TwinDos unit is now ready for use.
Washing environmentally and economically
–To get the most out of your machine,
load the maximum dry load for the pro-
gramme you are using.
–When smaller amounts of laundry are
washed, the automatic load recognition
system will reduce the amount of water
and energy used.
–Use the Express 20 programme for
small, lightly soiled loads.
–Modern detergents enable washing at
reduced temperatures (e.g. 20°C). Use
appropriate temperature settings for
saving energy.
–For precise dispensing, use automatic
detergent dispensing.
–Selecting the highest possible spin
speed for the wash programme will
save energy when drying in a tumble
dryer afterwards.
1. Preparing the laundry
ĺEmpty all pockets.
əForeign objects (e.g. nails,
coins, paper clips, etc.) can
cause damage to garments and
components in the machine.
ĺSort the laundry by colour and by care label. Most gar-
ments have a textile care label in the collar or side seam.
ĺPre-treat stains and badly soiled areas (see the booklet
"Miele's guide to laundry care").
2. Selecting a programme
ĺSwitch on the washing machine with the button.
Selecting a programme via the programme selector
ĺTurn the programme selector to the required pro-
gramme.
The load for the programme selected will appear in the
display. This will then be replaced by the standard display.
Selecting a programme using the programme
selector at the "Further programmes" position and
the display
ĺTurn the programme selector to
the Further programmes setting.
Automatic plus
appears in the display.
ĺTouch the or  sensor until the programme you want
appears in the display.
ĺConfirm the programme with the OK sensor.
The load for the programme selected will appear in the
display. Preset programme parameters will be displayed,
depending on the programme selected.
1 Detergent dispenser drawer
2 Control panel
3 Access to drain filter, drain pump
and emergency release
4 Door
5 Access panel for TwinDos
containers
3. Loading the washing machine
Opening the door
ĺReach under the door grip and
pull the door open.
ĺUnfold the laundry and load
loosely in the drum.
Closing the door
ĺMake sure that no items are
caught between the door and
the seal.
ĺShut the door with a gentle
swing.
4. Selecting programme settings
Selecting a temperature
ĺPress the Temperature button.
ĺSet the temperature you want with the and sen-
sors and confirm your selection with the OK sensor.
Selecting a spin speed
ĺPress the Spin speed button.
ĺSet the spin speed you want with the and sensors
and confirm your selection with the OK sensor.
Selecting Extra options
ĺPress the button for the option you want.
Switching on Delay start
The start of a programme can be delayed from 15 minutes
up to 24 hours, allowing you to make use of night-time
economy electricity rates, for example (see "Delay start" in
the operating instructions).
5. Adding detergent
There are several options for adding deter-
gent.
TwinDos
–Miele 2 Phase System
The optimum amount of UltraPhase 1 and
UltraPhase 2 will be dispensed automatically
according to the colour mix of the load.
ĺPress the Dos  sensor.
ĺUse the and sensors to select the
dosage mix (For white items or For coloured
items) and confirm your selection with the
OK sensor.
–Liquid detergent/Fabric softener
The most suitable agent will appear in the
display with a tick () beside it.
If both the agents present in the con-
tainers are suitable (e.g. detergent for
coloured items and fabric softener), then
both agents will be selected.
ĺConfirm the option displayed with the OK
sensor or select another detergent or fab-
ric softener with the and sensors.
Detergent dispenser drawer
ĺPull out the
detergent drawer
and add
detergent to the
compartments.
Detergent for the pre-wash
Detergent for the main wash,
including Soak if selected
 /  Fabric softener, liquid starch or
capsules
CapDosing
Three different types of capsule are available:
Fabric care (e.g. fabric softener)
Additives (e.g. detergent enhancers)
Detergent
See "Detergent" in the operating instruc-
tions for more information.
6. Starting the programme - the
end of the programme
Starting the programme
ĺPress the flashing Start/Stop button.
The door will lock (the will appear in the
display to show this) and the programme
will start.
At the end of the programme
The door is still locked during the Anti-
crease phase and the following will appear
alternately in the display:
Anti-crease/Finish and
 Press Sta rt/Stop
ĺPress the Start/Stop button. The door will
be unlocked.
ĺPull open the door.
ĺRemove the laundry.
əCheck that all items have been
removed from the drum.
ĺCheck the folds
in the door seal
for any small
articles, e.g.
buttons, which
might be lodged
there.
ĺSwitch the washing machine off with the
button.
ĺClose the door and remove any used
capsules which may be in the detergent
dispenser drawer.
Cancelling a programme
ĺPress the Start/Stop button.
The following will appear in the display:
Cancel programme
ĺTouch the OK sensor.
The suds will be pumped away. Prog. can-
celled will appear in the display.
ĺPull open the door.
ĺRemove the laundry.
Selecting another programme
ĺClose the door.
ĺSelect the programme you want.
ĺAdd detergent to the detergent dispenser
drawer, if necessary.
ĺPress the Start/Stop button.
Changing a programme and
settings
Programme
After the start of a programme, it is no
longer possible to select a different pro-
gramme.
Temperature/Spin speed
The temperature can be changed within the
first five minutes, except in the Cottons pro-
gramme. The spin speed can be changed
right up to the start of the final spin.
ĺPress the Temperature or Spin speed
button.
ĺUse the or and OK sensors to
change the temperature and spin speed.
Extra options
It is possible to select or deselect the Short
and Water plus Extra options up to five min-
utes after the programme has started.
It is not possible to make any changes to
the programme or to cancel it if the safety
lock has been activated.
Interrupting a programme
ĺSwitch the washing machine off with the
button.
ĺSwitch the washing machine back on
with the button to continue with the
same programme.
Adding or removing laundry
after a programme has started
ĺPress the Start/Stop button.
The following will appear in the display:
Cancel programme
ĺScroll up or down the list with the or 
sensor to:
Add laundry
ĺTouch the OK sensor.
The programme will stop and the door will
unlock.
ĺPull open the door.
ĺAdd or remove items.
ĺClose the door.
ĺPress the Start/Stop button.
The programme will continue.
The door cannot be opened if:
–the suds temperature is above 55°C.
–the water is above a certain level.
–the programme has reached the Spin
stage.
Programme
Load
(inkg) Temperature Items Extra options
Cottons 8.0 Cold to 90°C Cottons, linens or cotton mix fabrics, e.g. table linen, towelling,
underwear, T-shirts etc.
, , , , 
Minimum iron 4.0 Cold to 60°C Synthetic, mixed fibre and easy care cotton. , , , ,  Delicates 3.0 Cold to 60°C Delicate garments made from synthetic fibre, mixed fibre,
rayon and viscose.
, , , , 
Woollens 2.0 Cold to 40°C Machine-washable or hand-washable wool or wool blend fab-
ric. If the care label does not specify a temperature, wash using the cold setting.
Silks 1.0 Cold to 30°C Silks and other hand-washable fabrics with no wool content,
e.g. satin, lace and silk.
QuickPowerWash 5.0 40°C to 60°C Moderately soiled garments which are also suitable for wash-
ing in the Cottons programme.

Express 20 3.5 Cold to 40°C Cotton garments that have hardly been worn or are only very
lightly soiled.
, 
Shirts 2.0 Cold to 60°C Shirts and blouses made of cotton and mixed fibre. , , , ,  Dark garments/ Denim
3.0 Cold to 60°C Black and dark garments made from cotton, mixed fibres and
denim.
, , , , 
Drain/Spin –– Drain only: Select 0 rpm for the spin speed.
= Pre-wash; = Pre-ironing; = Short; = Water plus; = Stains An explanation of the programmes at the Further programmes position can be found in the "Programmechart" in the operating instructions.
1 Display with sensors
See points 10 to 15 for more information.
2 Start/Stop button
For starting the programme selected
and cancelling a programme once it has
started.
3 Temperature button
For selecting a temperature.
4 Spin speed button
For selecting the spin speed.
5 Delay start button
For selecting Delay start.
6 Extra option buttons
Various Extra options can be added to
the wash programme.
7 Programme selector
For selecting a wash programme.
8 PC optical interface
For service technicians.
9  button
For switching the washing machine on
and off. To save energy, the washing
machine will switch off automatically 15
minutes after the end of the programme /
Anti-crease phase or after being switched
on if no other selection is made.
10  sensor
Scrolls down the list to the next option or
decreases a value.
11 OK sensor
Confirms the programme selected, a
value set or opens a sub-menu.
12  sensor
Scrolls up the list to the next option or
increases a value.
13  Dos sensor
Switches on automatic detergent dis-
pensing.
14  Cap sensor
Activates cap dosing via the detergent
dispenser drawer.
15 EcoFeedback sensor
Provides information about the energy
and water consumption of the pro-
gramme.
Sensors 10 to 12 light up when the display
can be operated via the sensors.
3 5
12
4

en - AU, NZ M.-Nr. 10 028 130
Quick Start Guide
Washing machine
These short instructions are not a substitute for the operating instructions supplied with
the appliance. Please read the operating instructions supplied with your washing machine
before using it for the first time and take note of the Warning and Safety instructions, as
well as the full descriptions on how to use your appliance.
ProgrammeManager/Extra options Detergent
PROGRAMMEMANAGER/EXTRA OPTIONS/DETERGENT
Cleaning and care
CLEANING AND CARE
Problem solving guide
PROBLEM SOLVING GUIDE
ProgrammeManager
The ProgrammeManager option can
be used to customise the washing pro-
grammes to suit your requirements.
Intensive
For hard-wearing laundry that is very heav-
ily soiled. Cleaning efficiency is increased
through more intense mechanical action
and the application of more heat energy.
ECO
This option reduces energy consumption
whilst maintaining cleaning efficiency. This
is achieved by increasing the wash duration
and at the same time reducing the wash
temperature selected.
Extra gentle
This option decreases mechanical action in
order to reduce creasing.
Extra quiet
This option reduces noise levels during the
programme. Use this if you want to wash
during quiet periods (for instance, when
children are sleeping). The machine will acti-
vate the "Rinse hold" option and not spin.
The programme duration is longer.
AllergoWash
This option should be used where high
standards of hygiene are required. More
energy is used to lengthen temperature
holding times and more water is used to
increase rinsing efficiency. The items must
be suitable for drying in a tumble dryer 
and suitable for ironing .
Extra options
Extra options are selected and deselected
via the relevant buttons and the display.
Pre-ironing 
In order to reduce creasing, the laundry
undergoes a smoothing process at the end
of the programme. Reducing the maximum
load by 50% will give a better result. Please
note the load information in the display.
Small loads give a better result.
The garments must be suitable for drying in
a tumble dryer and suitable for iron-
ing .
Short
For light soiling with no visible staining.
The wash duration is reduced.
Water plus
The water level in the main wash and the
rinses will be increased if the Water plus
Extra option is selected.
You can select other functions for the Water
plus button. These are described in "Set-
tings".
Stains
In order to clean stained laundry more
effectively, you can choose between 7 dif-
ferent types of stain. The wash programme
will then adapt to the type of stain selected.
You can select one stain per wash cycle.
Miele recommended detergents
Programmes
Miele
UltraPhase 1/2
Miele
Cap 
Miele
Cap 
Miele
Cap 
Cottons – 
Minimum iron – 
Delicates ,   –
Woollens –,  – –
Silks –– –
QuickPowerWash – – –
Express 20 ––
Shirts – 
Dark garments/
Denim
– –
Drain/Spin –– – –
= Recommended; – = Not recommended
= Sportswear; = Down items; = WoolCare; = SilkCare; = Fabric softener;= Booster
The right amount to dispense will
depend on the following:
–The soiling level of the laundry.
Lightly soiled:
No visible dirt or stains. Possibly slight
body odour.
Normally soiled:
Visibly dirty and⁄or just a few slight stains.
Heavily soiled:
Soiling and⁄or stains clearly visible.
–The quantity of the laundry.
–Check with your local water supplier if
you do not know the hardness level in
your area.
Cleaning the drum (Hygiene info)
Washing at low temperatures and/or using
liquid detergent can cause bacteria and
unpleasant odours to build up in the wash-
ing machine. Use the Clean machine pro-
gramme to clean the machine. Run this
programme regularly or at the latest when
the Hygiene info message appears in the
display.
Dispensing fabric softener and
liquid starch at the end of the
programme
You can dispense fabric softener either by
using automatic dispensing or via the deter-
gent dispenser compartment.
Automatic dispensing
One of the automatic dispensing containers
must be filled with fabric softener.
ĺTouch the Dos  sensor.
ĺActivate the appropriate container.
Fabric softener will be dispensed in the last
rinse.
Manual dispensing
ĺAdd the fabric softener or liquid starch to
the compartment or insert the appro-
priate capsule. Do not exceed the max-
imum level mark.
It will be automatically dispensed in the final
rinse. At the end of the programme a small
amount of water remains in the fabric sof-
tener  compartment.
If starching frequently, thoroughly clean
the dispenser compartment, especially
the siphon, regularly.
Cleaning the TwinDos system
The washing machine has a cleaning pro-
gramme for cleaning the TwinDos system
containers and the hoses inside the wash-
ing machine.
The TwinDos containers (optional acces-
sory) are required to carry out cleaning.
əIf the system has not been used for
a long time (more than two months), the
detergent in the hoses can become vis-
cous. The hoses could become blocked
and would then need to be cleaned by
a service technician. Clean the TwinDos
system every time you change brand of
liquid detergent or fabric softener or if
the system has not been used for a long
period of time.
Starting the maintenance programme
The maintenance programme is located in
the Settings menu under TwinDos.
ĺFollow the instructions in the display and
refer to the relevant section in the operat-
ing instructions.
After cleaning you can fill one or both con-
tainers with new liquid detergent and/or
fabric softener.
Cleaning the compartment
Detergent residue can cause clogging.
ĺUse a damp cloth to clean the compart-
ment interior when you change the car-
tridge or container.
Cleaning the detergent dispenser
drawer
Washing at low temperatures and the use
of liquid detergent can lead to a build-up
of mould and bacteria in the detergent
dispenser drawer.
ĺClean the entire drawer at regular inter-
vals for hygiene reasons, even if you are
using the TwinDos system exclusively.
ĺPull out the
detergent
dispenser drawer
until a resistance
is felt.
ĺPress down the release button and, at
the same time, pull the drawer right out of
the machine.
ĺClean the detergent dispenser drawer
with warm water.
Cleaning the siphon and the fabric
softener channel
ĺPull the siphon
out of the
compartment
and clean it
under warm
running water.
ĺClean the siphon tube in the same way.
ĺRefit the siphon.
ĺClean the fabric
softener channel
using a brush
and warm water.
əLiquid starch can cause the siphon
to become clogged. Make sure that you
clean the siphon and siphon tube particu-
larly thoroughly after using liquid starch a
few times.
Cleaning the detergent dispenser
drawer housing
ĺUse a bottle brush to remove deter-
gent residues and limescale from the jets
inside the detergent dispenser drawer
housing.
To switch off the fault messages: Switch the washing machine off with the  button.
The messages will appear at the end of the programme and when the washing machine is
switched on and need to be confirmed with the OK sensor.
Problem/Fault message Possible cause and remedy
The display remains dark,
and the Start/Stop but-
ton indicator light does not
come on.
There is no power to the machine.
ĺCheck whether the mains plug is plugged in and
switched on.
ĺCheck whether the fuse or circuit breaker has tripped.
The washing machine has switched off automatically to
save energy.
ĺSwitch it back on with the  button.
The following appears in the
display:
  Service. Door locked
The door is not closed properly. The door lock could not
engage.
ĺClose the door again.
ĺStart the programme again. If this fault message contin-
ues to appear in the display, contact Miele.
The following appears in the
display:
 Check dr ainage. See 
The water outlet is blocked or restricted. The drain hose
has been fixed too high.
ĺClean the drain filter and the drain pump.
ĺCheck whether the maximum delivery height of 1 m has
been exceeded.
The following appears in the
display:
 Water inta ke. See 
The water inlet is blocked or restricted.
ĺCheck whether the tap is turned on properly.
ĺCheck whether the inlet hose is kinked.
ĺCheck whether there is sufficient water pressure.
The filter in the water inlet is blocked.
ĺClean the filter (see the operating instructions).
The following appears in the
display:
  Servi ce. Waterproof s yst.
The water protection system has reacted. The washing
machine is switched off.
ĺTurn off the tap.
ĺCall Miele.
The following appears in the
display:
  Servi ce. Fault F
There is a fault.
ĺRestart the programme. If this fault message continues
to appear in the display, contact Miele.
The following appears in the
display:
 Hygiene i nfo
A programme of at least 60°C has not been run for a long
period of time.
ĺIn order to prevent bacteria and unpleasant odours
building up in the machine, run the Clean machine pro-
gramme using Miele dishwasher and washing machine
cleaner or powder detergent.
Problem/Fault message Possible cause and remedy
The following appears in the
display:
 Check f ilter + jet
The pumps are dirty.
ĺClean the pumps as described in "Problem solving
guide - Opening the door in the event of a blocked
drain outlet and/or power failure" in the operating
instructions.
ĺStart the programme again after cleaning the pumps.
The jet in the top of the door ring is blocked with fluff.
ĺRemove the fluff with your finger. Do not use any sharp
or pointed tools to do this.
ĺStart the programme again after cleaning the jet.
If the fault message appears again, contact Miele. The
washing machine can still be used but with reduced func-
tionality.
Extra cooling
appears in the display after
a programme has been can-
celled.
For safety reasons, the door cannot be opened if the
suds temperature is higher than 55°C.
ĺWait until the temperature in the drum has decreased
and the message has gone out in the display.
The following appears in the
display:
  Service. Door locked
The door lock has jammed.
ĺCall Miele.
The following appears in
the display at the end of the
programme:
 Check de tergent
Excessive foam has built up during washing.
ĺCheck the amount of detergent dispensed.
ĺWith automatic detergent dispensing, check the dos-
age amount set.
ĺObserve the instructions on the detergent packaging
and the degree of soiling of the laundry.
ĺIf necessary, reduce the dosage amount by increments
of 10%.
The following appears in
the display at the end of the
programme:
 Contai ner 1 empty
or
 Contai ner 2 empty
or
 Cont. 1+2 empt y
The TwinDos container (or containers) is empty.
ĺFill the container or containers with liquid detergent or
fabric softener or replace the cartridge(s).
ĺCheck if the laundry is clean. There may not have been
enough detergent used.
ĺWash the items again if necessary.
