Miele KWT4154UG1 User manual

Installation Instructions
KWT4154 UG-1 en-CA
Installation, repair and maintenance work should be performed by
a Miele authorized service technician in accordance with national
and local safety regulations and the provided installation instructions.

,Avoid the risk of electrical shock
- Plug into a grounded 3-prong
outlet.
- Do not move the ground plug.
- Do not use an adapter.
- Do not use an extension cord.
Failure to follow these instructions
can result in death, fire, or electrical
shock.
Improper connection of the
equipment grounding conductor
may result in electric shock. If you
are in any doubt as to whether the
appliance has been properly
grounded, have the appliance
checked by a qualified electrician or
service technician.
Installation, repairs and other work
by unqualified persons could be
dangerous. The manufacturer will
not be held responsible for damage
or injury arising from unauthorized
work.
Before installing the appliance,
verify that the voltage, load and
circuit rating information found on
the data plate match the household
electrical supply.
If there are any questions regarding the
electrical connection of this appliance
to the power supply, please consult a
licensed electrician or call the Miele
Technical Service.
V1-800-565-6435
The appliance comes with a UL-listed,
3-wire power supply cord.
The appliance requires a 3-wire
receptacle.
The receptacle must be installed by a
licensed electrician only.
In the case of side-by-side installations,
a separate outlet must be used for each
appliance. Ideally, the power outlet
should be next to the appliance and
easily accessible. Do not connect the
appliance to the power supply by an
extension cord. Extension cords do not
guarantee the required safety of the
appliance (danger of overheating).
If any changes are needed to the
household wiring or power supply, this
work must be performed by a qualified
electrician.
Electrical connection
28

This appliance must be built in;
otherwise it could tip over.
To ensure that the appliance
functions correctly in tropical
climates where the ambient
temperature exceeds 38°C and air
humidity levels exceed 70%, the
appliance MUST be used in a
climate-controlled room.
Location
The appliance should be installed in a
dry, well-ventilated room.
The room temperature should not go
above or below the climate range for
which the appliance is designed.
The higher the ambient temperature of
the room, the more energy the
appliance requires to operate.
The appliance should not be installed
where it will be exposed to direct
sunlight or directly adjacent to a
heat-producing appliance such as an
oven or a radiator.
Climate range
The appliance is designed for use
within certain climate ranges (ambient
temperatures), and should not be used
outside this range. The climate range of
the appliance is stated on the data
plate inside the appliance.
Climate range Ambient room
temperature
SN
N
ST
T
SN-ST
SN-T
+10°C to +32°C
+16°C to +32°C
+18°C to +38°C
+18°C to +43°C
+10°C to +38°C
+10°C to +43°C
If the appliance is used in a room that is
too cold, the cooling system will switch
off for too long, causing the internal
temperature in the appliance to rise,
with the risk of affecting the wine stored
there.
Ventilation
The air at the back of the appliance
gets warm. The appliance housing unit
must be constructed to allow sufficient
space for ventilation.
The air intake and outlet must not be
covered or blocked in any way.
They should be dusted on a regular
basis.
Before installation
^Before building in, remove all
accessories from the appliance.
^Remove any cable clips from the rear
of the appliance.
^Check that all parts at the back of the
appliance are unhindered. Carefully
remove any hindrances.
Installation
29

The appliance is supplied right-hand
hinged. If left-hand door hinging is
required, follow the instructions below.
^Close the door, and unscrew the top
hinge pin from the door a.
^Unscrew the door stay bfrom
underneath the door.
^Tip the door forward slightly c, and
lift it up and off d.
^Unscrew the top hinge plate e, turn
it around, and refit it on the opposite
side.
^Unscrew the lower hinge plate f.
^Remove the hinge pin g, and
replace it in the hinge plate from
underneath. Ensure that the spacer
on which the hinge pin sits is
correctly positioned.
^Turn the hinge plate around, and refit
it on the opposite side.
Changing the door hinging
30

^Swap over the plug hand the hinge
pin guide iin the top of the door.
^Hang the door on the lower hinge pin
j, and close the door k.
^Refit the top hinge pin lthrough the
hinge pin plate into the door.
^Refit the door stay munderneath the
appliance by securing one screw into
the appliance door and another
through the plastic part of the hinge
pin plate.
Changing the door hinging
31

Appliance dimensions
* The overall height can be increased by 2
inches (50 mm) by adjusting the feet.
Adjustments
^Use the flat wrench provided to
adjust the feet as needed, so that the
appliance fits the countertop height.
Preparing the appliance
^With two people, carefully tip the
appliance backward.
^Attach the supplied trim panel a
below the appliance, and loosely
tighten the screws b.
^Arrange the trim panel aover the
long holes in the appliance door
recess.
^Tighten the screws ball the way
down onto the trim panel a.
Under-counter installation
32

Fitting the appliance into place
^Slide the appliance into the
installation area.
Ensure that the power cord does not
get caught.
Make sure the power socket remains
accessible.
^Using the attachment strip and
screws, fit the appliance into place.
Under-counter installation
33
