MIKRODEV XIO110-E0N-GD6-B2000 User manual

XIO110 EXPANSION FAMILY
HARDWARE MANUAL
•XIO110-E0N-GD6-B2000 (8 Digital Input)
•XIO110-E0N-GD0-B2000 (16 Digital Input)
•XIO110-E0N-GD7-B4000 (8 Digital Output)
•XIO110-E0N-GD1-B4000 (16 Digital Output)
•XIO110-E0N-GD8-B6000 (8 Digital Input, 8 Digital Output)
•XIO110-E0N-GD2-B0401 (8 Analog Input, 0-20 mA, 0-10 V)
•XIO110-E0N-GD3-B0000 (8 Analog Output, 0-20 mA)
•XIO110-E0N-GD3-B0800 (8 Analog Output, 0-10 V)
•XIO110-E0N-GD9-B0000 (4 Analog Input, 4 Analog Output, 0-20 mA)
•XIO110-E0N-GD9-B0900 (4 Analog Input, 4 Analog Output, 0-10 V)
•XIO110-E0N-GD4-B0000 (6 RTD Input, PT1000)
•XIO110-E0N-GD4-B0010 (6 RTD Giriş, PT100)
•XIO110-E0N-GDA-B0000 (1 DALI BUS)
09 / 2022
MIKRODEV_HM_XIO110_EN
v1.8

1
XIO110 EXPANSION FAMILY HARDWARE MANUAL
CONTENT
FIGURES LIST.................................................................................................................................... 2
Preface............................................................................................................................................. 3
About Mikrodev............................................................................................................................... 4
WARNING!....................................................................................................................................... 5
Mounting Information..................................................................................................................... 6
1XIO110 DIGITAL INPUT EXPANSION MODULES ................................................... 7
1.1 GENERAL INFORMATION ............................................................................ 7
1.2 CONNECTION DIAGRAM ............................................................................. 9
2XIO110 DIGITAL OUTPUT EXPANSION MODULES................................................11
2.1 GENERAL INFORMATION ...........................................................................11
2.2 CONNECTION DIAGRAM ............................................................................13
3XIO110 DIGITAL INPUT OUTPUT EXPANSION MODULES ......................................15
3.1 GENERAL INFORMATION ...........................................................................15
3.2 CONNECTION DIAGRAM ............................................................................16
4XIO110 ANALOG INPUT EXPANSION MODULES ..................................................18
4.1 GENERAL INFORMATION ...........................................................................18
4.2 CONNECTION DIAGRAM ............................................................................19
5XIO110 ANALOG OUTPUT EXPANSION MODULES................................................21
5.1 GENERAL INFORMATION ...........................................................................21
5.2 CONNECTION DIAGRAM ............................................................................22
6XIO110 ANALOG INPUT OUTPUT EXPANSION MODULES ......................................24
6.1 GENERAL INFORMATION ...........................................................................24
6.2 CONNECTION DIAGRAM ............................................................................25
7XIO110 RTD INPUT(PT100/PT1000) EXPANSION MODULES .................................27
7.1 GENERAL INFORMATION ...........................................................................27
7.2 CONNECTION DIAGRAM ............................................................................28
8XIO110 DALI EXPANSION MODULES .................................................................30
8.1 GENERAL INFORMATION ...........................................................................30
8.2 CONNECTION DIAGRAM ............................................................................31

2
XIO110 EXPANSION FAMILY HARDWARE MANUAL
FIGURES LIST
Figure 1 DIN Rail Mounting ..................................................................................... 6
Figure 2 Expansion Module Mounting ....................................................................... 6
Figure 3 GD6 Board Type Connector and Physical Interfaces ....................................... 7
Figure 4 GD0 Board Type Connector and Physical Interfaces ....................................... 8
Figure 5 Digital Input Expansion Module Power Connection Diagram ............................ 9
Figure 6 Digital Input Expansion Module Connection Diagram.....................................10
Figure 7 GD7 Board Type Connector and Physical Interfaces ......................................11
Figure 8 GD1 Board Type Connector and Physical Interfaces ......................................12
Figure 9 Digital Output Expansion Module Power Connection Diagram .........................13
Figure 10 Digital Output Expansion Module Connection Diagram.................................14
Figure 11 GD8 Board Type Connector and Physical Interfaces ....................................15
Figure 12 Digital Input Output Expansion Module Power Connection Diagram ...............16
Figure 13 Digital Input Output Expansion Module Connection Diagram ........................17
Figure 14 GD2 Board Type Connector and Physical Interfaces ....................................18
Figure 15 Analog Input Expansion Module Power Connection Diagram .........................19
Figure 16 Analog Input Expansion Module Connection Diagram ..................................20
Figure 17 GD3 Board Type Connector and Physical Interfaces ....................................21
Figure 18 Analog Output Expansion Module Power Connection Diagram.......................22
Figure 19 Analog Output Expansion Module Connection Diagram ................................23
Figure 20 GD9 Board Type Connector and Physical Interfaces ....................................24
Figure 21 Analog Input Output Expansion Module Power Connection Diagram ..............25
Figure 22 Analog Input Output Expansion Module Connection Diagram........................26
Figure 23 GD4 Board Type Connector and Physical Interfaces ....................................27
Figure 24 RTD Input Expansion Module Power Connection Diagram ............................28
Figure 25 RTD Input Expansion Module Connection Diagram ......................................29
Figure 26 GDA Board Type Connector and Physical Interfaces ....................................30
Figure 27 DALI Expansion Module Power Connection Diagram ....................................31
Figure 28 DALI Expansion Module Connection Diagram .............................................32
Figure 29 DALI Current-Limited Power Output Connection .........................................33

3
XIO110 EXPANSION FAMILY HARDWARE MANUAL
Preface
Mikrodev XIO110 series expansion modules are used together with MP110 PLC series and
DM100 Remote Terminal Unit series. There are 14 different types of XIO110 expansion
modules:
-XIO110-E0N-GD6-B2000 (8 Digital Input)
-XIO110-E0N-GD0-B2000 (16 Digital Input)
-XIO110-E0N-GD7-B4000 (8 Digital Output)
-XIO110-E0N-GD1-B4000 (16 Digital Output)
-XIO110-E0N-GD8-B6000 (8 Digital Input, 8 Digital Output)
-XIO110-E0N-GD2-B0401 (8 Analog Input, 0-20 mA, 0-10 V)
-XIO110-E0N-GD3-B0000 (8 Analog Output, 0-20 mA)
-XIO110-E0N-GD3-B0800 (8 Analog Output, 0-10 V)
-XIO110-E0N-GD9-B0000 (4 Analog Input, 4 Analog Output, 0-20 mA)
-XIO110-E0N-GD9-B0900 (4 Analog Input, 4 Analog Output, 0-10 V)
-XIO110-E0N-GD4-B0000 (6 RTD Input, PT1000)
-XIO110-E0N-GD4-B0010 (6 RTD Giriş, PT100)
-XIO110-E0N-GDA-B0000 (1 DALI BUS)
This document describes the hardware features of XIO110 series devices.
Please follow our website www.mikrodev.com for the up to date version of the document.

4
XIO110 EXPANSION FAMILY HARDWARE MANUAL
About Mikrodev
Since 2006, MIKRODEV has been developing and manufacturing industrial control and
communication products. MIKRODEV serves the system integrators in the public and
private sector, OEM and end users.
Our products are manufactured complying with the quality standards required by the
industrial automation industry and the quality of our products are proved on the field for
many years
MIKRODEV is one of the few companies in the world that has its own designed IEC 61131-
3 compliant library for its programmable logic control devices. In addition, the open,
flexible, programmable SCADA solution developed by MIKRODEV is also available to
customers.
MIKRODEV products' performance and wide range of applications make them possible for
customers to achieve faster, simplified and cost-effective results.

5
XIO110 EXPANSION FAMILY HARDWARE MANUAL
WARNING!
✓Please take care of the following issues when using Mikrodev devices.
✓Since the unit operates with 24 VDC (12-36 VDC) voltage, you should take care of
the voltage level that the unit is connected to. If a voltage above this voltage level
is applied, the device may be damaged and may be out of warranty.
✓Make sure that the energy connection of your device is connected to the ground or
to a properly grounded terminal.
✓Make sure that the environment in which your device is being used is free of
moisture, electric shock, vibration and dust.
✓Pay attention to the supply voltage and the connections of the product. Mikrodev is
not responsible for any issues due to power failure since there is no auxiliary supply
(UPS) on the device.
✓The fuse to be used must be a FF super fast type and current limit value 1A.
✓Do not use the device under conditions other than the environmental conditions
specified in the "Electrical Specifications" section (humidity, dust, liquid and
temperature, etc.)
✓Removing the warranty label on the product or removing the protective case will void
the warranty.
✓Products that are damaged, boxes have been changed and other brand labels are
affixed are not covered by the warranty.
✓The appliance must not be cleaned with solvents (thinner, benzine, acid etc.) or with
abrasive cleaning agents.
✓Only dry cloth should be used when cleaning the appliance.
✓Do not open the device by removing the case of the appliance, do not interfere with
the electronic components and circuits. There is no user-replaceable part inside the
device.
✓If there is a problem or malfunction on your device, it should only be repaired by
an authorized service. Installation and electrical connections must be made by
technical personnel in accordance with the instructions in the operating manual.
Failure to comply with these rules may result in death, serious injury or property
damage

6
XIO110 EXPANSION FAMILY HARDWARE MANUAL
Mounting Information
DIN Rail Mounting
First, the upper part of the device is mounted on the DIN rail. Then, with the help of the
springs behind the device, when a lightly force is applied to the lower part, the device
locates into the DIN rail easily and the montage is completed. (See Figure 1)
Figure 1 DIN Rail Mounting
Expansion Installation
Assembly between MP110 series PLC or RIO110 series remote I/O products and XIO110
series expansion modules is carried out by sliding the tabs over the rail so that the tabs
overlap each other.
Figure 2 Expansion Module Mounting

7
XIO110 EXPANSION FAMILY HARDWARE MANUAL
1XIO110 DIGITAL INPUT EXPANSION MODULES
1.1 GENERAL INFORMATION
1.1.1 GD6 Board Type(8 Digital Input) Physical Interfaces
Figure 3 GD6 Board Type Connector and Physical Interfaces
1
Device Power (V-) Connection
2
Device Power (V+) Connection
3
N/A
4
Digital Input Ground Connection
5
Digital Input Connections
6
N/A
7
Digital Input Status Information LED
8
System Running LED
9
System Power LED
10
ID Assign Switch
11
Expansion Connector

8
XIO110 EXPANSION FAMILY HARDWARE MANUAL
1.1.2 GD0 Board Type(16 Digital Input) Physical Interfaces
Figure 4 GD0 Board Type Connector and Physical Interfaces
1
Device Power (V-) Connection
2
Device Power (V+) Connection
3
N/A
4
Digital Input Ground Connection
5
Digital Input Connections
6
Digital Input Status Information LED
7
System Running LED
8
System Power LED
9
ID Assign Switch
10
Expansion Connector

9
XIO110 EXPANSION FAMILY HARDWARE MANUAL
1.1.3 General Device Specifications
SPECIFICATION
ITEM
DESCRIPTION
Electrical
Supply (Standard)
24 VDC (12-36VDC)
Supply (Optional)
Over Expansion Bus
Power
<10W
Power Protection
Yes
Enviromental
Conditions
Operating Temperature
-20…+60 C
Storage Temperature
-40…+85 C
Humidity
5…95 RH
Operating Altitude
0…2000 m
ID Assign
Dip Switch
Between 0-15
1.2 CONNECTION DIAGRAM
1.2.1 Supply Connection
Supply:
12-36 VDC, Protected
Power:
<10 W
Figure 5 Digital Input Expansion Module Power Connection Diagram

10
XIO110 EXPANSION FAMILY HARDWARE MANUAL
1.2.2 Digital Inputs
Order Code:
XIO110-E0N-GD6-B2000
XIO110-E0N-GD0-B2000
Module Input:
8 Channel, PNP
16 Channel, PNP
Module Input Range:
0-50 VDC
ON Voltage Range:
9-50 VDC
OFF Voltage Level:
0-5 VDC
Input Impedance:
3 Kohm>
Isolation:
Optical
OFF to ON Response:
20 us
ON to OFF Response:
90 us
Figure 6 Digital Input Expansion Module Connection Diagram

11
XIO110 EXPANSION FAMILY HARDWARE MANUAL
2XIO110 DIGITAL OUTPUT EXPANSION MODULES
2.1 GENERAL INFORMATION
2.1.1 GD7 Board Type(8 Digital Output) Physical Interfaces
Figure 7 GD7 Board Type Connector and Physical Interfaces
1
Device Power (V-) Connection
2
Device Power (V+) Connection
3
Digital Output Ground Connection
4
Digital Output Supply Connection
5
Digital Output Connections
6
N/A
7
Digital Output Status Information LED
8
System Running LED
9
System Power LED
10
ID Assigning Switch
11
Expansion Connector

12
XIO110 EXPANSION FAMILY HARDWARE MANUAL
2.1.2 GD1 Board Type(16 Digital Output) Physical Interfaces
Figure 8 GD1 Board Type Connector and Physical Interfaces
1
Device Power (V-) Connection
2
Device Power (V+) Connection
3
Digital Output Ground Connection
4
Digital Output Supply Connection
5
Digital Output Connections
6
Digital Output Status Information LED
7
System Running LED
8
System Power LED
9
ID Assigning Switch
10
Expansion Connector

13
XIO110 EXPANSION FAMILY HARDWARE MANUAL
2.1.3 General Device Specifications
SPECIFICATION
ITEM
DESCRIPTION
Electrical
Supply (Standard)
24 VDC (12-36VDC)
Supply (Optional)
Over Expansion Bus
Power
<10W
Power Protection
Yes
Enviromental
Conditions
Operating Temperature
-20…+60 C
Storage Temperature
-40…+85 C
Humidity
5…95 RH
Operating Altitude
0…2000 m
ID Assign
Dip Switch
Between 0-15
2.2 CONNECTION DIAGRAM
2.2.1 Supply Connection
Supply:
12-36 VDC, Protected
Power:
<10 W
Figure 9 Digital Output Expansion Module Power Connection Diagram

14
XIO110 EXPANSION FAMILY HARDWARE MANUAL
2.2.2 Digital Outputs
Order Code:
XIO110-E0N-GD7-B4000
XIO110-E0N-GD1-B4000
Module Output:
8 Channel, Mosfet Output
16 Channel, Mosfet Output
Module Output Type:
PNP Transistor
Module Output Range:
12-36 VDC
Module Output Current:
2 A @ 30 VDC
Module Output GND Common:
1 GND (16 Point/ Common)
Isolation:
Optical
Figure 10 Digital Output Expansion Module Connection Diagram

15
XIO110 EXPANSION FAMILY HARDWARE MANUAL
3XIO110 DIGITAL INPUT OUTPUT EXPANSION MODULES
3.1 GENERAL INFORMATION
3.1.1 GD8 Board Type(8 Digital Input, 8 Digital Output) Physical
Interfaces
Figure 11 GD8 Board Type Connector and Physical Interfaces
1
Device Power (V-) Connection
2
Device Power (V+) Connection
3
Digital Input/Output Ground Connection
4
Digital Output Supply Connection
5
Digital Output Connections
6
Digital Input Connections
7
Digital Output Status Information LED
8
Digital Input Status Information LED
9
System Running LED
10
System Power LED
11
ID Assigning Switch
12
Expansion Connector

16
XIO110 EXPANSION FAMILY HARDWARE MANUAL
3.1.2 General Device Specifications
SPECIFICATION
ITEM
DESCRIPTION
Electrical
Supply (Standard)
24 VDC (12-36VDC)
Supply (Optional)
Over Expansion Bus
Power
<10W
Power Protection
Yes
Enviromental
Conditions
Operating Temperature
-20…+60 C
Storage Temperature
-40…+85 C
Humidity
5…95 RH
Operating Altitude
0…2000 m
ID Assign
Dip Switch
Between 0-15
3.2 CONNECTION DIAGRAM
3.2.1 Supply Connection
Supply:
12-36 VDC, Protected
Power:
<10 W
Figure 12 Digital Input Output Expansion Module Power Connection Diagram

17
XIO110 EXPANSION FAMILY HARDWARE MANUAL
3.2.2 Digital Input and Outputs
Order Code:
XIO110-E0N-GD8-B6000
Module Input:
8 Channel, PNP
Module Input Range:
0-50 VDC
ON Voltage Range:
9-50 VDC
OFF Voltage Level:
0-5 VDC
Input Impedance:
3 Kohm>
Isolation:
Optical
OFF to ON Response:
20 us
ON to OFF Response:
90 us
Module Output:
8 Channel, Mosfet Output
Module Output Type:
PNP Transistor
Module Output Range:
12-36 VDC
Module Output Current:
2 A @ 30 VDC
Module Output GND Common:
1 GND (8 Point/ Common)
Isolation:
Optical
Figure 13 Digital Input Output Expansion Module Connection Diagram

18
XIO110 EXPANSION FAMILY HARDWARE MANUAL
4XIO110 ANALOG INPUT EXPANSION MODULES
4.1 GENERAL INFORMATION
4.1.1 GD2 Board Type(8 Analog Input) Physical Interfaces
Figure 14 GD2 Board Type Connector and Physical Interfaces
1
Device Power (V-) Connection
2
Device Power (V+) Connection
3
N/A
4
Analog Input Ground Connection
5
Analog Input Current Connections
6
Analog Input Voltage Connections
7
Analog Input Status Information LED
8
System Running LED
9
System Power LED
10
ID Assigning Switch
11
Expansion Connector

19
XIO110 EXPANSION FAMILY HARDWARE MANUAL
4.1.2 General Device Specifications
SPECIFICATION
ITEM
DESCRIPTION
Electrical
Supply (Standard)
24 VDC (12-36VDC)
Supply (Optional)
Over Expansion Bus
Power
<10W
Power Protection
Yes
Enviromental
Conditions
Operating Temperature
-20…+60 C
Storage Temperature
-40…+85 C
Humidity
5…95 RH
Operating Altitude
0…2000 m
ID Assign
Dip Switch
Between 0-15
4.2 CONNECTION DIAGRAM
4.2.1 Supply Connection
Supply:
12-36 VDC, Protected
Power:
<10 W
Figure 15 Analog Input Expansion Module Power Connection Diagram
