Mikroe BOARDS XBEE click User manual

2 3
2. Soldering the headers
3. Plugging the board in
Once you have soldered the headers your
board is ready to be placed into the desired
mikroBUS™socket. Make sure to align the
cut in the lower-right part of the board with
the markings on the silkscreen at the
mikroBUS™socket. If all the
pins are aligned correctly,
push the board all the way
into the socket.
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder the
pins carefully.
Turn the board upside down so that
the bottom side is facing you upwards.
Place shorter pins of the header into the
appropriate soldering pads.
Before using your click board™, make sure
to solder 1x8 male headers to both left and
right side of the board. Two 1x8 male headers
are included with the board in the package.
4. Essential features
XBee click is network-compatible with other
devices that conform to ZigBee standards. The
module operates at the 2.4-2.5GHz band, has
a wireless range of up to 60m indoors, or up to
1.2km outdoors (line-of-sight). The RF data
rate is up to 250 Kbps. To simplify deployment,
the click features a commissioning button
and an associated LED. They allow you to
issue simple conguration commands with
subsequent button presses (joining or leaving
networks, self-identication, restoring default
values etc.)
1
XBee click carries the Xbee®and Zigbee-
compliant XB24CZ7PIS-004 module with
a PCB antenna from Digi International. The
module provides wireless connectivity to
end-point devices in ZigBee mesh networks.
The board can communicate with the target
MCU either through the mikroBUS™UART
interface (TX, RX, RTS i CTS), or SPI (MISO,
MOSI, SCK, CS). Additional functionality is
provided by, Reset, and ATTN-DTR pins. Uses
3.3V power supply only.
1. Introduction
XBEE click Manual v101
0100000090060
XBEE click
click
BOARDS™
www.mikroe.com

SCK CS SDI SDO
SCK
CS
SDI
SDO
RTS
CTS
TX
RX
ATTN
R2
10K
VCC-3.3VVCC-3.3V
C2 10uF
VCC-3.3V
VCC-3.3VVCC-3.3V
T2
R1
2K2
LD1
C1 100nF
LD2
R4
2K2
R1
R2
Q1
PDTC114EU
RTS CTS
R3
1K
VCC-3.3V31
32
33
34
DIO1/AD1
DIO0/AD0/CB
Reserved
GND
22
23
24
25
26
27
28
29
30
35
36
37
RF
Reserved
DIO9/On_nSLEEP
VREF
DIO5/ASSOC
DIO6/nRTS
DIO3/AD3
DIO2/AD2
GND
Reserved
DIO4
DIO7/nCTS
1
2
3
4
GND
VCC
DOUT/DIO13
DIO14/DIN/nCONFIG
5
6
7
8
9
10
11
12
13
DIO12
nRESET
DIO10/ RSSI PWM/PWM0
DIO11/PWM1
Reserved
DIO8/nDTR/SLEEP_RQ
GND
DIO19/SPI_nATTN
GND
14
15
16
17 18 19 20
21 Reserved
Reserved Reserved Reserved DIO15/SPI_SO DIO16/SPI_SI DIO17/SPI_nSSEL DIO18/SPI_CLK
XBEE
XBee RF Module
C3
100nF
RESET_N
RESET_N
VCC-3.3V
AN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
MIKROBUS DEVICE CONN.
RX
TX
J1
DTR
ATTN-DTR
VCC-3.3V
ATTN-DTR
ASSOC
8. Code examples
MikroElektronika oers free tech support
(www.mikroe.com/support) until the end of
the product’s lifetime, so if something goes
wrong, we’re ready and willing to help!
Once you have done all the necessary
preparations, it’s time to get your click board™
up and running. We have provided examples
for mikroC™, mikroBasic™and mikroPascal™
compilers on our Libstock website. Just
download them and you are ready to start.
.com
6. Dimensions
MikroElektronika assumes no responsibility
or liability for any errors or inaccuracies
that may appear in the present document.
Specication and information contained in
the present schematic are subject to change
at any time without notice.
Copyright © 2015 MikroElektronika.
All rights reserved.
mm mils
LENGTH 57.15 2250
WIDTH 25.4 1000
HEIGHT* 5.33 210
5. Schematic
7. ATT/DTR jumper
9. Support
25.4 mm / 1000 mils
57.15 / 2250 mils
* without headers
10. Disclaimer
The ATT/DTR jumper is
for setting the interrupt
feature, depending on
whether SPI or UART is
used for data transmission
(ATT for SPI, DTR for UART).
