mikroElektronika WiFly click User manual

2 3
2. Soldering the headers
3. Plugging the board in
Once you have soldered the headers your
board is ready to be placed into the desired
mikroBUS™socket. Make sure to align the
cut in the lower-right part of the board with
the markings on the silkscreen at the
mikroBUS™socket. If all the
pins are aligned correctly,
push the board all the way
into the socket.
Turn the board upward again. Make sure
to align the headers so that they are
perpendicular to the board, then solder the
pins carefully.
Turn the board upside down so that
the bottom side is facing you upwards.
Place shorter pins of the header into the
appropriate soldering pads.
Before using your click board™, make sure
to solder 1x8 male headers to both left and
right side of the board. Two 1x8 male headers
are included with the board in the package.
4. Essential features
The RN-131 module’s rmware makes it easy
to set up, scan for access points, associate,
authenticate and connect the WiFly click to a
Wi-Fi network. The module is controlled with
simple ASCII commands. It has a multitude
of networking applications built in: DHCP,
UDP, DNS, ARP, ICMP, TCP, HTTP client, and
FTP client. Data rates of up to 1 Mbps are
achievable through UART. It contains both an
onboard chip antenna and a connector for an
external antenna. .
1
WiFly click carries RN-131, a standalone,
embedded wireless LAN module. It allows
you to connect your devices to 802.11 b/g
wireless networks. The module includes
preloaded rmware which simplies
integration. The mikroBUS™ UART interface
alone (RX, TX pins) is sucient to establish
a wireless data connection. Additional
functionality is provided by RST, WAKE, RTSb
and CTSb pins. The board uses a 3.3V power
supply only.
1. Introduction
WiFly click manual
ver 1.00
0100000081976
WiFly click
click
BOARD™
www.mikroe.com

AN
RST
CS
SCK
MOSI
MISO
+3.3V
GND
PWM
INT
RX
TX
SCL
SDA
+5V
GND
C1
100nF
VCC-3V3
GND GND
GND
R9
10K
GND
LD1
R1
2K2
GND
VCC
GND
VCC
UART-RX
UART-TX
UART-RX
UART-TX
RTS
CTS
RTS
R10
1K
CTS
RTS
CTSb
RTSb
CTSb
RTSb
RST
WAKE
RST
WAKE
R6
22K
GND
UART-RX
R3
49K9
R5
10K
R8
100K
LD3
LD4
R7
220
R4
220
R2
1K
LD2
GND
GND
GND
ASSOC
DATA
CONN
ASSOC
DATA
CONN
FP1
VCC-3V3
E1
100uF/20V
RN131
2
3
4
5
6
7
8
9
10
11
12
13
14 15 16 17 18 19 20 21 22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39 40
41 42
43 44
1
U1
J1
J2
8. Code examples
MikroElektronika oers free tech support
(www.mikroe.com/support) until the end of
the product’s lifetime, so if something goes
wrong, we’re ready and willing to help!
Once you have done all the necessary
preparations, it’s time to get your click board™
up and running. We have provided examples
for mikroC™, mikroBasic™and mikroPascal™
compilers on our Libstock website. Just
download them and you are ready to start.
.com
6. Dimensions
MikroElektronika assumes no responsibility
or liability for any errors or inaccuracies
that may appear in the present document.
Specication and information contained in
the present schematic are subject to change
at any time without notice.
Copyright © 2015 MikroElektronika.
All rights reserved.
mm mils
LENGTH 57.15 2250
WIDTH 25.4 1000
HEIGHT* 5.33 210
5. Schematic
7. SMD jumpers
9. Support
25.4 mm / 1000 mils
57.15 / 2250 mils
* without headers
10. Disclaimer
J1 and J2 jumper positions are for enabling
or disabling the functionality of RTS and CTS
control pins. To put them to use, solder Zero
ohm resistors
