MILL HT500 User guide

ASSEMBLY AND INSTRUCTION MANUAL (EN)
Please read the instructions carefully before use. Take good care of this manual for later use.
Series: PTC Fan Heater
Model: HT500
This product is only suitable for well insulated spaces or occastional use.

Table of contents
p. 3-5 Important Safety Information
p. 6 Specications
p. 6 Before rst use
p. 6 Description of the heater
p. 7 Instructions for use
p. 7 Use
p. 9 Maintenance
pp. 9 Warranty
p. 9 Waste Disposal
EN 2 millnorway.com
Please read the instructions carefully before use.
Take care of this manual for later use.
NEVER TOCH YOUR HEATER OR ITS CASING WITH WET HANDS!
IN ORDER TO AVOID OVERHEATING, DO NOT COVER THE HEATER.

Important safety information
You must obey common safety guidelines when using electrical pro-
ducts, especially in the presence of children.
WARNING! To avoid electric shock or damage due to the heat, al-
ways make sure the plug is pulled out before the heater is moved or
cleaned.
READ THE INSTRUCTIONS CAREFULLY
• The product is intended for home use only.
• Make sure the heater is connected to the house's regular mains,
as it indicated on the heater.
• New heaters will produce a specic odor when used the rst
time. This will stop after a short time and is completely harmless.
• Check for any pieces of packing foam or cardboard that may ha-
ve fallen into the heating elements of the heater. These pieces
must be removed in order to avoid unpleasant odors.
• Prevent the heater from overheating – do not cover.
• Always turn off the heater and unplug it when not used for a
long time.
• Pay special attention if the heater is used in rooms where child-
ren, the handicapped or elderly reside.
• The heater should not be set up directly beneath an electrical
socket outlet.
EN 3 millnorway.com

• The heater must not be used if either the cord or plug is dama-
ged. The heater must not be used if it has been dropped on the
oor or is damaged in any other way causing it to malfunction.
• The cord must be repaired by the manufacturer or by an expert if
it has been damaged, to avoid dangerous situations.
• Avoid using extension cords, which may overheat and could
possibly start a re.
• Never cover the air vents on the heater. Avoid potential re ha-
zards by making sure the air intakes are not blocked or covered.
The heater should be used in rooms with normal at oors.
• The heater should not be installed in close proximity to ammab-
le materials of any kind because there can always be a risk of
re.
• The heater must never be used in rooms where gasoline, paint
or other ammable liquids are stored, such as in a garage.
• Never touch an electric heater with wet hands.
• Some parts of this product can become very hot and cause
burns. Particular attention has to be given where children and
vulnerable people are present.
• The heater must be switched off, the plug removed and the hea-
ter must cool down before it is moved.
EN 4 millnorway.com

• Avoid overloading the mains (the circuit) where the heater is
connected. The heater may overload the electrical circuit if ot-
her electrical devices are plugged into the same socket outlet.
• Do not use this heater in small rooms when they are occupied
by persons not capable of leaving the room on their own, unless
constant supervision is provided.
• The device cannot be used by children under 8 years of age and
persons with reduced physical or mental abilities or lack of ex-
perience and knowledge unless they have been given supervi-
sion or instruction in the safe use of the device and understand
the hazards involved.
• Children should not play with the device. Cleaning and mainte-
nance should not be done by unsupervised children.
• Children under the age of 3 should be kept away from the de-
vice, unless they are under constant supervision.
• Children aged 3 to 8 years are only permitted to turn the device
ON/OFF, assuming the device is mounted according to the as-
sembly instructions and the children have received instruction
or supervision in the safe use of the device and understand the
hazards involved.
• Do not use this heater in the immediate surroundings of a bath,
a shower or a swimmingpool.
ATTENTION! This heater is only meant to be used as a supplementa-
ry heating source, and must not be used without supervision.
EN 5 millnoway.com

EN 6 millnorway.com
Model Thermostat Color Amperage Power (W)
HT500 Electronic White/Black
220-240V
50/60 Hz 500
Specications
Before rst use
After unpacking the heater, check to make sure the product was not damaged during transport. Contact the
retailer or importer if you discover any visible damages to the product.
Keep the outer packaging to transport the heater in the future. If you want to dispose of the packaging, make
sure it is done properly. Keep plastic bags away from children.
First use
After turning on the heater for the rst time or after an extended period without use, the heater can produce a
burnt odor for a short time. This is normal.
Please read all the instructions carefully before use. Save the instruction manual for future use.
Description of heater
1. Control panel
2. Heat emission
3. Plug
4. ON/OFF button
5. Intake of cold air
6. Night light

EN 7 millnorway.com
Instructions
Control panel
1. Button to increase the temperature
2. ON / Standby
3. Button to lower the temperature
4. Timer
5. LED display
6. Fan speed (low / high)
ATTENTION! This heater is only meant to be used as a supplementary
heating source, and must not be used without supervision.
Use
1. Insert the plug into a grounded electrical outlet.
NOTE! The fan heater must be placed in an upright position so that the control panel is at the top.
Minimum distance from the bottom of the fan heater to the ground or other objects must be 10 cm.
The minimum distance between the sides of the heater and any walls or other objects must be 50 cm.
2. Press the ON / OFF button on the side of the heater to turn it on. The night light is activated.
3. Press the ON / Standby button on the control panel to start the heater.
4. Press Temp + to increase the temperature.
5. Press Temp– to lower the temperature.
6. To adjust the speed of the fan, press Temp + and Temp– simultaneously. You can then choose between
2 speeds low / high.
7. Press Timer to activate timer function (0-12 hours).
Timer OFF: When the fan heater is on press Timer. The display now changes from temperature to hours.
Keep pressing the Timer button until you have reached the desired number of hours you want the fan
heater to be activated before it switches off automatically. You have the choice between 0 to 12 hours.
Timer ON: When the heater is in standby press Timer. The display now changes from temperature to
hours. Keep pressing the Timer button until you have reached the desired time for when you want the
fan heater to switch on automatically. You have the choice between 0 to 12 hours.
Deactivating the timer: Press the timer button until the number 0 appears on the display. The timer
function is now closed.
8. Press the ON / Standby button when you want to turn off the heater. This will stop the heating function,
but the fan will continue to blow air for about 1 minute for the heater to cool down. The fan will then
switch off automatically. Press the OFF button on the side of the heater and pull the plug out of the
socket.

EN 8 millnorway.com
Information requirment for the electric local space heaters
Model identifier(s): HT500
Item Symbol Value Unit Item Unit
Heat output Type of heat input, for electric storage
local space heaters only (select one)
Nominal heat output Pnom 0,5 kW manual heat charge control, with
integrated thermostat No
Minimum heat output
(indicative) Pmin 0,0 kW
manual heat charge control with
room and/or outdoor temperature
feedback
No
Maximum continuous
heat output Pmax,c 0,5 kW
electronic heat charge control
with room and/or outdoor tempe-
rature feedback
No
Auxiliary electricity
consumption fan assisted heat output No
At nominal heat out-
put elmax N/A kW Type of heat output/room temperature control (select one)
At minimum heat out-
put elmin N/A kW single stage heat output and no room temperature control No
In standby mode elSB 0,00038 kW Two or more manual stages, no
room temperature control No
with mechanic thermostat room
temperature control No
Seasonal space hea-
ting energy efficiency ηs37 % with electronic room temperature control Yes
electronic room temperature con-
trol plus day timer No
electronic room temperature con-
trol plus week timer No
Other control options (multiple se-
lections possible)
room temperature control, with
presence detection No
room temperature control, with
open window detection No
with distance control option No
with adaptive start control No
with working time limitation Yes
with black bulb sensor No
Contact details Mill International AS
Grini Næringspark 10, 1361 Østerås, Norway

Maintenance
1) For cleaning, always unplug the heater and leave it to cool.
2) Wipe the heater regularly with a damp cloth and dry the surface before turning on the heater again.
3) The heater must be cleaned at least once a month during the heating season.
CAUTION! The heater should never be immersed in water.
Avoid using detergents to clean the heater.
Never let any water get inside the heater; this can be hazardous.
4) Dust etc. should be removed with a soft cloth.
5) The heater can be stored in a dry and clean place.
6) If the heater stops working, do not attempt to repair it yourself because it can cause a re hazard and/or electric
shock.
Warranty
The warranty is valid for 2 years. The heater will be repaired or replaced during this time should any malfunction
occur. The warranty applies if the heater is used according to these instructions and the customer can present a
purchase receipt. If the heater malfunctions in any way, please contact the store where it was purchased or the
importer.
Waste disposal
The symbol indicates that this product is not to be disposed of together with household waste. This product
must be delivered to a recycling service or container for electrical appliances and electronic equipment. This is
done to avoid health risks and prevent harm to the environment. Local businesses (or the environmental station in
your neighborhood) are required by law to accept and recycle such products, as a means of environmentally sound
disposal.
Mill International AS
Grini Næringspark 10
1361 Osteras, Norway
Tel.: [phone]
www.millnorway.com
EN 9 millnorway.com
