MILL SG2000MEC User guide

Assembly and instruction manual
Series:
Convection
Please read the instructions carefully before use. Take good care of this manual for later use.
EN

Thanks for buying Mill
Our company was founded in Norway in 1992 by Cato Bryn, specializing in distribution
of oil lled radiators and other types of heaters. From 1992 to 2009, we had gained
signicant knowledge and expertise of dierent type of heaters, thus enabling us to sell to
many of the largest retailers in the Nordic countries.
In 2010, Cato’s son, Phillip joined the company. Philip looked at the heating industry with
fresh new eyes and wondered why there had been so little change with the appearance
of portable heaters in the last 20 years, especially since interior design in general had
changed dramatically over the years. Philip thought consumers should have more styles to
choose from other than the typical old-fashioned, traditional heaters.
Since heaters are part of so many homes, Philip and Cato decided to use their extensive
knowledge to re-invent the design of heaters. They wanted to create beautiful, modern
and minimalistic heaters, using the most advanced technology, that would complement
people’s homes. They launched the brand “Mill” in 2012.
Mill oers revolutionary, innovative Norwegian designs. We are continuously innovating to
complement our line of products to meet consumers’ demand.
Prospering on our success in the Nordics we decided to promote Mill at some of the
world’s largest electronic fairs and home shows in 2015 and 2016 - the feedback from
retailers and distributors all over the world were amazing. We are proud to say that
consumers in over 20 countries can now keep warm with style!

1
millheat.com
EN
Content
P. 2-3
P. 4
P. 4
P. 4
P. 4
P. 5
P. 5
P. 5
P. 6
P. 6
P. 7
P. 7
P. 7
P. 8
P. 8
P. 8
Important safety information
Specications
Before rst use
First use
Description of heater
Parts
Assembly
Instructions mechanical thermostat
Usage mechanical thermostat
Instructions electronic thermostat
Usage electronic thermostat
Temperature calibration
Resetting the heater
Maintenance
Warranty
Waste disposal
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Please read the instructions carefully before use. Take good care of this
manual for later use.

2
EN
You must obey common safety guidelines when using electrical
products, especially in the presence of children.
WARNING!
To avoid electric shock or damage due to the heat, always
make sure the plug is pulled out before the heater is moved or
cleaned.
READ THE INSTRUCTIONS CAREFULLY
• The product is intended for home use only.
• Make sure the heater is connected to the house's regular mains (230 V),
as indicated on the heater.
• New heaters will produce a specic odor when used the rst time. This
will stop aer a short time and is completely harmless.
• Check for any pieces of packing foam or cardboard that may have fallen
into the heating elements of the heater. These pieces must be removed
to avoid unpleasant odors.
• Prevent the heater from overheating – do not cover.
• Always turn o the heater and unplug it when not used for a long
period of time.
• Pay special attention if the heater is used in rooms where children, the
handicapped or elderly reside.
• The heater should not be set up directly beneath an electrical socket
outlet.
• The cord must not be laid under any kind of carpet. Make sure the cord
is laid in such a way that nobody can trip on it.
• The heater must not be used if either the cord or plug is damaged.
The heater must not be used if it has been dropped on the oor or is
damaged in any other way causing it to malfunction.
• The cord must be repaired by the manufacturer or by an expert if it has
been damaged, to avoid dangerous situations.
• Avoid using extension cords, which may overheat and could possibly
start a re.
• Never cover the air vents on the heater. Avoid potential re hazards
by making sure the air intakes are not blocked or covered. The heater
should be used in rooms with normal at oors.
• The heater should not be installed in close proximity to ammable
materials of any kind because there can always be a risk of re.
• The heater must never be used in rooms where gasoline, paint or other
ammable liquids are stored, such as in a garage.
Important safety information

3
millheat.com
EN
Display SG2000LED Display SG2000GLASS
ALL LANGUAGES
Display SG2000LED
STORE THIS INSTRUCTION
MANUAL FOR FUTURE USE!
NEVER TOUCH YOUR HEATER OR ITS
CASING WITH WET HANDS!
ATTENTION! This heater is only meant to be used as a supplementary heating
source, and must not be used without supervision
•Never touch an electric heater with wet hands. The heater should be
installed so a person showering or taking a bath cannot come into direct
contact with it.
•The heater becomes hot when it is on. Therefore, be careful and avoid
burning or scorching your skin.
•cool down before it is moved.
•Avoid overloading the mains (the circuit) where the heater is connected.
The heater may overload the electrical circuit if other electrical devices
are plugged into the same socket outlet.
•The product cannot be used by children under 8 years of age and persons
with reduced physical or mental abilities or lack of experience and
knowledge unless they have been given supervision or instruction in the
safe use of the product and understand the hazards involved.
•Children should not play with the product. Cleaning and maintenance
should not be done by unsupervised children.
•Children under the age of 3 should be kept away from the product, unless
they are under constant supervision.
•Children aged 3 to 8 years are only permitted to turn the product ON/OFF,
assuming the heater is mounted according to the assembly instructions
and the children have received instruction or supervision in the safe use of
the product and understand the hazards involved.
DO NOT COVER
Follow us on social media:
@millheat
millheat.co.uk
[email protected]
@

4
EN
First use
Description of heater
transport. Contact theretailer or importer if you discover any visible damages tothe product.
Keep the outer packaging to transport the heater in the future. If you want to dispose of
the packaging, make sure it is done properly. Keep plastic bags away from children.
d period without use, the
heater can produce a burnt odor for a short time. This is normal.
Please read all the instructions carefully before use. Save the instruction manual for future
use.
Please see table above for which models that have mechanical/electronic thermostats.
Mechanical thermostat and Electronic thermostat
Model Thermostat Color Amperage Power (W) Fan
SG2000MEC Mechanical White 220-240V~50/60Hz 1800-2000 No
SG2000LED Electronic White 220-240V~50/60Hz 1800-2000 Yes
SG2000GLASS Electronic White 220-240V~50/60Hz 1800-2000 Yes
SG2000LED BLACK Electronic Black 220-240V~50/60Hz 1800-2000 Yes
A B C
1. Heat emission
2. Thermostat
3. Output selector
4. Legs (plastic)
1. Heat emission
2. LED display
3. Thermostat + output selector
4. Fan
5. ON/OFF
6. Legs (aluminium)

5
millheat.com
EN
Parts
Assembly
1. Insert both legs into the brackets so you get a stable foot.
2. Remove the pre-mounted screws from the bottom of the heater and place the
heater gently on its head to mount the feet.
3. Two screws must be fastened on each foot bracket.
4. NEVER USE THE HEATER BEFORE THE LEGS HAVE BEEN TIGHTLY SCREWED.
1. Remove the pre-mounted screws on both legs before you insert them into the
brackets, so that you get a stable foot.
2. Attach the legs to the brackets by tightening 2 screws into each bracket.
3. Remove the pre-mounted screws from the bottom of the heater and place the
heater gently on its head to mount the feet.
4. Two screws must be fastened on each foot bracket.
5. NEVER USE THE HEATER BEFORE THE LEGS HAVE BEEN TIGHTLY SCREWED.
See gure 2 on separate illustration sheet
See gure 3 on separate illustration sheet
Mechanical thermostat
Mechanical thermostat
Electronic thermostat
Electronic thermostat
A
A
B
B
• 4 screws (pre-mounted)
• 2 foot brackets
• 2 rails for the feet
• 8 screws (pre-mounted)
• 2 foot brackets
• 2 rails for the feet
Instructions mechanical thermostat
Control Panel
1. Thermostat: Adjust the desired heat setting
2. Output selector:
0: OFF
I: 750W
II: 1250W
III: 2000W
WARNING: BE SURE THE FOOT IS FITTED CORRECTLY AND ACCORDING TO THE
INSTRUCTIONS BEFORE USING THE HEATER!
ATTENTION! This heater is only meant to be used as a supplementary heating source, and
must not be used without supervision
Please see table on page 4 for which models that have mechanical/electronic thermostats
Please see table on page 4 for which models that have mechanical/electronic thermostats
Please see table on page 4 for which models that have mechanical thermostats
See gure 4 on separate illustration sheet

6
EN
Control panel
1. Thermostat and output selector:
i. Turn the selector to the le to decrease the temperature, and turn the selector to
the right to increase the temperature.
ii. Push the button to change the desired power level. 3 power levels.
2. Fan ON/OFF
3. ON/OFF button
4. Power indicator — Shows whether the heater is using power or not
5. Indicates the output level
6. Indicates whether the fan is activated
7. Desired room temperature
WARNING: BE SURE THE FOOT IS FITTED CORRECTLY AND ACCORDING TO THE
INSTRUCTIONS BEFORE USING THE HEATER!
Instructions electronic thermostat
See gure 5 on separate illustration sheet
Please see table on page 4 for which models that have electronic thermostats.
ATTENTION! This heater is only meant to be used as a supplementary heating source, and
must not be used without supervision
1. Set the output selector to the OFF position (0) and the thermostat to minimum. Plug the
heater into a grounded outlet.
2. Set the output selector to position |, || or |||. Turn the thermostat up to the maximum
position. When the desired room temperature has been reached, turn the thermostat
slowly down until you hear a click. The thermostat can now remain in this position until
a dierent room temperature is desired. As soon as the room temperature falls below
this level, the heater will automatically switch on again. When the room has again
reached the desired temperature, the heater will switch o again.
3. If you wish to change the room temperature, repeat the instructions in step 2.
4. The heater has an overheat protection that turns the device o if any parts become
extremely hot.
5. To switch the heater o, turn the output selector to the 0 position. If the heater will be
le unused for a longer period of time, pull out the plug.
Usage mechanical thermostat

7
millheat.com
EN
Usage electronic thermostat
1. Plug the heater into a grounded outlet.
2. Press the ON/OFF button.
3. Choose the desired power |, || or |||, by pressing the output selector. Turn the thermostat
to the desired temperature while looking at the display. As soon as the room
temperature drops below this level, the heater will automatically start again. When the
room has reached the desired temperature again, the heater wi
4. The thermostat goes from 5 to 35°C.
5. If you want to change the temperature in the room, repeat step 3.
6. Press the fan button to start the fan. Note that the fan is only active when the heater is
heating up (when the power indicator is on).
7.
extremely hot.
8. If the temperature sensor is not functioning as it should, will be shown on the
or importer.
9.
longer period of time, pull out the plug.
Temperature calibration
There may be variances between the temperature registered by the heater and the actual
temperature in the room. This can be caused by several factors, however, the most common
is that the heater is placed a distance away from where you are. As the thermostat is fixed to
the heater, it will measure the air temperature in the immediate vicinity of where it is located.
The specific conditions of the room that the heater is in may dictate that there are some
variances in the air temperature where the heater is versus where you are located. To adjust
this, all Mill heaters are equipped with a calibration function which enables you to adjust the
temperature registered by the heater. Please note: the room must have a stable temperature
for calibration to work.
Press and hold for 5 seconds and use + or – to set the actual temperature observed
Resetting the heater
switch.

8
EN
Mill International B.V. - www.millheat.com
www.millheat.co.uk
[email protected]
Maintenance
Warranty
Waste disposal
1. For cleaning, always unplug the heater and leave it to cool.
2. Wipe the heater regularly with a damp cloth and dry the surface before turning on the
heater again.
3. The heater must be cleaned at least once a month during the heating season.
CAUTION! The heater should never be immersed in water.
Avoid using detergents to clean the heater.
Never let any water get inside the heater; this can be hazardous.
4.
5. The heater can be stored in a dry and clean place.
6. If the heater stops working, do not attempt to repair it yourself because it can cause a
The warranty is valid for 2 years. The heater will be repaired or replaced during this
time should any malfunction occur. The warranty applies if the heater is used according
to these instructions and the customer can present a purchase receipt. If the heater
malfunctions in any way, please contact the store where it was purchased or the importer.
This mark on a product and/or accompanying documents indicates that when it is to
be disposed of, it must be treated as Waste Electrical & Electronic Equipment (WEEE). Any
WEEE marked waste products must not be mixed with general household waste, but kept
separate for the treatment, recovery and recycling of the materials used. For proper
treatment, recovery and recycling; please take all WEEE marked waste to your Local
Authority Civic waste site, where it will be accepted free of charge. If all consumers dispose
of Waste Electrical & Electronic Equipment correctly, they will be helping to save valuable
resources and preventing any potential negative eects upon human health and the
environment, of any hazardous materials that the waste may contain.
Designed by Mill in Norway ®All Rights Reserved.
Made and assembled in China.
Exclusively distributed and imported by BML L24 9WD UK ©2017

9
millheat.com
Maintenance
Warranty
Waste disposal
Notes

Mill International B.V. - www.millheat.com
www.millheat.co.uk
[email protected]
Designed by Mill in Norway ®All Rights Reserved.
Made and assembled in China.
Exclusively distributed and imported by BML L24 9WD UK ©2017
